Teka AirFan User manual

Operating instructions
(Translation of the original operating instructions)
AirFan
TEKA Absaug- und Entsorgungs-
technologie GmbH
Industriestraße 13 D-46342 Velen
Postfach 1137 D-46334 Velen
Tel.: [phone]
Fax: [phone]
E-Mail: [e-mail]
www.teka.eu

BA_AirFan_161122_GB.doc 2 22.11.2016
List of contents
1. Diagrams / description of the elements ...............................................................................................2
2. Foreword..............................................................................................................................................3
3. Function of the TEKA – Extractor blower ............................................................................................3
4. Safety instructions ...............................................................................................................................4
5. Initial operation ....................................................................................................................................5
5.1. Connection of the appliances .......................................................................................................5
6. Technical data .....................................................................................................................................5
7. Declaration of conformity for TEKA – extractor blower .......................................................................6
1. Diagrams / description of the elements
Pos.1
Pos.2
Pos.3
Pos.4
Motor protective switch
Switches the ventilator on or off
Ventilator frame
Motor
Ventilator housing
Pos.5
Pos.6
Pos.7
Pos.8
Clamping lock
protective grid
Castor with brake
Castor without brake

BA_AirFan_161122_GB.doc 3 22.11.2016
2. Preface
Congratulations on purchasing the unit from the TEKA-series “AirFan”.
Our engineers ensure that our filter systems reflect the state of the art through continuous devel-
opment. Nevertheless, misuse or misconduct can endanger your safety.
Please observe the following for a successful use of the filter system:
Please read these instructions before operating the system, and observe the safety pre-
cautions to avoid injury!
Improper use of the equipment can cause serious injury or death!
Store this manual in a safe place! These instructions are to be regarded as a compo-
nent of the product!
Adhere to all product notes!
Observe the local regulations in force at the installation site!
Observe the manufacturer’s instructions. Contact the manufacturer in case of any un-
certainty.
Tel.: +49 28 63 - 92 82 - 0
Fax: +49 28 63 - 92 82 - 72
We thank you for your confidence in us and wish you every success.
3. Intended use
The TEKA – Extractor blower filter unit is primarily used for localised extraction of welding fumes. For
this purpose, the unit can be equipped with one flexible extractor hose or application-specific fittings.
Improper use of the equipment can lead to damage to individual parts and endan-
ger life and limb!
The system must not be used for the extraction of oil containing welding smoke, explo-
sive dusts and gases, metallic dust, hybrid mixtures, burning or glowing substances, gas-
es, water, etc. The system must also not be operated in explosive zones.
Please contact the manufacturer in case of doubt!
The polluted air is sucked into the extractor hood (or application-specific fitting) and transported outside
through the extractor hose.

BA_AirFan_161122_GB.doc 4 22.11.2016
4. Safety instructions
When using electrical equipment, the following basic safety rules must be observed, for protection
against electric shock, injury, or fire hazards.
•Before using the equipment, read and observe these instructions!
•Keep the operating and maintenance instructions in a safe place!
•Never use the extractor blower to extract easily inflammable or explosive gases!
•Never use the extractor blower for extracting aggressive media!
•Never use the extractor blower for extracting burning or glowing materials
•Never use the equipment to suck up any kind of liquid!
•Do not use the equipment for the extraction of organic substances without written approval from
the manufacturer!
•Protect the connectors against heat, moisture, oil, and sharp edges!
•Pay attention to the permitted supply voltage!
(Observe the data on the nameplate!)
•Only use TEKA spare parts!
•The exhaust vent must not be covered up or blocked!
•Always make sure that the unit is securely mounted!
•The mains supply cable for the unit must be checked regularly for possible damage!
•The extractor blower must not be used if the mains supply cable is not in perfect condition!
•Do not use the extractor blower if one or more of its components are faulty, missing, or dam-
aged. In any of these cases, please call the TEKA service department on ++44-(0) 28 63-92 82-
0.

BA_AirFan_161122_GB.doc 5 22.11.2016
5. Initial operation
The extractor blower is supplied with all connections.
The extractor blower can be used in any location.
The extractor blower may be installed outdoors.
The extractor fittings and possible other accessory equipment, must be installed or mounted on the ex-
tractor blower before initial operation.
Warning:
The extractor blower may never be operated without the grids (pos.6)!
5.1.Connection of the appliances
•Connect the extractor blower with the power supply.
(Observe the information on the nameplate!)
Warning:
Work on the electrical sections must only be carried out by qualified and authorized personnel.
(Observe the data on the nameplate!)
6. Technical data
Motor power
[kW]
Supply voltage
[V]
Frequency
[Hz]
Volumetric flow max.
[m³/h]
Protection
class
Weight
[kg]
0,75 230 50 2000 IP 54 28

BA_AirFan_161122_GB.doc 6 22.11.2016
7. Declaration of conformity for TEKA – AirFan
TEKA
Absaug - und Entsorgungstechnologie GmbH
Industriestraße 13
D - 46342 Velen
Phone:[phone] Fax:[phone]
e-Mail: [e-mail] Internet:http://www.teka.eu
We hereby declare under our sole responsibility that the product mentioned above, from the serial num-
ber A12000010011001 resp. the production number P25000010011001 on, conforms to the following
directives:
Machinery directive: 2006/42/EC
Electromagnetic compatibility: 2014/30/EU
Low voltage directive: 2006/95/EC
Applied harmonised standards:
- DIN EN 349
- DIN EN ISO 4414
- DIN EN ISO 12100
- DIN EN 60204 part 1
- DIN EN ISO 13857
- DIN EN 82079 part 1
plus further national standards and specifications:
- DIN 45635 part 1
This declaration will become void if the suction and filter unit is exposed to modifications that are not
approved by the manufacturer in written form.
Authorized representative for the technical documentation: TEKA GmbH, Technical department, D-
46342 Velen
Velen, 29th of december 2015
