LT910-WW User Manual
16.06.2023
Release 1.9

Contents
1General Terms and Conditions .......................................................... 3
1.1 General Information......................................................................................................................3
1.2 Contact for Support.......................................................................................................................3
1.3 Conventions used in this Manual................................................................................................4
1.4 Related Documentation................................................................................................................5
1.5 Abbreviations..................................................................................................................................5
1.6 Revision History..............................................................................................................................6
2Product Description ............................................................................ 6
2.1 Overview..........................................................................................................................................6
Please note the following:......................................................................................................................7
2.2 Identification...................................................................................................................................8
2.3 Physical Dimensions and Weight ................................................................................................8
2.4 Product Features and Technical Data.........................................................................................9
2.5 Telic Certified Accessories ..........................................................................................................10
3Safety and Product Care ................................................................... 12
3.1 Safety instructions .......................................................................................................................13
3.2 General precautions....................................................................................................................14
3.3 SIM card precautions...................................................................................................................14
3.4 Antenna precautions...................................................................................................................15
3.5 Storage Conditions ......................................................................................................................15
4Electrical Description......................................................................... 16
4.1 Power Connector .........................................................................................................................16
4.2 Antenna requirements................................................................................................................18
4.3 SIM card reader............................................................................................................................18
4.4 RS232 Serial Port..........................................................................................................................18
4.5 Mini USB Connector ....................................................................................................................19
5Operation ........................................................................................... 20
5.1 Switch ON the modem................................................................................................................20
5.2 Configuration of the bit rate on the serial interface ..............................................................21
5.3 Power off the modem .................................................................................................................21
5.4 Using low power mode of the modem.....................................................................................22
5.4.1 Enabling the low power mode...................................................................................................22
5.5 Wake up Events............................................................................................................................22
5.5.1 Wake up Event Examples .......................................................................................................23
5.6 Operating states / green LED.....................................................................................................25
5.7 Status LEDs (one yellow, one red) .............................................................................................25
5.8 Current consumption measurements......................................................................................26
5.9 Additional software configuration ............................................................................................26

LT910-WW User Manual - Telic AG
Pg 2
5.8.1 Activating / Deactivating GSM / UMTS / LTE Mode.................................................................26
5.8.3 Configuring specific frequency bands......................................................................................26
6Installation of the modem ................................................................ 27
6.1 Where to install the modem ......................................................................................................27
6.1.1 Environmental conditions..........................................................................................................27
6.1.2 WWAN Signal strength................................................................................................................27
6.1.3 Connection of components to the LT910-WW Terminal.......................................................27
6.1.4 Network and Subscription .........................................................................................................28
6.2 How to install the modem..........................................................................................................28
6.2.1 Power supply................................................................................................................................28
6.2.2 Securing the modem...................................................................................................................28
6.3 Antenna .........................................................................................................................................28
6.3.1 General..........................................................................................................................................28
6.3.2 Antenna type................................................................................................................................29
6.3.3 Antenna placement.....................................................................................................................29
6.3.4 The antenna cable.......................................................................................................................29
6.3.5 Possible communications disturbances ..................................................................................29

LT910-WW User Manual - Telic AG
Pg 3
1General Terms and Conditions
This technical description contains important information for the installation and use of the
LT910-WW Terminal. Read it carefully before working with the LT910-WW Terminal.
We cannot be held responsible for material loss or personal injury that is due to noncompliance
with the safety instructions. The warranty will be void in such circumstances.
Telic reserves the right to change the included information without prior notice and does not take
responsibility for errors in the document and/or for any missing information.
1.1 General Information
This installation manual consists of the following chapters:
Chapter
Description
1
General Information
provides basic information such as the conventions for the
warning levels, applicable related documentations, used abbreviations, a revision
history and contact information.
2
Product Description provides a brief overview about the mechanical specification
of the product as well as an overview of the functions and features of the device as
well as the available accessories.
3
Safety and Product Care addresses the indented use of this device and safety
related information important to read before using the device.
4
Electrical Description describes the electrical characteristics and pin allocation of
the device.
5
Operation provides details relating to the commissioning of the device, including
details on activating special features such as low power modes.
6
Installation of the modem provides instructions about how to install the device
for the M2M application.
1.2 Contact for Support
Please submit your request to TELIC AG customer support:
[e-mail]
Information about Telic AG products and accessories are available from the following web site:
http://www.telic.de.

LT910-WW User Manual - Telic AG
Pg 4
1.3 Important notice
Due to the nature of wireless communications, transmission and reception of data can
never be guaranteed. Data may be delayed, corrupted (i.e., have errors) or be totally lost.
Although significant delays or losses of data are rare when wireless devices such as the
LT910WW terminal are used in a normal manner with a well-constructed network, the
LT910WW should not be used in situations where failure to transmit or
receive data could result in damage of any kind to the user or any other party, including
but not limited to personal injury, death, or loss of property. Telic AG accepts no
responsibility for damages of any kind resulting from delays or errors in data transmitted
or received using the Telic AG product, or for failure of the Telic AG product
to transmit or receive such data.
1.4 Safety and hazards
Do not operate the Telic AG product in areas where blasting is in progress, near
Hazards medical equipment, near life support equipment, or any equipment which may be
susceptible to any form of radio interference. In such areas, the Telic AG product
MUST BE POWERED OFF. The Telic AG product can transmit signals that could
interfere with this equipment.
1.5 Conventions used in this Manual
The following conventions for warning levels are used in this manual:
Warning
Warnings against hazards that may result directly in serious injuries or death in
case of nonobservance.
Caution
Warnings against hazards that may result in injuries in case of nonobservance.
NOTICE

LT910-WW User Manual - Telic AG
Pg 5
Warnings against hazards that may result in material damage in case of nonobservance.
Indicates that the device can be damaged by electrostatic discharge.
This note contains helpful suggestions or references to material not
covered in the document.
1.6 Related Documentation
Please consult the download zone of the Telic AG website for additional documentation related
to the build-in module LE910C1-WWX, such as AT command reference. Note that these
documents can be accessed online only after you have registered on our website and agreed
with our terms of use. Please follow this link to register or create a user account:
https://www.telic.de/en/our-products/downloads
1.7 Abbreviations
Abbreviation
Explanations
WWAN
Wireless Wide Area Network
CSD
Circuit Switched Data
DCE
Data Circuit Terminating Equipment
DTE Data Terminal Equipment
GPRS
General Packet Radio Service
GSM
Global System for Mobile Communication
ME
Mobile Equipment
MO
Mobile Originated
MS
Mobile Station
RF Radio Frequency
SIM
Subscriber Identity Module
SMS
Short Message Service
TA
Terminal Adapter
TE
Terminal Equipment
TS
Telecom Services
Table 1: Abbreviations

LT910-WW User Manual - Telic AG
Pg 6
1.8 Revision History
Revision
Date
Changes
1.8 07.07.2022 Initial version
Table 2: Documentation change log
2Product Description
2.1 Overview
The pictures below show the mechanical design of the LT910-WW Terminal along with the
positions of the different connectors and mounting holes. The LT910-WW Terminal case is made
of durable PC/ABS plastics.
Figure 1: Connectors on rear side of the Terminal

LT910-WW User Manual - Telic AG
Pg 7
Figure 2: Connectors on front side of the Terminal
PLEASE NOTE THE FOLLOWING:
The terminal can be securely fitted into your application by using the mounting holes
positioned at the two corners of the device.
The SIM card can be inserted without the need for additional tools.
Section “4 Electrical Description” describes the pins and electrical characteristics of the
terminal’s various connectors.
Section “4.2 Antenna Connector” provides information about the antenna connector.
Special DIN rail mounting brackets (Art#. 12304 or Art# 12305) is available as an
accessory item which allows installation of the modem in industrial environments using
DIN rails. For more details of our accessories please check chapter 2.5 Telic Certified
Accessories.
1Note that the serial number consists of a 5-digit product ID followed by the device’s IMEI.
Label
Description
S/N
Serial number1
Serial number barcode
IMEI
international mobile equipment
identity
CE
CE mark

LT910-WW User Manual - Telic AG
Pg 8
2.2 Identification
On the bottom of the device, you will find the type label.
2.3 Physical Dimensions and Weight
Overall dimensions: 77x66x26mm
Weight: 91g
Disposal in accordance with
European directive 2002/96/CE

LT910-WW User Manual - Telic AG
Pg 9
Figure 3: Drawing of the terminal’s housing
2.4 Product Features and Technical Data
NOTICE
Telic AG may, at any time and without notice, make changes or improvements to the
products and services offered and / or cease producing or commercializing them.
NOTICE – Optional Features
Features identified as “optional” in this document are not assembled by default. Please
contact our sales team at [e-mail] to clarify the details for ordering terminal variants.
Category
Features
Details
Air Interface
LTE frequency
bands
B1/B2/B3/B4/B5/B7/B8/B12/B13/B14/B18/B25/B26/
B19/B20/B28

LT910-WW User Manual - Telic AG
Pg 10
UMTS frequency
bands B1/B2/B4/B5/B6/B8/B19
GSM frequency
bands B2/B3/B5/B8
LTE FDD Cat.1
3GPP release 10 compliant
Output Power
Class 3 (0.2W, 23dBm) for LTE
Class 3 (0.25W, 24dBm) for UMTS
Class 4 (2W, 33dBm) for GSM850/GSM900
Class 1 (1W, 30dBm) for GSM1800/1900
SMS SMS over IMS
SIM Card Holder
1x (1.8/3 Volt)
LEDs
1x WWAN + 2 configurable
Type Approvals
CE
Connectors /
interfaces
D-Sub (9-pin)
1x Female (RS232)
USB
1x Mini-USB
RJ11
For details have a look section "Power Connector"
Antenna
1x (FME male)
Software
AT Command Set
TS 27.005, 27.007 and Telit custom AT commands
Programming
Language
C (Telit application development environment:
AppZone)
SIM Application
Toolkit SIM application tool kit 3GPP TS 51.014
TCP/IP Stack
TCP, UDP, DNS, FTP, SMTP
SW Update
FOTA
Power
Management Voltage Range 7V - 32V
Hardware
Characteristics
Operating
Temperature
-30°C to +80°C
It is not recommended to operate the terminal
permanently on full load at maximum temperature.
To monitor the temperature please use the AT
command AT#TEMPMON
Dimensions 77x66x26mm
Weight
91g
Table 3: Feature overview
2.5 Telic Certified Accessories
NOTICE

LT910-WW User Manual - Telic AG
Pg 11
The antennas listed in this section are suitable both for use with GSM, UMTS and LTE
networks. Please check, though, which frequency bands your mobile network service
provider supports.

LT910-WW User Manual - Telic AG
Pg 12
Table 4: Accessories list
Please contact your distributor or Telic AG for availability or check Telic’s webpage
http://www.telic.de.
3Safety and Product Care
This device has been designed in accordance with industrial standards, manufactured with high
quality materials, and thoroughly tested. Nevertheless, its use may constitute a risk to persons or
cause material damage.
The following safety instructions must be followed to ensure the safety of users and of the
device.

LT910-WW User Manual - Telic AG
Pg 13
NOTICE
If these instructions are ignored, Telic AG will not assume responsibility for any damages
that are incurred. Telic AG may refuse warranty claims where evidence of product misuse is
found.
Please read the information in this section and the information in Section 6 Installation of the
modem before starting your integration work!
3.1 Safety instructions
PLEASE READ THESE SAFETY INSTRUCTIONS AND KEEP A COPY OF THEM.
The LT910-WW Terminal contains highly integrated components which can be damaged by
electrostatic discharge.
Therefore, only touch the LT910-WW Terminal on the housing or connectors and avoid
touching the components on the board.
Always ensure that the use of the modem is permitted. The modem may present a
hazard if used in the proximity of personal medical electronic devices. As a rule, the
modem must not be used in hospitals, airports or planes.
Never use the modem at a gas station, refueling point, blasting area or in any other
environment where explosives may be present.
Operating the modem close to other electronic devices, such as antennas, television sets,
and radios may cause electromagnetic interference.
This product is intended to be used with the antenna or other radiating element at least
20 cm away from any part of the human body. In applications where this rule cannot be
applied, the application designer is responsible for providing the SAR measurement test
report and declaration.
You are responsible for observing your country's safety standards, and where applicable,
the relevant wiring rules.
Warning
When using products which are exposed to electric voltage the valid regulations
must be observed.
Always make sure that the device is disconnected from the power supply before opening it.
You should only use tools on components, modules or devices if they are disconnected from the
power supply and the electric charge, which may still be stored in some components inside the
device, has been discharged. All cables and wires which are energized and connected to the device,
the module or components must be checked regularly for any damage of the isolation shield or

LT910-WW User Manual - Telic AG
Pg 14
fractures of the cables. If the supply cables are visibly damaged the device must be taken out of
commission immediately.
When using components or modules, the specification given in the corresponding description of
these components must strictly be observed. The device shall be operated only by appropriately
qualified personnel.
This device shall only be used for its intended purpose.
Please note that the quality and availibility of the WWAN network is depending on the network
coverage in the area of deployment and the performance of the network provider. We are not
responsible for any wireless connection errors or data loss caused by these external factors.
General precautions
The LT910-WW Terminal is designed for indoor use only. To use it in an outdoor application it
must be integrated into a weatherproof enclosure. Do not exceed the environmental and
electrical limits as specified in section “2.4 Product Features and Technical Data”.
Avoid exposing the modem to open flames or to extreme hot or cold temperatures.
Never try to dismantle the modem yourself. There are no components inside the modem
that can be serviced by the user. If you attempt to dismantle the modem, you will
invalidate the warranty.
The LT910-WW Terminal must not be installed or located where the surface temperature
of the plastics case may exceed 80°C.
All cables connected to the LT910-WW Terminal must be secured or clamped,
immediately adjacent to the modem's connectors, to provide strain relief and to avoid
transmitting excessive vibration to the modem in the installation.
Ensure the cables, supplying power, and input cable to the LT910-WW Terminal do not
exceed 3 meters.
To protect power supply cables and meet the fire safety requirements when the unit is
powered from a battery or a high current supply, connect a fast 2A/32V fuse in line with
the positive supply.
Do not connect any incompatible components or products to the LT910-WW Terminal.
3.2 SIM card precautions
Before handling the SIM card in your application, ensure that you are not charged with static
electricity. Use proper precautions to avoid electrostatic discharges.
When the SIM card hatch is opened, the SIM card connectors lies exposed under the SIM card
holder.
Caution! Do not touch these connectors! If you do, you may release an electrical
discharge that could damage the modem or the SIM card.

LT910-WW User Manual - Telic AG
Pg 15
When designing your application, the SIM card’s accessibility should be considered. We always
recommend that you have the SIM card protected by a PIN code. This will ensure that the SIM
card cannot be used by an unauthorized person.
3.3 Antenna precautions
Consider the risk of lightning in case the antenna is to be mounted outside. Follow the
instructions provided by the antenna manufacturer.
NOTICE
Please note that this LTE device is designed for use with one single antenna only. It does not
support antenna diversity.
Never connect more than one modem to a single antenna. The modem can be damaged
by radio frequency energy from the transmitter of another modem.
Like any mobile station, the antenna of the modem emits radio frequency energy. To
avoid EMI (electromagnetic interference), you must determine whether the application
itself, or equipment in the application’s proximity, needs further protection against radio
emission and the disturbances it might cause. Protection is secured either by shielding
the surrounding electronics or by moving the antenna away from the electronics and the
external signals cable.
The modem and antenna may be damaged if it encounters ground potentials other than
the one in your application.
3.4 Storage Conditions
It is recommended to store the unit within a temperature range from +15°C to +35°C and an
average annual relative humidity of max. 60% without condensation.

LT910-WW User Manual - Telic AG
Pg 16
4Electrical Description
The modem uses the following connectors:
RJ11 6 way (power)
Mini USB (for data)
SIM card reader
FME male coaxial jack (antenna connector)
D-SUB9 female, 9 pins (RS232 serial port)
4.1 Power Connector
An RJ11 six-way connector, as shown and described below, serves as a means of supplying and
controlling DC power to the modem. The use of an external power supply is necessary as the USB
port is not intended to be used as power source.
The supply voltage VCC required by the modem is 7V - 32V DC. Please note that applying the
supply voltage does not switch the modem on. To do so an additional active high control signal,
TO_IN, must be applied for > 1 second.
Please see chapter 5.1 Switch ON the modem for further important details about TO_IN and
power supply requirements, especially if TO_IN is applied in parallel to VCC.
VCC and GND are reverse polarity and overvoltage protected if the antenna interface
and the user’s application are not used or connected to separate grounds. Excessive
reverse voltage or overvoltage can destroy the device.

LT910-WW User Manual - Telic AG
Pg 17
Figure 4: RJ11 Pin connector
Pin
Signal
Direction
Limits
Description
1
VCC
Input
7 – 32V
Positive power input, DC
2
Not used
3
EMERG_OFF
Input
0 – 32V
Positive edge triggered signal to switch off modem
Only use after modem is fully switched on (PWRMON is
HIGH)
VIH > 5V, VIL < 0.5V
Power off: t > 3s
This signal triggers the command AT#SHDN
4
TO_IN
Input
0 – 32V
Positive edge triggered signal; used to switch on the
modem
VIH > 5V, VIL < 0.5V
Power on: t > 1s after VCC available
VIH = Voltage Input high
VIL = Voltage Input low
5 Not used
6 GND Input Negative power (ground) input and return path for TO_IN
and EMERG_OFF
Table 5: RJ11 Pin and signals description

LT910-WW User Manual - Telic AG
Pg 18
4.2 Antenna requirements
4.3 SIM card reader
The Terminal is fitted with a SIM card reader designed for 1.8V and for 3V SIM cards. It is the
hinge type which is lockable in the horizontal position and is accessed through a removable
panel.
4.4 RS232 Serial Port
The modem supports a standard RS232 serial interface via its 9 pin D-sub connector, shown
below. In line with serial communication terminology the Terminal should be considered as the
data circuit terminating equipment (DCE) and the external application or computer as the data

LT910-WW User Manual - Telic AG
Pg 19
terminating equipment (DTE). The maximum data rate to communicate with the LE910C1-WWX
Terminal is 250kbps Mbps.
The default data rate is 115kbps.
Pin
Signal
Direction
Limits
Description
1
DCD
Output
> + 4V
<- 4 V
Data carrier detect
2
RD
Output
> + 4V
<- 4 V
Received data
3
TD
Input
> + 2,4V
< 0.8 V
Transmitted data
4 DTR Input > + 4V
< 0.8 V
Data terminal ready
5
GND
-
0 V
Ground connection
6
DSR
Output
> + 4V
< - 4 V
Data set ready
7
RTS
Input
> + 2,4V
< 0.8 V
Request to send
8
CTS
Output
> + 4V
< - 4 V
Clear to send
9
RI
Output
> + 4V
< - 4 V
Ring indicator
Table 6: Electrical characteristics of the serial port signals
4.5 Mini USB Connector
Figure 5 shows gives an overview about the pin assignment of the mini USB connector from the
standard LT910-WW Terminal. The pin assignment of the two versions is the same.
The modem supports a standard USB 2.0 full speed slave interface to receive AT-commands as
well as data transmissions.
Drivers for Windows Desktop and instructions for Linux are available for download from the Telic
AG website (for registered users only).
