Terex SX15015H-101 Installation and operating manual

Service and Repair Manual
Serial Number Range
SX™-150
from SX15015H-101
to SX15016H-
499
This manual includes:
Repair
procedures
Fault Codes
Electrical and
Hydraulic Schematics
from SX150H-500
to SX150H-
611
For detailed maintenance
procedures, refer to the
appropriate Maintenance
Manual for your machine.
Part No. 1268496GT
Rev B
December 2019

Service and Repair Manual December 2019
Introduction
ii SX™-150 Part No. 1268496GT
Intr od ucti o n Intr od ucti o n
Important
Read, understand and obey the safety rules and
operating instructions in the appropriate Operator's
Manual on your machine before attempting any
procedure.
This manual provides troubleshooting and repair
procedures for qualified service professionals.
Basic mechanical, hydraulic and electrical skills are
required to perform most procedures. However,
several procedures require specialized skills, tools,
lifting equipment and a suitable workshop. In these
instances, we strongly recommend that
maintenance and repair be performed at an
authorized Genie dealer service center.
Compliance
Machine Classification
Group B/Type 3 as defined by ISO 16368
Machine Design Life
Unrestricted with proper operation, inspection and
scheduled maintenance.
Technical Publications
Genie has endeavored to deliver the highest
degree of accuracy possible. However, continuous
improvement of our products is a Genie policy.
Therefore, product specifications are subject to
change without notice.
Readers are encouraged to notify Genie of errors
and send in suggestions for improvement. All
communications will be carefully considered for
future printings of this and all other manuals.
Contact Us:
Internet: www.genielift.com
E-mail: [e-mail]
Find a Manual for this Model
Go to http://www.genielift.com
Use the links to locate Service Manuals,
Maintenance Manuals, Service and Repair
Manuals, Parts Manuals and Operator's Manuals.
Copyright © 2015 by Terex Corporation
1268496GT Rev B, December 2019
First Edition, Second Printing
Genie is a registered trademark of Terex South Dakota, Inc. in
the U.S.A. and many other countries.
"SX" is a trademark of Terex South Dakota, Inc.

December 2019 Service and Repair Manual
Introduction
Part No. 1268496GT SX™-150 iii
Revision History
Revision Date Section Procedure / Page / Description
A 9/2015 Initial Release
A1 9/2016 Introduction Serial Number Legend
A2 6/2017 Repair 8-3, 8-4, 8-5
Fault Codes Fault Code Source
A3 10/2018 Repair 8-3A, 8-4A
Schematics Electrical schematics
A4 12/2018 Specifications Machine Torque Specifications
B 12/2019 Cover Add ending serial break
Reference Examples:
Electronic Version
Click on any content or procedure in the Table of Contents to view
the update.
Section – Repair Procedure, 4-2
Section – Fault Codes, All charts
Section – Schematics, Legends and schematics

Service and Repair Manual December 2019
Introduction
iv SX™-150 Part No. 1268496GT
Serial Number Legend
To August 31,
2016
1 Model
2 Model year
3 Facility code
4 Sequence number
5 Serial number (stamped on chassis)
6 Serial label (located under cover)
From September 1, 2016
1 Model
2 Facility code
3 Sequence number
4 Serial label (located under cover)
5 Serial number (stamped on chassis)

December 2019 Service and Repair Manual
Safety Rules
Part No. 1268496GT SX™-150 v
Section 1 Safet y R ul es
Danger
Failure to obey the instructions and safety rules in
this manual and the appropriate Operator's Manual
on your machine will result in death or serious
injury.
Many of the hazards identified in the operator's
manual are also safety hazards when maintenance
and repair procedures are performed.
Do Not Perform Maintenance
Unless:
You are trained and qualified to perform
maintenance on this machine.
You read, understand and obey:
•manufacturer's instructions and safety rules
•employer's safety rules and worksite
regulations
•applicable governmental regulations
You have the appropriate tools, lifting
equipment and a suitable workshop.

Service and Repair Manual December 2019
Safety Rules
vi SX™-150 Part No. 1268496GT
Personal Safety
Any person working on or around a machine must
be aware of all known safety hazards. Personal
safety and the continued safe operation of the
machine should be your top priority.
Read each procedure thoroughly. This
manual and the decals on the machine,
use signal words to identify the following:
Safety alert symbol
—used to
alert
personnel to potential personal
injury hazards. Obey all safety
messages that follow this symbol
to avoid possible injury or death.
Indicates a imminently hazardous
situation which, if not avoided, will
result in death or serious injury.
Indica
tes a potentially hazardous
situation which, if not avoided,
could result in death or serious
injury.
Indicates a potentially hazardous
situation which, if not avoided,
may cause minor or moderate
injury.
Indicates a potentially hazardous
situation
which, if not avoided,
may result in property damage.
Be sure to wear protective eye wear and
other protective clothing if the situation
warrants it.
Be aware of potential crushing hazards
such as moving parts, free swinging or
unsecured components w
hen lifting or
placing loads. Always wear approved
steel
-toed shoes.
Workplace Safety
Any person working on or around a machine must
be aware of all known safety hazards. Personal
safety and the continued safe operation of the
machine should be your top priority.
Be sure to keep sparks, flames and
lighted tobacco away from flammable and
combustible materials like battery gases
and engine fuels. Always have an
approved fire extinguisher within easy
reach.
Be sure that all tools and working areas
are p
roperly maintained and ready for
use. Keep work surfaces clean and free of
debris that could get into machine
components and cause damage.
Be sure any forklift, overhead crane or
other lifting or supporting device is fully
capable of supporting and stab
ilizing the
weight to be lifted. Use only chains or
straps that are in good condition and of
ample capacity.
Be sure that fasteners intended for one
time use (i.e., cotter pins and self
-locking
nuts) are not reused. These components
may fail if they are
used a second time.
Be sure to properly dispose of old oil or
other fluids. Use an approved container.
Please be environmentally safe.
Be sure that your workshop or work area
is properly ventilated and well lit.

December 2019
Table of Contents
Part No. 1268496GT SX™-150 vii
Introduction Introduction...........................................................................................................ii
Important Information ............................................................................................. ii
Find a Manual for this Model .................................................................................. ii
Revision History..................................................................................................... iii
Serial Number Legend .......................................................................................... iv
Section 1 Safety Rules ..........................................................................................................v
General Safety Rules ............................................................................................. v
Section 2 Specifications .......................................................................................................1
Machine Specifications...........................................................................................1
Performance Specifications....................................................................................2
Hydraulic Oil Specifications....................................................................................3
Hydraulic Component Specifications......................................................................6
Manifold Component Specifications .......................................................................7
Deutz TD2011L04i Engine Specifications ..............................................................8
Deutz TD 2.9 Engine Specifications.......................................................................9
Perkins 1104D-44T Engine Specifications ...........................................................10
Perkins 854F-34T Engine Specifications .............................................................12
Machine Torque Specifications ............................................................................13
Hydraulic Hose and Fitting Torque Specifications ...............................................14
Torque Procedure ................................................................................................15

December 2019
Table of Contents
viii SX™-150 Part No. 1268496GT
Section 3 Repair Procedures..............................................................................................17
Introduction ...........................................................................................................17
Platform Controls ...............................................................................................19
1-1 Platform Circuit Board ....................................................................................19
How to Remove the LED Circuit Board ...........................................................20
1-2 Joysticks.........................................................................................................21
How to Reset a Proportional Valve Coil Default..............................................24
How to Set the Function Thresholds and Default Functions Speeds..............25
How to Adjust the Function Speeds ................................................................27
How to Adjust the Function Ramp Rate Setting..............................................27
Platform Components ........................................................................................29
2-1 Platform ..........................................................................................................29
2-2 Platform Leveling Cylinder .............................................................................30
2-3 Platform Rotator .............................................................................................31
How to Bleed the Platform Rotator..................................................................32
2-4 Platform Level Sensor ....................................................................................33
2-5 Platform Overload System (if equipped) ........................................................34
2-6 Platform Overload Recovery Message ..........................................................35
Jib Boom Components ......................................................................................37
3-1 Jib Boom.........................................................................................................38
3-2 Jib Boom Lift Cylinder ....................................................................................39
3-3 How to Remove the Jib Boom Bellcrank........................................................40
3-4 Jib Boom Bellcrank Angle Sensor ..................................................................41

December 2019
Table of Contents
Part No. 1268496GT SX™-150 ix
Boom Components ............................................................................................43
4-1 Primary Boom Cable Track ............................................................................44
4-2 Primary Boom.................................................................................................46
How to Remove the Primary Boom.................................................................47
How to Disassemble the Primary Boom .........................................................49
4-3 Primary Boom Lift Cylinder ............................................................................52
4-4 Extension Cylinder .........................................................................................54
4-5 Boom Extend and Retract Cables..................................................................56
How to Replace the Boom Extend/Retract Cables .........................................61
4-6 Primary Boom Angle Sensor..........................................................................64
4-7 Boom Length Sensor .....................................................................................67
Engines................................................................................................................69
5-1 RPM Adjustment ............................................................................................69
5-2 Flex Plate .......................................................................................................69
How to Install the Flex Plate............................................................................70
Ground Controls.................................................................................................71
6-1 Bypass/Recovery Key Switch ........................................................................71
How to Use the Recovery Mode .....................................................................72
6-2 Circuit Boards.................................................................................................73
6-3 Membrane Decal............................................................................................75
6-4 Full Machine Calibration.................................................................................76
Display Module ...................................................................................................77
Hydraulic Pumps ................................................................................................84
7-1 Function Pump ...............................................................................................84
How to Prime the Function Pump ...................................................................85
How to Adjust the Function Pump Standby Pressure .....................................85
How to Adjust the Function Pump Pressure Compensator ............................87
7-2 Drive Pump.....................................................................................................88
How to Prime the Drive Pump.........................................................................90

December 2019
Table of Contents
x SX™-150 Part No. 1268496GT
Manifolds .............................................................................................................92
8-1 Function Manifold Components......................................................................92
8-2 Valve Adjustments - Function Manifold..........................................................98
8-3 Platform Level and Rotation Manifold Components, to SX150H-518 ..........100
8-3A Platform Level and Rotation Manifold Components, from SX150H-519 ...101
8-4 Jib Boom Manifold Components, to SX150H-518 .......................................102
8-4A Jib Boom Manifold Components, from SX150H-519.................................103
8-5 Function Enable Manifold.............................................................................104
8-6 Steer and Axle Manifold Components, to SX150H-507...............................106
8-6A Steer and Axle Manifold Components, from SX150H-508 ........................110
8-7 Valve Adjustments - Steer and Axle Manifold ..............................................114
8-8 Traction Manifold Components ....................................................................116
8-9 Valve Adjustments - Traction Manifold.........................................................120
8-10 Generator Manifold Component.................................................................121
8-11 Valve Coils .................................................................................................122
Turntable Rotation Components.....................................................................124
9-1 Turntable Rotation Assembly .......................................................................124
How to Adjust the Turntable Rotation Gear Backlash...................................125
9-2 Turntable Level Sensor ................................................................................126
Axle Components .............................................................................................129
10-1 Steer Sensors.............................................................................................129
How to Calibrate a Replacement Steer Sensor ............................................131
How to Calibrate All Steer Sensors ...............................................................132
10-2 Steer Cylinders ...........................................................................................134
10-3 Axle Extension Cylinders............................................................................134
10-4 Axle Angle Sensors ....................................................................................135
Generators.........................................................................................................138
11-1 Welder Generator .......................................................................................138

December 2019
Table of Contents
Part No. 1268496GT SX™-150 xi
Section 4 Fault Codes .......................................................................................................139
Introduction.........................................................................................................139
Control System Fault Codes ...........................................................................140
Fault Matrix.........................................................................................................159
Fault Code Source .............................................................................................160
Deutz TD 2.9 L4 Engine Fault Codes ................................................................163
Perkins 854F-34T Engine Fault Code................................................................178
Section 5 Schematics........................................................................................................187
Introduction.........................................................................................................187
Wire Circuit Legend ............................................................................................188
Wire Color Legend .............................................................................................192
Limit Switches and Angle Sensors .....................................................................197
Circuit Connector Legend...................................................................................201
Connector Pin Legend........................................................................................204
Engine Relay and Fuse Panel Legend - Deutz TD2011L04i and Perkins
1104D-44T Models .....................................................................................218
Engine Relay and Fuse Panel Legend - Deutz TD 2.9 L4 Models ....................219
Engine Relay and Fuse Panel Legend - Perkins 854F-34T Models ..................220
Electrical Symbols Legend .................................................................................221
Hydraulic Symbols Legend.................................................................................222

December 2019
Table of Contents
xii SX™-150 Part No. 1268496GT
Electrical Schematics – Control Circuits .......................................................223
Control Circuits - Horn ........................................................................................224
Control Circuits - Power......................................................................................225
Control Circuits - Can Bus ..................................................................................228
Control Circuits - Deutz TD2011L04i Engine .....................................................229
Control Circuits - Deutz TD 2.9 L4Engine ..........................................................232
Control Circuits - Perkins 1104D-44T Engine ....................................................233
Control Circuits - Perkins 854F-34T Engine.......................................................236
Control Circuits - Axle Extend/Retract ................................................................237
Control Circuits - Steering ..................................................................................240
Control Circuits - Propel .....................................................................................241
Control Circuits - Turntable Rotate .....................................................................244
Control Circuits - Boom Up/Down.......................................................................245
Control Circuits - Boom Extend/Retract .............................................................248
Control Circuits - Jib Up/Down, Jib Rotate and Platform Rotate........................249
Control Circuits - Platform Level and Jib Bellcrank Level...................................252
Control Circuits - Platform Load Sense ..............................................................253
Control Circuits - Flashing Beacons, Oil Cooler and Drive/Work Lights ............256
Control Circuits - Recovery PLD.........................................................................257
Control Circuits - Telematics ..............................................................................260
Generator Receptacle Wiring- ANSI/CSA ..........................................................261
Generator Receptacle Wiring- CE ......................................................................264
Perkins 1104D-44T Engine Electrical Schematic...............................................265
Perkins 854F-34T Engine Electrical Schematic .................................................268
Perkins 854F-34T Engine Harness ....................................................................269
Deutz TD 2.9 L4 Engine Electrical Schematic....................................................272
Deutz TD 2.9 L4 Engine Harness.......................................................................273
Hydraulic Schematics ......................................................................................275
Hydraulic Schematic (to SX150H-507)...............................................................276
Hydraulic Schematic (from SX150H-508 to SX150H-518).................................277
Hydraulic Schematic (from SX150H-519) ..........................................................279
Electrical Schematic (to SX150H-518) ...............................................................281
Electrical Schematic (from SX150H-519) ...........................................................282

December 2019 Service and Repair Manual
Specifications
Part No. 1268496GT SX™-150 1
Section 2 Speci fi c ati ons
Machine Specifications
Tires and wheels
Tire size
445D50/710, FF
Tire ply rating
18
Tire weight, new foam
-filled
(minimum)
850 lbs
386 kg
Overall tire diameter
45.47 in
115.5 cm
Wheel diameter
28 in
71.1 cm
Wheel width
15 in
38.1 cm
Wheel lugs
10 @ 3/4 -
16
Lug nut torque, dry
320 ft-
lbs
434 Nm
Fluid capacities
Fuel tank
50 gal
189 liters
Hydraulic tank
110 gal
416 liters
Hydraulic system (including tank)
175 gal
663 liters
Drive hubs
67 fl oz
1981 cc
Turntable rotation drive hub
43 fl oz
1262 cc
Drive
hub oil type: SAE 90 multipurpose hypoid
gear oil API service classification GL5
For operational specifications, refer to the
Operator's Manual.
Continuous improvement of our products is a
Genie policy. Product specifications are
subject to change without notice or obligation.

Service and Repair Manual December 2019
Specifications
2 SX™-150 Part No. 1268496GT
Performance Specifications
Drive speed, maximum
Stowed position, high speed
2.3 mph
3.7 km/h
36ft / 8.9 sec
11 m / 8.9 sec
Raised or extended
0.4 mph
0.64 km/h
36 ft / 62-
68 sec
11 m / 62-
68 sec
Boom above 125 ft / 38.1 m
0.1 mph
0.16 km/h
18 ft / 124 -
132 sec
5.5 m / 124 -
132 sec
Braking distance, maximum
High range on paved surface
6 ft / 2 m
Gradeability
Refer to Operator's Manual
Boom function speeds, maximum from platform
controls
Jib boom up/down
58 -
62 sec
Jib boom rotate CW/CCW 60°
28 -
32 sec
Primary boom extend/retract
30 -
33 sec /
0 -
100 in / 254 cm
Primary boom up/down (stowed)
80 -
88 sec / 82°
Primary boom up/down
(stringpot = 76 in / 193 cm)
100 -
110 sec / 82°
Primary boom up/down
(stringpot = 158 in / 401 cm)
45 -
50 sec / 20°
Primary boom up/down
(stringpot = 238 in / 605 cm)
71 -
80 sec / 20°
Primary boom up/down
(stringpot = 370 in / 940 cm)
26 -
31 sec / 5°
Turntable rotate, drive enable to
drive enabl
e (80°) fully stowed
38 -
42 sec
Turntable rotate, drive enable to
drive enable (80°)
stringpot = 36 in / 91.4 cm
63 -
70 sec
Turntable rotate, drive enable to
drive enable (80°)
stringpot = 76 in / 193 cm
(above 75 ft / 22.8 m)
109 -
120 sec
Turntable
rotate, drive enable to
drive enable (80°)
stringpot = 258 in / 655 cm (above
125 ft / 38.1 m)
155 -
175 sec
For operational specifications, refer to the
Operator's Manual.
Continuous improvement of our products is a
Genie policy. Product specifications are
subject to change without notice or obligation.

December 2019 Service and Repair Manual
Specifications
Part No. 1268496GT SX™-150 3
Hydraulic Oil Specifications
Hydraulic Fluid Specifications
Genie specifications require hydraulic oils which are
designed to give maximum protection to hydraulic
systems,
have the ability to perform over a wide
temperature range, and the viscosity index should
exceed 140. They should provide excellent antiwear,
oxidation prevention, corrosion inhibition, seal
conditioning, and foam and aeration suppression
properties.
Clea
nliness level,
minimum
ISO 15/13
Water content,
maximum
250 ppm
Recommended Hydraulic Fluid
Hydraulic oil type
Chevron Rando HD Premium
Viscosity grade
32
Viscosity index
200
Optional Hydraulic Fluids
Mineral based
Shell Tellus S2 V 32
Shell Tellus
S2 V 46
Shell Tellus S4 VX 32 Shell
Shell Donax TG (Dexron III)
Chevron 5606A
Biodegradable
Petro Canada Environ MV
46
Fire resistant
UCON Hydrolube HP-
5046
Note: Genie specifications require additional
equipment and special installation instructions for
the approved optional fluids. Consult Genie
Product Support before use.
Optional fluids may not have
the same hydraulic lifespan and
may result in component
damage.
Note: Extended machine operation can cause the
hydraulic fluid temperature to increase beyond it's
maximum allowable range. If the hydraulic fluid
temperature consistently exceeds 200°F / 90°C an
optional oil cooler may be required.
Do not top off with incompatible
hydraulic fluids. Hydraulic fluids
may be incompatible due to the
differences in base additive
chemistry. When incompatible
fluids are mixed, insoluble
materials may form and deposit
in the hydraulic system,
plugging hydraulic lines, filters,
control valves and may result in
component damage.
Note: Do not operate the machine when the
ambient air temperature is consistently above
120°F / 49°C.
Hydraulic Fluid Temperature
Range
Ambient air temperature
1 Chevron hydraulic oil 5606A
2 Petro-Canada Environ MV 46
3 UCON Hydrolube HP-5046D
4 Chevron Rando HD premium oil MV

Service and Repair Manual December 2019
Specifications
4 SX™-150 Part No. 1268496GT
Chevron Rando HD Premium Oil
MV Fluid Properties
ISO Grade
32
Viscosity index
200
Kinematic Viscosity
cSt @ 200°F / 100°C
cSt @ 104°F / 40°C
7.5
33.5
Brookfield Viscosity
cP @
-4°F / -20°C
cP @
-22°F / -30°C
1040
3310
Flash point
375°F / 190°C
Pour point
-58°F / -
50°C
Maximum continuous operating
temperature
171°F / 77°C
Note: A hydraulic oil heating system is
recommended when the ambient temperature is
consistently below 0°F / -18°C.
Note: Do not operate the machine when the
ambient temperature is below -20°F / -29°C with
Rando HD Premium MV.
Chevron 5606A Hydraulic Oil
Fluid Properties
ISO Grade
15
Viscosity index
300
Kinematic Viscosity
cSt @ 200°F / 100°C
cSt @ 104°F / 40°C
cSt @
-40°F / -40°C
5.5
15.0
510
Flash point
180°F / 82°C
Pour point
-81°F / -
63°C
Maximum continuous operating
temperature
124°F / 51°C
Note: Use of Chevron 5606A hydraulic fluid, or
equivalent, is required when ambient temperatures
are consistently below 0°F / -17°C unless an oil
heating system is used.
Continued
use of Chevron
5606A hydraulic fluid, or
equivalent, when ambient
temperatures are consistently
above 32°F / 0°C may result in
component damage

December 2019 Service and Repair Manual
Specifications
Part No. 1268496GT SX™-150 5
Petro-Canada Environ MV 46
Fluid Properties
ISO Grade
46
Viscosity index
154
Kinematic Viscosity
cSt @
200°F / 100°C
cSt @ 104°F / 40°C
8.0
44.4
Flash point
482°F / 250°C
Pour point
-49°F / -
45°C
Maximum continuous operating
temperature
180°F / 82°C
Shell Tellus S4 VX Fluid
Properties
ISO Grade
32
Viscosity index
300
Kinematic Viscosity
cSt @ 200°F /
100°C
cSt @ 104°F / 40°C
9
33.8
Brookfield Viscosity
cSt @
-4°F / -20°C
cSt @
-13°F / -25°C
cSt @
-40°F / -40°C
481
702.4
2624
Flash point
>100
Pour point
-76°F / -
60°C
Maximum continuous operating
temperature
103°F / 75°C
UCON Hydrolube HP-5046 Fluid
Properties
ISO Grade
46
Viscosity index
192
Kinematic Viscosity
cSt @ 149°F / 65°C
cSt @ 104°F / 40°C
cSt @ 0°F /
-18°C
22
46
1300
Flash point
None
Pour point
-81°F / -
63°C
Maximum continuous operating
temperature
189°F / 87°C

Service and Repair Manual December 2019
Specifications
6 SX™-150 Part No. 1268496GT
Hydraulic Component
Specifications
Drive Pump
Type: bi
-directional variable displacement piston pump
Displacement per revolution
2.8 cu in
46 cc
Flow rate @ 2450 rpm
30 gpm
114 L/min
Drive pressure, maximum
3625 psi
250 bar
Charge Pump
Type
gerotor
Displacement per revolution
0.85 cu in
13.9 cc
Flow rate @ 2450 rpm
9 gpm
34 L/min
Charge pressure @ 2450 rpm
Neutral position
315 psi
21.7 bar
Function Pump
- Middle Pump
Type: variable displacement piston pump
Displacement
per revolution
0 to 1.8 cu in
0 to 30 cc
Flow rate @ 2450 rpm
0 to 20 gpm
0 to 76.4 L/min
Pressure, maximum
2700 psi
183 bar
Pressure compensator
2700 psi
183 bar
Standby pressure
350 psi
24 bar
Function Pump
- End Pump
Type
variable
displacement
piston pump
Displacement per revolution
0 to 1.8 cu in
0 to 30 cc
Flow rate @ 2450 rpm
0 to 20 gpm
0 to 76.4 L/min
Pressure, maximum
2900 psi
200 bar
Pressure compensator
2900 psi
200 bar
Standby pressure
350 psi
24 bar
Auxiliary Pump
Type
fixed
displacement
gear pump
Displacement per revolution
0.15 cu in
2.47 cc
Function manifold
System relief valve pressure,
maximum
3200 psi
221 bar
Primary boom extend relief pressure
(measured at
PTEST port)
2500 psi
172 bar
Platform Manifold
Platform
rotate and platform level
flow regulator
0.2 gpm
0.76 L/min
Steer/Axle Manifold
Axle extend relief pressure
2400 psi
165 bar
Traction Manifold
Hot oil relief pressure
250 psi
17.2 bar
Continuous improvement of our products is a
Genie policy. Product specifications are
subject to change without notice or obligation.

December 2019 Service and Repair Manual
Specifications
Part No. 1268496GT SX™-150 7
Brakes
Brake relief pressure
160 psi
11 bar
Drive Motors
Displacement per revolution
high speed:
1.19 cu in
19.5 cc
Displacement per revolution
low speed
2.7 cu in
45 cc
Hydraulic Filters
High pressure filter:
Beta 5 ≥
1000
High pressure filter bypass pressure
102 psi
7 bar
Medium pressure filter
Beta 3 ≥
200
Medium pressure filter bypass
pressure
51 psi
3.5 bar
Hydraulic tank return filter
10 micron with
25 psi / 1.7 bar
bypass
Drive motor case drain return filter
Beta 10 ≥
2
Manifold Component
Specifications
Plug torque
SAE No. 2
36 in-
lbs / 4 Nm
SAE No. 4
10 ft-
lbs / 13 Nm
SAE No. 6
14 ft-
lbs / 19 Nm
SAE No. 8
38 ft-
lbs / 51 Nm
SAE No.
10 41 ft-
lbs / 55 Nm
SAE No. 12
56 ft-
lbs / 76 Nm

Service and Repair Manual December 2019
Specifications
8 SX™-150 Part No. 1268496GT
Deutz TD2011L04i Engine
Displacement
220.9 cu. in
3.62 liters
Number of cylinders
4
Bore and Stroke
3.78 x 4.92 inches
96 x 125 mm
Horsepower net intermittent
@
2400 rpm
74 hp
55 kW
Induction system
turbocharged
Firing order
1 - 3 - 4 -
2
Low idle
1300 rpm
High idle
2450 rpm
Compression ratio
17.5:1
Compression pressure pressure (psi or bar) of the
lowest cylinder must be at least 75% of the highest
cylinder
Governor
centrifugal
mechanical
Valve Clearance, cold
Intake
0.012 in
0.3 mm
Exhaust
0.020 in
0.5 mm
Lubrication system
Oil pressure, hot (@ 2000 rpm)
40 to 60 psi
2.8 to 4.1 bar
Oil capacity (including filter)
12.8 quarts
12.1 liters
Oil viscosity requirements
-
22°F to 86°F / -30°C to 30°C 5W-
30
(synthetic)
-
4°F to 104°F / -20°C to 40°C 10W-
40
Above 5°F /
-15°C 15W-
40
Unit ships with 15W
-40. Extreme operating
temperatures may require the use of alternative
engine oils. For oil
requirements, refer to the
Engine Operator Manual for your engine.
Oil temperature switch
Installation torque
8 - 18 ft-
lbs
11 -
24 Nm
Temperature switch point
275°F
135°C
Oil Pressure switch
Installation torque
8 - 18 ft-
lbs
11 -
24 Nm
Pressure
switch point
22 psi
1.5 bar
Fuel injection system
Motorpal
Injection pump pressure, maximum
15,000 psi
1034 bar
Injector opening pressure
3046 psi
210 bar
Fuel requirement
For fuel requirements, refer to the engine Operator
Manual for your engine.
Starter motor
Current draw, normal load
140 -
200A
Cranking speed
250 -
350 rpm
Battery
– Auxiliary power units
Type
6V DC
Quantity
2
Battery capacity, maximum
285 AH
Reserve capacity @ 25A rate
745 minutes
Battery
– Engine starting and control system
Type
12V DC, Group 31
Quantity
1
Battery capacity, maximum
1000A
Reserve capacity @ 25A rate
200 Minutes
Alternator output
80A @ 14V DC
Fan belt deflection
3/8 to 1/2 inch
9 to 12 mm
