Tempest Cyclone G4 User manual

Cyclone G4 User Manual 1
User Manual
Cyclone G4
Revision 01.5
May 2017
© Tempest Lighting, Inc.

Cyclone G4 User Manual 2
Table of Contents
Table of Contents........................................................................................................................................................................................ 2
Approvals –North America.................................................................................................................................................................... 5
Approvals –Europe ................................................................................................................................................................................ 6
Approvals –China ................................................................................................................................................................................... 7
Introduction ................................................................................................................................................................................................ 8
IMPORTANT: Safety Advisories.............................................................................................................................................................. 8
Installation................................................................................................................................................................................................... 9
Dimensions, Rigging Points, and Maximum Projector Dimensions/Power ......................................................................................... 9
Access Clearance .............................................................................................................................................................................. 10
Airflow Clearance ............................................................................................................................................................................. 10
Snow Clearance ................................................................................................................................................................................ 10
Mounting Hardware Options ............................................................................................................................................................... 11
Mounting Bolts ................................................................................................................................................................................. 11
Mounting Options –Unistrut Kit ..................................................................................................................................................... 11
Mounting Options –Stacking Kit ..................................................................................................................................................... 12
Mounting Options –Swivel Stacking Kit.......................................................................................................................................... 12
Cyclovator 2 Tilt Kit............................................................................................................................................................................... 13
SAFETY WARNING............................................................................................................................................................................. 13
Cyclovator –Unistrut Mounting Rails.............................................................................................................................................. 13
Cyclovator –Inlet Cowl .................................................................................................................................................................... 13
Fixing the Cyclovator in Place .......................................................................................................................................................... 14
Mounting the Enclosure................................................................................................................................................................... 15
Setting the Show Position Stop........................................................................................................................................................ 16
Wiring the Enclosure ................................................................................................................................................................................ 17
Power Wiring ........................................................................................................................................................................................ 17
SAFETY NOTICE ................................................................................................................................................................................. 17
Electrical Standards .......................................................................................................................................................................... 17
Wiring Access.................................................................................................................................................................................... 18
One or Two Power Circuits? ............................................................................................................................................................ 19
Single Feed Power Termination....................................................................................................................................................... 20
Split Feed Power Termination ......................................................................................................................................................... 20
Wire Path .......................................................................................................................................................................................... 20
Single or Three-Phase?..................................................................................................................................................................... 20
Three phase Split Feed..................................................................................................................................................................... 20
AC Supply Voltage............................................................................................................................................................................. 20
North America, 208V Single Feed.................................................................................................................................................... 21

Cyclone G4 User Manual 3
North America, 208V Split Feed ...................................................................................................................................................... 22
North America –120/208V Three Phase, Single Feed ................................................................................................................... 23
North America –120/208V Three Phase, Split Feed...................................................................................................................... 24
International, 230V Single Feed....................................................................................................................................................... 25
International, 230V Split Feed ......................................................................................................................................................... 26
International, 230/400V Three-Phase, Single Feed........................................................................................................................ 27
International, 230/400V Three-Phase, Split Feed .......................................................................................................................... 28
Remote Monitoring Connections ........................................................................................................................................................ 29
RS485 (DMX/RDM) Cable Terminations.......................................................................................................................................... 30
Projector Power Control using DMX512 ......................................................................................................................................... 30
DMX/RDM Network, using JESE RDM-TRI....................................................................................................................................... 31
Digital Enclosure Control.......................................................................................................................................................................... 32
Schematic.............................................................................................................................................................................................. 32
DEC4 Main Functions ........................................................................................................................................................................... 33
Factory Settings –Data Modes ............................................................................................................................................................ 33
Other Operating Modes ....................................................................................................................................................................... 34
TEMP Mode ...................................................................................................................................................................................... 34
Monitor Mode .................................................................................................................................................................................. 34
Control Mode.................................................................................................................................................................................... 34
Service Mode .................................................................................................................................................................................... 34
DEC4 Control Parameters .................................................................................................................................................................... 35
Control Interface .............................................................................................................................................................................. 36
User Interface LCD Display............................................................................................................................................................... 37
Control Interface Operation ............................................................................................................................................................ 37
Control Menu........................................................................................................................................................................................ 38
Set DMX Options .............................................................................................................................................................................. 38
Set Temp Units ................................................................................................................................................................................. 39
Set Temp Ranges .............................................................................................................................................................................. 39
Set Lamp On Point............................................................................................................................................................................ 39
Reset Lamp Hours............................................................................................................................................................................. 39
Status Display.................................................................................................................................................................................... 40
DEC4 Firmware Updates .......................................................................................................................................................................... 41
Indirect Firmware Updates .................................................................................................................................................................. 41
Requirements ................................................................................................................................................................................... 41
Installation Procedure...................................................................................................................................................................... 41
Mounting the Projector............................................................................................................................................................................ 46
Enclosure Configuration....................................................................................................................................................................... 46
Landscape Configurations................................................................................................................................................................ 46

Cyclone G4 User Manual 4
Portrait Configurations..................................................................................................................................................................... 46
Projector-specific Mounting ................................................................................................................................................................ 47
Mount the Projector –Tabletop...................................................................................................................................................... 47
Mount the Projector –Ceiling ......................................................................................................................................................... 47
Mount the Projector –Portrait........................................................................................................................................................ 47
Connect Projector and Aux Equipment........................................................................................................................................... 48
Projector-specific Mounting ................................................................................................................................................................ 48
Panasonic PT-DZ21K Family ............................................................................................................................................................. 48
Christie J-Series/Roadster Family .................................................................................................................................................... 49
Christie Boxer –Portrait Mode........................................................................................................................................................ 49
Barco HDQ ........................................................................................................................................................................................ 50
These projectors (mounted in Cyclone 8500 enclosures), require some modification prior to installation................................... 50
Routine Maintenance ............................................................................................................................................................................... 51
Clean Port Glass................................................................................................................................................................................ 51
Check Filter ....................................................................................................................................................................................... 51
Check Temperature/Humidity Sensor............................................................................................................................................. 52
For After Sales Support .................................................................................................................................................................... 52
Troubleshooting........................................................................................................................................................................................ 53
Warranty ................................................................................................................................................................................................... 55
Appendix –TEMP Protocol....................................................................................................................................................................... 56
Physical Layer........................................................................................................................................................................................ 56
Developer’s Guide ................................................................................................................................................................................ 56

Cyclone G4 User Manual 5
Approvals –North America
This is to certify that the following products:
55.xxx.US Series Cyclone G4 Projector Enclosures
Have been tested and approved to standards UL 508 (electrical) and UL 50 (environmental), as NEMA 3R enclosures,
for use in the United States and Canada.
This declaration is made by the manufacturer
Tempest Lighting, Inc.
11845 Wicks Street, Sun Valley, CA 91352, USA
This declaration is based on tests that were conducted on the submitted samples of the above mentioned products.
Listing Report No. 3198609LAX-001a refers.
Dated: July 1st , 2016
Signature . . . . . . . . . . . . . .
Tempest Lighting Inc

Cyclone G4 User Manual 6
Approvals –Europe
CERTIFICATE AND DECLARATION OF CONFORMITY
FOR CE MARKING
Tempest Lighting, Inc.
11845 Wicks Street, Sun Valley, CA 91352 , USA
t: [phone] f: [phone] e: [e-mail]
www.tempest.biz
Tempest Lighting, Inc. declares that t heir
Cyclone G4 Projector Enclosure Series 55.xxx.xx
complies with the Essential Requirements of the following EU Directives:
Low Voltage Directive 2006/95/EC Test Report G4.51.LVD
Electromagnetic Compatibility Directive 2004/108/EC Test Report G4.51.EMC
and further conforms with the following EU Harmonized Standards:
EN 60065 : 2002 Test Report 60065.G4.51.01
EN 60529:2001-2002 Test Report 60529.G4.51.02
EN 61000-6-3:2007+A1:2011 Test Report 61000.G4.51.03
EN61000-6-1:2007 Test Report 61000.G4.51.03
EN55015:2006+A2:2009 Test Report 61000.G4.51.03
Dated: 1s t July 2016
Position of signatory: President
Name of Signatory: Tim Burnham
Signed below:
on behalf of Tempest Lighting, Inc.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Cyclone G4 User Manual 7
Approvals –China

Cyclone G4 User Manual 8
Introduction
Thank you for purchasing a Tempest enclosure! We have worked hard to provide you with the very
best product available for its purpose, and we shall continue to do everything possible to ensure
that it works well for you for many years to come.
Please read this manual before starting work!
In the event of difficulty, please contact your Tempest reseller or Tempest direct:
[email protected]
[phone]
We will do everything we can to help you get the very best results from your Tempest enclosure.
IMPORTANT: Safety Advisories
All installation and rigging work done must where applicable be designed and built in
accordance with norms and standards of the local authority having jurisdiction of the
installation site. It is the responsibility of the installer to obtain such approvals as may be
required to achieve full compliance.
All electrical work must be carried out by a suitably licensed electrical contractor in full
compliance with local electrical standards.
Lifting: some enclosures and the equipment inside them may be heavy. Use properly
rated lifting equipment where appropriate and never attempt to carry out work with
fewer than the number of workers needed to lift safely.
It is the responsibility of the installer to ensure that all local building, safety and electrical
codes are strictly adhered to in the installation of this enclosure. Tempest Lighting, Inc.,
its employees and agents are in no way responsible for damage arising from failure to
follow either the instructions in this manual or building, safety and electrical codes
prevailing at the installation location.
Do not attempt to install or operate the enclosure before fully reading and understanding
this manual
Never allow anyone who has not read this manual to open the enclosure or perform
maintenance on the projector within.
Never leave the enclosure unattended when open.
Always make sure all bolts and latches are tight and safety locks are in place after
performing any form of maintenance on the unit.
Do not open any electrical boxes until power has been shut off to all supply lines to the
enclosure (including the one powering the projector).
Do not open the enclosure in wet weather.

Cyclone G4 User Manual 9
Installation
Dimensions, Rigging Points, and Maximum Projector Dimensions/Power
Model
Projector Type
Format
DIM A
DIM B
DIM C
DIM D
DIM E
Weight
55.200
Panasonic Pt-DZ21K
Landscape
49.4”/1254
33.4”/848
19.4/493
47”/1194
31”/787
140lb/64kg
55.200P
Panasonic Pt-DZ21K
Portrait
49.4”/1254
19.4/493
33.4”/848
47”/1194
17”/432
150lb/68kg
55.220
Barco HDX
Landscape
49.4”/1254
29.4”/747
23.4”/594
47”/1194
27”/659
160lb/73kg
55.230
Christie CP2215
Landscape
49.4”/1254
29.4”/747
27.4”/696
47”/1194
27”/659
170lb/77kg
55.240
Christie Roadster (J)
Landscape
53.4”/1356
33.4”/848
25.4/646
51”/1295
31”/787
190lb/86kg
55.300
Christie Boxer
Landscape
57.4”/1457
33.4”/848
23.4”/594
55”/1397
31”/787
162lb/74kg
55.300P
Christie Boxer
Portrait
57.4”/1457
23.4”/594
33.4/848
55”/1397
21”/533
175lb/80kg
55.350
Barco HDF
Landscape
53.4”/1356
35.4”/900
29.4”/747
51”/1295
33”/838
200lb/91kg
55.400
Christie Roadie 45K
Landscape
69.4”/1763
41.4”/1053
32.4”/823
67”/1702
39”/991
240lb/109kg
55.450
Christie CP2230
Landscape
69.4”/1763
37.4”/951
35.4”/899
67”/1702
35”/889
245lb/111kg
55.45B
Christie Ballast
Landscape
31.4”/790
24.4”/610
26.4”/660
29”/737
22”/559
65lb/30kg
55.500
Barco HDQ
Landscape
69.4”/1763
37.4”/951
35.4”/899
67”/1702
35”/889
245lb/111kg
We are adding models all the time –check our web site for submittal drawings or consult factory for models not shown here
Rigging Points:
M12-1.75 x 38 (bolts supplied)
Cyclone 55.200-3xx 4 points top and bottom.
Cyclone 55.4xx and up 6 points top and
bottom.

Cyclone G4 User Manual 10
Access Clearance
Observe these minimum access clearances shown around
your enclosure
Airflow Clearance
Observe the minimum clearances shown around your
enclosure
Snow Clearance
In areas where snow is likely, make sure the base of the
enclosure is at least 24” [60cm] above highest potential
snow drift level.
H
3”/75mm
60cm/24in

Cyclone G4 User Manual 11
Mounting Hardware Options
Mounting Bolts
Each Enclosure must be mounted with FOUR points.
All mountings must be made using the four M12
threaded holes on the top or bottom of the
enclosure.
Use an 8mm hex key to secure the M12 socket cap
screws provided.
Tempest recommends the use of stainless steel
mounting hardware.
Make sure the inlet filter has at least 75mm/3in
clearance below.
IMPORTANT SAFETY NOTICE
Installer must ensure that all mounting points are secure
and conform to local safety regulations. Tempest Lighting
Inc. accepts no responsibility for damage or injury arising
from inappropriate or unsafe installation.
Mounting Options –Unistrut Kit
If mounting positions for the corner bolts are not
convenient, use the Unistrut Kit (55.UR.xxx) to add two
Unistrut rails and Unistrut spring nuts to the top or
bottom of the enclosure.
Using the spring nuts, the enclosure may now be
attached at any point along the Unistrut rails.
8mm
Mounted from Above:
M12-1.75 bolts
Use 8mm hex key
Plastic plugs
Mounted from Below:
Plastic plugs
M12-1.75 bolts
Use 8mm hex key
Unistrut Rails may be
mounted above or
below

Cyclone G4 User Manual 12
Mounting Options –Stacking Kit
Cyclone G4 may be stacked up to four units high, using
the 51.SK stacking Kit. You will need the total number of
Cyclones to be stacked, minus one stacking kit(s).
So for a stack of three enclosures, order 3-1=2 stacking
kits.
Note: Cyclone enclosures must be of the same model to
stack in this way.
51.SK Stacking Kit (set of four, for one enclosure)
Mounting Options –Swivel Stacking Kit
Cyclone G4 may be stacked two units high, with beams up
to 60°apart, using the Swivel Stacking Kit. Enclosures
must be the same model.
This is very useful for edge-blending across a wide area
with a limited number of rigging positions.
51.SS.xxx (where xxx is the Cyclone model number) Swivel
stacking kit for two G4 Cyclone enclosures
The Swivel Stacking Kit must be ordered with the Cyclone
enclosures it will be used with. Tempest will add more
fixing points to the enclosure frame required to attach the
Swivel Stacking Kit hardware.
Bolt top leg to M12
socket each corner
Bolt bottom leg to M12
socket each corner
Join top and bottom
sections together with
Clevis pins
Mount Swivel Brackets to
M12 threaded inserts in
enclosure frames with
the M12 bolts provided.
All four brackets are
identical
Join the radiused slots
using the Carriage
bolts and lock nuts
provided.
Adjust desired angle
and tighten nuts

Cyclone G4 User Manual 13
Cyclovator 2 Tilt Kit
SAFETY WARNING
IT IS A SAFETY REQUIREMENT that Cyclone enclosures be
horizontal any time you slide the projector out for
service. IT IS DANGEROUS to do this if the enclosure is not
horizontal, and MAY CAUSE DAMAGE TO THE PROJECTOR
OR INFLICT SERIOUS INJURY TO PERSONNEL. Tempest
Lighting Inc., its agents and employees, will not be liable
for consequences of failure to heed this safety warning.
Cyclovator 2 may be used for any G3 or G4 Cyclone
enclosure.
The enclosure may be installed at ground level, projecting
up (up onto a building, for example)…
…or, on a rooftop, projecting downwards.
In either case, the maximum tilt angle is 60°.
Cyclovator –Unistrut Mounting Rails
When Cyclone G4 is used with the Cyclovator Tilt Kit, the
Unistrut Kit (55.UR.xxx) is required to attach the
enclosure to the Cyclovator.
‘xxx’ is the Cyclone model number.
Cyclovator –Inlet Cowl
When Cyclone G4 is used with the Cyclovator Tilt Kit, with
a tilt angle greater than 40°, use the inlet cowl 55.IC.xx to
protect the inlet filter from weather.
‘xx’ is the filter size in inches –15 for 55.200-350, 22 for
55.400 and up.
Stainless Steel Unistrut
Rail Kit 55.UR.xxx
Inlet Cowl 55.IC.xx

Cyclone G4 User Manual 14
Fixing the Cyclovator in Place
The Cyclovator MUST be firmly attached to the ground, or
a suitable mounting structure, using four stainless steel
M12 (or US ½” size) bolts or anchors (not supplied).
Suitable substrates include concrete pads, steel
frameworks, roof beams. All mountings must comply with
all relevant building and safety norms in the jurisdiction
of the final installation. It is the responsibility of the
installer to obtain approval from a structural engineer or
other competent person for all such installations, and to
adhere strictly to local building and safety codes at all
times.

Cyclone G4 User Manual 15
Mounting the Enclosure
Make sure that the Unistrut rails are attached securely to
the 4 (or 6) M12 threaded sockets on the bottom of the
enclosure frame.
Set the Cyclovator to its horizontal position:
1. Loosen the two locking knobs (a)
2. Turn the crank handle (b) until the Cyclovator
saddle is horizontal
3. Tighten the two locking knobs (a)
Align the channel spring nuts (c):
4. The distance (d) between the channel nuts
should be the same as dimension E in the
installation page (the distance between centers
of the Unistrut channels)
5. Loosen the channel nut
bolts and align the
channel nuts with their
long sides parallel with
the end of the
Cyclovator saddle:
6. Carefully set the Cyclone enclosure on the
Cyclovator saddle, so that the channel nuts are
INSIDE the Unistrut rails.
7. PUSH UP and tighten the four M12 channel nut
bolts, so that the channel nuts lock in the
Unistrut channels.
8. Loosen the locking knobs and turn the crank
handle to test movement.
Unistrut Rails
Fixing Bolts (4 or 6)
(a)
(b)
(a)
(c)
(d)
Cyclovator Saddle
Cyclovator Base

Cyclone G4 User Manual 16
Steep Angles:
For steep projection angles, loosen the four channel nut
bolts and carefully slide the enclosure in the direction
that will be ‘down’.
The center of gravity will still be roughly centered in show
position, but you will have to work a bit harder to crank
the enclosure up to its show trim!
It is important to use the Inlet Cowl accessory for angles
above 40°.
Setting the Show Position Stop
Cyclovator gives you a locator for your show position, for
accurate show positioning.
With the Cyclovator in Show position:
1. Loosen the Locking Collar set screw (a)
2. Slide the Locking Collar firmly against the Acme
Nut Plate (b)
3. Tighten the Locking Collar nut (a)
4. You now have two reference locations:
Horizontal
Show
ALWAYS MAKE SURE THAT BOTH LOCKING KNOBS (c) ARE
LOOSE WHEN RAISING/LOWERING THE CYCLOVATOR,
AND TIGHT WHEN IN SHOW OR SERVICE POSITION.
(a)
(b)
(c)

Cyclone G4 User Manual 17
Wiring the Enclosure
Power Wiring
SAFETY NOTICE
All power wiring must be performed by a competent electrician, appropriately licensed in the jurisdiction where the installation takes
place. All electrical work must be done in full compliance with all electrical and safety norms applicable to the installation site. Isolate
all power feeds before opening the enclosure.
Tempest Lighting, Inc., its employees and agents will not be held responsible for damage or injury caused by disregarding this notice.
Electrical Standards
Important:
Enclosure model numbers including .US are for use in countries using US and Japanese style electrical systems:
200-208VAC 50/60Hz
Enclosure model numbers including .IN are for use in countries using European style electrical systems:
220-250VAC 50/60Hz
Note:
(1) Fans and Heaters are rated 200-250V
(2) Electronics are autosensing for any voltage 90-265VAC, 50/60Hz

Cyclone G4 User Manual 18
Wiring Access
Locate the two Conduit entry holes on the underside of
the enclosure:
Conduit openings accept PG21 (International) and ¾” NPT
(North America) conduit fittings.
Use permanent or flexible, outdoor rated, conduit to
connect power and signal cables to your Cyclone
enclosure.
ALWAYS RUN POWER AND SIGNAL CABLES IN SEPARATE
CONDUITS.
NOTE: Layout of Cyclone models may differ slightly
Open the back door, and remove the DEC4 Controller
cover. Identify the following parts:
Aux Equipment Power Outlet (dual C13)
AC Terminal Block
Earth/Ground Terminal
Projector Power Outlet (types vary)
DEC4 Motherboard
DEC4 Daughter Board(s)
Up to 3 daughter boards: types include Fan Control,
RS485 Comms, Ethernet, AC Assist Relay
DEC4 Controller
Cover
Exhaust Fan
Internal
Homogenizing
Blower
Cable
Management
Track
Conduit Entry:
SIGNAL
Conduit Entry:
AC POWER

Cyclone G4 User Manual 19
One or Two Power Circuits?
Tempest enclosures may be wired on single or double
circuit supplies. On a single feed, both enclosure and
projector are permanently on. With a split (double) feed
supply, you can switch off the projector when not in use,
while the enclosure continues to protect it 24/7.
Tip: most people use single feed.
Single Feed
Enclosure and projector are permanently on.
Enclosure and Projector must be rated for the
same voltage.
Supply must be rated for projector current plus
150 watts.
Supply must be permanently ON.
Split feed
Enclosure power must be permanently ON.
Projector power may be switched off.
Enclosure power must be rated for 650 watts.
Projector power must be rated for the projector (see
projector manual).
Projector and enclosure power must be same voltage.
For single feed wiring, no modification to the DEC4
Controller motherboard is needed.
IMPORTANT:
For split feed wiring, use a side cutter to cut both AC links at both
ends:
1
1
2
Single Feed
Split Feed

Cyclone G4 User Manual 20
Single Feed Power Termination
Connect Earth/Ground wire to Ground Terminal
Connect Live and Neutral to the terminals marked
FEED
Split Feed Power Termination
STOP! Did you cut the power links? See above.
Connect Earth/Ground wire to Ground Terminal
Connect Enclosure feed to the terminals marked FEED
Connect Projector feed to the terminals marked SPLIT
Wire Path
Pull incoming AC supply wires through the plastic
grommets shown here.
For clarity, the following diagrams do not show factory
wiring.
Single or Three-Phase?
Most Cyclone enclosures require a single phase 200-
240VAC AC supply (208V –2 hots @120V in US).
In just a few cases, presently:
Some high-output Barco projectors, eg HDQ
Some Christie projectors with external ballast,
eg Roadie 45K, CP4230
…a 3-phase AC supply is required.
Three phase Split Feed
IMPORTANT: Three-phase systems with split feed MUST be factory
configured. You CANNOT change a 3-phase Cyclone between single and
split feed in the field.
AC Supply Voltage
Tempest Cyclone enclosures require supply voltage in the
nominal range 200-250VAC, 50/60Hz.
Tempest G4 enclosures are very tolerant of supply
voltage variations:
DEC4 controller has a universal power supply
and operates on 90-265VAC
Enclosure fans and heaters are rated 200-
250VAC. Fans are over-dimensioned to cool
adequately down to 200V, and heaters
compensate thermostatically by increasing duty
cycle on lower supply voltages.
