TECshow ION 575 User manual

ION 575
USER MANUAL / MANUAL DE USUARIO
PLEASE READ THE INSTRUCTIONS CAREFULLY BEFORE USE
POR FAVOR LEA LAS INSTRUCCIÓNES ANTES DE USAR

Overview
ION 575 is a spot moving head powered by a 75W white LED.
The unit provides a motorized focus, 3-facet rotating prism,
0-100% full range dimmer and 0-30Hz range strobe. ION 575
also sports a color wheel with 8 dichroic lters + open with bi-
directional rainbow eect & a rotating gobo wheel with 7 in-
dexable and interchangeable rotating gobos. As in all the ION
series, the movements of this xture are highlighted because
of their precision and speed, thanks to its compact design &
3-phase motors.
Specications
Source & Optics
Light Source: 1 x 75W White LED
LEDs life: 60,000 hours
Photometric data
Luminous Flux: 6400 lumen, 6990 lux @ 2.5m (8 .)
Eects & Functions
Color wheel: 8 dichroic lters + open, indexable and bidirec-
tional rainbow eect
Color bounce
Rotating gobo wheel: 7 interchangeable, rotating, indexable
gobos + open
Gobo diameter: Outside 23 mm, Inside 18 mm
Gobo animation eect
Gobo shaking
Zoom: 13º to 18º
3-facet rotating prism
Motorized focus
Dimmer: Full range 0-100%
Strobe eect
Control
DMX channels:11/14
Hibernation when lost DMX for preset time
Soware upgrade via DMX
Fan speed auto-change according to temperature
Movement
Pan: 630° / 540°
Tilt: 265°
16-bit resolution
Auto repositioning
Electrical
Input voltage range: 100–240V, 50-60Hz
Power supply: Electronic auto-ranging
Power consumption: 160W
Physical
DMX connectors: 2 XLR connectors (XLR-3 In and Out)
Power supply connectors: Interlock In/Out
LED display
Dimensions: 299x252x431 mm. / 11.7x10x17 in.
Weight: 10 Kg. / 22 Lbs.
p. 2ION 575
ENGLISH VERSION

p. 3ION 575
ENGLISH VERSION
1. Product Introduction:
1.1 Before unpack the xture, pls make sure that the packing
is in good condition, following items will be found in the box:
• The xture
• This users guide
• 3m DMX cable
• 1.5m power cable with powercon
• Omega bracket for hanging installation
• Safety chain
1.2 Specication
Source
• Light source: 75w white led
• Led life: 60.000 hours
• Luminous Flux: 6400lumen, [email protected]
• Control: Remote on/o via DMX
• Ballast: switching mode power supply
Optical System
• Beam angle: 13° to 18°
X/Y
• Pan: 630° (4.0 sec) or 540°(3.58 sec), Tilt: 265° (2.8 sec)
• 16-bit resolution
• Auto repositioning
Colors
• 8+open, interchangeable, indexable and bidirectional
rainbow eect
• New color bounce eect
Gobos
• Outside ¢23mm, inside ¢18mm
• 7+ open custom interchangeable position for rotating
gobo wheel
• Real indexable and gobo shaking
• Distinctive gobo animation eect
Features
• DMX channels: 11/14
• Color wheel: 8+1 colors
• Rotating gobo wheel: 7+1 gobos
• Motorized focus
• Manual zoom from 13° to 18°
• Full range 0-100% dimmer
• Various strobe
• 3 facets prism
• Soware upgrade via DMX
• Hibernation when lost DMX for preset time
• Fan speed auto change according to temperature
Display
• LED display
• Flip
• Back-up communicating IC

1.3 Description of the Device
8. Handle
9. Mic
10. MODE/ESC button
11. Down button
12. Up buttom
13. Enter button
14. Powercon in
15. Powercon out
16. Fuse
17. 3-pin DMX out
18. 3-pin DMX in
1. Project lens
2. Head
3. Arm
4. Base
5. Display
6. Foot stand
7. Operation button
p. 4ION 575
ENGLISH VERSION

1 Open
2 Magenta
3 Orange
4
Sky blue
5 Pink
6 Yellow
7 Green
8 Blue
9Red
1.4 Colors and Gobos
p. 5ION 575
ENGLISH VERSION

Rotating gobo wheel
(slot-in-out gobos)
2. Safety and maintenance Information
2.1 Safety Info
Before operate this unit, please carefully read this users guide and keep if
needed in future. It’s necessary to respect following rules.
The disposal of the device aer lifecycle could damage the environment, need
to take it to special company for recycling or return to authorized dealer.
The products referred to in this manual conform to the Eur opean Community
Directives and are therefore marked with CE logo.
Keep this device away from children and unauthorized users, the manufac-
turer will not take responsibility for the damage due to any disregard of the
information provided in this manual and wrong operation.
Before operate the device, pls make sure the xture is in good housing, ensure
pan and tilt can rotate in its complete range.
p. 6ION 575
ENGLISH VERSION

Pls make sure minimal 0.5m distance need to kept between the xture to any
ammable material.
The device can only run with 100-240v voltage, 50/60Hz power, don’t connect
to any other wrong power. Disconnect the device from main power before
open the shield or maintenance.
The device is designed only for indoor usage, pls keep it away from moisture.
Do not expose the device under the sun or directly to any other lighting source.
Never look directly into the projecting lens when the xture is power on, the
light may trigger epileptic seizures in photosensitive persons or persons with
epilepsy. Especially at beam eect, extreme caution and observance of these
safety instructions is mandatory.
Don’t put or install the device on a surface that subject to vibration
or bumps.
Ta=45° C The device is supposed to work in the temperate range -15° C and +45° C, do
not use the device when the temperate exceed this range.
The lens, shield need to be replaced when obviously broken, never use the
device when the shield is not completed closed.
Safety I class device, need to be earth connected.
When the xture is hanged overhead, the safety rope must be xed to the
bottom of the device to the appropriate xing point.
Always carry the device by the handles, do not take the head or arm directly
for transportation.

--0.5m
2.2 Maintenance
2.2.1 Operation only allowed to qualied person, damages
due to unprofessional operation or remove of any parts in-
side will not be considered in warranty service. There are no
serviceable parts inside the device or package, service only
leaves to authorized dealers.
2.2.3 Never allow the optical components contact with oil,
fat or any other liquid.
2.2.4 A regular clearance of the device is needed for long-
term usage, this is very helpful to maintain the lifetime and
brightness need to use a so and lint-free cloth to clean the
optical system, fan and air owing tunnel.
p. 7ION 575
ENGLISH VERSION

2.2.5. Trouble Shooting
2.2.6 Replacement of the fuse
Need to replace with same type and rating, which originally
installed in the device.
Step One: Unplug power cable from main power.
Step Two: Unscrew the fuse holder out of the housing with a
screwdriver.
Step Three: Remove the broken fuse and replace with an ex-
act same type of new fuse.
Step Four: Insert the fuse holder back to the housing and
screw tight and reconnect power.
Problems Possible reasons Checking or solutions
Device not power up Powercon or power cable damaged Change a good power cable to try
Faulty power supply Replace new power supply
Pan/Tilt error or vibrate
Faulty Pan/Tilt PCB Replace PT001 PCB
Faulty opto sensor Replace opto sensor OP001
Cable loosen Check the cable connect to OP001
LED o
Temperature protection Check the temperature from menu
Fan not working Check the fan speed info from menu
Faulty LED Replace new LED
Dimmer and strobe set at 0 Set dimmer and strobe channel at 255
Faulty power supply Replace new power supply
Device not response to DMX
Faulty communication IC Replace the IC with back-up one in the display PCB
Faulty display PCB Replace new display PCB
Wrong DMX addressing Check the address and setting
Faulty DMX cable Change to a good DMX cable
3. Installation
3.1 The device could be either put on a solid and even Sur-
face, or mounted upside down or sideways like le picture.
3.2 The mounting place must be suicient stable and be able
to support a weight of 10 times of the unit’s weight. When the
xture is hanged, always additionally secure the device with
the safety chain, fasten the safety rope at a suitable position
so that the maximum fall of the projector will be 20 cm
p. 8ION 575
ENGLISH VERSION

How to do mounting installation.
Step three: Install the whole device onto appropri-
ate truss and fasten the clamps, tight the safety rope
with the truss or other xing point at a suitable posi-
tion that drop down distance not exceed 20 cm.
Step two: Install the clamp and bracket on the bot-
tom of panel, fasten the quick-locks;
Step one: Installation the clamp onto the bracket;
4.1 Meaning of the icon in menu
CONNECT LIGHT INFOMATION SET PROGRAM
p. 9ION 575
ENGLISH VERSION

4.2 Menu tree
Default setting shadowed. Mark with 1. can be basic reload-
ed, 2. be program reloaded, 3. can be private reloaded.
Mode
Addr XXX DMX address setting
Slav Choose Slave mode
Sequ Alon/Mast Choose Sequence mode
Sund Alon/Mast Choose Sound mode
Lamp Temp 80~139℃, 80℃ Lamp o if temperature continu- ously over for 5 minutes
Adju CHxx=XXX….. Adjust value of each channels
Info DriT XXXC Temperature of driver
Set
Rest Reset
Move
RPan ON/OFF Pan Reverse
RTilt ON/OFF Tilt Reverse
Degr 630/540 Choose Pan Degree
Enco ON/OFF Encoder wheel on/o
Mode Mod1/Mod2 Choose pan/tilt mode
UI
Mic 0~99%,60% Sensitivity of Mic
Sign Close/Hold/Auto/Music Mode when no signal
Fan Auto Speed /High Speed Fans mode
Hibe OFF, 01M~99M, 15M Sleeping mode
Back 02~60m 02m Show backlight time
Flip ON/OFF Display 180°reverse
User Use1/Use2 Users mode
Cali Code XXX Password: 050
CHxx XXX Calibrate channel value
Ver X1.0.0 IC Version
load ON/OFF Reload Default
p. 10ION 575
ENGLISH VERSION

5. DMX connection and DMX protocol
5.1 DMX addressing:
5.1.1 The device is controlled by universal DMX 512 protocol,
DMX address is the start channel used to receive instructions
from the external controller. For independent control, each
xture must be assigned its unique address control channels.
For example, this device has four channel modes: 11/14, if
we set the mode at standard 11 channels mode, and there
are several models need to be independently controlled, we
just simply address rst xture at 1, and second xture at 12,
third one at33, etc.
If the devices have the same address, they will behave syn-
chronically.
DMX addressing is limited, don’t set the address so high that
without enough control channels for the xtures.
Display is ashing when no DMX signal is received.
5.1.2 This device is equipped with 3-pins DMX in and out
sockets only. Pin 1 = GND | Pin 2 = Signal (-) | Pin 3 = Signal (+)
5.1.3 The termination is prepared by soldering a 120Ω resis-
tor between pins 2 and 3.
5.1.4 Connection: us DMX cable with 3-pin XLR-plugs to con-
nect the controller with the xture or one xture with another.
p. 11ION 575
ENGLISH VERSION

5.2 DMX chart
Channel name function Min DMX Max DMX
St Ex
1 1 Pan Pan Coarse 0 255
2Pan ne Pan Fine 0 255
2 3 Tilt Tilt Coarse 0 255
4Tilt ne Tilt Fine 0 255
3 5 Movment
Speed fastest to Slowest 0 255
6Movment
Function
Normal 0 15
Movement With Backout 16 31
TBD 32 255
4 7 Shutter
Shutter closed 0 31
No function (shutter open) 32 63
Strobe eect slow to fast 64 95
No function (shutter open) 96 127
Pulse-eect in sequences 128 159
No function (shutter open) 160 191
Random strobe eect slow to fast 192 223
No function (shutter open) 224 255
5 8 Dimmer Dimmer(Close to Open) 0 255
6 9 Color
Indexed
Position 1 (Open) 0 2
Position 2 ~ Position 18 3 53
Indexed With Backout
Position 1 (Open) 54 56
Position 2 ~ Position 18 57 106
Indexed With Bounce
Position 1 107 119
Position 2 ~ Position 10 120 223
Forward Wheel Spin
Stop to fastest 224 239
Reverse Wheel Spin
Stop to fastest 240 255
p. 12ION 575
ENGLISH VERSION

7 10 Rot Gobo
Indexed
Position 1 (Open) 0 5
Position 2 ~ Position8 6 47
Indexed With Backout
Position 1 (Open) 48 53
Position 2 ~ Position8 54 95
Indexed With Shake
Position 2 98 115
Position 3 ~ Position8 116 223
Forward Wheel Spin
Stop to fastest 224 239
Reverse Wheel Spin
Stop to fastest 240 255
8 11 Gobo Rot
Continuous
Positioning from 0-360 degrees 0 191
Forward Animate Rotate
Stop to fastest 192 207
Reverse Animate Rotate
Stop to fastest 208 223
Forward Spin
Stop to fastest 224 239
Reverse Spin
Stop to fastest 240 255
9 12
Prism & Prism
Prism Rot Position 1 (Open) 0 3
Prism Rot Forward Spin
Stop to fastest 4 127
Prism Rot Reverse Spin
Stop to fastest 128 255
10 13 Focus Continuous
Focus In to Focus Out 0 255
11 14 Control
Normal 0 7
Reset All 8 15
Pan&Tilt Reset 16 23
Color Reset 24 31
Gobo Reset 32 39
TBD 40 47
Other Reset 48 55
Display O 56 63
Display On 64 71
TBD 72 87
Hibernation 88 95
TBD 96 255
Channel name function Min DMX Max DMX
St Ex
p. 13ION 575
ENGLISH VERSION

6. Unique Features
6.1 RDM, stand for “Remote Device Management”, with this
function, users can realize remote control of the device, such
as remotely changing DMX address, reverse pan/tilt setting,
check a lot of useful information such as temperature, pow-
er consumption, fan speed. Etc. Every single device has a
unique RDM code before le factory to distinguish from each
other, usually not suggest users change this code freely.
6.2 Soware upgrade function via DMX cable, if there is any
new rmware for this device come out, it can be upgraded
simply via a soware upgrade box, no need to change any
mechanical parts. The upgrade box is not included in the
package, if need any further assistance pls just contact au-
thorized dealers.
6.3 Hibernation, the device will enter sleeping mode if acti-
vated aer a period of disconnecting DMX signal to save the
power consumption, and will return immediately as soon as
the DMX signal is sent again.
6.4 Display battery, this function is prepaid in the display
PCB, users just need to install a normal 10440 600mAh 3.7V
rechargeable lithium battery, then users could power on the
display and do setting without connect to main power.
6.5 Display back-up communication IC, there is a back-up
communication IC installed in the display PCB, so users could
replace at once if the working one is broken, no need to wait
long time from service.
6.6 Display ip, by press up and down button for more than
3 seconds, the display will ip automatically, this function is
useful to read menu conveniently when device is hanged.
p. 14ION 575
ENGLISH VERSION

8. Dimensions Drawing
9. Technical specication
Power supply 100-240 V AC, 50/60 Hz ~
Power consumption 160W
LED 75w white led
DMX channels 11/14 modes
Beam angle 13° to 18°
Luminous ux 6400lumen, [email protected]
Fuse T 3.15 A, 250 V
Device dimensions 299x252x431mm
Net Weight 10KG
p. 15ION 575
ENGLISH VERSION

p. 16ION 575
VERSIÓN ESPAÑOL
Descripción
Ion 575 es un cabezal móvil tipo spot que cuenta con un LED
blanco de 75W. La unidad provee, además, foco motorizado,
prisma de 3 caras, dimmer de rango completo y un estrobo
de 0-30Hz. Ion 575 cuenta, por otra parte, con una rueda de
ltros dicróicos con 8 colores + abierto, efecto de arcoiris bi-
direccional, y otra rueda con 7 gobos rotativos, indexables
e intercambiables. Al igual que toda la serie ION, los movi-
mientos de este modelo se destacan por su velocidad y pre-
cisión, gracias a su motor de 3 fases y su compacto diseño.
Especicaciones
Fuente & Óptica
Fuente de luz: 1 LED blanco de 75W
Vida útil promedio: 60,000 horas
Información fotométrica
Flujo lumínico: 6400 lumen, 6990 lux @ 2.5m (8 .)
Efectos y Funciones
Rueda de color: 8 ltros dicroicos + abierto, efecto arcoiris
indexable & bidireccional
Rebote de color
Rueda de gobos rotativos: 7 gobos rotativos, intercambiables
e indexables + abierto
Diámetro de gobo: por fuera 23 mm, por dentro 18 mm
Efectos de animación de gobo
Gobo Shaking
Zoom: 13º a 18º de ángulo de haz
Prisma rotativo de 3 caras
Foco motorizado
Dimmer: Rango completo 0-100%
Efecto estrobo
Control
Canales DMX:11/14
Hibernación cuando pierde DMX por tiempo preestablecido
Actualización de soware vía DMX
Velocidad del ventilador acorde a la temperatura
Movimiento
Pan: 630° / 540°
Tilt: 265°
16-bit de resolución
Reposicionamiento automático
Eléctrico
Rango de voltaje de entrada: 100–240V, 50-60Hz
Alimentación: Rango automático
Consumo máximo de potencia: 160W
Físico
Conectores DMX: 2 conectores XLR (XLR-3 de entrada & salida)
Conectores de alimentación: Interlock Entrada/Salida
Display LED
Dimensiones: 299x252x431 mm. / 11.7x10.3x17 pulg.
Peso: 10 Kg. / 22 Lbs.

p. 17ION 575
VERSIÓN ESPAÑOL
1. Información del producto
1.1 Antes de abrir el embalaje, revise que se encuentre en
buen estado. La caja contiene:
• 1 equipo.
• 1 manual del usuario.
• 1 cable DMX de 3m.
• 1 cable de suministro eléctrico, conector powerCON de
1.5m.
• Soporte Omega para instalación.
• Cable de seguridad.
1.2 Especicaciones técnicas
Fuente
• Fuente de luz: Led blanco de 75w.
• Vida útil del led: 60.000 horas.
• Flujo lumínico: 6400 lumen, 6990lux @ 2.5m.
• Control: Encendido y apagado remoto vía DMX.
• Balasto: Fuente de alimentación conmutable.
Óptica
• Ángulo de haz: 13° a 18°.
• Movimiento
• Pan: 630° o 540°, Tilt: 265°.
• Resolución de 16 bits.
• Reposicionamiento automático.
Colores
• 8 colores + abierto. Intercambiables, indexables y efecto
arcoíris bidireccional.
• Efecto rebote de color.
Gobos
• Diámetro por fuera: ℃23mm Por dentro: ℃18mm.
• Rueda de gobo rotativo: 7 gobos + abierto. Posición in-
tercambiable.
• Posición indexable y movimiento de gobos.
• Efectos de animación de gobos.
Características
• Canales DMX: 11/14.
• Rueda de color: 8 colores +1.
• Rueda de gobos rotativos: 7 gobos +1.
• Foco motorizado.
• Zoom manual de 13° a 18°.
• Dimmer: Rango completo: 0-100%
• Efecto estrobo.
• Prisma de tres caras.
• Actualización del soware vía DMX.
• Hibernación programada sin conexión DMX.
• Velocidad del ventilador variable según la temperatura
del equipo.
Visualización
• Pantalla LCD.
• Rotación de pantalla.
• Comunicación de respaldo IC

1.3 Descripción del equipo
1. Lente
2. Cabezal
3. Brazo
4. Base
5. Pantalla LCD
6. Soporte
7. Teclas de operación
8. Manija
9. Micrófono
10. Tecla MODE/ESC
11. Tecla de desplazamiento hacia abajo
12. Tecla de desplazamiento hacia arriba
13. Tecla Enter
14. Conector Powercon de entrada
15. Conector Powercon de salida
16. Fusible
17. Salida DMX de 3 pines
18. Entrada DMX de 3 pines
p. 18ION 575
VERSIÓN ESPAÑOL

1 Abierto
2 Magenta
3 Naranja
4
Celeste
5 Rosado
6 Amarillo
7 Verde
8 Azul
9 Rojo
1.4 Colores y Gobos
p. 19ION 575
VERSIÓN ESPAÑOL

Rueda de gobos rotativos
2. Instrucciones de seguridad y mantenimiento
2.1 Seguridad
Antes de utilizar la unidad, lea atentamente el presente manual y consérvelo
para referencias futuras. Deberá cumplir con todas las espefcicaciones con-
signadas en el presente manual.
Si luego de nalizada la vida útil de la unidad, ésta debiera ser desechada,
deberá entregarla a una empresa especializada en su reciclaje o devolverla a
un distribuidor autorizado a n de procurar el cuidado del medioambiente.
Los productos referenciados en el presente manual cumplen con las Directivas
de la Comunidad Europea y por tal motivo exhiben el marcado CE.
Mantenga la unidad alejada de niños y usuarios no autorizados; el fabricante
no asumirá responsabilidad alguna por daños generados al no cumplir con las
pautas indicadas en el presente manual o una ejecución indebida.
Antes de poner en funcionamiento la unidad, asegúrese de que ésta no se
ha dañado como consecuencia de su transporte. Verique que el pan y el tilt
pueden rotar en su rango completo.
p. 20ION 575
VERSIÓN ESPAÑOL
