Teletek electronics TFT Assembly instructions

Attention:
This manual contains information on limitations regarding product use and
function and information on the limitations as to liability of the manufacturer.
The entire manual should be carefully read.
The information in this manual is a subject to change without notice!
ver. 1.0.8
IRIS/SIMPO
Repeater
Addressable Fire Alarm Repeater Panel
Model: TFT
Installation &
Programming Manual

IRIS/SIMPO Repeater TFT - Addressable Fire Alarm Repeater Panel –Installation & Programming Manual
2
Table of Contents
1. INTRODUCTION........................................................................................................................................................ 4
1.1. General Description ................................................................................................................................... 4
1.2. General Specifications............................................................................................................................... 4
1.3. Technical Specifications ............................................................................................................................ 4
1.4. Functional Features ................................................................................................................................... 4
2. INSTALLATION.......................................................................................................................................................... 5
2.1. Wall Mounting ............................................................................................................................................ 5
2.2. Initial Power-up .......................................................................................................................................... 7
2.3. Sound Signalization ................................................................................................................................... 7
3. ELECTRICAL CONNECTIONS ................................................................................................................................. 7
3.1. PCB Elements............................................................................................................................................ 7
3.2. Main Power Supply.................................................................................................................................... 8
3.3. Redundant Network RS485 ....................................................................................................................... 8
3.4. LAN Network.............................................................................................................................................. 9
3.5. Hardware Restore Defaults........................................................................................................................ 9
4. INSTALLER PROGRAMMING MENUS .................................................................................................................... 10
4.1. Common Information.................................................................................................................................. 10
4.1.1. Functional Buttons for Operation ............................................................................................................ 10
4.1.2. General Information for Text Introducing................................................................................................ 10
4.1.3. General Information for Digits Introducing.............................................................................................. 11
4.1.4. Quick Logging Out of the Installer Programming Menus........................................................................ 11
4.2. Programming Menus.................................................................................................................................. 12
4.2.1. Panel Settings............................................................................................................................ 12
4.2.1.1. Setting Access Codes and Levels for Operation....................................................... 12
4.2.1.2. Setting of Network Parameters.................................................................................. 14
4.2.1.2.1 Network Settings......................................................................................... 14
4.2.1.2.2. Panels........................................................................................................ 15
4.2.1.3. Disable the Internal Buzzer........................................................................................ 17
4.2.1.4. Changing the Language............................................................................................. 17
4.2.1.5. “Screen-Saver” – Company Logo Setting.................................................................. 17
4.2.2. Restore Defaults ........................................................................................................................ 18
4.2.3. Save the Configuration .............................................................................................................. 18
4.3. Maintenance Menus................................................................................................................................... 18
4.3.1. Setting Time............................................................................................................................... 19
4.3.2. Setting Date ............................................................................................................................... 19
4.3.3. Setting the Display..................................................................................................................... 19
4.3.3.1. Coordinates Calibration ............................................................................................. 20
4.3.3.2. Colors Review............................................................................................................ 21
4.3.3.3. Setting the Screen Backlight...................................................................................... 21
4.3.4. Software Revision and Firmware Update .................................................................................. 21
4.3.5. Review the Log Memory for Events........................................................................................... 22
4.3.6. Clear the Log Memory for Events .............................................................................................. 23
APPENDIX А.................................................................................................................................................................. 23
APPENDIX B.................................................................................................................................................................. 26

IRIS/SIMPO Repeater TFT - Addressable Fire Alarm Repeater Panel –Installation & Programming Manual
3
GUARANTEE
The guarantee terms are determined by the serial number (barcode) of the electronic device!
During the guarantee period the manufacturer shall, at its sole discretion, replace or repair any defective product when it is returned to the factory. All
parts replaced and/or repaired shall be covered for the remainder of the original guarantee, or 6 months, whichever period is longer. The original
purchaser shall immediately send manufacturer a written notice of the defective parts or workmanship.
INTERNATIONAL GUARANTEE
Foreign customers shall possess the same guarantee rights as those any customer in Bulgaria, except that manufacturer shall not be liable for any
related customs duties, taxes or VAT, which may be payable.
GUARANTEE PROCEDURE
The guarantee will be granted when the appliance in question is returned. The guarantee period and the period for repair are determined in advance.
The manufacturer shall not accept any product, of which no prior notice has been received via the RAN form at: http://teletek-electronics.com/en/ran-
form
The setup and programming included in the technical documentation shall not be regarded as defects. Teletek Electronics bears no responsibility for
the loss of programming information in the device being serviced.
CONDITIONS FOR WAIVING THE GUARANTEE
This guarantee shall apply to defects in products resulting only from improper materials or workmanship, related to its normal use. It shall not cover:
•Devices with destroyed serial number (barcode);
•Damages resulting from improper transportation and handling;
•Damages caused by natural calamities, such as fire, floods, storms, earthquakes or lightning;
•Damages caused by incorrect voltage, accidental breakage or water; beyond the control of the manufacturer;
•Damages caused by unauthorized system incorporation, changes, modifications or surrounding objects;
•Damages caused by peripheral appliances unless such peripheral appliances have been supplied by the manufacturer;
•Defects caused by inappropriate surrounding of installed products;
•Damages caused by failure to use the product for its normal purpose;
•Damages caused by improper maintenance;
•Damages resulting from any other cause, bad maintenance or product misuse.
In the case of a reasonable number of unsuccessful attempts to repair the product, covered by this guarantee, the manufacturer’s liability shall be
limited to the replacement of the product as sole compensation for breach of the guarantee. Under no circumstances shall the manufacturer be liable
for any special, accidental or consequential damages, on the grounds of breach of guarantee, breach of agreement, negligence, or any other legal
notion.
WAIVER
This Guarantee shall contain the entire guarantee and shall be prevailing over any and all other guarantees, explicit or implicit (including any implicit
guarantees on behalf of the dealer, or adaptability to specific purposes), and over any other responsibilities or liabilities on behalf of the manufacturer.
The manufacturer does neither agree, nor empower, any person, acting on his own behalf, to modify, service or alter this Guarantee, nor to replace it
with another guarantee, or another liability with regard to this product.
UNWARRANTED SERVICES
The manufacturer shall repair or replace unwarranted products, which have been returned to its factory, at its sole discretion under the conditions
below. The manufacturer shall accept no products for which no prior notice has been received via the RAN form at: http://teletek-
electronics.com/en/ran-form.
The products, which the manufacturer deems repairable, will be repaired and returned. The manufacturer has prepared a price list and those
products, which can be repaired, shall be paid for by the Customer. The devices with unwarranted services carry 6 months guarantee for the replaced
parts.
The closest equivalent product, available at the time, shall replace the products, the manufacturer deems un-repairable. The current market price shall
be charged for every replaced product.
STANDARDS AND CONFORMITY
Conforms and approved in accordance with CPR (Construction Products Regulation).
DOCUMENTATION FEEDBACK
If you have any comments or suggestions on our products’ manuals or installation instructions you can email us on: [e-mail]
Your feedback on product documentation will help us to improve the contents of our manuals and stickers and keep them up-to-date.
Please, include in your feedback email the product name, the revision of the manual or instruction (8-digit number with Revision and date of issue)
and the page number.
21
1293
DoP No: 138
Teletek Electronics JSC
Bulgaria, Sofia 1407, 14А Srebarna Str., Tel.: [phone], Fax: [phone]
e-mail: [e-mail]
IRIS/SIMPO Repeater
Intended for use in fire detection and fire alarm systems in and around buildings.

IRIS/SIMPO Repeater TFT - Addressable Fire Alarm Repeater Panel –Installation & Programming Manual
4
1. INTRODUCTION
1.1. General Description
IRIS/SIMPO Repeater TFT is a control panel for remote indication of fire alarm, fault, trouble, warning and other type of
events, reported from iRIS8, SIMPO and other Repeater panels connected into one common network. The IRIS/SIMPO
Repeater can operate only as a part of a network. It repeats the status of the connected fire panels and informs for
events.
Up to 64 panels can operate in a single network, including IRIS/SIMPO Repeater, iRIS8 and SIMPO fire alarm panels.
The connection in the network between the panels can be realised via LAN or RS232 communication protocol. Only one
type of connection can be used in a single network.
1.2. General Specifications
The front panel of Repeater TFT has a color graphic LCD touch screen display (800/480 TFT) performing user-friendly
operation with menus. Separate user, maintenance and installer passwords provide access to the functions of the
panel. The panel has a built-in real time clock and calendar, supported with built-in battery in case of main and backup
power supply failure.
Events like FIRE, RESET, FAULTS, etc., including for the rest of the panels in the network, are saved in the memory,
thereby creating an event log-file. It contains the time and date, the fire panel number, the address of the device, the
type (module, detector, sounder or periphery device), the name of the device, the zone, the name of the zone, etc.
1.3. Technical Specifications
•Main Power Supply*...................................................24±4V DC
•Frequency ..................................................................50/60Hz
•Maximal Consumption................................................0.4A
•Cross Section of the Connection Wires .....................0.5-2.5mm2
•Maximum distance between two panels ....................up to 1000m
•Operating Temperature..............................................from -5°C to +50°C
•Relative Humidity Resistance ....................................up to 95% (without condense)
•Dimensions.................................................................200x330x48mm
•Weight........................................................................0.90kg
* Note: 24V DC External power supply with backup batteries. It is possible to power on the Repeater panel from an
addressable Fire alarm panel (AUX output of iRIS8 or SIMPO panel), but this is not recommended for big system
configurations.
Attention: The earth connection has to be realized in accordance with the rules for the electrical safety with the total
resistance in the circuit lower than 10Ω. It is mandatory to connect the earth connector of the main power supply cable
to the middle input of the Repeater panel terminal and check the connection to be tight and stable - see item 3.2.
1.4. Functional Features
•Operation in a common network with iRIS8, SIMPO and other Repeater panels.
•TTE Communication Protocol
•Up to 64 panels in a redundant network.
•Ring or Line network type topology
•RS485 interface
•LAN interface
•Micro USB port for software and firmware update
•Memory log for 10000 events
•TFT color screen touch display
•Multilanguage support of the menus
•Built-in battery supporting real-time clock and date in case of main and backup power supply failure
•Built-in buzzer for sound indication of events

IRIS/SIMPO Repeater TFT - Addressable Fire Alarm Repeater Panel –Installation & Programming Manual
5
2. INSTALLATION
Attention:
Do not install the Repeater panel near power electromagnetic fields (radio equipment, electric motors, etc.)!
The panel should be installed by qualified specialists only.
The electronic components of the panel are vulnerable to electrostatic discharge.
2.1. Wall Mounting
•The Repeater panel must be installed in a clean dry place and must not be subjected
to impacts or vibrations. It must be situated far from heating appliances. The
temperature must be within -5ºСand +50ºC.
The recommended mounting height is 1500 –1600 mm up from the floor surface.
The TFT screen must be well visible from the users and situated approximately at eye
level.
Leave enough space from all wall corners, at least 300 mm. The right side of the
Repeater must be free for access because of the micro USB for software and firmware
updates.
Attention: The Repeater panel is not water-proof!
• The main elements of the enclosure box are presented in Figure 2.
Figure 2
1–TFT color touch screen.
2–Front cover.
3–Left and Right side covers.
4–Clips on the box bottom holding the side covers.
• The left and right side covers, are mounted to the box bottom via clips. To remove the side covers, press the clip at the
box bottom (1) and pull the cover upward (2) –Figure 3.
Figure 3
Figure 1

IRIS/SIMPO Repeater TFT - Addressable Fire Alarm Repeater Panel –Installation & Programming Manual
6
• The left and right side covers, are specific and cannot be exchanged with one another. The covers have marks at the
back side, showing the position (left or right) for mounting.
To proceed with wall mounting, the installer must remove the front cover from the bottom –Figure 4.
1–Left side cover. It has a mark “1” at the back side.
2–Right side cover. It has a mark “2” at the back side.
3–Use a crossed slot screwdriver to undo the screws
holding the front cover to the box bottom.
Attention: Be careful not to damage the TFT touch
screen while dismounting the front cover!
Figure 4
• For running the cables for main power supply and network connection, make appropriate holes at the box bottom
being careful not to damage the PCB and TFT screen of the Repeater panel.
• Mount the box bottom at the installation place using appropriate fixtures according the mounting surface. Note that, not
all of the mounting holes at the box bottom are available for use. Lever horizontally the box, before tighten the screws.
Attention: Do not remove the PCB from the box bottom!
Figure 5
• Run the cables and make the network and electrical connections, BUT DO NOT power on the panel on this step.
• Place the front cover back and tighten the screws.
• Mount the Left and Right side covers to the box bottom as observe their correct place –look for the marks at the back
side –Figure 6. Press the side cover downwards until a click is heard.
Figure 6

IRIS/SIMPO Repeater TFT - Addressable Fire Alarm Repeater Panel –Installation & Programming Manual
7
2.2. Initial Power-up
When turned on, the Repeater panel always conducts a procedure of loading the parameters, which usually takes about
30 sec. A long sound signal is heard. There is no access to the menus of the Repeater panel during that procedure.
Access Level 1 is loaded. Upon the initial start-up, the Repeater does not hold any configurations.
Next, the installer has to perform settings for the network and the parameters of the Repeater as described at item 4.
2.3. Sound Signalization
The IRIS/SIMPO Repeater panel is equipped with internal buzzer for sound signalization in case of events.
Signalization
Description
Button
Single short beep indicating the pressing of a button.
Reset or Event
Single long beep indicating reset of the Repeater or receiving of message for Disable, Test or
Warning event.
Technical trouble
Short beeps in case of receiving of messages for Fault event (for the Repeater itself or for other fire
alarm panels in the network). The beeps can be stopped from Access Level 2 and 3 after
performing Silencing Buzzer from the Main Screen menu.
The beeps will stop when the technical trouble is restored and the fault event is cleared
automatically from the Faults list.
Fire Alarm
Continuous sound signal for activated Fire Alarm from zone or Evacuation. The sound can be
stopped from Access Level 2 and 3 after performing Silencing Buzzer from the Main Screen menu.
3. ELECTRICAL CONNECTIONS
3.1. PCB Elements
Attention: Do not remove the PCB from the box bottom!
Figure 7
1–Main power supply terminal. See item 3.2.
2–RS485 interface. Used for realizing network with other panels via RS485 communication
protocol. See item 3.3.
3 –LED Indication for the status of the network via RS485 interface. See item 3.3.
4 –LAN interface connector. See item 3.4.
5 –Micro USB port for software and firmware update. See also item 4.3.4.
6 –Jumper for hardware restore defaults. See item 3.5.
7 –Built-in 3V backup battery for the real-time clock and jumper BTR for battery activation. The
jumper BTR is factory set and must not be removed.
8 –Built-in sound buzzer (on the back side of the PCB).
TFT Touch Screen

IRIS/SIMPO Repeater TFT - Addressable Fire Alarm Repeater Panel –Installation & Programming Manual
8
3.2. Main Power Supply
Connect the external power supply unit 24V DC as observe the polarity of the connection. It is recommended to use
power supply unit with backup batteries to guarantee the operation of the Repeater in case of mains power supply
failure.
3.3. Redundant Network RS485
The Repeater panel is designed with option for connection in a redundant network with other SIMPO, iRIS8 and
Repeater panels (up to 64). The redundant network is based on RS485 interface.
The RS485 interface is built-in the Repeater panel. For operation in a common redundant network with other fire panels
they must be equipped with Redundant Network Module –Figure 8. The Redundant network module is connected to
“NETWORK” interface connector on the fire panel PCB (interface module in iRIS8).
Note: The RS485 interface terminals are accessible after removing the left side cover of the enclosure box.
Figure 8
The following table represents the correspondence of Tx/Rx terminal connections for IN and OUT communication lines.
Observe the polarity of
the RS485 interface
connection!
Repeater TFT
IN
OUT
Tx
Rx
Tx
Rx
+
-
+
-
+
-
+
-
Redundant
Network
Module
IN
Rx
-
+
Tx
-
+
OUT
Rx
+
-
Tx
+
-
In installer’s menu (Access Level 3) enter SYSTEM –PROGRAMMING –PANEL –NETWORK –NETWORK
SETTINGS, and set option “RS485” for Network type –see item 4.2.1.2.1.
Fire Panel
iRIS8/
SIMPO
Redundant
Network
Module
Repeater
TFT
Indication
LEDs
Indication
LEDs
External power
supply unit
The LED indication for RS485 interface in both
Repeater and Redundant module has same meaning:
•OUT - Output communication
•Central Commun. - Panel-Module
communication
•IN - Input communication
In normal operation mode the LEDs are blinking.
In case of trouble with the communication line the
LES are lighting on.

IRIS/SIMPO Repeater TFT - Addressable Fire Alarm Repeater Panel –Installation & Programming Manual
9
The maximum cable length between two network modules and/ or repeater panel is 1000m.
Figure 9
Up to 64 panels can be connected in a common redundant network.
Figure 10
3.4. LAN Network
The realization of LAN network is possible only for Repeaters and other iRIS8 addressable fire alarm panels (up to 64).
The LAN connection can be direct panel-to-panel or by means of a HUB via TCP/IP protocol.
Note: The LAN connector is accessible after removing the left and right side covers and the front panel of the enclosure
box –see item 2.1 and Figures 4 and 5.
In installer’s menu (Access Level 3) enter SYSTEM – PROGRAMMING –PANEL –NETWORK –NETWORK
SETTINGS, and set for Network type option “LAN” –see item 4.2.1.2.1.
3.5. Hardware Restore Defaults
This is an option for restoring the factory set parameters of the Repeater panel.
It is recommended, before making a Restore Defaults of the Repeater, to save its current system configuration
as TDF file using ProsTE specialized programming software. After hardware resetting, load the TDF back to the
Repeater and save time for introduce settings in menus. For details about ProsTE specialized programming software
ask your local distributer of the equipment.
To perform hardware, restore defaults do as follows:
1. Turn off the main and backup power supply of the Repeater panel.
2. Remove the right side cover as shown on Figure 3.
3. Put a jumper on Restore Defaults terminals on the PCB of the Repeater –Figure 7, position 6.
4. Turn on the main and backup power supply of the Repeater. A long sound signal is heard. The screen enters into
procedure for hardware calibration of the display. Perform the calibration as follow the detailed description how to do
that in item 4.3.3.1 .
5. Remove the Restore Defaults jumper.
6. Close the right side cover of the enclosure box.
Maximum 64 panels
iRIS8 Fire panel
SIMPO Fire panel
Repeater TFT
Redundant network
Module 1
Redundant network
Module 2
iRIS8 Fire panel
iRIS8 Fire panel
SIMPO
Fire panel
Repeater TFT
Power
supply
24V DC
Redundant
Module
Redundant
Module
Redundant
Module

IRIS/SIMPO Repeater TFT - Addressable Fire Alarm Repeater Panel –Installation & Programming Manual
10
4. INSTALLER PROGRAMMING MENUS
4.1. Common Information
At Access Level 3 the Installer has full rights for entire programming of the Repeater.
To enter the Installer Programming menus, press ACCESS button from the Main Screen and introduce the code for
Access Level 3 –3333 is the default factory set combination.
Press ACCESS button to change the Access Level.
Enter code for Access Level 3 entry (3333 –by default)
and confirm with OK button.
4.1.1. Functional Buttons for Operation
Button
Description
Confirmation and saving of the entered parameters.
Step back in programming menus. Cancelling the introduced changes.
Enter in additional submenu.
Quick button for exit the programming menus and returning back to Main Screen.
4.1.2. General Information for Text Introducing
The text introducing is via virtual keyboard, presenting access to different type of letters, symbols and numbers. The
virtual keyboard is shown on the screen after pressing an active text field. Up to 40 symbols, including space intervals,
can be entered for a name or other description in the system.
After pressing an active text field in a menu, the screen displays the virtual keyboard.
Latin Letters screen keyboard.
Use the special buttons to switch to different type of letters
or symbols. After entering the text and confirming with
ENTER button you must also save the text with APPLY
button on the respective programming menu.
Press EXIT to reject the entered text and go back to
programming menus.
- Switch to Cyrillic Letters
- Switch to Latin Letters
- Switch to Special Letters
- Switch to Symbols
- Switch to Digits
- Switch between Capital and Small Letters
- Enter (confirmation) button.
- Backspace (delete) button.

IRIS/SIMPO Repeater TFT - Addressable Fire Alarm Repeater Panel –Installation & Programming Manual
11
The following screens present the different type letters/symbols accessible in Repeater panel.
Cyrillic Letters screen keyboard.
Special Letters screen keyboard.
Symbols screen keyboard.
Digits screen keyboard.
Note: Use the special buttons “LAT”, “SYM”, “SPE” or
“CYR” to swich back to letters/symbols introducing
screen. Use OK button to confirm the entered text and
go back to the programming menu.
4.1.3. General Information for Digits Introducing
The digits introducing is via virtual keyboard. After pressing an active field for introducing digits in a menu, the screen
displays the virtual digit keyboard.
- Enter (confirmation) button.
- Backspace (delete) button.
Use EXIT button for step back and rejecting the entered
values. If the entered value is out of the range of the set
parameter, it will be cleared automatically after pressing
OK button.
4.1.4. Quick Logging Out of the Installer Programming Menus
With the quick logging out, the Installer can change the Access Levels 3 to the lower User Level 1 without need of
entering a code combination.
Press ACCESS button for changing the user Level.
Press LOG OUT button for quick logging out.
Access Level 1 is set for operation.

IRIS/SIMPO Repeater TFT - Addressable Fire Alarm Repeater Panel –Installation & Programming Manual
12
4.2. Programming Menus
To enter the Programming menus, press SYSTEM ( ) button from Main Screen:
Press PROGRAMMING menu button. The following menus are available for settings.
Quick summery for the submenus:
- Setting Repeater Panel parameters
- Restore to factory default settings
- Save the Repeater system configuration
4.2.1. Panel Settings
In the PANEL submenu, the Installer sets a list with the most important parameters for the operation of the Repeater
panel.
Press PANEL menu button.
Quick summery for the submenus:
- Access Codes for Users and Levels
- Network settings for the Repeater
- Disable/Enable the internal buzzer
- Change the Language
- Set Company Information (Screen Saver)
4.2.1.1. Setting Access Codes and Levels for Operation
There are three access levels for control in Repeater panel with different functionalities and rights for operation. Four
access codes can be set with different access level for users.
The default code combinations (factory set) with set access levels are presented in the following table.
Access
Level
Description
Factory
Code
Access and Functionalities
1
User
0000
1111
Only Silence buzzer and Evacuate* buttons are active. It is not allowed to enter
Maintenance and Programming access levels.
* Just for those cases, when there is active fire alarm signal, received from a loop device.
2
Maintenance
2222
Silence buzzer, Silence sounders, Reset and Evacuate buttons are active.
Maintenance access level entry, which allows partial programming and menu
settings.
3
Installer
3333
Silence buzzer, Silence sounders, Reset and Evacuate buttons are active.
Installer access level entry, which allows full programming and settings.

IRIS/SIMPO Repeater TFT - Addressable Fire Alarm Repeater Panel –Installation & Programming Manual
13
Enter SYSTEM - PROGRAMMING –PANEL –ACCESS CODES menu.
Fields description:
•Access Code Number –Use the left/right buttons to
change the code number. Up to 4 code numbers are
available for operation.
•Access Code –Active button for changing the set
code combination.
•Access Code Level –Active button for changing the
access level of the set code number.
To change the code combination, press the active digit button next to ACCESS CODE field.
Enter new 4-digits code combination into the text field.
Press OK.
Enter again the same code to verify it. Press OK.
The following messages inform for errors during verifying
the access code:
“Wrong Code” –The second entered code combination
does not much with the first one.
“Text” –Less than 4 digits are entered in the field.
In case the new code is valid and correctly verified, the
Repeater returns to ACCESS CODE menu showing the
new code set into the Access Code active digits button.
Press APPLY button to save the change.
To change the Access Level, press the active digit button next to ACCESS CODE LEVEL field. Every pressing of the
button increases the number in the field. The Access Levels are described in the table above.
Attention: There must be at least one code in the system with an access code level 3! It is not allowed to
edit a level of access (3) if it is the only one!
Press APPLY button to save all introduced changes.
Auto Log Off –Option for automatic logging out from the
current set Access Level 2 or 3 after a time period and no
operation with the Repeater. If the automatic log out is
enabled, the Repeater will log out to Access Level 1 when
the programmed time is over.
The option is Disabled by default. Every pressing of
Disabled/Enabled button changes the setting.
The time period is set in minutes from 1 to 60 (30 minutes
by default). To change it, press the active digits button
and enter new time period - see item 4.1.3.

IRIS/SIMPO Repeater TFT - Addressable Fire Alarm Repeater Panel –Installation & Programming Manual
14
4.2.1.2. Setting of Network Parameters
Enter SYSTEM - PROGRAMMING –PANEL –NETWORK menu.
Quick summery for the submenus:
•Network Settings –Menu for setting the parameters
for connection between the Repeater and other panels
in the network.
•Panels –Menu for review information about the type,
name, status of all panels in the network. Setting the
options for Receiving/Sending commands from/to other
panels.
4.2.1.2.1 Network Settings
Enter NETWORK SETTING submenu. The settings are distributed in two separate screens.
Press MORE button to move to the next screen.
Press APPLY button to save all introduced changes.
Press APPLY button to save all introduced changes.
Press EXIT button to move back to previous screen.
Fields description and available settings at Network Settings submenu:
Name
Enter the name of the Repeater panel - up to 40 digits. Refer to item 4.1.2 for details about
text introducing.
Port
TCP/IP port for communication between the panels in the network. The port number must
be set one and the same for all connected panels. In case of changing the port number,
the Repeater panel must be reset from the main screen.
Panel Number
Unique Repeater panel number (1-64) in the network is introduced. By this number the
panels can “recognize” each other.
Network Status
Set the status of using the panel in the network. Every pressing of the button changes the
status Enabled/Disabled. When the status is Disabled, the Repeater is disconnected from
the network and is not visible for the rest of the panels. A fault message “Panel Fault” for
the disabled panel is displayed from the other panels in the network.
Network Type
Set the network type according the used connection between the panels: LAN (in case of
LAN interface network connection is used –see item 3.4) or RS485 (in case of using
Redundant Network interface module –see item 3.3).
Attention: Only one network type must be used for the entire network!
Protocol
Choose the communication protocol type according used BMS system software - Modbus
RTU over TCP/IP or Modbus TCP/IP.
Panel IP Address
Set the IP address of the Repeater according the realized local Ethernet network.
Netmask
Set the Netmask.
Router
Set the Router IP address.
Panel MAC Address
Review of the unique MAC address of the Repeater.
Redundancy
Option for ignoring a fault message for broken connection in the redundant network. Every
pressing of the button changes the status OFF/ON. Set ON if you want to monitor the
continuity of the redundant network. Set OFF to disable the monitoring.

IRIS/SIMPO Repeater TFT - Addressable Fire Alarm Repeater Panel –Installation & Programming Manual
15
4.2.1.2.2. Panels
After Enabling the Network, every panel starts looking for other panels in the network. If a new panel is found in the
system it is added to the panels list with the number set into its Network Settings. The panels are displayed also with
unique name (is set), IP address and current status in the network. All new found panels must be added to Repeater
configuration.
Enter PANELS submenu. The settings are distributed in two separate screens.
Press MORE button to move to the next screen for
receiving messages and repeating status of the outputs.
Press APPLY button to save all introduced changes.
These are the settings for receiving messages from other
panels and repeating their current status in the network.
Press EXIT button to move back to previous screen.
Fields description and available settings at Panels submenu:
Panel Number
Use the left/right arrow buttons to scroll the numbers of available panels connected to the
network. You can also enter the number directly pressing the active digit button and use
the virtual digits keyboard. Up to 64 panels can be connected in a common network.
Panel Name
In the field is displayed the set name for the panel.
Panel IP Address
Review of the IP address of the panel.
Panel Status
Active button for operation with functionality
according the current status:
ADD –New panel is found. Press the
button to add it to the configuration.
DELETE –Remove present or fault panel
from the configuration.
FIX –Active, when a change in the network
settings for the current panel is applied.
Press the button for quick correction and
fixing the new settings.
Current status field:
NEW PANEL –The panel is new for the
configuration. Press ADD button to confirm.
PRESENT –The panel is in normal
operation mode.
FAULT –Fault mode, problem with
connection in the network.
THIS –This is the current panel from which
the other panels are reviewed.
NONE –No found/set panel at this number.
Receive Commands
Option for enabling receiving of control commands (Evacuate, Reset, Silence Alarm and
Silence Buzzer) from other panels in the network. Every pressing of the button changes
the status Enabled/Disabled. By default, the option is Disabled.
Send Commands
Option for enabling sending of control commands (Evacuate, Reset, Silence Alarm and
Silence Buzzer) to other panels in the network. Every pressing of the button changes the
status Enabled/Disabled. By default, the option is Disabled.
Receive Messages
Option for enabling receiving messages for events from other panels in the network. Every
pressing of the button changes the status Enabled/Disabled. The button is used for global
enabling the settings for Repeating the operation of the outputs of connected fire panels.
By default, the option is Disabled.
Repeat Sounder*
Option for enabling the repeating Sounder output status of the remote panels including the
delays. By default, the option is Disabled.
Repeat Fire Brigade*
Option for enabling the repeating Fire Brigade output status of the remote panels including
the delays. By default, the option is Disabled.
Repeat Fire Protection*
Option for enabling the repeating Fire Protection output status of the remote panels
including the delays. By default, the option is Disabled.
Repeat Fault Output*
Option for enabling the repeating Fault output status of the remote panels including the
delays. By default, the option is Disabled.
* Note: The options are available for setting only when the Receiving Messages option is Enabled. In case of alarm,
fault or disable type event, the Repeater will display on its screen the current status of the outputs of connected fire
alarm panel(s).

IRIS/SIMPO Repeater TFT - Addressable Fire Alarm Repeater Panel –Installation & Programming Manual
16
Examples for settings in PANELS submenu.
The receiving of messages for events is Enabled. The
options for repeating the outputs status are available for
further settings. Every pressing of the button will change
the status Enabled/Disabled.
Press APPLY button to save all introduced changes.
The receiving of messages for events is Disabled. The
options for repeating the outputs status are unavailable
for settings. Even if there are options set as Enabled, they
will be inactive and the panel will not repeat the status of
any of the outputs.
Press EXIT button to move back to previous screen.
Examples for status in PANELS submenu.
New panel number is found in the network configuration.
Press ADD button. The status will change to PRESENT. If
there is set name for this panel it will be displayed into the
text field. Next step is to Enable the “Receiving” and
“Sending” control commands to other panels. Confirm with
APPLY button to save the settings.
The screen displays the information for the Repeater
panel –status THIS. No other settings for
Receiving/Sending commands or messages are
available. Remember, the Receiving/Sending commands
and messages for events for the Repeater itself can be
done only via the other connected panels in the network.
IMPORTANT NOTES!
The main purpose of the Repeater panel is presenting remote indication of fire alarm, fault, trouble, warning and other
type of events, reported from other fire alarm panels (IRIS and SIMPO series) or repeater panels connected into one
common network.
In case of making software or hardware Restore Defaults, the Repeater will restore the factory default settings,
including the Network Settings:
•The Panel Number of the Repeater at Network Settings submenu is set by default as 1 - the installer must set
the real number of the Repeater in the network before enabling it –see item 4.2.1.2.1.
•All connected panels will be recognised as NEW and must be added manually one-by-one in the PANELS
submenu of the Repeater.
•The options for Receiving/Sending control commands and receiving/repeating of messages for events are
Disabled –the installer must enable all of them to restore the reporting from the other panels in the network
and the remote indication in case of events –see item 4.2.1.2.2.
•The Repeater panel must be deleted from the rest panels in the network and ADDED again after all settings
are completed.
It is recommended, before making a Restore Defaults of the Repeater, to save its current system configuration
as TDF file using ProsTE specialized programming software. After software or hardware resetting, load the TDF
back to the Repeater and save time for introduce settings in menus. For details about ProsTE specialized programming
software ask your local distributer of the equipment.

IRIS/SIMPO Repeater TFT - Addressable Fire Alarm Repeater Panel –Installation & Programming Manual
17
4.2.1.3. Disable the Internal Buzzer
This a submenu to enabling/disabling the internal buzzer of the Repeater.
Enter SYSTEM - PROGRAMMING –PANEL - DISABLE menu.
By default, the internal buzzer is Enabled.
Single press the button to change the state from Enabled
to Disabled. Confirm the new setting pressing the APPLY
button on the top of the screen.
To return to Programming Menus, press EXIT button.
Note: The Enabled state of the internal buzzer will be restored to Disabled every time after switching off the mains
power supply of the Repeater.
4.2.1.4. Changing the Language
The Repeater panel supports operation in different languages. By default, it is set English language for the menus.
Changing the language is quick without need of confirmation.
Enter SYSTEM - PROGRAMMING –PANEL –LANGUAGE menu.
Find your language in the list and just press its button.
The language of the Repeater menus will change
immediately and the Repeater will return in Main screen
automatically.
Note: The Language setting is made just for the concrete
Repeater panel. It is possible operation of panels in
network set in different languages of the menus.
4.2.1.5. “Screen-Saver” – Company Logo Setting
This is an option for turning off the Main Screen and displaying some company information while the Repeater is in
normal operation mode. In case of missing active messages for events and there is no pressed button, the Repeater will
switch on to “Screen saver” with company information after 60 seconds.
Enter SYSTEM - PROGRAMMING –PANEL –COMPANY LOGO menu.
Four rows for introducing information are available.
Press the active text field to enter text using the virtual
keyboard –refer to item 4.1.2 for details about text
introducing.
Confirm the settings pressing the APPLY button on the
top of the screen.
Note: You must enter information into at least one row to
enable the “Screen Saver” with Company logo option.
To return to Programming Menus, press EXIT button.

IRIS/SIMPO Repeater TFT - Addressable Fire Alarm Repeater Panel –Installation & Programming Manual
18
4.2.2. Restore Defaults
In the RESTORE DEFAULTS menu, the Installer can reset the Repeater panel to the factory settings of all the menus.
The language of menus will restore in English. It is necessary to program also the Network and Panel settings to restore
the operation of the Repeater in the network. The memory log file will not reset or cleared, as all records will be saved.
It is recommended, before making a Restore Defaults of the Repeater, to save its current system configuration
as TDF file using ProsTE specialized programming software.
Enter SYSTEM - PROGRAMMING –RESTORE DEFAULTS menu.
Press YES button to restore to factory settings.
Press NO or EXIT button to cancel.
One started, the Restore Defaults process cannot be
stopped or canceled. When the process is completed, the
Repeater will return to Main Screen at Access Level 3.
4.2.3. Save the Configuration
In this menu the installer performs saving the set Repeater system configuration. The panel will ask for confirmation of
the action.
Enter SYSTEM - PROGRAMMING –SAVE menu.
Press YES button to save the configuration.
Press NO or EXIT button to cancel.
One started, the Save configuration process cannot be
stopped or canceled. When the process is completed, the
Repeater will return to Main Screen at Access Level 3.
4.3. Maintenance Menus
To enter the Maintenance menus, press SYSTEM ( ) button from Main Screen, and then press MAINTENANCE
menu button. The following menus are available for settings.

IRIS/SIMPO Repeater TFT - Addressable Fire Alarm Repeater Panel –Installation & Programming Manual
19
4.3.1. Setting Time
Enter SYSTEM –MAINTENANCE - TIME menu.
Use the up and down arrow buttons to set the time.
You can also directly enter the new settings using the
virtual digit keyboard after selecting the digit button for
hour/minutes –item 4.1.3.
Confirm the new set time with APPLY button.
The Repeater will change the time immediately without
need of resetting.
Use EXIT button to return back to Maintenance Menus.
4.3.2. Setting Date
Enter SYSTEM –MAINTENANCE - TIME menu.
Use the up and down arrow buttons to set the date.
You can also directly enter the new settings using the
virtual keyboard after selecting the digit button for
year/month/day –item 4.1.3. (Note: The months are
entered with numbers –1 for January, 2 for February, …
11 –November and 12 for December.)
Confirm the new set date with APPLY button.
The Repeater will change the date immediately without
need of resetting.
Use EXIT button to return back to Maintenance Menus.
4.3.3. Setting the Display
Enter SYSTEM –MAINTENANCE - DISPLAY menu. The following submenus are available for settings.
Quick summery for the submenus:
•Coordinates –Perform hardware calibration of the
TFT screen.
•Colors –Review the supported color palette of the
display.
•Power Save Backlight –Enable/Disable the backlight
of the screen.

IRIS/SIMPO Repeater TFT - Addressable Fire Alarm Repeater Panel –Installation & Programming Manual
20
4.3.3.1. Coordinates Calibration
It is possible that after a certain period of use, the parameters of the TFT screen display to change, causing difficulties
in pressing buttons, lower sensitivity, etc. This requires the display to be calibrated periodically. It is recommended to
use touch pen for precise calibration and to avoid damage and contamination of the sensitive TFT screen.
Do not use sharp instruments for pressing the screen, like screwdrivers, tweezers or pliers, because they can
scratch or break the plastic surface of the screen and the Repeater panel to become not operable!
Enter COORDINATES submenu. The calibration procedure requires selection (3 times) of some specific places on the
screen, following the displayed messages on the middle.
1. Press 3 times in sequence the blue dot in the upper left
corner of the screen. The message in the middle will
remand you how many times are left.
2. Press 3 times in sequence the blue dot in the upper
right corner of the screen. The message in the middle will
remand you how many times are left.
3. Press 3 times in sequence the blue dot in the bottom
right corner of the screen. The message in the middle will
remand you how many times are left.
4. Press 3 times in sequence the blue dot in the bottom
left corner of the screen. The message in the middle will
remand you how many times are left.
5. Message for succesful calibration is diplayed. Press the
screen anywhere to return to DISPLAY menu.
If the calibration is unsuccessful, it is announced with
message for failure. In that case is recommended to
perform the calibration again. Press the screen anywhere
to return to DISPLAY menu.
