TEFAL ULTRAGLIDE Anti-Calc FV2660 User manual

ULTRAGLIDE
Anti-Calc
EN
www.tefal.com
1800138416-01 FV26XX UK_110x154 19/01/16 11:27 Page1

According to model
*
2
1800138416-01 FV26XX UK_110x154 19/01/16 11:27 Page2

3
1800138416-01 FV26XX UK_110x154 19/01/16 11:27 Page3

4
IMPORTANT AFETY RECOMMENDATION
• Please read these instructions carefully before first
use. This product has been designed for domestic and
indoor use only. Any commercial use, inappropriate
use or failure to comply with the instructions, the
manufacturer accepts no responsibility and the
guarantee will not apply.
• Never unplug the appliance by pulling the power
cord. Always unplug your appliance: before filling the
water tank or rinsing the water tank, before cleaning
the appliance, after each use.
• The appliance must be used and placed on a flat,
stable, heat and water resistant surface. When you
place the iron on the iron rest, make sure that the
surface on which you place it is stable.
• This appliance is not intended to be used by persons
(including children) with reduced or impaired
physical, sensory or mental capabilities or persons
lacking appropriate knowledge or experience, unless
a person responsible for their safety provides either
supervision or appropriate instructions concerning
use of the appliance prior to its use.
• Children should be supervised to ensure they do not
play with the appliance.
• This appliance may be used by children aged 8 or
over and persons lacking appropriate knowledge or
experience or persons with reduced or impaired
physical, sensory or mental capabilities provided that
•
•
•
•
1800138416-01 FV26XX UK_110x154 19/01/16 11:27 Page4

5
st
d
e
e
e
er
e
g
t,
u
e
s
d
s
ss
er
g
ot
or
or
d
at
they have been thoroughly instructed regarding use
of the appliance, are supervised, and understand the
risks involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not
be made by children without supervision. Keep the
iron and its cord out of reach of children less than 8
years of age when it is energized or cooling down.
• The surfaces of your appliance can reach very
high temperatures when functioning, which may
cause burns. Do not touch the hot surfaces of the
appliance (accessible metal parts and plastic
parts adjacent to the metallic parts).
• Never leave the appliance unattended when it is
connected to the mains. Before storing the appliance,
once it is unplugged, please wait until it has cooled
down (around 1 hour).
• The appliance must not be used if it has been
dropped, if it has any visible damage, if it leaks, or if it
functions abnormally in any way. Do not attempt to
dismantle your appliance: have it examined at an
Approved Service Centre to avoid any danger.
• The iron should only be used with the base provided
(for cordless irons).
• Check the electrical power for sign of wear or damage
prior to use. If the electrical power cord is damaged, it
must be replaced at an Approved Service Centre to
avoid any danger.
1800138416-01 FV26XX UK_110x154 19/01/16 11:27 Page5

6
• The iron must always be placed on its base and never on its heel (for cordless irons) .
• Your iron and its base must be used and placed on a stable surface. When you place the iron on its
base, ensure that the surface on which the base is placed is stable.
• For your safety, this appliance conforms to all applicable regulations (Low Voltage Directive,
Electromagnetic Compatibility, Environment, etc).
• Your steam iron is an electrical appliance: it must be used under normal conditions of use. It is
designed for domestic use only.
• Always plug your steam iron:
- into a mains circuit with voltage between 220 V and 240 V,
- into an earthed electrical socket.
Connecting to the wrong voltage may cause irreparable damage to the appliance and will
invalidate your guarantee. If you are using a mains extension lead, ensure that it is correctly rated
(16A) with an earth, and is fully extended.
• Completely unwind the power cord before plugging into an earthed socket.
• The soleplate of your iron can reach extremely high temperatures, and can cause burns: do not
touch them. Never touch the electrical power cords with the soleplate of the iron.
• Your appliance emits steam, which can cause burns. Always handle the iron with care, especially
when ironing vertically. Never direct the steam towards people or animals.
• Never immerse your steam iron in water or any other liquid. Never place it under a running tap.
• The plug must be removed from the socket-outlet before the water tank is filled with water.
PLEA E RETAIN THI IN TRUCTION
BOOKLET FOR FUTURE REFERENCE
Environment protection first !
i Your appliance contains valuable materials which can be recovered or
recycled.
‹ Leave it at a local civic waste collection point.
1800138416-01 FV26XX UK_110x154 19/01/16 11:28 Page6

7
UMMARY
Important safety recommendations ............................................................................................................ p. 4
Before first use................................................................................................................................................................................... p. 8
Which water should I use?............................................................................................................................................. p. 9
Filling the water tank............................................................................................................................................................... p. 9
Adjusting the temperature and steam...................................................................................................... p. 10
Dry ironing................................................................................................................................................................................................. p. 11
Getting more steam.................................................................................................................................................................. p. 11
Vertical steam ironing............................................................................................................................................................ p. 12
Dampening clothing (Spray)........................................................................................................................................... p. 13
While ironing ....................................................................................................................................................................................... p. 13
Auto-Off Function (according to model)............................................................................................................. p. 13
Iron storage............................................................................................................................................................................................. p. 14
Cleaning the anti-calc Collector............................................................................................................................ p. 15
Cleaning the anti-calc valve (once per month)............................................................................ p. 16
Descaling the steam chamber (3 times a year) .......................................................................................... p. 17
Cleaning the soleplate.......................................................................................................................................................... p. 18
Problems, possible causes, solutions.............................................................................................................. p. 19
IMPORTANT AFETY RECOMMENDATION
PREPARATION
U E
IRON TORAGE AND MAINTENANCE
I THERE A PROBLEM WITH YOUR IRON?
ts
ve,
is
will
ed
ot
ly
or
1800138416-01 FV26XX UK_110x154 19/01/16 11:28 Page7

8
emove any labels from the soleplate before
heating the iron.
Before using the steam function in your iron
for the first time, we recommend that you
allow the iron to operate a few moments in
a horizontal position without coming into
contact with your laundry. Keeping the iron
in this position, push the steam button seve-
ral times.
During the first few uses, the appliance may
produce smoke, a harmless odour and a light
emission of particles. These are simply the
engineering residues from the manufactu-
ring process burning off. These are harmless
and will quickly disappear.
BEFORE FIR T U E
1800138416-01 FV26XX UK_110x154 19/01/16 11:28 Page8

9
If your water is very hard, mix 50% untreated tap water
with 50% distilled water (available in hardware stores).
PREPARATION
Which water should I use?
Filling the water tank
• Your appliance was designed to operate using untreated
tap water. However, it is necessary to periodically clean
the steam chamber to remove any mineral deposits.
• Do not use pure demineralised or pure distilled water,
water from clothes dryers, scented or softened water,
rain water, filtered, bottled or boiled water, water from
refrigerators, batteries or air conditioners, pure distilled
water or rain water as these may damage the iron. These
types of water contain organic waste, mineral elements
that become concentrated when heated and cause
spitting, brown staining, leaking or premature wear on
your iron
• Unplug the iron before filling it.
• Set the steam control to
• Lift the iron and, holding it at a slight incline, point the
soleplate up.
• Open the water tank cover.
• Fill the water tank to the mark “Max”.
• Close the water tank cover.
Warning ! Do not fill your iron through the scale
collector opening. Do not remove the anti-calc
collector to fill the tank.
Max
Max
1800138416-01 FV26XX UK_110x154 19/01/16 11:28 Page9

10
10
U E
Adjusting the temperature and steam
• Set the steam control to
• Adjust the temperature control, referring to the table
below.
• The temperature indicator light turns on.
• It will turn off automatically once the soleplate
achieves the desired temperature.
FABRIC TEMPERATURE CONTROL
POSITION
LINEN Max
COTTON •••
WOOL ••
SIL /SYNTHETIC
(Polyester, Acetate, Acrylic,
Polyamide)) •
OK
= STEAM ZONE
Set the temperature control dial to match the type of
fabric you wish to iron. Your iron automatically and
accurately determines the exact temperature and
steam flow that are suitable, in order to guarantee the
best results.
• Plug in the appliance.
1800138416-01 FV26XX UK_110x154 19/01/16 11:28 Page10

11 11
Dry ironing
• Set the temperature according to the fabric to be
ironed.
• Set the steam control to
• You may continue to iron when the indicator light
turns off.
Getting more steam
• Set the thermostat control to “Max” or “•••”.
• Press the turbo steam button periodically (turbo
steam).
• To avoid water dripping on the laundry, maintain an
interval of a few seconds in between each press.
Your iron heats quickly: begin with fabrics that require
lower temperatures.
When ironing fabrics with most delicate fibres: set the
ironing temperature for the most fragile fibre.
The iron will not heat up if the thermostat control is
set to "Min".
Max
1
sec.
1800138416-01 FV26XX UK_110x154 19/01/16 11:28 Page11

12
Vertical steam ironing
• Hang the item on a hanger and keep the fabric taut
with one hand. The steam is very hot; never steam iron
clothing while it is being worn—always use a hanger.
• Set the thermostat control to “Max”
• Press the turbo steam button (turbo steam) in pulses,
moving the iron from top to bottom.
• Hold the iron at a distance of a few centimetres from
the clothing to avoid burning delicate fabrics.
Max
1
sec.
NO
1800138416-01 FV26XX UK_110x154 19/01/16 11:28 Page12

13
Dampening clothing (Spray)
• When dry or steam ironing, press repeatedly on the
spray button to moisten clothing and remove stubborn
creases.
• Ensure that there is water in the tank before using the
spray button.
Auto-Off Function (according to model)
• If the iron remains unused for more than 8 minutes on
the heel rest or more than 30 seconds laid flat or on
its side, the electronic system will cut the power, the
iron will stop heating and the auto-off indicator will
begin to flash.
• To restart the iron, move it gently until the indicator
stops flashing.
While ironing
• Do not lay the iron down on the soleplate; use the heel
rest for this purpose.
NO
OK
1800138416-01 FV26XX UK_110x154 19/01/16 11:28 Page13

14
IRON TORAGE AND
MAINTENANCE
Storing your iron
• Unplug the iron and wait for the soleplate to cool
(approx. 1 hour).
• Empty the water tank.
• Set the steam control to .
• Wrap the cord lightly around the bottom of the iron's
body. Store the iron on its heel rest.
1H
1800138416-01 FV26XX UK_110x154 19/01/16 11:28 Page14

15
• Unplug the iron, empty the water tank and wait for the
soleplate to cool down (approx. 1 hour).
• Once the steam iron has completely cooled down, raise
and turn the tab of the collector to unlock it.
• Remove the collector from the iron, it contains the
limescale collected in the iron.
• To clean the collector thoroughly rinse in water to
remove the limescale inside.
• Reposition the collector in its housing and turn the tab
a quarter turn to the right in order to lock the collector
and ensure it is watertight.
Warning ! The iron does not work without the anti-
calc collector.
1
2
Cleaning the anti-calc Collector (every 4 months)
1800138416-01 FV26XX UK_110x154 19/01/16 11:28 Page15

16
• Unplug your iron and empty the water tank.
• To remove the anti-calc valve, open the water tank
cover and pull on the valve near the steam control.
• Soak the valve for 4 hours in a glass of water with
lemon juice.
• Rinse the valve under the tap.
• Insert the valve in place, pushing it until you hear a
click.
Beware!
Never touch the end of the valve.
The iron will not function without the anti-calc valve.
Click
4h
Cleaning the anti-calc valve (once per month)
1800138416-01 FV26XX UK_110x154 19/01/16 11:28 Page16

17
• Allow your iron to heat up with a full water tank while
on its heel rest and with the temperature control set
to maximum.
• Once the indicator light switches off, unplug the iron
and place it over a sink.
• Remove the anti-calc collector.
• Shake the iron gently in a horizontal position above
the sink until some of the water (containing the
impurities) leaks from the soleplate. You may push the
turbo steam trigger to help flush out the minerals.
• To finish the process, replace the anti-calc collector,
pushing it until you hear a click.
• Plug in your iron for 2 minutes on the heel rest to dry
the soleplate.
Max
Max
Click
2
min.
Descaling the steam chamber (once per month)
1800138416-01 FV26XX UK_110x154 19/01/16 11:28 Page17

18
• Unplug your iron and, once cooled, wipe it with a soft
cloth.
• Never use chemical or abrasive products.
Cleaning the soleplate
• While the soleplate is still cool, clean it with a damp
non-metallic pad.
• Never use chemical or abrasive products.
NO
NO
During the next use, turn on your iron in a horizontal
position without putting it into contact with your
laundry in order to eliminate any water containing
mineral residues that remain in the soleplate.
1800138416-01 FV26XX UK_110x154 19/01/16 11:28 Page18

19
PROBLEM PO IBLE CAU E OLUTION
Water is leaking
from the holes in
the soleplate.
You are using the steam when
the iron is not hot enough.
Wait for the indicator light to turn
off.
You are using the turbo steam
button (turbo steam) too often.
Wait a few seconds between each
use.
You have stored the iron
horizontally without emptying
the water tank or setting the
steam control to
.
See the chapter on "Storing your
iron".
The iron leaks at
the start of
ironing.
You have removed the anti-calc
collector to fill up your iron.
Do not remove the anti-calc collector
when filling the iron.
The steam control dial is not set
to when filling the water tank.
Ensure that the steam control dial is
set to when filling the water tank.
A brown
discharge
coming from
the soleplate
is staining the
clothing.
You are using chemical descaling
agents.
Do not introduce a descaling agent
into the water tank.
You are not using the right type
of water.
Clean the steam chamber and see
the chapter on "What water should I
use?"
Clothing fibres are building up in
the holes of the soleplate and
burning.
Clean the steam chamber and the
soleplate with a damp sponge.
Periodically vacuum the holes in the
soleplate.
The soleplate is
dirty or brown
and may stain
clothing.
The temperature of the iron is
too hot.
Clean the soleplate as indicated
above. Consult the table of
temperatures to adjust the
temperature.
You are using starch. Clean the soleplate as indicated
above. Spray the starch on the reverse
side of the clothing to be ironed.
Your laundry has not been rinsed
sufficiently or you are ironing a
new item of clothing before
washing it.
Ensure that your laundry is
sufficiently rinsed to eliminate
potential soap deposits or chemical
products on new items of clothing
being sucked up by the iron and then
deposited on the linen.
I THERE A PROBLEM WITH YOUR IRON?
1800138416-01 FV26XX UK_110x154 19/01/16 11:28 Page19

PROBLEM PO IBLE CAU E OLUTION
Your iron
produces little to
no steam.
The water tank is empty. Fill it up.
The anti-calc collector is
dirty.
Clean the anti-calc collector.
Your iron is clogged up with
limescale.
Clean the anti-calc collector and
steam chamber.
Your iron has been used for
too long in the dry ironing
function.
Clean the steam chamber.
The soleplate is
scratched or
damaged.
You have placed your iron
on a metallic iron rest or
ironed over metal zips or
fastners.
Always place your iron on its heel
rest when not in use.
Do not iron over metal zips or
fastners.
The iron steams
once the water
tank has been
filled.
The steam control dial is
not set to .
Ensure that the steam control dial is
set to .
The water tank is too full. Do not exceed the max level for
filling.
The spray does
not spray water.
The water tank is not full
enough.
Add water to the water tank.
If you have any problems or queries please call our Customer
Relations team first for expert help and advice.
ee Helpline number in the separate guarantee
and country list leaflet.
I THERE A PROBLEM WITH YOUR IRON?
1800138416-01 - 01/16 - FTL2
1800138416-01 FV26XX UK_110x154 19/01/16 11:28 Page20
