USB2.0 Extender
# UNE0100A10
This USB2.0 Extender can easily send the USB signals via Cat-5/5e/6 cable up to 100
meters at data rate of High Speed (480Mb/s) . Without any configuration or software driver,
this USB extender allows you to extend your USB device up to 100m from your computer,
which overcomes the typical USB cable limitation.
Features:
Extend signal transmission distance of a USB devices up to 100m via a Cat 5/5e/6 cable
Support all major operating systems, such as Windows, MacOS and Linux
Plug and play, no additional drivers required
High speed up to 480Mbps
Support low speed USB, compatible with USB1.1
Packing list:
1 * USB2.0 Extender transmitter
1 * USB2.0 Extender receiver
1 * DC 5V 2A Power adapter
1 * User manual

www.tesmart.com
2
Panel descriptions:
Transmitter:
ID
Name
Description
1
UTP output
Connect a Cat 5/5e/6 cable between this port and the
RJ45 connector port on the receiving unit
2
Power status
The LED will be active once transmitter is powered up
3
USB input
Connect the USB source to this input
Receiver:
ID
Name
Description
1
DC 5V
5V DC power supply
2
UTP input
Connect a Cat 5/5e/6 cable between this port and the
RJ45 connector port on the sending unit
3
Power status
The LED will be active once receiver is connected 5V
DC power supply
4
USB input
Connect the USB source to this output

www.tesmart.com
3
Connection Diagram:

www.tesmart.com
4
Specification
UNE0100A10
USB2.0 Extender
Technical
Transmission distance
100M
Data rate
480Mbps
ESD protection
Human body model - ±8kV (Air-gap discharge)
Transmitter
1* USB Type A
1* RJ45
Receiver
1* RJ45
1* USB Type A
Mechanical
Chasing material
Aluminum Alloy
Product Dimensions
RX: 60 (W) x 48 (D) x 24 (H) mm
TX: 60 (W) x 48 (D) x 24 (H) mm
Item Weight
288g
Power supply
DC 5V 1A
Operating/Storage
temperature
0 to 70 degree/-40 to 85 degree
Operating Humidity
10 to 90% RH
