QSG TSW212
Main Page > TSW Switches > TSW212 > QSG TSW212
This Wiki page contains the online version of the Quick Start Guide (QSG) for the TSW212
managed switch . Here you will find an overview of the various components on the front and back
of a TSW212 device, hardware installation instructions, first login information, device specifications,
and general safety information. It is highly recommended to acquaint yourself with the Quick Start
Guide before using the device. You can also locate a printed version of the Quick Start Guide in the
packaging box of your device.
Contents
• 1 Safety information
- 1.1 General
- 1.2 CE Declaration of Conformity
- 1.3 Operating conditions
- 1.4 Faulty and damaged products
- 1.5 Electrical safety
- 1.6 Product handling
• 2 Front view
• 3 Back view
• 4 Connectors
• 5 Video Quick Start Guide
• 6 Hardware installation
• 7 Login to device
Safety information
Before starting operating the device, please review recommendations and precautions to minimize
the possibility of accidents. Safety precautions presented are supplementary and subject to the local
safety regulations. When various operations are executed on the device, the user must fully follow
the safety instructions and recommendations provided with the device.
General
Technical specifications
Input voltage range 7-57 VDC
Max power consumption 6 W
Bundled accessories specifications*
Power adapter No accessories
Order code dependant.
TSW212 must be used in compliance with any and all applicable national and international laws and
with any special restrictions regulating the utilization of the communication module in prescribed
applications and environments.

CE Declaration of Conformity
[BG] Bulgarian
С настоящото TELTONIKA NETWORKS декларира, че този TSW212 е в
съответствие със съществените изисквания и други разпоредби на
Директиви 2014/30/EU, 2014/35/EU, 2011/65/EU.
[HR] Croatian
Ovim TELTONIKA NETWORKS izjavljuje da je ovaj TSW212 u skladu s bitnim
zahtjevima i ostalim relevantnim odredbama Direktive 2014/30/EU, 2014/35/EU,
2011/65/EU.
[CZ] Czech
TELTONIKA NETWORKS erklærer hermed, at denne TSW212 er i
overensstemmelse med de væsentlige krav og andre bestemmelser i direktiv
2014/30/EU, 2014/35/EU, 2011/65/EU.
[DK] Danish
Hereby, TELTONIKA NETWORKS declares that this TSW212 is in compliance
with the essential requirements and other relevant provisions of Richtlijnen
2014/30/EU, 2014/35/EU, 2011/65/EU.
[NL] Dutch
Hereby, TELTONIKA NETWORKS declares that this TSW212 is in compliance
with the essential requirements and other relevant provisions of Richtlijnen
2014/30/EU, 2014/35/EU, 2011/65/EU.
[EE] Estonian
Käesolevaga kinnitab TELTONIKA NETWORKS seadme TSW212 vastavust
Direktiivide 2014/30/EU, 2014/35/EU, 2011/65/EU põhinõuetele ja nimetatud
direktiivist tulenevatele teistele asjakohastele sätetele.
[FI] Finish
TELTONIKA NETWORKS vakuuttaa täten että TSW212 tyyppinen laite on
Direktiivien 2014/30/EU, 2014/35/EU, 2011/65/EU oleellisten vaatimusten ja sitä
koskevien direktiivin muiden ehtojen mukainen.
[FR] French
TELTONIKA NETWORKS déclare par la présente que ce TSW212 est conforme
aux exigences essentielles et autres dispositions des Directives 2014/30/EU,
2014/35/EU, 2011/65/EU.
[DE] German
TELTONIKA NETWORKS erklärt hiermit, dass dieses TSW212 den
grundlegenden Anforderungen und anderen Bestimmungen der Richtlinien
2014/30/EU, 2014/35/EU, 2011/65/EU entspricht.
[GR] Greek
Η TELTONIKA NETWORKS δηλώνει ότι το παρόν TSW212 συμμορφώνεται με
τις βασικές απαιτήσεις και άλλες διατάξεις των Οδηγιών 2014/30/EU,
2014/35/EU, 2011/65/EU.
[HU]
Hungarian
A TELTONIKA NETWORKS kijelenti, hogy ez a TSW212 megfelel a 2014/30/EU,
2014/35/EU, 2011/65/EU irányelvek alapvető követelményeinek és egyéb
rendelkezéseinek.
[IE] Irish
Leis seo, dearbhaíonn TELTONIKA NETWORKS go gcomhlíonann an TSW212
seo bunriachtanais agus forálacha ábhartha eile Threoir 2014/30/EU,
2014/35/EU, 2011/65/EU.
[IT] Italian
Con la presente, TELTONIKA NETWORKS dichiara che questo TSW212 è
conforme ai requisiti essenziali e ad altre disposizioni pertinenti della Direttive
2014/30/EU, 2014/35/EU, 2011/65/EU.
[LV] Latvian TELTONIKA NETWORKS ar šo paziņo, ka šis TSW212 atbilst pamatprasībām un
citiem Direktīvas 2014/30/EU, 2014/35/EU, 2011/65/EU noteikumiem.
[LT] Lithuanian
Šiuo dokumentu UAB TELTONIKA NETWORKS deklaruoja, kad šis TSW212
atitinka esminius reikalavimus ir kitas 2014/30/EU, 2014/35/EU, 2011/65/EU
Direktyvų nuostatas.
[MT] Maltese
TELTONIKA NETWORKS b'dan tiddikjara li dan TSW212 jikkonforma mar-
rekwiżiti essenzjali u dispożizzjonijiet oħra tad-Direttivi 2014/30/EU,
2014/35/EU, 2011/65/EU.

[NO]
Norwegian
TELTONIKA NETWORKS erklærer herved at denne TSW212 er i samsvar med de
grunnleggende kravene og andre bestemmelser i Direktivene 2014/30/EU,
2014/35/EU, 2011/65/EU.
[PL] Polish
TELTONIKA NETWORKS niniejszym oświadcza, że niniejszy TSW212 jest zgodny
z zasadniczymi wymaganiami i innymi postanowieniami Dyrektyw 2014/30/EU,
2014/35/EU, 2011/65/EU.
[PT]
Portuguese
A TELTONIKA NETWORKS declara que esta TSW212 cumpre os requisitos
essenciais e outras disposições das Directivas 2014/30/EU, 2014/35/EU,
2011/65/EU.
[RO] Romanian
TELTONIKA NETWORKS declară prin prezenta că acest TSW212 este în
conformitate cu cerințele esențiale și cu alte dispoziții ale Directivelor
2014/30/EU, 2014/35/EU, 2011/65/EU.
[SK] Slovak
Spoločnosť TELTONIKA NETWORKS týmto vyhlasuje, že tento TSW212 spĺňa
základné požiadavky a ďalšie ustanovenia smerníc 2014/30/EU, 2014/35/EU,
2011/65/EU.
[SI] Slovenian TELTONIKA NETWORKS izjavlja, da je ta TSW212 skladen z bistvenimi
zahtevami in drugimi določbami Direktiv 2014/30/EU, 2014/35/EU, 2011/65/EU.
[ES] Spanish
TELTONIKA NETWORKS declara por la presente que este TSW212 cumple los
requisitos esenciales y otras disposiciones de las Directivas 2014/30/EU,
2014/35/EU, 2011/65/EU.
[SE] Swedish
TELTONIKA NETWORKS förklarar härmed att denna TSW212 uppfyller de
grundläggande kraven och andra bestämmelser i Direktiven 2014/30/EU,
2014/35/EU, 2011/65/EU.
FCC
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
This device may not cause harmful interference.1.
This device must accept any interference received, including interference that may cause2.
undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This

equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which
case the user will be required to correct the interference at his own expense.
FCC Caution: Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
ISED Canada
This device contains license-exempt transmitter(s)/receiver(s) that comply with Innovation, Science,
and Economic Development Canada's license-exempt RSS(s). Operation is subject to the following
two conditions:
This device may not cause interference;1.
This device must accept any interference, including interference that may cause undesired2.
operation of the device.
L'émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR
d'Innovation, Sciences et Développement économique Canada applicables aux appareils radio
exempts de licence. L'exploitation est autorisée aux deux conditions suivantes:
L'appareil ne doit pas produire de brouillage;1.
L'appareil doit accepter tout brouillage radioélectrique subi, mźme si le brouillage est.2.
NOM
La operación de este equipo está sujeta a las siguientes dos condiciones:
Es posible que este equipo o dispositivo no cause interferencia perjudicial.1.
Este equipo o dispositivo debe aceptar cualquier interferencia, incluyendo la que pueda causar2.
su operación no deseada.
Detailed compliance information is available at the following internet address: wiki.teltonika-
networks.com/view/Certificates.
This sign means that is necessary to read the User's Manual before you start using the device.
This sign on the package means that all used electronic and electric equipment should not be
mixed with general household waste.
Hereby, TELTONIKA NETWORKS declares that this TSW212 is in compliance with the essential
requirements and other relevant provisions of Directive 2014/53/EU. The full text of the EU
Declaration of Conformity is available at the following internet address:
https://wiki.teltonika-networks.com/view/TSW212_CE/RED
Hereby, TELTONIKA NETWORKS declares that the radio equipment type TSW212 is in
compliance with Radio Equipment Regulations 2017. The full text of the UK declaration of

conformity is available at the following internet address:
https://wiki.teltonika-networks.com/view/TSW212_UKCA.
Operating conditions
Operating temperature: -40° to +75° Celsius
Humidity should be in the range of 10% to 90% (non-condensing). Only use the device in dry
environments.
Out of direct sunlight
Away from heat source, corrosive substances, salts, and flammable gases
Attention: operation outside the permissible range can considerably shorten the service life of the
device.
Faulty and damaged products
Do not attempt to disassemble the device or its accessories.
Only qualified personnel must service or repair the device or its accessories.
If your device or its accessories have been submerged in water punctured or subjected to a
severe fall, do not use until they have been checked at an authorized service center.
Electrical safety
Only use approved accessories.
Do not connect with incompatible products or accessories.
It is recommended to ground devices with grounding terminals before connecting them to
power. Failure to ground appropriately might result in a shock hazard. The cross-sectional
area of the protective grounding conductor should be at least 1mm2.
Product handling
You alone are responsible for how you use your device and any consequences related to its
use.
Use of your device is subject to safety measures designed to protect users and their
environment.
Always treat your device and its accessories with care and keep it in a clean and dust-free
place.
Do not expose your device or its accessories to open flames, lit tobacco products, liquid,
moisture, or high humidity.
Do not drop, throw or try to bend your device or its accessories.
Do not use harsh chemicals, cleaning solvents, or aerosols to clean the device or its
accessories.
Do not paint your device or its accessories.
Do not attempt to disassemble your device (exemptions for devices that require disassembly
for SIM insertion) or its accessories: it does not contain any user-serviceable parts. For safety

reasons, the equipment should be opened only by qualified personnel.
Make sure to use ESD personal protective equipment while the equipment is serviced.
Do not use your device in an enclosed environment where heat dissipation is poor.
Prolonged use in such space may cause excessive heat and raise ambient temperature, which
will lead to the automatic shutdown of your device or the disconnection of the mobile network
connection for your safety. To use your device again after such a shutdown, cool it in a well-
ventilated place before turning it on.
Please check all national laws and local regulations for the disposal of electronic products.
Do not operate the device where ventilation is restricted.
Do not use or install this product near water to avoid fire or shock hazards.
Avoid exposing the equipment to rain or damp areas.
Arrange power and Ethernet cables so that they are not likely to be stepped on or have items
placed on them.
Ensure that the voltage and the rated current of the power source match the device’s
requirements. Do not connect the device to an inappropriate power source.
During a thunderstorm, no operations should be carried out on the device and cables.
The unit must be powered off where blasting is in progress and explosive atmospheres are
present or near medical life support equipment.
Do not leave your device and its accessories within reach of small children or allow them to
play with it. They could hurt themselves or others and could accidentally damage the device.
Your device contains small parts with sharp edges that may cause an injury choking hazard.
The device may become warm during regular use.
Front view
Back view
Connectors
POWER SOCKET PINOUT
RJ45 LED MEANING
SFP LED MEANING

Video Quick Start Guide
Need some help setting up your Teltonika Networks TSW212 managed switch? Watch our quick
start guide video and follow the step-by-step instructions to easily set up your new router for
operation.
Hardware installation
Login to device
1. Ensure the
Network
connection is
Enabled. Go to
Start —
Control Panel
— Network
and Internet —
Network and
Sharing
Center. Click
on the
Change
adapter
settings in
the left panel,
then right-
click on
Network
Adapter, and
select Enable.

2. Right-click
on Network
Adapter and
select
Properties.
Then select
Internet
Protocol
Version 4 and
click
Properties.
3. If not
selected,
check to Use
the following
IP address
and enter
192.168.1.5.
4. Click in the
Subnet mask
it should get
auto-filled
with
255.255.255.0.
Click OK.
5. To enter the
managed switch
's Web interface
(WebUI), type
http://192.168.1.2
into the URL field
of your Internet
browser.
2. When
prompted for
authentication
enter the
username admin
and enter the
password located
on the device
information
label/engraving.

6. After logging
in, you must set a
new password for
security reasons.
You will not be
able to interact
with the managed
switch ’s WebUI
until the default
password is
changed. The
new password
must consist of a
minimum of 8
characters.
Requirements:
one uppercase
letter, one
lowercase letter,
and one digit.
