TechOrbits OF-33R User manual

INSTALLATION MANUAL
ELECTRIC
SIT-STAND DESK
150kg (330lbs)
min 630mm
max 1290mm
OF-33R

A (x2) B (x3)
E (x3)
C (x2)
S-A (x32)
1
2
S-D (x5)S-B (x20) S-C (x4) S-E (x20) S-F (x1)
D (x2)
F (x4) G (x1) H (x1)
I (x1) J (x6) K (x1) L (x1) M (x1)
S-E
S-E
HG
A
D
C

2
3
3
C
D
F
S-F
H
120°90°
OR
G
S-A
S-F

4
5
4
A
E
S-A
S-F

5
6
B
J
7
S-F
BS-A

8
6
S-F

7
10
9
S-B

8
12
11
1 & 2 & 3 P
AC
A C
K
L
I
K
S-C
1
2

1 2 3
9
13
S-C
M

10
14

11
15

Plug the Power Cord into a 110v or 220v outlet
IMPORTANT! You must Reset the desk prior to use:
Press and hold the “ “ button on the Handset until the desk reaches its lowest height.
Release the “ “ button. Press and hold the “ “ button again for about 10 seconds until the
desk lowers a little bit more, slightly rises and stops. Release the “ “ button.
Your desk is now ready to use.
To program up to four presets:
Use the “ / “ buttons to nd a desired height, then press “ ”followed by a number 1-4.
User Guide
Digital Control Panel For
Electric Height Adjustable Desk
TECHNICAL SPECIFICATIONS
Height Range
Base Width
Travel Speed
Weight Capacity
Duty Cycle
63cm(24.8”) - 129cm(50.8”)
100cm(39.4”)min 170cm(67”)max
38mm(1.5”)per second
100kg(220lbs).
10%, Max. 2 mins on, 18 mins off
4 Memory presets
Soft Start/Stop
Adjustable leveling studs
MEMORY SETTINGS
Save up to four commonly used desk heights and recall them quickly.
Use the UP or DOWN button to move the desk to the desired height.
Press the “S” button.
Press the “1, 2, 3, or 4” button to assign the current height to a number on the handset.
To bring the desk back to any of those assigned heights, press the numbered button.
PROGRAMMING INSTRUCTIONS
1
2
3
4
12

Plug the Power Cord into a 110v or 220v outlet
IMPORTANT! You must Reset the desk prior to use:
Press and hold the “ “ button on the Handset until the desk reaches its lowest height.
Release the “ “ button. Press and hold the “ “ button again for about 10 seconds until the
desk lowers a little bit more, slightly rises and stops. Release the “ “ button.
Your desk is now ready to use.
To program up to four presets:
Use the “ / “ buttons to nd a desired height, then press “ ”followed by a number 1-4.
User Guide
Digital Control Panel For
Electric Height Adjustable Desk
TECHNICAL SPECIFICATIONS
Height Range
Travel Speed
Weight Capacity
Duty Cycle
63cm(24.8”) - 129cm(50.8”)
38mm(1.5”)per second
150kg(330lbs).
10%, Max. 2 mins on, 18 mins off
4 Memory presets
Soft Start/Stop
Adjustable leveling studs
MEMORY SETTINGS
Save up to four commonly used desk heights and recall them quickly.
Use the UP or DOWN button to move the desk to the desired height.
Press the “S” button.
Press the “1, 2, 3, or 4” button to assign the current height to a number on the handset.
To bring the desk back to any of those assigned heights, press the numbered button.
PROGRAMMING INSTRUCTIONS
1
2
3
4
13

The handset will then display the current height, and you should be able to operate the desk.
You may also need to do this if the desktop is ever unplugged or loses power.
4
5
If the error message persists after performing the Reset procedure, contact us or local distributors to get support.
DESCRIPTION CODE TROUBLESHOOTING SOLUTION
Abnormal Standby Current SC0 Power on again. If the code persists, replace the Control Box
Abnormal Power Supply Board SC1 Power on again. If the code persists, replace the Control Box
Abnormal Memory SC2 Power on again. If the code persists, replace the Control Box
Abnormal Sensor SC3 Power on again. If the code persists, replace the Control Box
Collision Protection by Sensor R-2 The desktop will stop and retract 5cm(2”)
Unsynchronized legs R-3 Perform Reset procedure
Overheated HOT Let the desk rest for 18 minutes
Communication Failure R-5 Check the connection between Handset and Control Box or replace Handset
Abnormal Voltage R-6 Power on again. If the code persists, replace the Control Box
Mechanical Failure R-8 Perform Reset procedure. If the code persists, replace the Leg
Rest not completed RST Perform Reset procedure
Short Circuit EX0 Power on again. If the code persists, replace the Control Box
Overload EX1 Reduce the load on desk
Wrong Running Direction EX3 Perform Reset procedure. If the code persists, replace the Leg
Collision Protection EX4 The desktop will stop and retract 5cm (2”)
Motor Stalling EX5 Perform Reset procedure. If the code persists, replace the Leg
Motor Open Phase EX2 Perform Reset procedure. If the code persists, replace the Leg
Disconnections of Motor Cable EX6 Check the connection between leg and control box
Remarks: X means 1(the rst leg), 2(the second leg), 3(the third leg)
In the event of a power outage or if the power cord is unplugged, a manual reset may
be necessary (see Reset Instructions above)
This product is designed with a duty cycle of 10% (2 min. On, 18 min. off)
Keep Children away from electric height-adjustable desks, control units and handsets.
There is a risk of injury and electric shock
Do not open any of components: lifting columns, control box, or handset.
There is a danger of electric shock
Keep all electrical components away from liquids
