Telrad CPE12000 Series User manual

AUG 2019
Version: 2.5
User
Manual
LTE Outdoor CPE12000

LTE Outdoor CPE12000 | User Manual 2
Legal Rights
© Copyright 2017 Telrad Networks Ltd. All rights reserved.
The material contained herein is proprietary, privileged, and confidential and owned by Telrad Networks or its
third party licensors. No disclosure thereof shall be made to third parties without the express written
permission of Telrad Networks Ltd.
Telrad Networks Ltd. reserves the right to alter the equipment specifications and descriptions in this
publication without prior notice. No part of this publication shall be deemed to be part of any contract or
warranty unless specifically incorporated by reference into such contract or warranty.
Trade Names
BreezeCOM®, BreezeMAX®, 4Motion®and/or other products and Telrad Networks/or services referenced
herein are either registered trademarks, trademarks or service marks of Telrad Networks Ltd.
All other names are or may be the trademarks of their respective owners.
Statement of Conditions
The information contained in this manual is subject to change without notice. Telrad Networks Ltd. shall not
be liable for errors contained herein or for incidental or consequential damages in connection with the
furnishing, performance, or use of this manual or equipment supplied with it.
Warranties and Disclaimers
All Telrad Networks Ltd. (“Telrad Networks“) products purchased from Telrad Networks or through any of
Telrad Networks' authorized resellers are subject to the following warranty and product liability terms and
conditions.
Exclusive Warranty
(a) Telrad Networks warrants that the Product hardware it supplies and the tangible media on which any
software is installed, under normal use and conditions, will be free from significant defects in materials and
workmanship for a period of fourteen (14) months from the date of shipment of a given Product to Purchaser
(the "Warranty Period"). Telrad Networks will, at its sole option and as Purchaser's sole remedy, repair or
replace any defective Product in accordance with Telrad Networks' standard R&R procedure.
(b) With respect to the Firmware, Telrad Networks warrants the correct functionality according to the

LTE Outdoor CPE12000 | User Manual 3
attached documentation, for a period of fourteen (14) month from invoice date (the "Warranty Period")".
During the Warranty Period, Telrad Networks may release to its Customers firmware updates, which include
additional performance improvements and/or bug fixes, upon availability (the "Warranty"). Bug fixes,
temporary patches and/or workarounds may be supplied as Firmware updates.
Additional hardware, if required, to install or use Firmware updates must be purchased by the Customer.
Telrad will be obligated to support solely the two (2) most recent Software major releases.
TELRAD NETWORKS SHALL NOT BE LIABLE UNDER THIS WARRANTY IF ITS TESTING AND EXAMINATION
DISCLOSE THAT THE ALLEGED DEFECT IN THE PRODUCT DOES NOT EXIST OR WAS CAUSED BY PURCHASER'S
OR ANY THIRD PERSON'S MISUSE, NEGLIGENCE, IMPROPER INSTALLATION OR IMPROPER TESTING,
UNAUTHORIZED ATTEMPTS TO REPAIR, OR ANY OTHER CAUSE BEYOND THE RANGE OF THE INTENDED USE,
OR BY ACCIDENT, FIRE, LIGHTNING OR OTHER HAZARD.
Disclaimer
(a) The Software is sold on an "AS IS" basis. Telrad Networks, its affiliates or its licensors MAKE NO
WARRANTIES, WHATSOEVER, WHETHER EXPRESS OR IMPLIED, WITH RESPECT TO THE SOFTWARE AND THE
ACCOMPANYING DOCUMENTATION. TELRAD NETWORKS SPECIFICALLY DISCLAIMS ALL IMPLIED WARRANTIES
OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE AND NON-INFRINGEMENT WITH RESPECT
TO THE SOFTWARE. UNITS OF PRODUCT (INCLUDING ALL THE SOFTWARE) DELIVERED TO PURCHASER
HEREUNDER ARE NOT FAULT-TOLERANT AND ARE NOT DESIGNED, MANUFACTURED OR INTENDED FOR USE
OR RESALE IN APPLICATIONS WHERE THE FAILURE, MALFUNCTION OR INACCURACY OF PRODUCTS CARRIES A
RISK OF DEATH OR BODILY INJURY OR SEVERE PHYSICAL OR ENVIRONMENTAL DAMAGE ("HIGH-RISK
ACTIVITIES"). HIGH-RISK ACTIVITIES MAY INCLUDE, BUT ARE NOT LIMITED TO, USE AS PART OF ON-LINE
CONTROL SYSTEMS IN HAZARDOUS ENVIRONMENTS REQUIRING FAIL-SAFE PERFORMANCE, SUCH AS IN THE
OPERATION OF NUCLEAR FACILITIES, AIRCRAFT NAVIGATION OR COMMUNICATION SYSTEMS, AIR TRAFFIC
CONTROL, LIFE SUPPORT MACHINES, WEAPONS SYSTEMS OR OTHER APPLICATIONS REPRESENTING A
SIMILAR DEGREE OF POTENTIAL HAZARD. TELRAD NETWORKS SPECIFICALLY DISCLAIMS ANY EXPRESS OR
IMPLIED WARRANTY OF FITNESS FOR HIGH-RISK ACTIVITIES.
(b) PURCHASER'S SOLE REMEDY FOR BREACH OF THE EXPRESS WARRANTIES ABOVE SHALL BE REPLACEMENT

LTE Outdoor CPE12000 | User Manual 4
OR REFUND OF THE PURCHASE PRICE AS SPECIFIED ABOVE, AT TELRAD NETWORKS'S OPTION. TO THE
FULLEST EXTENT ALLOWED BY LAW, THE WARRANTIES AND REMEDIES SET FORTH IN THIS AGREEMENT ARE
EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES OR CONDITIONS, EXPRESS OR IMPLIED, EITHER IN FACT
OR BY OPERATION OF LAW, STATUTORY OR OTHERWISE, INCLUDING BUT NOT LIMITED TO WARRANTIES,
TERMS OR CONDITIONS OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, SATISFACTORY QUALITY,
CORRESPONDENCE WITH DESCRIPTION, NON-INFRINGEMENT, AND ACCURACY OF INFORMATION
GENERATED, ALL OF WHICH ARE EXPRESSLY DISCLAIMED. TELRAD NETWORKS' WARRANTIES HEREIN RUN
ONLY TO PURCHASER, AND ARE NOT EXTENDED TO ANY THIRD PARTIES. TELRAD NETWORKS NEITHER
ASSUMES NOR AUTHORIZES ANY OTHER PERSON TO ASSUME FOR IT ANY OTHER LIABILITY IN CONNECTION
WITH THE SALE, INSTALLATION, MAINTENANCE OR USE OF ITS PRODUCTS.
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate this equipment.

LTE Outdoor CPE12000 | User Manual 5
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 25cm
between the radiator & your body.
This transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter.
Limitation of Liability
(a) TELRAD NETWORKS SHALL NOT BE LIABLE TO THE PURCHASER OR TO ANY THIRD PARTY, FOR ANY LOSS OF
PROFITS, LOSS OF USE, INTERRUPTION OF BUSINESS OR FOR ANY INDIRECT, SPECIAL, INCIDENTAL, PUNITIVE
OR CONSEQUENTIAL DAMAGES OF ANY KIND, WHETHER ARISING UNDER BREACH OF CONTRACT, TORT
(INCLUDING NEGLIGENCE), STRICT LIABILITY OR OTHERWISE AND WHETHER BASED ON THIS AGREEMENT OR
OTHERWISE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
(b) TO THE EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT SHALL THE LIABILITY FOR DAMAGES
HEREUNDER OF TELRAD NETWORKS OR ITS EMPLOYEES OR AGENTS EXCEED THE PURCHASE PRICE PAID FOR
THE PRODUCT BY PURCHASER, NOR SHALL THE AGGREGATE LIABILITY FOR DAMAGES TO ALL PARTIES
REGARDING ANY PRODUCT EXCEED THE PURCHASE PRICE PAID FOR THAT PRODUCT BY THAT PARTY (EXCEPT
IN THE CASE OF A BREACH OF A PARTY'S CONFIDENTIALITY OBLIGATIONS).

LTE Outdoor CPE12000 | User Manual 6
Table of Contents
Table of Contents....................................................................................................................................6
1. About this Guide.............................................................................................................................8
Prerequisite Skills and Knowledge..................................................................................................8
Conventions Used in this Document..............................................................................................8
2. Introduction....................................................................................................................................9
Product Highlights ..........................................................................................................................9
3. Outdoor Specifications.................................................................................................................10
3.1. LTE Specifications .................................................................................................................10
3.2. Electrical / Physical Specifications........................................................................................11
3.3. PoE Adapter Specification ....................................................................................................11
4. Product Package ...........................................................................................................................12
5. Connectors ...................................................................................................................................13
6. LED Indicators...............................................................................................................................14
7. Installation....................................................................................................................................16
Connecting the Cables..................................................................................................................17
8. Web Interface...............................................................................................................................23
8.1. Login to Web-GUI .................................................................................................................23
Brief Summary Page .....................................................................................................................24
Detailed Configuration Page.........................................................................................................27
8.2. Menu Structure ....................................................................................................................30
9. Reference Manual ........................................................................................................................31
9.1. LTE Network..........................................................................................................................31
LTE| Status| Basic.................................................................................................................32
LTE | Status | Advance .........................................................................................................35
LTE| Status| PDN..................................................................................................................36
LTE | Cell Selection ...............................................................................................................37
LTE | Default PDN.................................................................................................................40
LTE | Multiple PDN ...............................................................................................................41
LTE | Advanced.....................................................................................................................42
LTE | PIN ...............................................................................................................................43
LTE | PLMN selection............................................................................................................45
LTE | Cell lock........................................................................................................................46
9.2. Network................................................................................................................................46
Network | Status ..................................................................................................................47

LTE Outdoor CPE12000 | User Manual 7
Network | WAN Setting (NAT Mode) ...................................................................................49
Network | WAN Setting (Tunnel Mode)...............................................................................51
Network | WAN Setting (Bridge Mode) ...............................................................................54
Network | WAN Setting (Router Mode)...............................................................................57
Network | LAN Setting .........................................................................................................59
Network | Port Management | Port Forwarding (Available in NAT, Tunnel Mode).............63
Network | Port Management | Port Trigger (Available in NAT, Tunnel Mode)....................65
Network | Routing(Available in Router, Tunnel Mode)........................................................67
Network | DSCP....................................................................................................................68
Network | MGMT Service ....................................................................................................69
9.3. IPv6.......................................................................................................................................70
IPv6| Status ..........................................................................................................................71
IPv6 | Settings | Internet Connect Type...............................................................................72
IPv6 | Settings | Extend WAN Prefix ....................................................................................73
IPv6 | Settings | Prefix Delegation.......................................................................................74
IPv6 | Settings | Static..........................................................................................................75
9.4. Firewall: ................................................................................................................................76
Firewall | Basic .....................................................................................................................77
Firewall | Access Restriction ................................................................................................79
10. Management........................................................................................................................81
Management | Account .......................................................................................................82
Management | Device Setting .............................................................................................83
Management | Device Log...................................................................................................84
Management | Device Time.................................................................................................86
Management | Restore Default ...........................................................................................87
Management | Software......................................................................................................89
Management | RM Settings.................................................................................................92
11. Monitoring..........................................................................................................................103
Monitoring | Status............................................................................................................104
Monitoring | Iperf ..............................................................................................................106
Monitoring | Diagnostic Tools............................................................................................108
12. About..................................................................................................................................109
About | Status ....................................................................................................................110

LTE Outdoor CPE12000 | User Manual 8
1.About this Guide
This document provides information and procedures on the installation and configuration of
CPE12000 LTE Outdoor CPE. Applicable products:
CPE-12000SG-PRO-1D-3.x (for Bands 42&43)
CPE-12000SG-PRO-1D-3.x-B48 (for Band 48)
Prerequisite Skills and Knowledge
To use this document effectively, you should have a working knowledge of Local Area Networking
(LAN) concepts and wireless Internet access infrastructures. In addition, you should be familiar with
the following:
Hardware installers should have a working knowledge of basic electronics and mechanical
assembly, and should understand related local building codes.
Network administrators should have a solid understanding of software installation procedures
for network operating system and troubleshooting knowledge. LTE Indoor CPE has a web GUI
which supports http/https protocol; it could be used to configure the CPE settings through the
web browser by user’s PC. Please refer to the following pages for more detail.
Conventions Used in this Document
The following typographic conventions and symbols are used throughout this document:
Very important information. Failure to observe this may result in
damage.
Important information that should be observed.
Additional information that may be helpful but not required.
bold
Menu commands, buttons and input fields are displayed in bold

LTE Outdoor CPE12000 | User Manual 9
2.Introduction
Product Highlights
Support TDD-LTE Mode Band 42,43 & 48 *
Support 3GPP Release 12 compliant
Support up to UE LTE Downlink Category 12 **
Support 4x4 MIMO DL with 40MHz CA Maximum
Support DL 256QAM with DL 2x2 MIMO only
2Tx &4Rx configuration support
Support 1.8V and 3V SIM and USIM card for LTE Mode
Supports Dynamic Host Configuration Protocol
Built-in web server for web-based configuration
Password protected access and configuration
Supports IEEE 802.3, IEEE 802.3u, 802.3ab (10/100/1000 Mbps)
Support Power over Ethernet of Outdoor WAN port {802.3 at} Supports
Supports VPN pass-through& End Point
Support IP67 Environmental Proof
* B48 support is subject to FCC certification with a dedicated P/N please refer to the release notes
** TDD Cat 12 with 4x4 + 40MHz carrier aggregation

LTE Outdoor CPE12000 | User Manual 10
3. Outdoor Specifications
3.1. LTE Specifications
Item
Description
Standard Compliance
3GPP Rel. 12
Duplex Mode
TDD
Frequency Bands
42, 43, 48*
Channel bandwidth (MHz)
5, 10, 15, 20
Modulation
DL: QPSK, 16QAM, 64QAM, 256QAM
UL: QPSK, 16QAM, 64QAM
Transmit Modes (TM’s)
TM1, TM2, TM3, TM4, TM8
Carrier Aggregation
Downlink Carrier Aggregation support
Tx/Rx Ports
2 Tx / 4 Rx
Maximum Transmit Power
23 dBm Per Port
Antenna
13 ± 1 dBi
L2 & L3
Multiple APN
PLMN and Cell Selection
Authentication
USIM and SIM function
QoS
Non-GBR, GBR
MTU Size
Layer 2 - 1,600 bytes
Layer 3 –1,500 bytes
* B48 ordering with B48 suffix to the P/N
Note: for actual supported features please refer to the software Release Notes.

LTE Outdoor CPE12000 | User Manual 11
3.2. Electrical / Physical Specifications
Item
Description
Dimensions (HxWxD)
277 x 140 x 75 mm
Weight
0.6 Kg | 1.3 lbs.
Physical Interface
LAN - 10/100/1000
Power Source
PoE
Environmental
IP67 - withstands harsh weather and outdoor environments
Operating Temperature
-40° to 55° C | -40° to 131° F
Humidity
5% to 95% non-condensing
ESD Rating
+/-15KV
Power Consumption
6.7W
3.3. PoE Adapter Specification
Item
Description
Power Source
100~240VAC
Output Power (PoE)
56V / 0.27A
User Interfaces
Data only : 1xLAN RJ45
Maximum cable length
100m

LTE Outdoor CPE12000 | User Manual 12
4.Product Package
Item
Qty
1
LTE Outdoor CPE
1
2
Quick Installation Guide
1
3
PoE Adapter
1
4
Power Plug
1
5
Mounting Kit
1
If any item of mentioned above is missing or damaged, please contact
our customer support immediately.

LTE Outdoor CPE12000 | User Manual 13
5.Connectors
The Outdoor LTE CPE has following connectors (from left to right):
1. One RJ-45 connector for connecting to the PoE adaptor.
2. LED indicator inside and SIM card slot for inserting SIM card.
3. A grounding screw on the rear panel.
3

LTE Outdoor CPE12000 | User Manual 14
6.LED Indicators
LED name
Location
Color
LED Behavior
Status Indication
LED List
●●●
●●●●●
MAIN power
●○○
○○○○○
Blue
ON
Power On
OFF
Power Off
Ethernet
status
○●○
○○○○○
Orange
Steady ON
Detect Ethernet
Device Connected
Blinking
N/A
OFF
No Ethernet action
SIM status
○○●
○○○○○
Green
Steady ON
SIM Detected and
LTE connected
Blinking when
On-hook
No SIM Detected
OFF
SIM Detected and
No LTE connection
LTE Status LED : Link Status
When CPE is power on, each LED indicates
each link status; change upon customer
requirement
LTE 1
○○○
●○○○○
Blue
Steady ON
Signal is poor
SINR < 3dB
LTE 2
○○○
●●○○○
Blue
Steady ON
Signal is weak
3dB <SINR < 11dB
LTE 3
○○○
●●●○○
Blue
Steady ON
Signal is Good
11dB < SINR <
18dB

LTE Outdoor CPE12000 | User Manual 15
LTE 4
○○○
●●●●○
Blue
Steady ON
Signal is very good
18dB < SINR <
23dB
LTE 5
○○○
●●●●●
Blue
Steady ON
Signal is Excellent
23dB < SINR

LTE Outdoor CPE12000 | User Manual 16
7.Installation
Selecting a Location: LTE Outdoor CPE should be pole-mounted outdoors and aligned so its
antenna faces the nearest LTE eNodeB. When selecting a suitable location for the unit, consider
these guidelines:
•Place LTE Outdoor CPE as high as possible to achieve the best possible link quality.
•Place the LTE Outdoor CPE away from power and telephone lines.
•Avoid placing LTE Outdoor CPE too close to any metallic reflective surfaces.
•Be sure to ground LTE Outdoor CPE with an appropriate grounding wire (not included) by
attaching it to the grounding screw on the unit and to a good ground connection.
Mounting the ODU: Mount LTE Outdoor CPE on a 1”-4” pole using the supplied kit, or the
optional tilt accessory.
•Using the clamp
1. Thread the M10*100mm bolt through a spring washer, flat washer and the bracket holes.
2. With the connector facing downward, attaché LTE Outdoor CPE to a 1”-4” pole.
3. Attach the bracket to the other side of the pole.
4. Thread the M10*100mm bolts through both holes on either side, and tighten the nuts.

LTE Outdoor CPE12000 | User Manual 17
Connecting the Cables
Outdoor Connection: Connect a grounding cable between the Ground terminal of the LTE
outdoor CPE and a good ground connection
Preparing and connecting the cable: Use only UTP-FTP 4x2x24AWG CAT. 5E outdoor cable from
an approved manufacturer. The cable provides pin-to-pin connection on both ends
1. Prepare the cable: Use a crimp too for RJ-45 connectors to prepare the wires. Insert them
into the appropriate pins and use the tool to crimp the connector. Make sure to do the
following:
•Remove as small a length as possible of the external jacket. Verify that the external
jacket is well inside the sealing cover when connected to the unit, to ensure good
sealing.
•Pull back the shield drain wire before inserting the cable into the RJ-45 connector, to
ensure a good connection with the connector’s shield after crimping.
The following figure shows the required wire pair connections. The color codes used in
standard cables supplied by the manufacturer are as listed in the table.

LTE Outdoor CPE12000 | User Manual 18

LTE Outdoor CPE12000 | User Manual 19
2. Connect the cable
•Remove the sealing cable gland plug from the gland nut.
•Open the sealing gland nut and remove it. Don not disassembles the gland base from
the bracket.
•Insert the cable into the sealing gland base and connect it to the RJ-45 connector at the
bottom of the CPE. Make sure the connector is completely inserted and tightened.
•Insert the rubber bushing on the cable into the gland base.
•Tighten the gland nut. Use the dedicated tool for fastening the sealing glands.
3. Seal the connector
•Attach the mastic tape (ScotchfilTM Electrical Insulation Putty) and wrap it around the
connector butting up against the connector. Do not over stretch.
•Squeeze to tighten the mastic sealer. Make sure there are no air bubbles.
•Slide the cold shrink sleeve on top of the connector. Make sure that the sleeve covers
both cable connector and unit connector.
•Pull the cord slowly to shrink the sleeve.

LTE Outdoor CPE12000 | User Manual 20
PoE Connection
1. It is assumed that the RJ-45 cables are already connected to the LTE outdoor CPE.
Assemble an RJ-45 connector with a protective cover on the other end of the LTE outdoor
CPE cable.
2. Connect the other end of the cable from ODU to the PoE adaptor which labeled “PoE”
3. Connect RJ45 cable from PoE adaptor which label “LAN”to a PC/NB/Hub/Switch.
Use ONLY the PoE adaptor which supplied with the ODU. Otherwise,
LTE Outdoor CPE may be damaged.
4. Plug in PoE into power line. The device will start the booting process. Please wait for a
minute to let the booting process complete.
