TEFAL Fasteo User manual

www.tefal.com
Fasteo
EN
TE_CENTRALE_FASTEO_1800142429.qxp_110x154 17/10/2016 14:19 PageC1

c
db
a
3
2
5
11
12
8
4
EN Depending on model
*
TE_CENTRALE_FASTEO_1800142429.qxp_110x154 17/10/2016 14:19 PageC2

2
55
7
6
1
13
109
x3
STEAMBOOST
www.tefal.com
TE_CENTRALE_FASTEO_1800142429.qxp_110x154 17/10/2016 14:19 PageP1

4
1.
www.tefal.com
MAX
EN Depending on model
*
*
TE_CENTRALE_FASTEO_1800142429.qxp_110x154 17/10/2016 14:19 Page4

5
1.
www.tefal.com
2.
www.tefal.com
ON
ON
OK
OK
TE_CENTRALE_FASTEO_1800142429.qxp_110x154 17/10/2016 14:19 Page5

NO
6
2.
www.tefal.com
max.
TE_CENTRALE_FASTEO_1800142429.qxp_110x154 17/10/2016 14:19 Page6

7
2.
www.tefal.com
max.
OK
x3
STEAMBOOST
max.
EN Depending on model
*
TE_CENTRALE_FASTEO_1800142429.qxp_110x154 17/10/2016 14:19 Page7

NO OK OK
8
2.
www.tefal.com
wool - lainewool - laine
silk - soiesilk - soie
synth. - synth.synth. - synth.
NO
max.
TE_CENTRALE_FASTEO_1800142429.qxp_110x154 17/10/2016 14:19 Page8

9
2.
www.tefal.com
OFF
MAX
TE_CENTRALE_FASTEO_1800142429.qxp_110x154 17/10/2016 14:19 Page9

10
3.
www.tefal.com
OFF
2H
ON
TE_CENTRALE_FASTEO_1800142429.qxp_110x154 17/10/2016 14:19 Page10

11
3.
www.tefal.com
OFF
1H
OFF
3s
OK
TE_CENTRALE_FASTEO_1800142429.qxp_110x154 17/10/2016 14:19 Page11

12
3.
www.tefal.com
1H
NO
NO
TE_CENTRALE_FASTEO_1800142429.qxp_110x154 17/10/2016 14:19 Page12

EN
Important recommendations
Safety instructions
• Please read these instructions carefully before first use.
This product has been designed for domestic indoor use
only. Any commercial use, inappropriate use or failure to
comply with the instructions, the manufacturer accepts
no responsibility and the guarantee will not apply.
• Never unplug the appliance by pulling the power cord.
Always unplug your appliance:
- before filling the water tank.
- before cleaning the appliance,
- after each use.
• The appliance must be used and placed on a flat, stable,
heat-resistant surface. When you place the iron on the
iron rest, make sure that the surface on which you place
it is stable.
• This appliance is not intended to be used by persons
(including children) with reduced or impaired physical,
sensory or mental capabilities or persons lacking
appropriate knowledge or experience, unless a person
responsible for their safety provides either supervision or
appropriate instructions concerning use of the appliance
prior to its use.
• Children should be supervised to ensure they do not play
with the appliance.
• This appliance may be used by children aged 8 or
over and persons lacking appropriate knowledge or
experience or persons with reduced or impaired
physical, sensory or mental capabilities provided that
they have been thoroughly instructed regarding the
TE_CENTRALE_FASTEO_1800142429.qxp_110x154 17/10/2016 14:19 Page13

14
use of the appliance, are supervised, and understand
the risks involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not
be made by children without supervision. Keep the
iron and its cord out of reach of children less than
8 years of age when it is in use or cooling down.
• The surfaces of your appliance marked by this
symbol can reach very high temperatures when
functioning, which may cause burns. Do not touch
the hot surfaces of the appliance (accessible metal
parts and plastic parts adjacent to the metallic
parts) until the appliance has completely cooled.
• Never leave the appliance unattended when it is
connected to the mains. Before storing the appliance,
once it is unplugged, please wait until it has cooled down
(around 1 hour).
• Never fill your appliance directly from the tap.
• The cartridge cap must not be opened during use.
• The appliance must not be used if it has been dropped,
if it has any visible damage, if it leaks, or if it functions
abnormally in any way. Do not attempt to dismantle
your appliance: have it examined at an Approved Service
Centre to avoid any danger.
• Check the electrical power cord and water connection
cord for signs of wear or damage prior to use. If the
electrical power cord or the water connection cord is
damaged, it must be replaced by an Approved Service
Centre to avoid any danger.
• For your safety, this appliance conforms to all applicable regulations (Low Voltage Directive, Electromagnetic
Compatibility, Environment, etc).
• Your appliance is an electrical appliance: it must be used under normal conditions of use. It is designed for domestic
use only.
• It is equipped with a thermal fuse to avoid overheating.
• Always plug your appliance:
- into a mains circuit with voltage between 220 V and 240 V (Alternating current only),
- a socket outlet with an earth connection.
TE_CENTRALE_FASTEO_1800142429.qxp_110x154 17/10/2016 14:19 Page14

15
Connecting to the wrong voltage may cause irreparable damage to the appliance and will invalidate your
guarantee.
If you are using a mains extension lead, ensure that it is correctly rated (16A) with an earth connection, and is fully
extended. Always ensure that the base unit is positioned close enough to the ironing surface to avoid straining and
premature wear of the water connection cord.
• Completely unwind the power cord before plugging into an earthed socket outlet.
• Do not leave the power or water connection cords close to or in contact with sources of heat or sharp edges.
• The sole plate of your iron and the iron rest on the base unit and cartridge cap can reach extremely high
temperatures, and can cause burns: do not touch them. Never touch the electrical power cords with the sole plate
of the iron.
• Always use a vented/mesh ironing board to prevent water spots on clothes and to avoid hot steam venting
sideways. Be careful of hot steam when ironing close to the edges of the board. Never iron in a seated position with
your legs under the ironing board.
• Your appliance emits steam, which can cause burns. Always handle the iron with care, especially when ironing
vertically. Never direct the steam towards people or animals.
• Never immerse your appliance in water or any other liquid. Never place it under a running tap.
• The first time the appliance is used, there may be some fumes and smell but this is not harmful. If you
use the appliance for the first time, if you have replaced the anti calc cartridge or after filling the water
tank, press the steam control button continuously for few minutes pointing it away from your linen, in
order to prime the pump and obtain steam.
• When in use, the electric pump injects water into the iron solepate. It makes a noise but this is normal.
• Safety instructions Anti calc cartridge:
- Not for drinking
- Keep out of the reach of children
- Dispose with household refuse
- Keep in cool dry place
Preparation
What water may be used ?
This appliance has been designed to be used with untreated tap water.
Types of water not to use: In order to prevent your appliance life, you should not use water from clothes dryers,
scented or softened water or water with additives, water from refrigerators, batteries, air conditioners, rain water,
boiled, filtered or bottled water. Do not use pure distilled nor pure demineralised water.
All the types of water listed above may contain organic waste, mineral or chemical elements that can cause spitting,
brown staining or premature wear of the appliance.
Do not fill the water tank from the cartridge compartment.
Cartridge
Anti calc maintenance
Do not put any descaling substances (vinegar,industrial descaling products, etc.) in the water tank or in the anti calc
compartment, they could damage your appliance.
Using the appliance without changing the cartridge can damage the appliance and stop its steaming performance.
Press on the anti calc button only if you have changed the cartridge.
To ensure the efficiency of the cartridge, please remove it from its plastic bag and remove the cap just before use.
The international guarantee will not cover any damages which occurs as a result of using the appliance without
changing the cartridge
PLEASE RETAIN THIS INSTRUCTION
BOOKLET FOR FUTURE REFERENCE
TE_CENTRALE_FASTEO_1800142429.qxp_110x154 17/10/2016 14:19 Page15

16
Locking system (depending on model)
Your appliance is fitted with a retaining hoop to hold the iron onto the base with a locked position for easy
transport and storage:
• Locking. • Unlocking.
To transport your appliance using the handle of the iron:
• Put the iron on the iron rest plate and raise the retaining hoop over the iron until it locks into place.
• Hold the iron by the handle to transport your appliance.
Preparation
What water may be used ?
This appliance has been designed to be used with untreated tap water.
Types of water not to use: In order to maintain your appliance life, you should not use water from clothes dryers,
scented or softened water or water with additives, water from refrigerators, batteries, air conditioners, rain water,
boiled, filtered or bottled water.
All the types of water listed above may contain organic waste, mineral or chemical elements that can cause spitting,
brown staining or premature wear of the appliance.
If your water is very hard, we recommend you use a mix of 50% untreated tap water and 50% distilled water
available in hardware stores.
Do not use pure distilled nor pure demineralised water.
Do not fill the water tank from the cartridge compartment.
Filling the water tank
• Place your iron on a flat, stable, horizontal surface that is heatproof and waterproof.
• Always ensure that the base unit is positioned close enough to the ironing surface to avoid straining and wear
of the cord.
• We recommend that you use a mesh type ironing board to allow steam to pass through the garments for better
ironing results and also to prevent steam venting sideways.
• Check that your appliance is unplugged and open the refill inlet cover on the front of the water tank.
• Fill the water tank with untreated tap water until the max level.
• Close the water tank refill inlet cover.
• Do not fill the water tank from the cartridge compartment.
• This appliance is designed to be used with a cartridge.
Using your appliance
The first time the appliance is used, there may be some fumes and smell but this is not harmful. They will not affect use
and will disappear rapidly.
• Completely unwind the power cord and the water connection cord.
• Plug in your appliance to an earthed socket.
• Press on the on / off switch. The max indicator located on the control panel flashes while the iron heats up. When
the max indicator light stops flashing and the iron thermostat light goes out (after 2 minutes approximately),
the appliance is ready for use.
• If you use the appliance for the first time, if you have replaced the anti calc cartridge or after filling the
water tank, press the steam control button continuously for a few minutes pointing it away from your linen,
in order to prime the pump and obtain steam when the temperature dial is in the 3 dot position.
1. Steam control button
2. Iron temperature control dial
3. Iron thermostat light
4. iron rest plate
5. Water tank
6. Lock system (depending on model)
7. Water tank refill inlet
8. Water connection cord
9. Water connection cord storage compartment
10. Anti Calc cartridge
11. Control panel
a. Reset Anti-calc button
b. Anti-calc indicator
c. Max steam mode and steam ready indicator
d. ECO steam mode indicator
12. Illuminated on / off switch
13. Soleplate
Description
EN • PLEASE REFER TO SAFETY INSTRUCTIONS AT THE BEGINNING
OF THIS BOOKLET BEFORE USING YOUR APPLIANCE
TE_CENTRALE_FASTEO_1800142429.qxp_110x154 17/10/2016 14:19 Page16

17
• When in use, your electric pump injects water into the iron solepate. It makes a noise but this is normal.
Use
Setting the temperature
Do not place the iron on a metal support.When taking a break from ironing, always place the iron on the iron
rest plate of the unit. It is equipped with non-slip pads and has been designed to withstand high
temperatures.
• Place the iron's temperature control dial according to the type of fabric to be ironed (see table below).
• The iron thermostat light comes on. Important: whenever you start using your iron and whenever you change the
temperature during use, the iron is fully ready for use when its iron thermostat light goes out.
• While ironing, the light of the iron turns on and off, as the temperature adjusts without interrupting ironing.
• Steam may take some time to start as your appliance needs to activate its water circuit.
• The steam can only be used on 3 dots setting area (see below table). For other garments (1 dot and 2 dots) the
iron is not hot enough to produce steam and therefore it is not recommended to use the steam control button
as this may cause water dripping from the soleplate.
• The steam will stop when you release the button.
• Always spray starch onto the reverse side of the fabric to be ironed.
Before using the iron for the first time, or if you have not used the steam button for a long time, press the steam
control button several times in a row, holding the iron away from your clothes.
• Iron temperature setting:
- Start with the fabrics to be ironed at a low temperature (•) and finish with those which need higher temperatures
(••• or Max).
- Mixed fibre fabric: set the ironing temperature to the setting for the most delicate fabric.
• If you put your thermostat in the “min” position, the iron does not heat.
Steam boost function
• Your appliance includes the Steam boost: automatic sequential steam for effortless use. To be used in particular
for thick fabrics.
• To obtain this function, press the steam control button under the handle three times in quick succession.
ECO MODE: Your appliance has an ECO mode function which uses less power whilst still producing a good steam
flow to iron your garments properly. This mode can only be used on 3 dots setting (••• or Max) (see Above table).
Dry ironing
• Do not press the steam control button under the iron handle.
Vertical steam ironing
Recommendations : for fabrics other than linen or cotton, hold the iron a few centimetres from the garment to avoid
burning the fabric.
• Set the iron temperature control dial to the MAX position.
• Hang the garment on a coat hanger.
As steam is very hot : never attempt to remove creases from a garment while it is being worn, always hang
garments on a coat hanger.
• Holding the iron in a vertical position, press repeatedly on the steam control button (underneath the iron handle)
moving the iron from top to bottom.
SETTING THE TEMPERATURE AND STEAM OUTPUT ACCORDING TO TYPE OF FABRIC TO BE IRONED
TYPE OF FABRICS Setting temperature control
Synthetics, Silk
Wool, Viscose
Linen, cotton MAX ECO
TE_CENTRALE_FASTEO_1800142429.qxp_110x154 17/10/2016 14:19 Page17

18
Refilling the water tank
• The water tank is empty.
• Switch off then unplug the appliance and open the flap on the tank.
• Fill a jug with untreated tap water then fill the tank up to the max mark.
• Plug in and switch the appliance on again by pressing the on/off switch.
Maintenance and cleaning
Anti calc maintenance
Do not put any descaling substances (vinegar, industrial descaling products, etc.) in the water tank or in the anti calc
cartridge compartment, they could damage your appliance.
To extend the life of your appliance and to avoid scale, your appliance is equipped with a anti calc cartridge system. This
anti calc cartridge system is located below the iron rest.
The cartridge will need to be changed only when the anti-calc indictor flashes which will depend on your frequency of
ironing and how much steam you use.
Operation:
The appliance has an anti calc indicator located on the control panel. When this indicator is flashing it means that
the anti calc cartridge is no longer efficient and must be replaced by a new one.
To replace your anti calc cartridge :
- Never replace the anti calc cartridge during use.
- Switch off and unplug your appliance.
- Wait for at least one hour and check that the appliance is cold.
- Open the anti calc cartridge cover.
- Pull the used anti calc cartridge out of its compartment.
- Be careful, some water drops may fall out of the anti calc cartridge when you remove it from its compartment.
This is normal and the water is harmless.
- Take the new anti calc cartridge out of its bag.
- Place the new anti calc cartridge in the compartment and press it down until it locks.
- Close the anti calc cartridge cover.
- Plug and switch on your appliance. The max indicator located on the control panel flashes while the iron heats
up. When the max indicator light stops flashing and the iron thermostat light goes out (after 2 minutes
approximately), the appliance is ready for use.
- Press the anti calc reset button on the control panel. (3 seconds)
- You might have to press the steam control button for a few minutes to start the steam again as your appliance needs
to re-activate its water circuit when the temperature dial is in the 3 dot position.
This operation is essential to maintain the working life of your appliance.
Using the appliance without changing the cartridge can damage the appliance and stop its steaming
performance. Press on the anti calc button only if you have changed the cartridge.
To ensure the efficiency of the cartridge, please remove it from its plastic bag just before use. The
international guarantee will not cover any damages which occur as a result of using the appliance without
changing the cartridge.
Cleaning your appliance
Before cleaning, ensure your appliance is unplugged and that the soleplate and the iron have cooled down for least
1 hour.
• Do not use detergent or descaling products for cleaning the soleplate base-unit.
• Never hold the iron or the base unit under the tap.
• Regularly clean the soleplate with a damp, non-metallic washing up pad.
• Clean the plastic parts of the appliance occasionally with a soft cloth.
Storing your appliance
• Warning: do not touch the soleplate while still hot.
• Store the water connection cord in its compartment.
• Leave the iron (and the iron rest) to cool down for 1 hour before storing it away.
TE_CENTRALE_FASTEO_1800142429.qxp_110x154 17/10/2016 14:19 Page18

19
A problem with your appliance ?
PROBLEMS CAUSES SOLUTIONS
Your iron is producing little or no
steam.
You have just filled the tank or chan-
ged the anti-calc cartridge, or you
have just started using it.
Press the steam control button conti-
nuously for few minutes pointing it
away from your linen, in order to
prime the pump.
There is no anti calc cartridge in the
appliance or it is not properly instal-
led.
Make sure the anticalc cartridge is
installed and locked down in its com-
partment.
Steam cannot be produced at the
temperature you have selected.
Set the thermostat control in the co-
loured zone (••• or MAX).
The water tank is empty. Fill the tank.
Water runs out of the holes of the so-
leplate.
You are using steam for the first time
or you have not used it for some
time.
Press on the steam control button
away from your ironing board until
the iron produces steam.
The setting is not correct (1 dot / 2
dots) and the soleplate is not hot en-
ough to produce steam.
Set the iron at 3 dots (••• or MAX)
and wait for the iron thermostat light
to go out before activating the steam
button again.
Water streaks appear on the linen.
Your ironing board is saturated with
water because it is not suitable for
use with a steam generator.
Check that your ironing board is
suitable. We recommend that you
use a vented/mesh type ironing
board.
Brown streaks come through the
holes in the soleplate and stain the
linen.
You are using chemical descaling
agents or additives in the water
ironing.
Never add this type of product in the
water tank (see “for what water may
be used”). Contact an Approved Ser-
vice Centre.
Your linen is not rinsed sufficiently or
you have ironed a new garment be-
fore washing it.
Ensure linen is rinsed thoroughly to
remove any soap deposits or chemi-
cals on new garments which may be
sucked up by the iron.
The soleplate is dirty or brown and
may stain the linen.
You are ironing at too high a tempe-
rature.
See our recommendations regarding
temperature control setting.
You are using starch. Always spray starch on the reverse
side of the fabric to be ironed.
Steam or water escapes under the
base of the appliance. The appliance is faulty. Stop using your appliance and contact an Approved Service Centre.
The “anti calc” indicator is flashing. The anti calc cartridge is no longer
efficient.
Replace the anti calc cartridge with a
new one then press the reset button
for a minimum of 3 seconds.
The anti calc indicator is still flashing
after replacing the cartridge.
You have not pressed the reset
button.
Press the reset button until the light
stops flashing.
If you have any problems or queries please call our Customer Relations team first for expert help and advice: 0345 602 1454
UK / [phone] - ROI or consult our website - www.tefal.co.uk
Environment protection first !
i Your appliance contains valuable materials which can be recovered or recycled.
‹Leave it at a civic waste disposal centre.
TE_CENTRALE_FASTEO_1800142429.qxp_110x154 17/10/2016 14:19 Page19

1800142429/01 - 41/16
TE_CENTRALE_FASTEO_1800142429.qxp_110x154 17/10/2016 14:19 PageC4
