TECshow MAGIC CUBE User manual

P. 1
| Tecshow Magic Cube
USER MANUAL / MANUAL DE USUARIO
PLEASE READ THE INSTRUCTIONS CAREFULLY BEFORE USE
POR FAVOR LEA LAS INSTRUCCIÓNES ANTES DE USAR
MAGIC CUBE
Versatile moving head - 25 x 4-in-1 15W LEDs

P. 2
Tecshow Magic Cube |
Magic Cube
Versatile moving head - 25 x 4-in-1 15W LEDs
Magic Cube is a versatile mobile head that sports
25 4-in-1 15W LEDs with a variable zoom angle of 8º
to 58º. Thanks to its design, zoom function, endless
pan & tilt movement and its ability to control pixel
by pixel, this xture serves both for writing and stun-
ning visual effects. With its 4-in-1 LED technology
the equipment not only has a smooth color mixing
without multicolored shadows, but also gives the
possibility to choose between RGBW and CMY. The
unit also comes with a virtual color wheel with 20
built-in configurations, including seven color tem-
perature presets. Magic Cube is a professional and re-
liable solution to the most demanding applications
in the industry.
Specications
Source & Optics
• Light Source: 25 x 4-in-1 15W LEDs
• LEDs life: 50,000 hours
• Beam angle: 8° to 58°
Photometric data
• 8º beam angle: 15600 lux @ 5m (16 .)
• 58º beam angle: 1447 lux @ 5m (16 .)
Eects & Functions
• Pixel mapping: Pixel by pixel control
• Dimmer: Full range 0-100%
• Strobe eect
• Smooth RGBW & CMY color mixing
• Virtual color wheel
• Vivid, saturated and uniform colors
• CTC function
Control
• Operational modes: DMX, Master/Slave,
Sound-active & Auto-run
• DMX Channels: 19/24/124
Movement
• Pan: Unlimited
• Tilt: Unlimited
• 16-bit resolution
• Auto repositioning
Electrical
• Input voltage range: 100–240V, 50-60Hz
• Max. power consumption: 400W
Physical
• DMX Connectors: 2 XLR connectors (XLR-3
input & output)
• Power supply connectors: PowerCON® In/Out
• Touch screen display
• Dimensions: 412x280x524 mm./16.2x11x20.6
in.
• Weight: 16.5 Kg. / 36 Lbs.
1. OVERVIEW
English version

P. 3
| Tecshow Magic Cube
Thank you for your patronage. We are condent that
our excellent products and service can satisfy you. For
your own safety, please read this user manual carefully
before installing the device.
In order to install, operate, and maintain the lighting
safety correctly. We suggest that the installation and
operation should be done by the veried technician and
follow the instruction strictly.
English version

P. 4
Tecshow Magic Cube |
Any person involved with the installation, operation and maintenance of this device has to:
• be qualied
• follow carefully the instructions of this manual
Installation
Before installation, please read the user manual
carefully, then prepare Fasten Lock (2 pcs), Clamps
(2 pcs), and Safety Rope (1 pc).
1. Upward the moving beam bottom, use 2 pcs
Fasten Lock tighten at bottom of moving beam.
Check it again.
2. Hang up the xture on the truss by clamps,
tighten according to the truss diameter.
3. Use the safety Rope tighten for safety issue.
Thank you for having chosen this professional mov-
ing head. You will see you have acquired a powerful
and versatile device. Unpack the device. Inside the
carton box you should nd:
a. Moving Head 1 unit
b. Signal Cable 1 pc
c. Power Cable 1 pc
d. User Manual 1 unit
e. Fasten Lock/Quick Couplers 1 pair
(Flight case, Safety cable and Clamps are optional,
please contact your dealer)
Please check carefully that there is no damage
caused by transportation. Should there be any
problem, please consult your dealer and don’t
install this device.
2. SAFETY
3. INTRODUCTION
Keep this device away from rain and moisture!
CAUTION!
English version
Unplug mains lead before opening the housing.
CAUTION!

P. 5
| Tecshow Magic Cube
4. DIMMER MODES & DMX512 CONNECTION
English version
Dimmer Modes
DMX connect
Output
DMX %
Optically Linear
DMX in DMX out
DMX out
DMX controller

P. 6
Tecshow Magic Cube |
English version
DMX input
DMX input DMX output
DMX output
Common
Common
DMX -
DMX +
Not used
Not used
DMX +
DMX -
5. LCD DISPLAY
Main Menu Sub-Menu Description
Set
Run Mode DMX / Auto/ Master/Slave
DMX Address Press up and down key to choose the address value(001~512)
Channel Mode 19CH Mode1/24CH Mode2/124CH Mode3
X Invert OFF / ON
Y Invert OFF / ON
LCD Backlight OFF / ON
Color Dimmer Linear/Square
Graphic Display OFF / ON
Color Mixing RGBW / CMY
PAN/Tilt Mode Speed / Time
Blackout Moving OFF / ON
FAN Mode Auto / High
System Reset All Reset / PAN / Tilt Reset / zoom Reset
Restore Setting
Manl
Pan Press up and down buttons to adjust the xture pan degree
Pan Fine Pan degree Fine
Tilt Press up and down buttons to adjust the xture tilt degree
Tilt Fine Tilt degree Fine
Pan Control Pan polar rotation
Tilt Control Tilt polar rotation
Speed Press up and down buttons to change the speed of pan/tilt
P/S function LED DMX setting

P. 7
| Tecshow Magic Cube
English version
Color wheel Press up and down buttons to choose the mixing color and Color
Jump
Red/Cyan Press up and down buttons to add/reduce the lux of color red/cyan
Red/Cyan Fine Press up and down buttons to add/reduce the lux of color red/cyan
ne
Green/Magenta Press up and down buttons to add/reduce the lux of color green/ma-
genta
Green/Magenta Fine Press up and down buttons to add/reduce the lux of color green/ma-
genta ne
Blue/Yellow Press up and down buttons to add/reduce the lux of color blue/yellow
Blue/Yellow Fine Press up and down buttons to add/reduct the lux of color blue/yellow
ne
White Press up and down buttons to add/reduct the lux of color white
White Fine Press up and down buttons to add/reduct the lux of color white ne
CTC Press up and down buttons to choose the dierent white light
Pixel eects Function for the back light LED board
Pixel eects Speed Function speed
Zoom Press up and down buttons to adjust the optical lens angle
Strobe Press up and down buttons to change the speed of Strobe with dim-
ming Channel switch
Dimmer Press up and down buttons to adjust the xture brightness from dark
to full bright(0~100%)
Dimmer Fine Adjust the xture brightness from dark to full bright ne
Red1 Press up and down buttons to add/reduce the lux of color red 1
Green1 Press up and down buttons to add/reduce the lux of color green 1
Blue1 Press up and down buttons to add/reduce the lux of color blue 1
White1 Press up and down buttons to add/reduce the lux of color white 1
Red2 Press up and down buttons to add/reduce the lux of color red 2
Green2 Press up and down buttons to add/reduce the lux of color green 2
Blue2 Press up and down buttons to add/reduce the lux of color blue 2
White2 Press up and down buttons to add/reduce the lux of color white 2
....... ........
Red25 Press up and down buttons to add/reduce the lux of color red 25
Green25 Press up and down buttons to add/reduce the lux of color green 25
Blue25 Press up and down buttons to add/reduce the lux of color blue 25
White25 Press up and down buttons to add/reduce the lux of color white 25
Infor
Display Version Soware version
Display Infor This is date we manufactured the LCD board
Master Infor This is date we manufactured the main board

P. 8
Tecshow Magic Cube |
English version
Total use time This is the time we have used for the light from the production so far.
The Use Of Time This is the time when we use the light on the electricity
LED Temperature This is LED temperature display
Expe Password Adjust the calibration data
↓ ↓/↑ LCD Reverse
6. LCD DISPLAY
7. CHANNELS CHART
dress, press knob to conrm, the present address
will blink on the display, rotate the knob to adjust
the address from 0 to 512, press the knob to store.
Please refer to the following diagram to address
your DMX512 channel for the rst 4 units
If you use a universal DMX controller to control the
units, you have to set DMX address from 1 to 512 so
that the units can receive DMX signal. Rotate MENU
knob to enter menu mode, select DMX Functions,
press knob to conrm, press knob to select DMX Ad-
Channel mode Unit 1 Address Unit 2 Address Unit 3 Address Unit 4 Address
19 channels 1 20 39 58
24 channels 1 25 49 73
124 channels 1 125 249 373
Channel modes Function Value Detail information
1 1 1 Pan 0~255 Pan (8bit)
2 2 2 Pan Fine 0~255 Pan Fine (16bit)
3 3 3 Tilt 0~255 Tilt (8bit)

P. 9
| Tecshow Magic Cube
English version
4 4 4 Tilt Fine 0~255 Tilt Fine (16bit)
5 5 5 Pan control
0~55
56~155
156~255
No function
Continuous rotation from fast to slow,forwards
Continuous rotation from slow to fast,Backwards
6 6 6 Tilt control
0~55
56~155
156~255
No function
Continuous rotation from fast to slow,forwards
Continuous rotation from slow to fast,Backwards
7 7 7 Pan/Tilt Speed 0~255 From fast to slow
8 8 8 DMX setting
0~50
51~65
66~80
81~110
111~125
126~140
141~170
171~185
186~200
201~205
206~220
221~235
236~250
251~255
Reserved
RGBW color mixing mode
CMY color mixing mode
Reserved
Blackout while pan/tilt moving
Disabled blackout while pan/tilt moving
Reserved
Fans mode:Auto (if temp>40☐ fans high)
Fans mode: high
Reserved
Pan/Tilt reset
Zoom reset
All reset
Reserved
9 9 9 Virtual color
wheel
0
1~2
3
4~5
6
7~9
10~12
13~15
16
17~55
56
57~95
96
97~134
135
136~174
1756
176~214
215
216~246
247
248~255
No function
White 2700K
White 2700K (Halogen lamp mode)
White 3200K
White 3200K (Halogen lamp mode)
White 4200K
White 5600K
White 8000K
Blue
Red=0,Green=up,Blue=full,White=0
Red=0,Green=full,Blue=full,White=0
Red=0,Green=full,Blue=down,White=0
Red=0,Green=full,Blue=0,White=0
Red=up,,Green=full,Blue=0,White=0
Red=full,Green=full,Blue=0,White=0
Red=full,Green=down,Blue=0,White=0
Red=full,Green=0,Blue=0,White=0
Red=full,Green=0,Blue=up,White=0
Red=full,Green=0,Blue=full,White=0
Red=down,Green=0,Blue=full,White=0
Red=0,Green=0,Blue=full,White=0
Rainbow eect

P. 1 0
Tecshow Magic Cube |
English version
10 10 10 Red/Cyan 0~255 Red/Cyan (8bit)
*11 11 Red/Cyan Fine 0~255 Red/Cyan (16bit)
11 12 12 Green/Magenta 0~255 Green/Magenta (8bit)
*13 13 Green/Magenta
Fine
0~255 Green/Magenta (16bit)
12 14 14 Blue/Yellow 0~255 Blue/Yellow (8bit)
*15 15 Blue/Yellow
Fine
0~255 Blue/Yellow (16bit)
13 16 16 White 0~255 White(8bit) if CMY mode selected no function
*17 17 White Fine 0~255 White(16bit) if CMY mode selected no function
14 18 18 CTC 0~255 CTC
15 19 19 RGBW function
0~2
3~206
207~254
255
No function
Eect 1 to 41
Eect run
RGBW 100%
16 20 20 RGBW function
speed
0~255 From slow to fast
17 21 21 Zoom 0~255 Zoom
18 22 22 Shutter/Strobe
0~31
32~63
64~95
96~127
128~143
144~159
160~191
192~223
224~255
Shutter close
Shutter Open
Strobe eect from slow to fast
Shutter Open
Opening pulse in sequences from slow to fast
Closing pulse in sequences from slow to fast
Shutter Open
Random strobe-eect from slow to fast
Shutter Open
19 23 23 Dimmer 0~255 Dimmer (8bit)
*24 24 Dimmer Fine 0~255 Dimmer Fine (16bit)
* * 25 Red Pixel 1 0~255 Red Pixel 1
* * 26 Green Pixel 1 0~255 Green Pixel 1
* * 27 Blue Pixel 1 0~255 Blue Pixel 1
* * 28 White Pixel 1 0~255 White Pixel 1
* * ...... ...... ...... ......
* * 121 Red Pixel 25 0~255 Red Pixel 25
* * 122 Green Pixel 25 0~255 Green Pixel 25
* * 123 Blue Pixel 25 0~255 Blue Pixel 25
* * 124 White Pixel 25 0~255 White Pixel 25
