Texas Instruments Stellaris LM3S6965 User manual

EK-LM3S6965-06 Copyright © 2007–2010 Texas Instruments
User’s Manual
Stellaris® LM3S6965 Evaluation Board

2January 6, 2010
Copyright
Copyright © 2007–2010 Texas Instruments, Inc. All rights reserved. Stellaris and StellarisWare are registered trademarks of Texas Instruments.
ARM and Thumb are registered trademarks, and Cortex is a trademark of ARM Limited. Other names and brands may be claimed as the property
of others.
Texas Instruments
108 Wild Basin, Suite 350
Austin, TX 78746
http://www.ti.com/stellaris

Stellaris® LM3S6965 Evaluation Board
January 6, 2010 3
Table of Contents
Chapter 1: Stellaris® LM3S6965 Evaluation Board .......................................................................................7
Features..............................................................................................................................................................8
Block Diagram ....................................................................................................................................................8
Evaluation Kit Contents ......................................................................................................................................9
Evaluation Board Specifications .....................................................................................................................9
Features of the LM3S6965 Microcontroller.........................................................................................................9
Chapter 2: Hardware Description..................................................................................................................11
LM3S6965 Microcontroller................................................................................................................................11
Device Overview...........................................................................................................................................11
Ethernet ........................................................................................................................................................11
Clocking........................................................................................................................................................11
Reset.............................................................................................................................................................11
Power Supplies.............................................................................................................................................12
Debugging.....................................................................................................................................................12
USB Device Controller Functions .....................................................................................................................13
Device Overview...........................................................................................................................................13
USB to JTAG/SWD.......................................................................................................................................13
Virtual COM Port...........................................................................................................................................13
Serial Wire Out..............................................................................................................................................13
Organic LED Display ........................................................................................................................................13
Features........................................................................................................................................................13
Control Interface ...........................................................................................................................................14
Power Supply................................................................................................................................................14
Design Guidelines.........................................................................................................................................14
Further Reference.........................................................................................................................................14
Other Peripherals..............................................................................................................................................14
Speaker.........................................................................................................................................................14
MicroSD Card Slot........................................................................................................................................14
Push Switches ..............................................................................................................................................14
User LED ......................................................................................................................................................15
Bypassing Peripherals......................................................................................................................................15
Interfacing to the EVB.......................................................................................................................................15
Using the In-Circuit Debugger Interface ...........................................................................................................16
Appendix A: Schematics................................................................................................................................17
Appendix B: Connection Details...................................................................................................................23
Component Locations.......................................................................................................................................23
Evaluation Board Dimensions...........................................................................................................................24
I/O Breakout Pads ............................................................................................................................................24
Recommended Connectors..............................................................................................................................25
ARM Target Pinout ...........................................................................................................................................26
References .......................................................................................................................................................26

4January 6, 2010
List of Figures
Figure 1-1. Stellaris LM3S6965 Evaluation Board Layout.................................................................................7
Figure 1-2. LM3S6965 Evaluation Board Block Diagram ..................................................................................8
Figure 2-1. ICD Interface Mode .......................................................................................................................16
Figure B-1. Component Locations ...................................................................................................................23
Figure B-2. Evaluation Board Dimensions.......................................................................................................24

Stellaris® LM3S6965 Evaluation Board
January 6, 2010 5
List of Tables
Table 2-1. Stellaris LM3S6965 Evaluation Board Hardware Debugging Configurations................................12
Table 2-2. Isolating On-Board Hardware........................................................................................................15
Table B-1. I/O Breakout Pads.........................................................................................................................25
Table B-2. Recommended Connectors...........................................................................................................25
Table B-3. 20-Pin JTAG/SWD Configuration..................................................................................................26

6January 6, 2010

January 6, 2010 7
Stellaris® LM3S6965 Evaluation Board
The Stellaris® LM3S6965 Evaluation Board is a compact and versatile evaluation platform for the
Stellaris LM3S6965 ARM® Cortex™-M3-based microcontroller. The evaluation kit uses the
LM3S6965 microcontroller’s fully integrated 10/100 Ethernet controller to demonstrate an
embedded web server.
You can use the board either as an evaluation platform or as a low-cost in-circuit debug interface
(ICDI). In debug interface mode, the on-board microcontroller is bypassed, allowing programming
or debugging of an external target. The kit is also compatible with high-performance external JTAG
debuggers.
This evaluation kit enables quick evaluation, prototype development, and creation of application-
specific designs for Ethernet networks. The kit also includes extensive source-code examples,
allowing you to start building C code applications quickly.
Figure 1-1. Stellaris LM3S6965 Evaluation Board Layout
PlaceholderImage
86%'HYLFH
,QWHUIDFH
EDVH7(WKHUQHW-DFN
PLFUR6'&DUG0HPRU\6ORW
SLQ,2
EUHDNRXW
KHDGHU
SLQ,2
EUHDNRXW
KHDGHU
1DYLJDWLRQ
6ZLWFKHV
6HOHFWVZLWFK
6WDWXV/('
6SHDNHU
'HEXJRXW/('
5HVHWVZLWFK
3RZHU/('
2/('*UDSKLFV
'LVSOD\
-7$*6:'
LQSXWDQG
RXWSXW
6WHOODULV70
/06
0LFURFRQWUROOHU
,QFLUFXLW'HEXJ
,QWHUIDFH
CHAPTER 1

Features
8January 6, 2010
Features
The Stellaris LM3S6965 Evaluation Board includes the following features:
Stellaris LM3S6965 microcontroller with fully-integrated 10/100 embedded Ethernet controller
Simple setup; USB cable provides serial communication, debugging, and power
OLED graphics display with 128 x 96 pixel resolution
User LED, navigation switches, and select pushbuttons
Magnetic speaker
LM3S6965 I/O available on labeled break-out pads
Standard ARM® 20-pin JTAG debug connector with input and output modes
USB interface for debugging and power supply
MicroSD card slot
Block Diagram
Figure 1-2. LM3S6965 Evaluation Board Block Diagram
USB
USB Stellaris
LM3S6965
Microcontroller
Dual
USB
Device
Controller
I/OSignals
OLED Display
128 x 96
Debug
Nav
Switch
Switch
LED
I/O Signal Break-out
I/O Signal Break-out
JTAG/SWD
Output/Input
USB Cable
Reset
+3.3V
Regulator
SWD/JTAG
Mux
UART0
Target
Cable
Speaker
RJ45
Jack+
Magnetics
CAT5Cable

Stellaris® LM3S6965 Evaluation Board
January 6, 2010 9
Evaluation Kit Contents
The evaluation kit contains everything needed to develop and run applications for Stellaris
microcontrollers including:
LM3S6965 Evaluation Board (EVB)
USB cable
20-pin JTAG/SWD target cable
CD containing:
–A supported version of one of the following (including a toolchain-specific Quickstart
guide):
• Keil™ RealView® Microcontroller Development Kit (MDK-ARM)
• IAR Embedded Workbench
• Code Sourcery GCC development tools
• Code Red Technologies development tools
• Texas Instruments’ Code Composer Studio™ IDE
–Complete documentation
–Quickstart application source code
–Stellaris® Firmware Development Package with example source code
Evaluation Board Specifications
Board supply voltage: 4.37–5.25 Vdc from USB connector
Board supply current: 250 mA typ (fully active, CPU at 50 MHz)
Break-out power output: 3.3 Vdc (60 mA max), 15 Vdc (15 mA max)
Dimensions: 4.0” x 2.45” x 0.7” (LxWxH)
RoHS status: Compliant
Features of the LM3S6965 Microcontroller
32-bit RISC performance using ARM® Cortex™-M3 v7M architecture
–50-MHz operation
–Hardware-division and single-cycle-multiplication
–Integrated Nested Vectored Interrupt Controller (NVIC)
–42 interrupt channels with eight priority levels
256 KB single-cycle Flash
64 KB single-cycle SRAM
Four general-purpose 32-bit timers
Integrated Ethernet MAC and PHY
Three fully programmable 16C550-type UARTs
Four 10-bit channels (inputs) when used as single-ended inputs

Features of the LM3S6965 Microcontroller
10 January 6, 2010
Two independent integrated analog comparators
Two I2C modules
Three PWM generator blocks
–One 16-bit counter
–Two comparators
–Produces two independent PWM signals
–One dead-band generator
Two QEI modules with position integrator for tracking encoder position
0 to 42 GPIOs, depending on user configuration
On-chip low drop-out (LDO) voltage regulator

January 6, 2010 11
Hardware Description
In addition to a microcontroller, the Stellaris LM3S6965 evaluation board includes a range of useful
peripherals and an integrated ICDI. This chapter describes how these peripherals operate and
interface to the MCU.
LM3S6965 Microcontroller
Device Overview
The heart of the EVB is a Stellaris LM3S6965 ARM Cortex-M3-based microcontroller. The
LM3S6965 offers 256 KB Flash memory, 50-MHz operation, an Ethernet controller, and a wide
range of peripherals. Refer to the LM3S6965 data sheet (order number DS-LM3S6965) for
complete device details.
The LM3S6965 microcontroller is factory programmed with a quickstart demo program. The
quickstart program resides in the LM3S6965 on-chip Flash memory and runs each time power is
applied, unless the quickstart has been replaced with a user program.
Ethernet
A key feature of the LM3S6965 microcontroller is its fully integrated Ethernet controller. Only a
RJ45 jack with integrated magnetics and a few passive components are needed to complete the
10/100baseT interface. The RJ45 jack incorporates LEDs that indicate traffic and link status.
These are automatically managed by on-chip microcontroller hardware. Alternatively, the LEDs
can be software controlled by configuring those pins as general-purpose outputs.
The LM3S6965 supports automatic MDI/MDI-X so the EVB can connect directly to a network or to
another Ethernet device without requiring a cross-over cable.
Clocking
The LM3S6965 microcontroller has four on-chip oscillators, three are implemented on the EVB. A
8.0-MHz crystal completes the LM3S6965’s main internal clock circuit. An internal PLL, configured
in software, multiples this clock to 50-MHz for core and peripheral timing.
A small, 25-MHz crystal is used by the LM3S6965 microcontroller for Ethernet physical layer
timing and is independent of the main oscillator.
Reset
The LM3S6965 microcontroller shares its external reset input with the OLED display. In the EVB,
reset sources are gated through the CPLD, though in a typical application a simple wired-OR
arrangement is sufficient.
Reset is asserted (active low) under any one of three conditions:
Power-on reset
Reset push switch SW1 held down
Internal debug mode—By the USB device controller (U4 FT2232) when instructed by
debugger
CHAPTER 2

Hardware Description
12 January 6, 2010
Power Supplies
The LM3S6965 is powered from a +3.3-V supply. A low drop-out (LDO) regulator regulates +5-V
power from the USB cable to +3.3-V. +3.3-V power is available for powering external circuits.
A +15-V rail is available when the OLED display is active. The speaker and OLED display
boost-converter operate directly from the +5-V rail.
Debugging
Stellaris microcontrollers support programming and debugging using either JTAG or SWD. JTAG
uses the signals TCK, TMS, TDI, and TDO. SWD requires fewer signals (SWCLK, SWDIO, and,
optionally, SWO, for trace). The debugger determines which debug protocol is used.
Debugging Modes
The LM3S6965 evaluation board supports a range of hardware debugging configurations.
Table 2-1 summarizes these configurations.
Modes 2 and 3 automatically detect the presence of an external debug cable. When the debugger
software is connected to the EVB's USB controller, the EVB automatically selects Mode 2 and
illuminates the red Debug Out LED.
Debug In Considerations
Debug Mode 3 supports evaluation board debugging using an external debug interface. Mode 3 is
automatically selected when a device such as a Segger J-Link or Keil ULINK is connected.
Boards marked Revision D or later automatically configure pin 1 to be a 3.3-V reference, if an
external debugger is connected. To determine the revision of your board, locate the product
number on the bottom of the board; for example, EK-LM3S6965-D. The last character of the
product number identifies the board revision.
A configuration or board-level change may be necessary when using an external debug interface
with revisions A through C of this evaluation board. Because the evaluation board supports both
debug out and debug in modes, pin 1 of the 20-pin JTAG/SWD header is, by default, not
connected to +3.3 V. Consequently, devices requiring a voltage on pin 1 to power their line buffers
may not work.
Two solutions exist. Some debugger interfaces (such as ULINK) have an internal power jumper
that, in this case, should be set to internal +3.3-V power. Refer to debugger interface
Table 2-1. Stellaris LM3S6965 Evaluation Board Hardware Debugging Configurations
Mode Debug Function Use Selected by
1 Internal ICDI Debug on-board LM3S6965
microcontroller over USB
interface.
Default mode
2 ICDI out to JTAG/SWD
header The EVB is used as a USB to SWD/JTAG interface to an
external target.
Connecting to an external
target and starting debug
software. The red Debug Out
LED will be ON.
3 In from JTAG/SWD header For users who prefer an
external debug interface
(ULINK, JLINK, etc.) with the
EVB.
Connecting an external
debugger to the JTAG/SWD
header.

Stellaris® LM3S6965 Evaluation Board
January 6, 2010 13
documentation for full details. However, if your debugger interface does not have a selectable
power source, it may be necessary to install a 0-Ωresistor on the evaluation board to route power
to pin 1. Refer to the schematics and board drawing in the appendix of this manual for the location
of this resistor.
USB Device Controller Functions
Device Overview
An FT2232 device from Future Technology Devices International Ltd manages USB-to-serial
conversion. The FT2232 is factory configured to implement a JTAG/SWD port (synchronous serial)
on channel A and a Virtual COM Port (VCP) on channel B. This feature allows two simultaneous
communications links between the host computer and the target device using a single USB cable.
Separate Windows drivers for each function are provided on the Documentation and Software CD.
A small serial EEPROM holds the FT2232 configuration data. The EEPROM is not accessible by
the LM3S6965 microcontroller.
For full details on FT2232 operation, go to www.ftdichip.com.
USB to JTAG/SWD
The FT2232 USB device performs JTAG/SWD serial operations under the control of the debugger.
A CPLD (U2) multiplexes SWD and JTAG functions and, when working in SWD mode, provides
direction control for the bidirectional data line.
Virtual COM Port
The Virtual COM Port (VCP) allows Windows applications (such as HyperTerminal) to
communicate with UART0 on the LM3S6965 over USB. Once the FT2232 VCP driver is installed,
Windows assigns a COM port number to the VCP channel.
Serial Wire Out
The evaluation board supports the Cortex-M3 serial-wire output (SWO) trace capabilities. Under
debugger control, the CPLD can route the SWO datastream to the virtual communication port
(VCP) transmit channel. The debugger can then decode and interpret the trace information
received from the VCP. The normal VCP connection to UART0 is interrupted when using SWO. Not
all debuggers support SWO. Refer to the Stellaris LM3S6965 data sheet for additional information
on the trace port interface unit (TPIU).
Organic LED Display
The EVB features an organic LED (OLED) graphics display with 128 x 96 pixel resolution. OLED is
a new technology that offers many advantages over LCD display technology.
Features
RiT P14201 series display
128 columns by 96 rows
High-contrast (typ. 500:1)
Excellent brightness (120 cd/m2)
Fast 10 us response

Hardware Description
14 January 6, 2010
Control Interface
The OLED display has a built-in controller IC with synchronous serial and parallel interfaces.
Synchronous serial (SSI) is used on the EVB as it requires fewer microcontroller pins. Data cannot
be read from the OLED controller; only one data line is necessary. Note that the SSI port is shared
with the microSD card slot. The Stellaris® Firmware Development Package (included on the
Documentation and Software CD) contains complete drivers with source-code for the OLED
display.
Power Supply
A +15-V supply is needed to bias the OLED display. A FAN5331 device from Fairchild combines
with a few external components to complete a boost converter. When the OLED display is
operating, a small amount of power can be drawn from the +15-V rail to power other devices.
Design Guidelines
The OLED display has a lifetime of about 13,000 hours. It is also prone to degradation due to
burn-in, similar to CRT and plasma displays. The quickstart application includes both a screen
saver and a power-down mode to extend display life. These factors should be considered when
developing EVB applications that use the OLED display.
When using the EVB as an in-circuit debug interface (ICDI), the OLED display is held in reset to
reduce power consumption and eliminate display wear-out.
Further Reference
For additional information on the RiT OLED display, visit www.ritekdisplay.com.
Other Peripherals
Speaker
A small, magnetic audio transducer connects through a MOSFET to PD1/PWM1, allowing a range
of options for generating simple and complex tones. Use of the +5-V rail reduces switching noise
on the +3.3-V rail.
MicroSD Card Slot
Removable Flash cards are an ideal media for storing data such as web page content. The source
code on the CD includes example code for reading data from standard FAT formatted SD cards.
All data and control transactions use the SD card’s SPI mode. Note that the SD card specification
does not require that a card supports the SPI mode, but most cards do so in practice. Cards from
several vendors have been used with the EVB.
MicroSD cards are very small and require careful handling. the SD card slot on the EVB is a push-
push type (push to insert; push again to eject).
Note: To avoid damage, remove power before inserting or removing cards.The EVB does not
implement SD card power control.
Push Switches
The EVB has five general-purpose input switches. Four are arranged in a navigation-style
configuration. The fifth functions as a Select switch.

Stellaris® LM3S6965 Evaluation Board
January 6, 2010 15
User LED
A user LED (LED3) is provided for general use. The LED is connected to PC5/CCP1, allowing the
option of either GPIO or PWM control (brightness control). Refer to the Quickstart Application
source code for an example of PWM control.
Bypassing Peripherals
Excluding Ethernet, the EVB’s on-board peripheral circuits require 16 GPIO lines. Two additional
GPIO lines are assigned to Ethernet LEDs. This leaves 20 GPIO lines and 4 ADC channels
immediately available for connection to external circuits. If an application requires more GPIO
lines, the on-board hardware can be disconnected. The EVB is populated with 16 jumper links,
which can be cut with a knife to isolate on-board hardware. The process can be reversed by
installing 0603- 0-ohm chip resistors.
Important: The quickstart application will not run if one or more jumpers are removed.
Interfacing to the EVB
An array of accessible I/O signals makes it easy to interface the EVB to external circuits. All
LM3S6965 I/O lines (except those with both JTAG and SWD functions) are brought out to 0.1”
pitch pads. For quick reference, silk-screened labels on the PCB show primary pin functions.
Table B-1 on page 25 has a complete list of I/O signals as well as recommended connectors.
Table 2-2. Isolating On-Board Hardware
MCU Pin EVB Function To Isolate, Remove...
Pin 26 PA0/U0RX Virtual COM port receive JP1
Pin 27 PA1/U0TX Virtual COM port transmit JP2
Pin 10 PD0/IDX0 SD card chip select JP3
Pin 11 PD1/PWM1 Sound JP4
Pin 30 PA4/SSI0RX SD card data out JP5
Pin 31 PA5/SSI0TX SD card and OLED display data in JP6
Pin 28 PA2/SSI0CLK SD card and OLED display clock JP7
Pin 22 PC7/PHB0 OLED display data/control select JP8
Pin 29 PA3/SSI0FSS OLED display chip select JP9
Pin 73 PE1/PWM5 Down switch JP10
Pin 74 PE2/PHB1 Left switch JP11
Pin 72 PE0/PWM4 Up switch JP12
Pin 75 PE3/PHA1 Right switch JP13
Pin 61 PF1/IDX1 Select switch JP14
Pin 47 PF0/PWM0 User LED JP15
Pin 23 PC6/CCP3 Enable +15 V JP16

Hardware Description
16 January 6, 2010
Most LM3S6965 I/O signals are +5-V tolerant. Refer to the LM3S6965 data sheet for detailed
electrical specifications.
Using the In-Circuit Debugger Interface
The Stellaris LM3S6965 Evaluation Kit can operate as an In-Circuit Debugger Interface (ICDI).
ICDI acts as a USB to the JTAG/SWD adaptor, allowing debugging of any external target board
that uses a Stellaris microcontroller. See “Debugging Modes” on page 12 for a description of how
to enter Debug Out mode.
Figure 2-1. ICD Interface Mode
The debug interface operates in either Serial-Wire Debug (SWD) or full JTAG mode, depending on
the configuration in the debugger IDE.
The IDE/debugger does not distinguish between the on-EVB Stellaris microcontroller and an
external Stellaris microcontroller. The only requirement is that the correct Stellaris device is
selected in the project configuration.
Evaluation Board Target
Board
Stellaris
MCU
Target
Cable
`
USB
PC with IDE/
debugger
Stellaris
MCU
TCK/SWCLK bypasses the
on-board microcontroller
JTAG or SWD connects to the
external microcontroller
Connecting Pin 18 to GND sets
external debug mode

January 6, 2010 17
Schematics
This section contains the schematics for the LM3S6965 evaluation board:
LM3S6965 Micro and 10/100 Ethernet on page 18
OLED Display, Switches, and Audio on page 19
USB, Debugger Interfaces, and Power on page 20
JTAG Logic with Auto Mode Detect and Hibernate on page 21
APPENDIX A

1
1
2
2
3
3
4
4
5
5
6
6
D D
C C
B B
A A
Document Number:
RevSheetDate: of
3/26/2008 1 3
Drawing Title:
Page Title:
Size
Ethernet Evaluation Board
LM3S6965 Micro and 10/100 Ethernet
B
D
1
Revision Date Description
History
18PF
C8
18PF
C9
INT_TCK
TMS/SWDIO
PC2/TDI
PC3/TDO
ADC3
ADC2
ADC1
ADC0
MCURSTn
6
5
8
4
2
3
1
7
1CT:1
TX+
TX-
RX+
RX-
1CT:1
Y+
Y-
G+
G-
3
8
7
4
5
6
11
12
2
1
GL
GR
9
10 NC
GND
P4
J3011G21DNL
R3
49.9
+3.3V
C7
0.01UF
R2
49.9
R6
49.9 R7 49.9
C3
0.1UF
+3.3V
C4
0.1UF
+3.3V
C6
10pF
C1
10pF C2 10pF
C18
0.01UF
C13
0.01UF C14 0.01UF C16 0.1UF
C15
0.1UF
C12
0.1UF
+3.3V
+3.3V
R4
330
PA1/U0Tx
PA2/SSI0CLK
PA3/SSI0FSS
PA4/SSI0RX
PA5/SSI0TX
PA0/U0Rx
R1
10K
+3.3V
Stellaris Microcontroller
R5
330
+3.3V
+3.3V
PA6/I2CSCL
PA7/I2CSDA
TMS/SWDIO
PC2/TDI
PC3/TDO
PC4/PhA0
PC5/C1+/C0o
PC6/CCP3
PC7/PhB0
PE0/PWM4
PE1/PWM5
PE2/PhB1
PE3/PhA1
PG0/U2RX
PG1/U2TX
PF1/IDX1
PF0/PWM0
PD7/CCP1
PD6/FAULT
PD5/CCP2
PD4/CCP0
PD3/U1TX
PD2/U1RX
PD1/PWM1
PD0/IDX0
PB7/TRST
PB6/C0+
PB5/C1-
PB4/C0-
PB3/I2CSDA
PB2/I2C0SCL
PB1/PWM3
PB0/PWM2
PF2/LED1
PF3/LED0
C19
0.1UF C20 4.7UF
C17
4.7UF
Ethernet 10/100baseT
1 2
Y1
25.00MHz
JP1
JP2
PA0/U0Rx
PA1/U0Tx
VCP_RX
VCP_TX
JP7
JP9 SSICLK
OLEDCSn
PA2/SSI0CLK
PA3/SSI0FSS
JP6
SSITX
PA5/SSI0TX
On-board Peripheral Signals
free GPIO lines as required.
JP14
SELECT_SWn
JP15
LED
JP12
UP_SWn
JP10
DOWN_SWn
JP11
JP13 LEFT_SWn
RIGHT_SWn
Jumpers can be cut to
JP4
SOUND
JP5
SSIRX
PA4/SSI0RX
OSC32IN
OSC32OUT
JP8
OLEDDC
JP3
CARDCSn
PF1/IDX1
PF0/PWM0
PE0/PWM4
PE1/PWM5
PE2/PhB1
PE3/PhA1
PD1/PWM1
PD0/IDX0
PD4/CCP0
PD6/FAULT
PC7/PhB0
C5
10pF
12
3334 3635
59 60
ADC3
ADC1
PD0/IDX0
PD2/U1RX
PG1/U2TX
PC7/PhB0
PC5/C1+/C0o
PA1/U0Tx
PA3/SSI0FSS
PA5/SSI0TX
PA7/I2CSDA
PB4/C0-
PD5/CCP2
PD7/CCP1
ADC0
ADC2
PD1/PWM1
PD3/U1TX
PG0/U2RX
PC6/CCP3
PC4/PhA0
PA0/U0Rx
PA2/SSI0CLK
PA4/SSI0RX
PA6/I2CSCL
+3.3V
+5V
+15V
PB5/C1- PB6/C0+
PB7/TRST PC2/TDI
PC3/TDO PE3/PhA1
PE2/PhB1
PE0/PWM4 PE1/PWM5
PB2/I2C0SCL PB3/I2CSDA
PB1/PWM3
PF1/IDX1 PB0/PWM2
PF3/LED0 PF2/LED1
OSC32OUT
OSC32IN
+3.3V
PF0/PWM0
I/O Break-out Headers
R33
10K
+3.3V
1 2
Y3
8.00MHz
18PF
C40
18PF
C41
A 5/12/07 First Production Release
B 6/29/07 Improve SWD out feature, add SWO support, 1-bit
C 8/09/07 Change to RiT 128x96 OLED display
OLED display option.
JP16
EN+15V
PC6/CCP3
Install R271/25/08
+3.3V
R35
12.4K
PA0/U0RX
26
PA1/U0TX
27
PA2/SSI0CLK
28
PA3/SSI0FSS
29
PA4/SSI0RX
30
PA5/SSI0TX
31
PC0/TCK/SWCLK
80
PC1/TMS/SWDIO
79
PC2/TDI
78
PC3/TDO/SWO
77
PC4/PhA0
25
PC5/C1+/C0o
24
PC6/CCP3
23
PC7/PhB0
22
PD0/IDX0 10
PD1/PWM1 11
PD2/U1RX 12
PD3/U1TX 13
PD4/CCP0 95
PD5/CCP2 96
PD6/FAULT 99
PD7/CCP1 100
GND
9
GND
15
GND
21
GND
33
RST
64
LDO 7
MOSCin
48
MOSCout
49
PB0/PWM2 66
PB1/PWM3 67
PB2/I2C0SCL 70
PB3/I2C0SDA 71
PB4/C0- 92
PB5/C1- 91
PB6/C0+ 90
PB7/TRST 89
PE0/PWM4
72
PE1/PWM5
73
PE2/PhB1
74
PE3/PhA1
75
ADC3
6ADC2
5
PA6/I2C1SCL
34
PA7/I2C1SDA
35
ADC1
2ADC0
1
PF0/PWM0 47
PF1/IDX1 61
PF2/LED1 60
PF3/LED0 59
MDIO 58
TXON 46
TXOP 43
ERBIAS 41
PG0/U2RX
19
PG1/U2TX
18
XTALNPHY
17
XTALPPHY
16
GND
42
RXIP 40
RXIN 37
VDD33 36
GND
86 GND
85
VDD33 84
VDD33 83
AVDD 3
AVDD 98
AGND
97 AGND
4
VDD33 8
VDD33 20
VDD33 32
VDD33 44
VDD33 56
VDD33 68
VDD33 81
VDD33 93
GND
39
GND
45
GND
54
GND
57
GND
63
GND
69
GND
82
GND
87
GND
94 VDD25 14
VDD25 38
VDD25 62
VDD25 88
WAKE
50
HIB
51
XOSC0
52
XOSC1
53
VBAT 55
CMOD0
65
CMOD1
76
U1
LM3S6965
12.4K 1% resistor required on Pin 41 for
compatibility with future LM3S6965 revisions.
See Product Change Notification.
Add R35 for future compatibility.3/25/08DTie R6/R7 to +3.3V. Add TVCC control.
Schematic page 1

1
1
2
2
3
3
4
4
5
5
6
6
D D
C C
B B
A A
Document Number:
RevSheetDate: of
3/26/2008 2 3
Drawing Title:
Page Title:
Size
Ethernet Evaluation Board
OLED Display, Switches and Audio
B
D
2
R18
330
DBGOUTLED
Reset
SW1
SW-B3S1000
SELECT_SWn
UP_SWn
DOWN_SWn
LEFT_SWn
RIGHT_SWn
RESET_SWn
R15
10K
+3.3V
Select
Up
Down
Left
Right
Debug Out
R16
330
LED
Status
R20
330
Power
R9
2.2
+5V
Q1
NDS331N
R12
10K
SOUND
Speaker Circuit
Status LEDs
User Switches
+3.3V
D1
MBR0520
SW2
SW-B3S1000
SW3
SW-B3S1000
SW4
SW-B3S1000
SW5
SW-B3S1000
SW6
SW-B3S1000
microSD Card Slot
1
2
3
4
5
6
7
8
9
10 11 12
P3
2908-05WB-MG
+3.3V
C28
0.1UF
+3.3V
CARDCSn
SSITX
SSICLK
SSIRX
R17
10K
R19
10K
+3.3V
+3.3V
1
2
BZ1
NFT-03A
LED2
Green
LED3
Red
LED4
Green
C30
OMIT
R14
200K
SSITX
SSICLK
+3.3V
128x96 OLED Graphics Display
C26
4.7UF
MCURSTn
OLEDDC
+15V
OLEDCSn
C23
0.1UF C21 0.1UF
RGS13128096WH000
NC
1
VCIR
2
VCOMH
3
LVSS
4
VSS
5
BS1
6
BS2
7
IREF
8
CSn
9
RESn
10
D/Cn
11
R/Wn
12
E
13
D0/SCLK
14
D1/SDIN
15
D2
16
D3
17
D4
18
D5
19
D6
20
D7
21
VDDIO
22
VDD
23
VCC
24
NC
25
U2
OLED-RIT-128X96
+15V 50mA Power Supply for OLED Display
+15V
FB 3
VIN
5
SHDNn
4GND 2
SW 1
U7
FAN5331
+5V
C24
4.7UF C25
4.7UF
D2
MBR0520
0.1UF
C22
120pF
C27
R13
200K
R11
17.8K
EN+15V
R10
10K
10uH
L1
NR4018T100M
+3.3V
Schematic page 2

1
1
2
2
3
3
4
4
5
5
6
6
D D
C C
B B
A A
Document Number:
RevSheetDate: of
3/26/2008 3 3
Drawing Title:
Page Title:
Size
Ethernet Evaluation Board
USB, Debugger Interfaces and Power
B
D
3
FB1
60ohm @ 100 MHz
GND
18
GND
25
GND
34
ADBUS0 24
ADBUS1 23
ADBUS2 22
ADBUS3 21
ADBUS4 20
ADBUS5 19
ADBUS6 17
ADBUS7 16
ACBUS0 15
ACBUS1 13
ACBUS2 12
ACBUS3 11
BDBUS0 40
BDBUS1 39
BDBUS2 38
BDBUS3 37
BDBUS4 36
BDBUS5 35
BDBUS6 33
BDBUS7 32
BCBUS0 30
BCBUS1 29
BCBUS2 28
BCBUS3 27
SI/WUA 10
SI/WUB 26
GND
9
AGND
45
VCC 3
VCC 42
VCCIOA 14
VCCIOB 31
AVCC 46
PWREN# 41
XTOUT
44 XTIN
43
EECS
48
EESK
1
EEDATA
2
TEST
47
RESET#
4
RSTOUT#
5
3V3OUT
6
USBDM
8
USBDP
7
U4
FT2232D
+3.3v
USB+5V
R21 27
R22 27
1 2
3 4
5 6
7 8
910
11 12
13 14
15 16
17 18
19 20
P2
Header 10X2
+3.3V
+3.3V
DBG_JTAG_EN
R24
10K
R25
1.5K
R23
1.5K
R30
330
+5V
+5V
+5V+5V
XTDI
XTMS
TCK
TDI/DI
TDO/DO
TMS/OUTEN
+3.3V+5V
0.1UF
C37 0.1UF
C33
0.1UF
C34
0.1UF
C35
0.1UF
C36
0.1UF
C31
USB Device Controller
Channel A : JTAG / SW Debug
Channel B : Virtual Com Port
USB +5V to +3.3V 500mA Power Supply
R31
27
R29
27
R26
27
XTCK
R28
27
VCP_RX
VCP_TX
TCK/SWCLK
PC2/TDI
PC3/TDO
TMS/SWDIO
C32
0.01UF
5V D- D+ ID G
1 2 3 4
7
5
6
P1 54819-0519 +3.3V
SRSTN
TARGETCABLEn
XTDO
R27
27
TP4
TP3
TP2
TP1
TP5
TP6
+3.3V
PLD JTAG TEST POINTS
PLD_TCK
PLD_TMS
PLD_TDI
PLD_TDO
VOUT 4
SENSE 5 VIN2
6
GND
2
NC 3
GND 7
VIN1
1U6
LP8345ILD-3.3
USB+5V
R32
4.7K
+3.3v
Debug Interface Logic
JP18
PC3/TDO
TCK/SWCLK
TMS/SWDIO
PC2/TDI
C38
4.7UF C39 4.7UF
JTAG/SWD Interface
Input/Output
USB Interface
TDI 1
A5
2
A6
3
A7
4
GND (Bank 0)
5
VCCO (Bank 0)
6
A8
7
A9
8
A10
9
A11
10
TCK 11
VCC 12
GND 13
A12
14
A13
15
A14
16
A15
17 CLK1/I 18
CLK2/I 19
B0 20
B1 21
B2 22
B3 23
B4 24
TMS 25
B5 26
B6 27
B7 28
GND (Bank 1)
29 VCCO (Bank 1) 30
B8 31
B9 32
B10 33
B11 34
TDO 35 VCC 36
GND 37
B12 38
B13
39 B14 40 B15/GOE1 41
CLK3/I 42 CLK0/I 43
A0/GOE0
44
A1
45
A2
46
A3
47
A4
48
Bank 0 Bank 1
U3
LC4032V-75TN48C
+3.3V
PC2/TDI
MCURSTn
DBGOUTLED
TARGETCABLEn
PC3/TDO
RESET_SWn
0.1UF
C29
+3.3V
TMS/SWDIO
TCK/SWCLK
Omit
JP17
USBSH
CS 1
SK 2
DI 3
DO 4 GND
5ORG
6NC
7VCC
8
1K 64X16
U5
CAT93C46
1 2
Y2
6.00MHz
18PF
C10
18PF
C11
PB7/TRST
0.1UF
C42
R34
4.7K
+3.3V
INT_TCK
SWO_EN
VCP_TX_SWO
MODE
MODE is reserved
for future use.
R8
4.7K
+3.3V
XVCC
Schematic page 3
