tekflo jet User manual

Jet Hand Dryer
Instructions Manual

2 3
Table of Contents
Product Dimensions 3
Product Features, Technical Specications & Package Contents 4
Installation & Safety Guidelines 5
Installation Instructions 6
Operation Guidelines 8
Cleaning & Maintenance Guidelines 9
Warranty Details 10
Product Dimensions

4 5
Product Features, Technical Specications
& Package Contents
Product Features:
• Super-slimline compact dryer - just 100mm deep
• Looks great while saving space
• Switchable heating element means power can be adjusted down to 400W -
reducing running costs and carbon footprint
• Powerful ‘blade’ motor dries hands in just 10 seconds
• Heavy duty Stainless Steel casing gives excellent ongoing protection against
corrosion and vandalism
• The automatic ‘no touch’ operation ensures impeccable hygiene
• No unnecessary energy wastage thanks to the automatic cut-o
• Reduced noise levels of 72dB for quick and quiet drying
• Easy to install and maintain
• Finishes available in Brushed Metal, Reex Silver and Arctic White
Technical Specications:
• Shell material: 304 Stainless Steel
• Standard nishes: Brushed Metal,
Silver, White
• Rated voltage: AC 220-240V
• Rated frequency: 50 / 60 Hz
• Rated Power: Variable: 400W –
950W (Switchable Heating Element)
• Installation: wall mounted
• Drying time: 10 Seconds
• Air speed: 85 M/s
• Noise output: 72dB
• Operation: infrared automatic ‘no
touch’
• Timing protection: 60 seconds auto
cut o
• Thermal protection: cut o above
70C
• Air Filter: Yes
• Unit dimensions: 275mm W x
300mm H x 100mm D
• Net weight: 4.0 kg
• Warranty: 2 Years
• Certication: CE, RoHs
Package Contents:
• Hand dryer
• Wall mounting bracket
• Fixtures and ttings
• User manual and installation guide
Installation & Safety Guidelines
• All electrical installation and repair work should be carried out by a qualied
electrician in accordance with current locals codes or regulations.
• Do not attempt any disassembly or modication of the unit that is not expressly
stated in this manual.
• Do not install when the product (power cable) is electried.
• Install securely in a location strong enough to support the weight of the unit.
• Install the hand dryer on a smooth surface and in an area where people are not
likely to collide with the object once installed.
• Do not scratch, damage, process, excessively bend, pull, twist or bundle the
power cable, and do not place heavy objects onto it or trap it.
• Do not use in a hot location such as a shower room, where condensation may
form on the unit, or where water may splash directly at the unit.
• Do not install this hand dryer above sources of water such as sinks or taps.
• Do not install in locations where salt damage may occur, or where corrosive,
neutral, or reductive gases are present.

67
Installation Instructions
1. Remove the chassis
• Prior to installation, remove the two screws and lift o the outer chassis to expose
the mounting plate.
2. Fix the mounting plate:
• Having removed the mounting plate from the rear of the dryer, x to the wall
using the provided xings as per the diagram measurement guide.
3. Hang the dryer on mounting plate:
• Carefully hang the dryer chassis on to the mounting plate and ensure it is
securely attached.
Recommended Mounting Heights
Measurements are from the base of the unit to the oor
• Mens: 45” (114 cm)
• Ladies: 43” (109 cm)
• Teenagers: 41” (104 cm)
• Small Children: 35” (89 cm)
• Disabled: 39” (99 cm)
1) 2)
3)

8 9
Operation Guidelines
• Before inserting hands under the dryer, shake o any excess water.
• This hand dryer incorporates no touch sensor activation for hygienic use.
Simply place your hands 10cm from the air outlet and the hand dryer will be
automatically activated.
• Remove your hands away from the air outlet and the hand dryer will be
deactivated after 2 seconds.
• The hand dryer will automatically cut o after running for 60 seconds if the
sensor is activated for this period. If need be, remove hands from the sensor and
return your hands and the dryer will re-activate.
Cleaning & Maintenance Guidelines
Cleaning and maintenance should be carried out by service personnel only. It is
recommended that cleaning be carried out regularly every month.
1. Ensure that the unit is disconnected from the mains supply.
2. Remove the front cover by releasing the two xing screws.
3. Carefully remove any build up of dust from within the dryer mechanism.
4. Then replace the cover and wipe down the exterior of the dryer with a damp
cloth, removing any build of up dirt.
5. Ensure the unit is completely dry before reconnecting the power supply.

10 11
Warranty Details
• All Teko Hand Dryers are guaranteed to be free from defects in parts and
manufacture for 2 years from the date of purchase, provided that the product is
used under the normal operating conditions stated within the manual.
• The warranty is only available to the original purchaser and is not transferable.
Your consumer rights are not aected.
• If there are any defects with your hand dryer please contact the provider stating
your invoice number, date of purchase, full name and address.
• Do not attempt to repair or take apart the hand dryer your self. If the hand dryer
has been tampered with before it arrives with us, the warranty will be void.
• We advise that all customers retain original packaging should the unit need to be
returned.
• If your hand dryer occurs a problem outside of the warranty period, we oer a
repair service where we can collect and professionally repair your hand dryer.
Notes

12
Visit www.teko.com or email enquiries@teko.com
for more information
