TeleMann DTR5000N User manual

Hardware Description
Here, you will be given the explanation of the front and rear panel of DTR5000N. Each of
display, ports, connections will be specifically explained.
Front Panel Configuration
1LED DISPLAY
This shows the channel number or other information as follows :
During power is off, the dash ‘-‘ will be displayed at each digit, which
indicates that your DTR5000N is in stand-by mode. Immediately after your
decoder turns on, ‘C . . .’ will in turn light up at each digit, which means that
your DTR5000N is ready to operate.
If your DTR5000N locks a channel, its channel number will be displayed.
Whenever you change the channel, the number of the changed channel will be
displayed.
2REMOTE SENSOR
It receives the infrared signal from Remote Control and operates your
DTR5000N.
3

Smart Card and/or PCMCIA Card Slot (Option), or Not Used
These two slots can be used either for Conditional Access System with Smart
card, or Common Interface Module with PCMCIA card, or may not be used at

DTR5000N Hardware Description
all in case of free-to-air only according to the option configuration of the
DTR5000N.
When you want to watch Pay-per-view TV program or enjoy Internet service
on a usage basis, you should purchase a smart card or PCMCIA card from the
service provider and insert it into this slot. The detailed usage explanation will
come with the card that you purchased.
5CHANNEL DOWN
You can sequentially select the previous service by pressing this DOWN key.
6POWER This key allows you to turn your DTR5000N on or off.
7CHANNEL UP
You can use this key to select the next channel sequentially.
Rear Panel Configuration
1LNB IN Satellite antenna input terminal. The LNB power (14/18V) and the switching
signals (22KHz/DiSEqC) are also supplied to LNB through this terminal.
2LNB OUT
It is for connecting another STB to your DTR5000N. Connect this terminal to
LNB IN terminal of the other STB via RF cable.
3RS-232 serial port
An operator for customer services can use this port for the transmission of the
preprogrammed channel information from a PC to the DTR5000N. Or this port
can also be used for main board testing and software upgrading.
4SYSTEM monitor port
This connector is connected to PC and used ONLY for MAINTENANCE such
as software upgrading and After Service.
5LAN portIt should be connected to LAN via Ethernet cable in order to support data

DTR5000N Hardware Description
broadcast service and telnet monitor.
6VIDEO output terminal
Connect this terminal to video input terminal of TV or VCR.
7AUDIO L/R output terminals
Connect these terminals to audio L/R input terminals of TV, VCR, or Hi-Fi
audio system.
8S-VIDEO output terminal
This terminal is connected to S-VIDEO input terminal of TV or VCR to output
S-VIDEO signal.
9VCR SCART connector
Connect this connector to that of VCR via a SCART cable.
10 TV SCART connector
Connect this connector to that of TV via a SCART cable.
10 VCR SCART connector
Connect this connector to that of VCR via a SCART cable.
11 0/12V OUT
Connect this terminal to an external 0/12Volt switch box.
12 TV OUT
Connect this terminal to the input of TV or VCR via a coaxial cable.
13 ANT IN
Connect this terminal to a terrestrial UHF antenna via coaxial cable.
14 POWER INPUT
Connect the power cord of AC85V to 265V, 50/60Hz
15 GROUND
How to Connect Your DTR5000N to Various Systems
As shown in the figure below, you can connect your DTR5000N to a TV set, a VCR
and a Hi Fi system. Consult your local supplier for assistance in setting-up your
system best suited to your requirements.
CAUTION !
Please DO NOT plug in the main power supply cord until you have
finished all other connection!

DTR5000N Hardware Description
Connection of your DTR5000N to a TV set
Connect your DTR5000N to a TV set with SCART.
Connection of your DTR5000N to a VCR
Connect the SCART connector of VCR to that on your DTR5000N.
Connection of your DTR5000N to a Hi Fi system
Connect a RCA/Cinch stereo cable from the AUDIO L/R terminals on your
DTR5000N to the LINE, AUX, SPARE or EXTRA input terminals on your Hi Fi
system.
