TET SICA20I2P User manual

TET TOKYO ELETECH CORPORATION
1
1. Product description
The SICA20I2P is designed to save space on the target board when using JTAG
equipment to test, debug or evaluate a system. The target board connector has a 5 x 7mm
footprint, which is 1/6th the size compared with traditional connector with 2.54mm pitch.
This cable adapter converts 2.54mm pitch connector at an emulator side into 0.5mm pitch
at a target board. Therefore, this cable can be placed closed to CPU. The target board
connector surface mounted on PCB without needing any “through holes”. Now, the other
side of PCB is available for mounting more components.
2. Specifications
2.1 Operating and Storage environments:
Title Operating environment Storage environment
1. Temperature 10 to 35℃-10 to 50℃
2. Relative humidity 35 to 80% (No condensation on any devices)
3. Chemical gas No corrosive gas should exist in the environment.
2.2 Mechanical and Electrical specifications:
Title Specifications
１Outer dimensions 34 x 52 x 17mm
２Connector at an emulator side HIF3FC-20PA-2.54DSA(71)
３Header at target side Custom made connector, 20pins, 0.5 mm pitch
４Socket at target side Custom made connector, 20pins, 0.5mm pitch
５Cable material FPC, polyamides, double layers
６DC resistance 300ｍΩ Max
７Life of connectors 500 times Min
８Current rating 0.5A/line Max
Instruction for use
Small Interface Cable Adapter, SICA20I2P

TET TOKYO ELETECH CORPORATION
2
2.3 The kit includes:
・ SICA20I2P cable One piece
・ Mating socket at a target board(SICA2P20S) One piece
・ Notes for handling SICA One piece
2.4 Recommend soldering temperature profile on the surface of the mating socket
at target side, SICA2P20S.
1. Please visit the following web site to get the target board footprint pattern.
http://www.tetc.co.jp/pdf/sica_zumen/sica2p20s.pdf
2. The thickness and opening of metal mask stencils for SICA2P20S
Thickness : 150μ
Opening of metal mask stencils : 60%
3. Soldering temperatures :
a . Lead free soldering (Sn-3Ag-0.5Cu)
Solder reflow equipment :
Preheating temperature : 220℃for 40 seconds max.
Maximumtemperature: 260℃
Handsoldering:
Maximumtemperature: 380℃for 3 seconds or less.
b. Tin-lead soldering
Solder reflow equipment :
Preheating temperature : 200℃for 30 seconds max.
Reflowtemperature : 245℃
Handsoldering:
Maximumtemperature :350℃for 3 seconds or less.

TET TOKYO ELETECH CORPORATION
3
3. How to use it:
1. Turn off the power to emulator and the
target board! Connect the emulator cable,
the emulator and target board as shown in
Fig 3.1.
A polarity key prevents the user to plug the
emulator cable and the SICA together in the
wrong direction as shown in Fig 3.2. Check
the key’s position before assembling the
header and the socket.
2. Again observing the proper key alignment,
plug the socket on SICA cable target end
onto the header on the target board as
shown in Fig3.3.
Target board
SICA
Micro computer
Fig 3.3
Connect
Emulator
SICA
Fig 3.1
Connect
Emulator cable
Fig 3.2
SICA
Key
Polarity key
Emulator cable

TET TOKYO ELETECH CORPORATION
4
4. Cable wiring diagram
Cable wiring diagram is shown in
Fig4.1. Triangle mark indicates
pin#1. The pin#1 on the SICA
connected to pin#1 on the other end.
That is, pins are connected to
straight across the cable.
5. Notes for handling SICA -Small Interface Cable Adapter-
1) SICA is developed for tests, evaluations, and / or development of the electronics system
development in laboratory environment; Therefore SICA does not satisfy any EMI
standards or safety rules.
2) SICA should not be used for the electronics or electrical systems where EMI and
reliability against environments can be a safety factor, such as transportation, medical,
navigation, nuclear power control system and etc.
3) While developing a new application using SICA make sure you follow the pin diagram
exactly as shown in this manual.
4) Do NOT bend flex cable too sharply, because it might break the internal conductive
trace. Insert or extract the cable using the stiffener.
Specifications, the mechanical construction, all other information might be changed without notice.
TOKYO ELETECH CORPORATION
〒110-0006
3-10 Akihabara Taito-ku,
TOKYO JAPAN
TEL：[phone]
FAX : [phone]
URL : http://www.tetc.co.jp/ 2006.06.30 TET-MANU-SICA20I2P-Rev3
Emulator cable
Target side header
Connector at
emulator side
9
4
5
7
8
6
11
12
13
10
14
15
16
17
18
19
20
3
2 1
▼
1
9
4
5
7
8
6
11
12
13
10
14
15
16
17
18
19
20
3
2 1
9
4
5
7
8
6
11
12
13
10
14
15
16
17
18
19
20
3
2 1
19
20
2
Fig 4.1
