Telstra 4GX MF833V USB User manual

Telstra 4GX
MF833V USB
User Manual

2ZTE Copyright © 2023. All rights reservedVersion 1.1 / September 2023
IMPORTANT
Software updates
We always recommend that you have the latest
software update installed on your USB Modem - this will
ensure that you have the latest features, most stable
and secure experience while using this device.
Refer to section “Settings > Device settings >
Software Update (page 16) for additional information.

3ZTE Copyright © 2023. All rights reservedVersion 1.1 / September 2023
Modem Overview / LED Indicators
Part Overview
1. Modem cap 4. USB (A -type) connector
2. Front cover 5. microSDHC™ card slot
3. Indicator LED’s 6. micro-SIM card slot
Setting up the Device
Step 1 : SIM Type
Make sure you are using a Telstra micro-SIM card:
(U) SIM micro-SIM nano-SIM

4ZTE Copyright © 2023. All rights reservedVersion 1.1 / September 2023
Step 2 : Activate SIM
If your SIM is not yet active visit telstra.com/activate
Follow the prompts to activate your SIM.
Step 3 : Inserting Micro SIM
Press and slide the front plastic cover
down and remove it.
Insert your micro SIM as shown - ensure
the metal contacts are facing down.
Optional: You can add a microSDHC
(High Capacity) card to use the device
as portable USB storage.
Replace the top cover.
2
4
1
3

5ZTE Copyright © 2023. All rights reservedVersion 1.1 / September 2023
LED indicator legend
Red: No Network
The device is not registered to the mobile network.
There is no micro-SIM card inserted.
There is no network service available.
Green: 3G Connection
Solid: The device is registered to the 3G network.
Flashing: Active data transfer on the 3G network.
Blue: 4G Connection
Solid: The device is registered to the 4G network.
Flashing: Active data transfer on the 4G network
Green / Blue alternate ashing
The software is upgrading.
Connecting to Your PC
Connect the modem to your computer’s USB port.
The operating system automatically detects and identies your modem and
creates a new connection. You may require a USB-A to USB-C adapter to connect
to your computer system.
Access the Internet
After the modem is connected to your computer successfully the browser will
automatically launch, you can now access the Internet.
Check the modem homepage to make any conguration changes.
When you insert the USB modem, it automatically will open your default web
browser at the modem’s conguration homepage.

6ZTE Copyright © 2023. All rights reservedVersion 1.1 / September 2023
You can make any changes to the settings through this homepage.
You can access this conguration homepage by entering either m.home or
192.168.0.1 in the web browsers address bar.
International Roaming
• The Roaming icon indicates you are connected to a foreign network.
• If Roaming is enabled on your data plan then roaming data charges will apply
when connected via a roaming network.
• Contact Telstra to discuss your data charges and roaming options.
Software Installation / Uninstall
Windows users :
The USB will work
Start > All Programs > TELSTRA 4G USB > Uninstall
MAC users :
Depending on your Mac OS, this device may work without installing any additional
software. Driver Software is provided on the USB and will auto appear on the
desktop as a Telstra USB volume. To install, simply trigger the contained Telstra
4GX USB app and follow the presented prompts
If required to uninstall the driver, navigate to System > Applications and run
Uninstall TELSTRA 4G USB app (you will be prompted to remove the USB if
connected)
Important Note :
If your MAC device switches to sleep mode, the USB modem may no longer
be recognised by your mac, simply remove and re-insert the USB modem to
restore the device connection.
For any further trouble shooting tips - refer to the rear of this manual.
Built-in Web Interface
Connect this USB modem to any device via any vacant USB-A and open your
default web browser.

7ZTE Copyright © 2023. All rights reservedVersion 1.1 / September 2023
Enter m.home or 192.168.0.1 in the browser address bar to the device homepage.
• The home page shows a brief summary of the device status and your remaining
data from Telstra.
• Software update notications (if applicable) will be shown on this page
Screens Overview
Lock-screen
Overview :
On the initial loading of the WEB GUI, you will be presented the login screen.
The factory set default password is “Admin” (Caps sensitive).
To increase security, we highly recommend changing this default set password.
Instructions :
To change the default set password:
> Navigate to Settings > Device Settings > Account Management.
> Click Next to proceed to the PPP Prole Conguration

8ZTE Copyright © 2023. All rights reservedVersion 1.1 / September 2023
> Click Next to proceed to the PPP Authentication
> Click Next to proceed to congure Automatic Update preference.
> Select Disable if you wish Click Next to proceed to the Summary page
> Click Finish
Important Note :
To reset your USB settings and /or password at any stage, simply navigate
to the Factory Reset option via the Help menu and follow the set prompts.
Once reset the password will default set to Admin.
Home Tab
Overview :
The Home page is the default landing page that presents a quick summary of your
devices network connection status, data usage summary, received SMS messages,
service number and site navigation.
This device will automatically connect to the Telstra 4G or 3G network.
(Some device settings can only be changed when the device is disconnected from
the network).

9ZTE Copyright © 2023. All rights reservedVersion 1.1 / September 2023
Instructions : To change to manual connection
Disconnect or Connect your devices mobile connection:
> Click on Connect or Disconnect
> The Device & connection status (Disconnect, 3G Connected or 4G
Connected) will update on this page to its current state.
Quick access to change your SIM PIN page:
> Navigate to Settings > Home
> Under the PIN status, select the Change option.
> You will be redirected to the USIM PIN Management
(See USIM PIN Management for further instructions).
Important :
Changing the SMS PIN should be carried out with caution. When choosing
a new SIM PIN, it is recommended to usemmended to use a unique combination of numbers
that is not easily guessable or shared with others.
Settings > Quick Setup (wizard)

10ZTE Copyright © 2023. All rights reservedVersion 1.1 / September 2023
Overview :
The Quick Settings page allows you to congure your device in 5 simple steps to
quickly setup your device to your preference.
Instructions :
Accessing the Quick Settings Wizard for setting up your device:
> Navigate to Settings > Quick Settings
> Click Next to proceed to the PPP Prole Conguration
> Click Next to proceed to the PPP Authentication
> Click Next to proceed to congure Automatic Update preference.
> Select Disable if you wish Click Next to proceed to the Summary page
> Click Finish
Advanced Settings
Settings > Network Settings > WAN Connection Mode
Overview :
Your device has been congured to be Plug and Play, so it will power on and
