TECshow MASTERPAR 25 User manual

USER MANUAL / MANUAL DE USUARIO
PLEASE READ THE INSTRUCTIONS CAREFULLY BEFORE USE
POR FAVOR LEA LAS INSTRUCCIÓNES ANTES DE USAR
Indoor DMX LED Par – 14 x 6-in-1 12W LEDs
MASTERPAR 25

MASTERPAR 25 - INDOOR DMX LED PAR – 14 X 6-IN-1 12W LEDS
ENGLISH VERSION
p. 2
Features
MasterPAR 25 is an indoor LED Par powered by 14 x 6-in-1
12W LEDs with a 40º beam angle, featuring six-color LED
technology, which enables smooth RGBWA+UV mix with no
multicolor shadows and UV mode. The unit sports a LED
refresh rate of 4000 Hz, which makes it ideal for TV Studios.
MasterPAR 25 is designed to give you great flexibility with its
4 operational modes (Auto run, Manual, Sound active, DMX
& Master/Slave) and 0-100% electronic dimming, making it
the ideal solution for any given application.
Source & Optics
Light Source: 14 x 12W 6-in-1 LEDs
LEDs life: 50,000 hours
LED Refresh rate: 4000Hz
Beam angle: 25º
Photometric data
Luminous Flux:
- Red: 650 lux @ 2m (6.5 .)
- Green: 930 lux @ 2m (6.5 .)
- Blue: 48 lux @ 2m (6.5 .)
- White: 1310 lux @ 2m (6.5 .)
- Ambar: 490 lux @ 2m (6.5 .)
- UV: 47 lux @ 2m (6.5 .)
Eects & Functions
Six-color LED technology: Smooth RGBWA+UV mix with no
multi colored shadows
Optimized UV eect
Dimmer: Full range 0-100% general & for all six colors
Strobe eect
4 built-in programs
Flicker free
Control
DMX channels: 6/7/10
Operational modes: DMX, Master/Slave, Auto-run, Static
colors, Sound-active & Built-in programs
Electrical
Input voltage range: AC100–240V, 50-60Hz
Power consumption: 168W
Physical
LCD display
DMX connectors: 2 XLR connectors (XLR-3 In and Out)
Power supply connector
Dimensions: 240x240x260 mm. / 9.4x9.4x10.2 in.
Weight: 4.5 Kg. / 9.9 Lbs.

p. 3
Operation
Attention: It is important to read this manual before you
install or use this product.
Control Board Menu Up Down Enter
When navigating the menu: Control Board
Use “UP” button to move up.
Use “DOWN” button to move down.
Use “ENTER” button to go on.
Use “MENU” button to back.
Step changing - Speed from slow to fast
Strobing - Speed from slow to fast
Sound active - Speed from slow to fast
Cross fade - Speed from slow to fast
Version display
Fan start Temperature set
Temperature display
Aberration - set
LED test
Display set
Sound active sensitivity
Master and slave set
Static color Setting
DMX CH Setting
DMX Address set
Menu
MASTERPAR 25 - INDOOR DMX LED PAR – 14 X 6-IN-1 12W LEDS
ENGLISH VERSION

p. 4
DMX Set
6 DMX Channels
7 DMX Channels
10 DMX Channels
Channel Level Function
Ch1 0-255 Red Linear adjustment 0-100%
Ch2 0-255 Green Linear adjustment 0-100%
Ch3 0-255 Blue Linear adjustment 0-100%
Ch4 0-255 White Linear adjustment 0-100%
Ch5 0-255 Amber Linear adjustment 0-100%
Ch6 0-255 Purple Linear adjustment 0-100%
Channel Level Function
Ch1 0-255 General-dimmer. Linear intensity adjustment 0-100%
Ch2 0-255 Red Linear adjustment 0-100%
Ch3 0-255 Green Linear adjustment 0-100%
Ch4 0-255 Blue Linear adjustment 0-100%
Ch5 0-255 White Linear adjustment 0-100%
Ch6 0-255 Amber Linear adjustment 0-100%
Ch7 0-255 Purple Linear adjustment 0-100%
Channel Level Function
Ch1 0-255 General-dimmer. Linear intensity adjustment 0-100%
Ch2 0-255 Linear Strobe frequency adjustment from 1 to 20HZ
Ch3 0-255 Marco
Ch4 0-255 Marco Program Speed from slow to fast
Ch5 0-255 Red Linear adjustment 0-100%
Ch6 0-255 Green Linear adjustment 0-100%
Ch7 0-255 Blue Linear adjustment 0-100%
Ch8 0-255 White Linear adjustment 0-100%
Ch9 0-255 Amber Linear adjustment 0-100%
Ch10 0-255 Purple Linear adjustment 0-100%
MASTERPAR 25 - INDOOR DMX LED PAR – 14 X 6-IN-1 12W LEDS
ENGLISH VERSION

p. 5
General maintenace
To maintain optimum performance fixtures should be
cleaned frequently. Unplug fixture from power. Use a vacuum
or air compressor and a so brush to remove dust collected
on external vents and internal components. Clean all glass
gently when the fixture is cold with a mild solution of glass
cleaner or Isopropyl Alcohol and a so lint free cotton cloth
or lens tissue.
Important Information
To reduce the impact on human health and the environment,
old appliances must be collected separately.
