DS16EV51-AEVKD User Guide Rev A
December 2008
© National Semiconductor Corporation
1
DS16EV51-AEVKD
DVI Extender Demo Kit for Dual or Single Link DVI Cables
General Description
The DS16EV51-AEVKD Dual/Single link DVI Cable Extender Demo Kit provides a complete DVI system extension solution
using two National’s DS16EV5110A’s - Video Equalizers.
Two Molex DVI connectors are used as the input and the output connections for a dual or single link DVI system. This version
of the kit demonstrates both a single link and a dual link DVI system.
The Analog Pins of a typical DVI link (R, G, B, Hsync, and Vsync) are not connected. The DDC signals, Hot Plug, 5V Power
and 5V Ground are directly connected between the DVI connectors, making this demo kit HDCP compliant.
A 3.3V VCC 1-pin header (J4) and a GND 1-pin header (J5) are used for the power supply.
Alternately, an AC/DC power adapter (>800mA) is required for the evaluation kit to provide 5V DC voltage for easy portability.
A 1.8 mm DC Power Jack is used to connect the AC/DC Power Adapter. National’s LP3965, a 3.3V, 1500mA, Fast, Ultra Low
Dropout Linear Regulator, converts the 5V power supply voltage to a 3.3V power supply voltage that powers the
DS16EV5110A’s.
Features
•Compatible with DTV Resolutions 480i, 480p, 720i, 720p, 1080i, 1080p (8 bit, 10 bit, 12 bit color depth)
•Compatible with the Single Link Computer Resolutions of VGA, SVGA, XGA, SXGA, UXGA
•Compatible with the Dual Link Computer Resolutions of QXGA, WQXGA
•Supports TMDS DVI or HDMI Dual/Single Link
•Adjustable rotary switch for easy custom EQ boost level setting to reach maximum length of TMDS Interface
with HDMI, or DVI Cables
•Single 3.3V Supply
•Ultra Portable with AC/DC Power Adapter (not included in the kit)
•500 mW Typical Power Consumption of each DS16EV5110A device
•>6kV ESD Rating
•-40 to 85C Industrial Temperature Range
•The DS16EV5110A demo kit extends TMDS with the 28 AWG STP DVI cable as follows:
Format Link Resolution
Pixel bandwidth (MPixel/s)
60Hz LCD with 20% blanking
Per channel bandwidth (Gb/s)
60Hz LCD with 20% blanking
DVI Cable
Length
VGA Single 640 x 480 22.1 0.221 > 45m
SVGA Single 800 x 600 34.6 0.346 > 40m
XGA Single 1024 x 768 56.5 0.565 > 35m
SXGA Single 1280 x 1024 94.4 0.944 > 30m
UXGA Single 1600 x 1200 138.0 1.380 > 25m
HDTV Single 1920 x 1080 149.3 1.493 > 25m
QXGA Dual 2048 x 1536 113.2 1.132 > 30m
WQXGA Dual 2560 x 1600 147.5 1.475 > 25m
Applications
High Definition Displays and Televisions
High Definition Front- Projectors
LCD Computer Monitors
DVI-D/HDMI Cable Extender

DS16EV51-AEVKD User Guide Rev A
December 2008
© National Semiconductor Corporation
2
Ordering Information
PART: DS16EV5110ASQ
DVI Demo Board for DVI Dual/Single Link Cables: DS16EV51-AEVKD
HDMI Demo Board for HDMI Cables: DS16EV51-AEVKH
CAT5 Demo Board for CAT5 Cables: DS16EV51-AEVKC
Typical Applications
Bill of Materials
DESIGNATION QTY DESCRIPTION
C2, C4, C6, C8, C10, C12, C15, C17 8 0.01uF +10% Ceramic Capacitor 0402
C1, C3, C5, C7, C9, C11, C13, C14, C16 9 0.1uF +10% Ceramic Capacitor 0402
C59 1 33uF +10% Tantalum Capacitor 3528
C60 1 68uF +10% Tantalum Capacitor 3528
D4 1 LED Green
D5 1 LED Red
R19, R23 2 453 ohm +5% Resistor 0402
R20 1 1K ohm +5% Resistor 0402
R24 1 10K ohm +5% Resistor 0402
R21, R22 2 50 ohm +5% Resistor 0402
J45, J46 2 DVI-I Receptacle Female
J47 1 DC Power Jack 1.8 mm
J4, J5 2 1 pin header (J4: VDD=3.3V, J5:GND)
J7, J8, J9, J10, J11, J12 5 1X2 pin header
J15 1 1X3 pin header
U13, U14 2 National DS16EV5110A
U15 1 National LP3965 – 3.3V -1500mA
U3 1 94HBB08RAT Rotary Dip Switch
Greater than 25 m DVI /HDMI
Cable, 28 AWG STP, 1.65 Gbps
DVI Video Source DS16EV51-AEVKD High Definition Display

DS16EV51-AEVKD User Guide Rev A
December 2008
© National Semiconductor Corporation
3
Quick Start Guide:
1. Connect 3.3V DC power to J4 and ground to J5 from the power supply.
Or, plug the AC/DC power adapter to the DC power Jack
AC/DC power adapter requirement: Output DC 4V~6V, Output current > 800mA
2. Attach two DVI cables to the DVI Input and Output Connectors
3. Turn on the DVD/Computer and the Monitor/HDTV.
Adjustment and Control Description
Component Name Function
D4 PWR The LED turns on when 5V DC applied
D5 SD The LED turns on when the DS16EV5110 does not detect clock signal
J47 5V DC Optional DC Power Jack for 1.8 mm Adaptor Plug
J4 3.3V 3.3V VCC power supply
J5 GND GND
J10 FEB and GND Optional SMBus control of U14 (See Datasheet)
J9 CS and VDD Optional SMBus control of U14 (See Datasheet)
J7 FEB and GND Optional SMBus control of U13 (See Datasheet)
J8 CS and VDD Optional SMBus control of U13 (See Datasheet)
J11, J12 SDA, SDC and GND Optional SMBus access (See Datasheet)
J15 Loop Back Control
Connect “LED” and “SD” to enable D5 function.
Connect “SD” and “EN” to enable look back control function. When the clock
signal is not detected, the DS16EV5110A enters power down mode.
U3 Rotary Switch
Turn the switch to control the EQ boost setting. “0” on the switch refers to the
boost setting of “0X00”, “7” on the switch refers to the boost setting of “0X07”.
See datasheet for detail Boost setting information.
Connection in Dual Link Application
DS16EV5110A
DS16EV5110A
D0
D1
D2
CLK
D3
D4
D5
D0
D1
D2
CLK
D3
D4
D5
CLK CLK
SD
SD
EN
EN CS
CS

DS16EV51-AEVKD User Guide Rev A
December 2008
© National Semiconductor Corporation
4
Schematics

DS16EV51-AEVKD User Guide Rev A
December 2008
© National Semiconductor Corporation
5
Layout Considerations
•Keep the clock and data transmission lines as short as possible with controlled 50 ohm single-ended impedance. Or,
use differentially coupled traces with 100 ohm impedance.
•Avoid using vias on the clock and data transmission lines on the input side of the DS16EV5110A.
•Place power supply decoupling capacitors close to the VCC pins.
Top View Layout Bottom View Layout
