TECHWOOD ST64 User manual

FFH-5670A-Eng(062H)
Before connecting, operating or adjusting this product,
please read this instruction booklet carefully and completely.
MIDI COMPONENT SYSTEM

Precautions
2
Explanation Graphical Symbols:
The lightning flash with arrowhead symbol,
within an equilateral triangle is intended to
alert the user to the presence of uninsulated
dangerous voltage within the product’s enclo-
sure that may be of sufficient magnitude to
constitute a risk of electric shock to persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and mainte-
nance(servicing) instructions in the literature
accompanying the appliance.
WARNING
TO REDUCE THE RISK OF FIRE OF ELECTRIC
SHOCK, DO NOT EXPOSE THIS APPLIANCE TO
RAIN OR MOISTURE.
To avoid electrical shock, do not open the cabinet,
Refer servicing to qualified personnel only.
The apparatus shall not be exposed to dripping or
splashing and that no objects filled with liquids,
such as vases, shall be placed on the apparatus.
Warning:
Do not install this equipment in a confined space such
a book case or similar unit.
This label is located on the interior.
This Compact Disc player is classified as a CLASS 1
LASER product.
The CLASS 1 LASER PRODUCT label is located on
the exterior.
REGULATORY INFORMATION:
FCC Part 15
This product has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when
the product is operated in a residential installation. This
product generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference
to radio communications. However, there is no guarantee
that interference will not occur in a particular installation.
If this product does cause harmful interference to radio or
television reception, which can be determined by turning
the product off and on, the user is encouraged to try to
correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the product and
receiver.
• Connect the product into an outlet on a circuit different
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV
technician for help.
FCC WARNING: This equipment may generate or use
radio frequency energy. Changes or modifications to this
equipment may cause harmful interference unless the
modifications are expressly approved in the instruction
manual. The user could lose the authority to operate this
equipment if an unauthorized change or modification is
made.
CAUTION
Use of controls or adjustments or performance of pro-
cedures other than those specified herein may result
in hazardous radiation exposure.
Laser component in this product is capable of emit-
ting radiation exceeding the limit for Class 1.
CAUTION:INVISIBLE LASER RADIATION WHEN
OPEN AND INTERLOCKS DEFEATED. AVOID
EXPOSURE TO BEAM.
VARNING:OSYNLIG LASERSTRÅLNING NÄR
DENNA DEL ÄR ÖPPNAD STRÅLEN ÄR FARLIG.
Attention:Quand l'appareil est ouvert, ne pas
s'exposer aux radiations invisibles du faisceau laser.
CLASS 1 LASER PRODUCT
KLASSE 1 LASER PRODUKT
LUOKAN 1 LASER LAITE
KLASS 1 LASER APPARAT
CLASSE 1 PRODUIT LASER
RISK OF ELECTRIC
SHOCK DO NOT OPEN
CAUTION
CAUTION:TO REDUCE THE RISK OF ELECTRIC
SHOCK DO NOT REMOVE COVER(OR BACK)
NO USER SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSON-
NEL.

Table of Contents
3
INTRODUCTION
INTRODUCTION
Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Table of Contents . . . . . . . . . . . . . . . . . . . . . . . . . . 3
IMPORTANT SAFETY INSTRUCTIONS . . . . . . . . . . 4
Before Use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Safety Precautions. . . . . . . . . . . . . . . . . . . . . . . . 5
Notes on Discs . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Notes on Remote Control. . . . . . . . . . . . . . . . . . . 5
Front Panel/Rear Panel . . . . . . . . . . . . . . . . . . . . . . 6
Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Display Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Speaker System Connection . . . . . . . . . . . . . . . . 8
Antenna (Aerial) Connections. . . . . . . . . . . . . . . . 8
BEFORE OPERATION
Setting the CLOCK . . . . . . . . . . . . . . . . . . . . . . . . . 9
Sleep Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Using Microphone (OPTIONAL) . . . . . . . . . . . . . . . 9
Timer Function . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Auxiliary Function . . . . . . . . . . . . . . . . . . . . . . . . . 10
Audio Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . 11
Volume Adjustment . . . . . . . . . . . . . . . . . . . . . . 11
Sound Quality Adjustment . . . . . . . . . . . . . . . . . 11
MUTE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
SURROUND . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
DISPLAY MODE. . . . . . . . . . . . . . . . . . . . . . . . . 11
XDSS (Extreme Dynamic Sound System) . . . . . 11
DEMO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
DIMMER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
OPERATION
Presetting the radio stations. . . . . . . . . . . . . . . . . 12
Listening to the radio . . . . . . . . . . . . . . . . . . . . . . 13
Tape Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Basic Playback. . . . . . . . . . . . . . . . . . . . . . . . . . 14
To Stop Play . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Tape Counter Reset . . . . . . . . . . . . . . . . . . . . . . 14
To Play Fast Rewind or Fast Forward . . . . . . . . . 14
Dubbing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Recording . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Basic Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Recording from Radio, CD or Auxiliary source . . 15
CD to Tape Synchronized Recording . . . . . . . . . 15
CD Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . 16-18
Basic Playback. . . . . . . . . . . . . . . . . . . . . . . . . . 16
To Pause Play . . . . . . . . . . . . . . . . . . . . . . . . . . 16
To Stop Play . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
To Skipping the Track . . . . . . . . . . . . . . . . . . . . . 16
To Play Fast Rewind or Fast Forward . . . . . . . . . 16
To Go to the next discs. . . . . . . . . . . . . . . . . . . . 16
To Select a disc directly . . . . . . . . . . . . . . . . . . . 16
To Replace discs during Playback . . . . . . . . . . . 17
To Repeat Play . . . . . . . . . . . . . . . . . . . . . . . . . 17
To Program Play . . . . . . . . . . . . . . . . . . . . . . . . 18
Reference
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
About the symbols for instructions
Indicates hazards likely to cause harm to the unit
itself or other material damage.
Indicates special operating features of this unit.
Indicates tips and hints for making the task easier.
