Tektronix TLA715 Series User manual

TLA700 Series Tektronix Logic Analyzer
Declassification and Security
Instructions
www.tektronix.com
077-0038-00

Copyright © Tektronix. All rights reserved. Licensed software products are owned by Tektronix or its subsidiaries
or suppliers, and are protected by national copyright laws and international treaty provisions.
Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication
supersedes that in all previously published material. Specifications and price change privileges reserved.
TEKTRONIX and TEK are registered trademarks of Tektronix, Inc.
Contacting Tektronix
Tektronix, Inc.
14200 SW Karl Braun Drive
P.O. Box 500
Beaverton, OR 97077
USA
For product information, sales, service, and technical support:
In North America, call 1-800-833-9200.
Worldwide, visit www.tektronix.com to find contacts in your area.

Logic Analyzer Technical Report
1
Date: June 28, 2005
Subject: Memory Erasure & Parts in TLA714, TLA715, TLA720, TLA721.
MEMORY ERASURE PROCEDURE
These products contain an open architecture PC with REMOVABLE hard drive (an option for a second internal hard
drive is also available). All user storable data is stored on the removable and the internal (if optioned) hard drive.
There are DOD approved scrubbing software packages available for the hard drive(s). We have no recommendations
regarding the available packages. After the hard drive(s) have been scrubbed, you can reinstall the operating system
using the Image CD that came with the Logic Analyzer. This returns the Logic Analyzer hard drive to the initial factory
shipped state.
Another approach, if no internal hard drive has been optioned, is that you can simply remove the removable hard drive.
It is located on side panel for easy removal. This drive can then be stored or destroyed. Additional hard drives can be
purchased from Tektronix with a hard disk image of Windows 2000 and the TLA logic analyzer application. The new
hard drives can then be inserted and the instrument is returned to its "like new" factory default configuration.
Remove setup information from the BIOS by resetting the BIOS to default on power-up. Next, follow the “Setting Up
the TLA700 Controller BIOS” procedure shown in the manual that came with the product. If the TLA Application
software has been updated, use the “Setting Up the TLA700 Controller BIOS” procedure shown in the manual that
came with the newer software.
Remove all floppy disks and format them (don’t use “Quick Format”), store them, or destroy them.
Remove all CDs. Rewritable CDs can be formatted, stored or destroyed. Non-rewritable CDs can either be stored or
destroyed.
If you have any questions, contact the Tektronix Technical Support Center at 1-800-833-9200*3.

Logic Analyzer Technical Report
2
MEMORY PARTS – TLA714
039-0047-01 – Controller Board (made by the Radisys Corp.)
Part Number Reference
designator Description Qty
E28F400B5-T80
TSOP48 U53 IC, BIOS 1
64KX32100TQFP U15 IC, Cache 1
156-8389-00 U5 IC, SODIMM, DRAM, 64 MB (made by Micron
Technology, Inc.) 1 standard
156-4858-00 U5 IC, SODIMM, DRAM, 128 MB (made by Micron
Technology, Inc.) 1 optional
156-8389-00 U6 IC, SODIMM, DRAM, 64 MB (made by Micron
Technology, Inc.) 1 optional
156-4858-00 U6 IC, SODIMM, DRAM, 128 MB (made by Micron
Technology, Inc.) 1 optional
671-3487-01 – Front Panel Board
Part Number Reference
designator Description Qty
156-6990-00 U201
U202 IC, Processor; CMOS, 8-BIT, 15K EPROM, 352 Bytes RAM, 576 Bytes ROM 2
Hard Disk Drive(s)
Part Number Reference
designator Description Qty
119-6493-00 Hard Disk Drive Hard Disk Drive, Winchester, 2.5 in, 10 GB,
Single Platter 1 standard
119-6494-01 Hard Disk Drive Hard Disk Drive, Winchester, 2.5 in, 30 GB,
Single Platter 1 optional

Logic Analyzer Technical Report
3
MEMORY PARTS – TLA715
039-0114-04 – Controller Board (made by the Radisys Corp.)
Part Number Reference
designator Description Qty
Intel 82802
Firmware Hub U40 IC, BIOS 1
156-4857-00 SODIMM#1
SODIMM#2 SODIMM, DRAM, 256 MB (made by Micron Technology, Inc.) 1 standard 1 optional
671-5344-00 – Front Panel Board
Part Number Reference
designator Description Qty
156-6990-00 U201
U202 IC, Processor; CMOS, 8-BIT, 15K EPROM, 352 Bytes RAM, 576 Bytes ROM 2
Hard Disk Drive(s)
Part Number Reference
designator Description Qty
119-6833-00 Hard Disk Drive Hard Disk Drive, UDMA100, 2.5 in, 20 GB,
Single Platter, Removable 1 standard
119-6751-00 Hard Disk Drive Hard Disk Drive, UDMA100,, 2.5 in, 60 GB, Internal 1 optional

Logic Analyzer Technical Report
4
MEMORY PARTS – TLA720, TLA721
671-3982-02 – Enhanced Monitor Board
Part Number Reference
designator Description Qty
160-9691-01 U24 IC, Memory, CMOS, EPROM, 64K X 16 1
156-6421-01 U29 U31 U32 U34 IC, Memory, CMOS, DRAM, 1MEG X 4 4
156-6461-01 U22 U24 U25 IC, Memory, CMOS, Flash, 256K X 8 3
156-4522-00 U44 IC, Memory, CMOS, PROM, 212K X 1 1
156-6510-01 U1 IC, Memory, CMOS, EPROM, 1K X 8, Serial 1
MEMORY PARTS – TLA720
039-0048-02 – Controller Board (made by the Radisys Corp.)
Part Number Reference
designator Description Qty
E28F400B5-T80
TSOP48 U53 IC, BIOS 1
64KX32100TQFP U15 IC, Cache 1
156-8389-00 U5 IC, SODIMM, DRAM, 64 MB (made by Micron
Technology, Inc.) 1
156-4858-00 U5 IC, SODIMM, DRAM, 128 MB (made by Micron
Technology, Inc.) 1 optional
156-8389-00 U6 IC, SODIMM, DRAM, 64 MB (made by Micron
Technology, Inc.) 1
156-4858-00 U6 IC, SODIMM, DRAM, 128 MB (made by Micron
Technology, Inc.) 1 optional
Hard Disk Drive(s)
Part Number Reference
designator Description Qty
119-6494-01 Hard Disk Drive Hard Disk Drive, Winchester, 2.5 in, 30 GB,
Single Platter 1 standard
119-6832-00 Hard Disk Drive Hard Disk Drive, Winchester, 2.5 in, 40 GB,
Single Platter 1 optional

Logic Analyzer Technical Report
5
MEMORY PARTS – TLA721
039-0015-04 – Controller Board (made by the Radisys Corp.)
Part Number Reference
designator Description Qty
Intel 82802
Firmware Hub U40 IC, BIOS 1
156-4857-00 SODIMM SODIMM, DRAM, 256 MB (made by Micron
Technology, Inc.) 2
Hard Disk Drive(s)
Part Number Reference
designator Description Qty
119-6751-00 Hard Disk Drive Hard Disk Drive, Winchester, 2.5 in, 60 GB,
Single Platter 1 standard
119-6751-00 Hard Disk Drive Hard Disk Drive, Winchester, 2.5 in, 60 GB,
Single Platter 1 optional
If you have any questions, contact the Tektronix Technical Support Center at 1-800-833-9200*3.
