Temtop S1 User manual

S1
User Manual

PM2.5 (Particulate Matter 2.5) refers to fine particles with diameter of 2.5
micrometers or less. Due to its tiny size, PM2.5 can be absorbed into
bloodstream and the lungs, which may cause eye and nose irritation, cough,
asthma, emphysema, lung disease, heart attacks, cancer and etc.
Temperature & Humidity may often be ignored however they do have a significant
impact on individual’s well-being , comfort, health and safety as well as your
property. High humidity may lead to an increase in household air pollutants
especially the biological contaminants such as molds, bacteria, viruses and dust
mites; cold, low humidity may cause nosebleeds, skin and respiratory irritations,
dyspnea, static electricity and etc.
AQI (AirQuality Index) is a quick guide showing howclean or pollutedthe airis,
using a range from 0 to 500, where higher index values indicate higher levels of
air pollution and higher risks to health. There are six pollutants for AQI in US
standard: PM2.5/10, O3, SO2, NO2, CO, where Temtop only focus on PM2.5/10
and follows the US EPA Standards to compute AQI.
1
Factors Aecting Air Quality
AQI

★Do not place detector in heavily polluted environments for a long time; or it
may cause damages to the sensor.
★Do not use the detector in a humid environment for a long time to ensure the
measurement accuracy.
★Do not cover the vents of the detector, and do not let flu enter the detector,
otherwise the particle sensor may not work properly.
★This product is only used to monitor the health of the indoor environment and
cannot be used as a professional measurement tool.
★ Do not disassemble the device. In the event of a defect, please contact your
dealer. The dealer will contact the Service Centre and can send the device in
to be repaired, if necessary.
★ Children should only use the device under adult supervision. Keep packaging
material, like plastic bags and plastic film, out of the reach of children,as they
pose a choking hazard.
2
Important

① Work mode ②PM2.5 &AQI level ③Temperature &Humidity level
④Battery level &Charging status ⑤Health level display area
⑥Built-in magnet ⑦Vents ⑧Air inlet
3
Overview
①
②
③⑥
⑦
⑧
④
⑤

⑨ Power button ⑩ air outlet ⑪ USB port ⑫ Mode button
⑬ Temperature and humidity detection port
⑭ Bracket (Optional)
4
Overview
⑨
⑬
⑫
⑩
⑪ ⑭

5
Specifications
Model
PM2.5
Temperature*
Humidity
Dimension
Battery Capacity
S1
Sensor: Laser PM sensor
Measuring range: 0-999 µg/m³
Resolution: 0.1 µg/m³
Accuracy: ±5 µg/m³ (0-50 µg/m³)
±10 µg/m³ (50-100 µg/m³)
±10% (100-500 µg/m³)
Measuring range: -10-60°C
Resolution: 0.1°C,Accuracy: ±0.5°C
Measuring range: 0-99.9% RH
Resolution: 0.1% RH,Accuracy: ±3% RH
3.5*2.7*0.7 (inches)
800mAh

6
Specifications
Work Mode
Battery Life
Input
Display
Weight
Operation Environment
Note: The above data are from Temtop Laboratory.
Smart Mode (automatic)/
Real-time mode (about 1.5s)/Interval Mode (5min)/
Power-saving Mode (30min)
≥14hr (Real-time mode)
≥7Days (Power-saving Mode)
5V/1A
Segment code screen 3.3inches
About 110g
-10-60°C/0-99.9%
*1) When the product is charged, the temperature will have an error of ±0.5°C, and it will recover in about
10 minutes after full change.
2) When the temperature measurement environment suddenly changes, and the temperature dierence
is large, it takes 3 to 5 minutes Adaptation time.

●Indoor use: Keep the room/area airtight for 10 minutes to obtain more accurate results.
●If battery level shows , please charge the detector promptly to avoid eects during use
(also chargeable when turned o).
Warning !
7
Operation

8
Press 3s to turn ON/OFF the S1 monitor.
Long press 3S
1. On/O

9
Mode display
① The S1 has four working modes, and you can switch the working mode by pressing the
Mode button after power on.
Smart mode
Embedded sensor automatic control algorithm, taking into account the dynamic balance
of data detection and product battery life, to provide users with a good experience!
Real-time mode
Real-time collection of temperature, humidity and particulate matter data on the device;
Note: The data is collected about 1.5 seconds for particulate matter, and about 5 seconds for
temperature and humidity.
2.Display
A
R
Mode Button:
1.Short press to switch between the
work mode (4 dierent types)
2.Long press to switch between the
temperature unit (
°F / °C )

1) When the battery is displayed as
empty, please charge it in time, and
the charging icon will be displayed
when charging.
2)When the battery power is extremely
low,the battery icon will flash 3 times
and then shut down.
Power display
Charging icon
USB interface
10
⑤ Interval Mode (5min)
1) PM2.5 Sensor works every 5 minutes;
2) The temperature and humidity are still maintained for 1 minute to refresh.
Power-saving Mode (30min)
1) PM2.5 Sensor works every 30 minutes;
2) The temperature and humidity are still maintained for 1 minute to refresh.
② S1 monitoring function
30

11
Air Quality Parameter for Reference
Pollutant
PM2.5(µg/m³)
AQI*
Status GOOD
0-12
0-50
FAIR
12.1-55.4
51-150
POOR
＞55.4
＞150
*Refers to EPA Standards.

12
Place The Scene
① Directly place ②Bracket placement ③Magnetic placement

FAQ (frequently asked questions)
Q: Why is the PM2.5 reading constantly changing?
A: As PM2.5 concentration in the environment is changing all the time not
only due to environment factors like changes in airfow, humidity, wind
direction and etc. but also due to common pollutant sources like smoking,
cooking; exhaust emissions from vehicles, smoke from burning coal/chimneys/
furnaces and etc. All these may infuence the PM2.5 concentrations and
give differences in the readings.
Q: Why is the test result abnormal or below normal?
A: ① Please check whether the air inlet or outlet has been covered or fuid
is in.
② Gently shake the detector during detection to increase the interaction
with surrounding air.
③ The sensor may be not recovered, Please place the detector outdoors
for ventilation.
Q: Why is data reading unstable?
A: As the airflow in the environment changes, the distribution of the
measured substance concentration may not be uniform. It is temporarily
recommended to try again in an environment with stable airflow.
13

14
What's Included
● Detector x 1
● USB Cable x 1
● User Manual x 1
● Bracket or accessories set x1 (Optional)

15
Warranty
Before return or delivery for repair, please check if the following items are ready:
* Including invoice, order number and etc.
Temtop warranty does NOT include:
●
Malfunction or damages caused by artificial damage or modification.
●
Other deliberate damages.
Temtop warrants the included detector for 1 year from the date of original purchase. The item
can be exchanged or returned within 30 days if the defect is not caused by artificial damage.
Detector &
Accessories
Complete
Package
Proof of
Purchase*
Gift (if any)
√
√
√
Return
Exchange
Repair
√
√
√
√
√
√

Elitech Technology, Inc.
2528 Qume Dr, Ste 2
San Jose, CA 95131 USA
Tel: [phone]
Sales: [email protected]
Website: www.temtopus.com
Elitech Brasil Ltda
R. Dona Rosalina, 90 - Igara, Canoas - RS,
92410-695, Brazil
Tel: [phone]
Sales: [email protected]
Website: www.elitechbrasil.com.br
Elitech (UK) Limited
Unit 13, Greenwich Centre Business Park
53 Norman Road, London, SE10 9QF UK
Tel: [phone]
Sales: [email protected]
Website: www.elitecheu.com
V1.0
