Read This First
Preface
Read This First
About This Manual
This user’s guide describes the characteristics, operation, and use of the
Modular MSOP8 EVM. This EVM is a multi-device, 12 to 16 bit, SSI, analog
to digital converter Evaluation Module. A complete circuit description, as well
as schematic diagram and bill of materials, are included.
How to Use This Manual
This document contains the following chapters:
Chapter 1—EVM Overview
Chapter 2—Analog Interface
Chapter 3—Digital Interface
Chapter 4—Power Supplies
Chapter 5—EVM Operation
Chapter 6—EVM Bill of Materials and Schematic
Information About Cautions and Warnings
This book may contain cautions and warnings.
This is an example of a caution statement.
A caution statement describes a situation that could potentially
damage your software or equipment.
This is an example of a warning statement.
A warning statement describes a situation that could potentially
cause harm to you.

-4
The information in a caution or a warning is provided for your protection.
Please read each caution and warning carefully.
Related Documentation From Texas Instruments
To obtain a copy of any of the following TI documents, call the Texas
Instruments Literature Response Center at [phone] or the Product
Information Center (PIC) at [phone]. When ordering, identify this
booklet by its title and literature number. Updated documents can also be
obtained through our website at www.ti.com.
EVM Compatible Device Data Sheets: Literature Number:
ADS7816 SBAS110
ADS7817 SBAS230
ADS7818 SBAS078
ADS7822 SBAS062
ADS7834 SBAS098
ADS7835 SBAS102
ADS8320 SBAS108
ADS8321 SBAS123
ADS8324 SBAS172
ADS8325 SBAS226
Application Notes/Additional Literature: Literature Number:
Op Amps for Everyone SLOD006
5-6K Interface Board SLAU104
Single and Bipolar Supply Signal Conditioning Boards SLAU105
Third Party Tools: Vendor Website:
HPA449 Development Board (MSP430 Tools) www.softbaugh.com
Speedy 33 (DSP Tools) www.hyperception.com
FCC Warning
This equipment is intended for use in a laboratory test environment only. It gen-
erates, uses, and can radiate radio frequency energy and has not been tested
for compliance with the limits of computing devices pursuant to subpart J of
part 15 of FCC rules, which are designed to provide reasonable protection
against radio frequency interference. Operation of this equipment in other en-
vironments may cause interference with radio communications, in which case
the user at his own expense will be required to take whatever measures may
be required to correct this interference.

-1
Contents
Contents
1 EVM Overview 1-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.1 Features 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.2 Introduction 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2 Analog Interface 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3 Digital Interface 3-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4 Power Supplies 4-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.1 ADC Power 4-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.2 Stand Alone Operation 4-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.3 Reference Voltage 4-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5 EVM Operation 5-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.1 Analog Input 5-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.2 Digital Control 5-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.3 Chip Select (Shut Down) 5-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.4 Digital I/O Buffers 5-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.5 Default Jumper Locations 5-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6 EVM BOM and Schematic 6-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6.1 EVM Schematic 6-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tables
2-1 Analog Interface Pin Out 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3-1 Digital Interface Pin Out 3-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4-1 Power Supply Pin Out 4-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5-1 List of Jumpers 5-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6-1 Bill of Materials 6-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

-2

1-1
EVM Overview
EVM Overview
The following section gives a general overview of the Modular MSOP8
evaluation board.
Topic Page
1.1 Features 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.2 Introduction 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 1

Features
1-2
1.1 Features
Full-featured evaluation board for a variety of single channel, eight pin Mi-
cro SOP, 12 and 16-bit, serial Output, analog to digital converters
On-board reference and buffer circuits
High-speed serial interface
Modular design for use with a variety of DSP and micro controller interface
boards
1.2 Introduction
The Modular MSOP8 Evaluation Module is an updated version of the
Burr-Brown DEM-MSOP8 evaluation board. The EVM is designed so that a
single printed wiring board (PWB) supports a variety of high speed 12 and 16
bit serial ADC’s.
The modular EVM form factor allows for direct evaluation of the ADC’s
performance and operating characteristics. This EVM is compatible with the
5-6K Interface Board (SLAU104) from Texas Instruments and additional 3rd
party boards such as the HPA449 demonstration board from SoftBaugh, Inc.
(www.softbaugh.com) and the Speedy33tfrom Hyperception, Inc.
(www.hyperception.com).

2-1
Analog Interface
Analog Interface
For maximum flexibility, the Modular MSOP8 EVM is designed for easy
interfacing to multiple analog sources. Samtec part numbers
SSW-110-22-F-D-VS-K and TSM-110-01-T-DV-P provide a convenient 10-pin
dual row header/socket combination at J1. This header/socket provides
access to the analog input pins of the ADC. Consult Samtec at
www.samtec.com or call 1-800-SAMTEC-9 for a variety of mating connector
options.
Table 2-1.Analog Interface Pin Out
Pin Number Signal Description
J1.2 AD_IN+ Noninverting Input (Differential Devices)/Analog Input (Single Ended Devices)
J1.4 AD_IN- Inverting Input (Differential Devices)/Analog Ground (Single Ended Devices)
J1.6 Unused
J1.8 Unused
J1.10 Unused Pins are unused and should be left open for use with future amplifier and sensor
J1.12 Unused Pins are unused and should be left open for use with future amplifier and sensor
input modules.
J1.14 Unused
J1.16 Unused
J1.18 REF(-) Unused
J1.20 REF(+) External Reference Source Input (2.5V NOM, 2.525 MAX)
J1.15 Unused
J1.1- J1.19
(odd) AGND Analog ground connections (except J1.15)
Chapter 2

2-2

3-1
Digital Interface
Digital Interface
The Modular MSOP8 EVM is designed for easy interfacing to multiple control
platforms. Samtec part numbers, SSW-110-22-F-D-VS-K and
TSM-110-01-T-DV-P, provide a convenient 10-pin dual row header/socket
combination at J2. This header/socket provides access to the digital control
and serial data pins of the MSOP8 EVM. Consult Samtec at www.samtec.com
or 1-800-SAMTEC-9 for a variety of mating connector options.
Table 3-1.Digital Interface Pin Out
Pin Number Signal Description
J2.1 CS Chip Select –Active low signal, enables data transfer –jumper configurable
(see schematic)
J2.3 SCLK Serial Clock
J2.5 SCLKR Serial Clock Return (for DSP Host systems)
J2.7 FS Frame Sync for DSP host systems –alternate Chip Select through JMP2 (see
schematic)
J2.9 FSR Frame Sync Return (for DSP Host systems)
J2.11 Unused
J2.13 SDO Serial Data Output
J2.15 Unused
J2.17 Unused
J2.19 SPARE
Chapter 3

3-2

4-1
Power Supplies
Power Supplies
The Modular MSOP8 EVM board requires 5 V dc for the analog section. This
includes the voltage reference (U2), the reference buffer (U4), and optionally,
the ADC installed on the EVM (via JMP1). Supply voltages of 1.8 V to 5 V dc
for the digital section are also required. When used in combination with one
of the DAP Interface boards, J3 provides connection to the common power bus
described in document SLAU104. Table 4-1 shows the pin out of J3.
Table 4-1.Power Supply Pin Out
Signal Pin Number Signal
Unused 1 2 Unused
+5VA 3 4 Unused
DGND 5 6 AGND
+1.8VD 7 8 +VD1
+3.3VD 9 10 +5VD
When power is supplied to J3, JMP3 allows for one of four different dc voltages
to be applied to the digital sections of the ADC. See the schematic and PWB
silkscreen for details.
Topic Page
4.1 ADC Power 4-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.2 Stand Alone Operation 4-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.3 Reference Voltage 4-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 4

ADC Power
4-2
4.1 ADC Power
The device installed on the modular MSOP8 EVM has several options in
regards to its power source. Refer to the schematic for the following
discussion.
JMP1 and JMP3 allow the user to select the power supply used by the ADC.
When JMP1 is in the default factory position (Shunt on pins 1-2), power to the
ADC comes from J3.3 or TP5. Single gate digital buffers (U3, U5, and U6) are
installed on the ADC’s digital input/output lines to allow operation with low
voltage controllers, such as the MSP430. The supply voltage to these buffers
is determined by JMP3 or the voltage applied to TP7.
4.2 Stand Alone Operation
When used as a stand alone EVM, the analog power can be applied to TP5,
referenced to TP6. Digital power can be applied to TP7 referenced to TP4.
While filters are provided for all power supply inputs, optimal performance of
the EVM requires a clean, well-regulated power source.
Caution
The ADC’s that are compatible with this EVM have a variety of
power supply requirements. Check the appropriate data sheets
and verify all power supplies are within the safe operating limits of
the ADC before applying power to the EVM.
4.3 Reference Voltage
The modular MSOP8 can be configured to use the onboard reference/buffer
circuits (U2 and U4) or an external reference applied to J1.20. Jumpers JMP5
and JMP6 control the reference source. In the factory default position (shunt
on JMP5 pins 1-2), a 2.5 V reference is supplied by U2. Moving the shunt at
JMP5 to positions 2-3 allows an external reference applied to J1.20 to be
used.
Caution
The ADC’s that are compatible with this EVM have a variety of
reference requirements. Check the appropriate data sheets and
verify external reference sources are within the safe operating
limits of the ADC before applying power to the EVM.
JMP6 controls the actual application of the reference source to the ADC. Note
that JMP6 is not installed on EVM boards for ADS7818, ADS7834, and
ADS7835 devices. In the factory default position (shunt on pins 1-2), the
reference source is the on board reference/buffer circuit. Moving the shunt on
JMP6 to pins 2-3 allows the voltage applied to the ADC (+Vadc) to be used
as the reference source.

5-1
EVM Operation
EVM Operation
The following section provides information in the analog input, digital control,
and general operating conditions of the Modular MSOP8 EVM.
Topic Page
5.1 Analog Input 5-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.2 Digital Control 5-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.3 Chip Select (Shut Down) 5-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.4 Digital I/O Buffers 5-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.5 Default Jumper Locations 5-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 5

Analog Input
5-2
5.1 Analog Input
The analog input source can be applied directly to J1 (top or bottom side) or
through optional amplifier and signal conditioning modules. The analog input
range is dependent on the configuration of the EVM and the ADC installed at
location U1. Consult the datasheet for the device to determine the maximum
analog input range.
5.2 Digital Control
The digital control signals can be applied directly to J2 (top or bottom side).
The modular MSOP8 EVM can also be connected directly to a DSP or a micro
controller interface board, such as the HPA449. See the product folder for the
EVM or the installed device for a current list of compatible interface and/or
accessory boards.
5.3 Chip Select (Shut Down)
Jumper JMP2 is provided to allow the selection of the signals applied to the
chip select (/CS) or shutdown (SHDN) pin of the ADC installed on the EVM.
The factory default condition for the EVM is to place a shunt jumper between
pins 1-2 of JMP2. This allows the Frame Sync (FS) signal from DSP host
systems to be used as a chip select for the ADC. This signal originates from
J2.7. When JMP2 is moved to pins 2-3, the /CS (SHDN) signal is applied via
J2.1.
5.4 Digital I/O Buffers
Single gate buffers U3, U5 and U6 are provided to ensure the safe operation
of the modular MSOP8 EVM with low voltage host controllers. The digital I/O
voltage applied to these buffers via JMP3 should be set in accordance with the
operating voltage of the host controller.
5.5 Default Jumper Locations
Table 5-1 provides a list of jumpers found on the EVM and their factory default
conditions.
Table 5-1.List of Jumpers
Jumper Shunt Position Jumper Description
JMP1 Pins 1-2 Controls ADC Supply Voltage (default is +5Va Source)
JMP2 Pins 1-2 Controls ADC /CS(SHDN) Pin (default is FS from DSP Host)
JMP3 Pins 5-6 Controls Digital I/O Voltage (default is +3.3Vd Source)
JMP4 CLOSED Ties ANALOG and DIGITAL grounds together
JMP5 Pins 1-2 Controls External Ref. Source (default is +2.5V from U2)
JMP6 Pins 1-2 Controls REFERENCE Source to ADC (default is onboard reference/buffer
circuit)

6-1
EVM BOM and Schematic
EVM BOM and Schematic
The following table contains a complete bill of materials for the modular
MSOP8 EVM bill of materials.
Table 6-1.Bill of Materials
Designators Description Manufacturer Mfg. Part Number
C2 C3 C4 C13 Not Installed
R11 Not Installed
C1 0.47 µF, 0805, ceramic, X7R, 25 V, 10% Panasonic ECJ-2YB1C474K
C11 C12 C14 0.1 µF, 0805, ceramic, X7R, 50 V, 10% Panasonic ECJ-2YB1H104K
C6 C8 C10 10 µF, 1206, ceramic, Y5V, 10 V, 10% Panasonic ECJ-3YF1A106Z
C5 C14 C15 10 µF, A case, tantalum, 10 V Panasonic ECS-T1AY106R
L1 L2 L3 15 µH inductor, SMT, 1608 Series Inductors, Inc. CTDS1608C-153
J1 J2 (top side) 10 Pin, dual row, SMT header (20 [postive) Samtec TSM-110-01-T-DV-P
J1B J2B (bottom side) 10 Pin, dual row, SMT socket (20 positive) Samtec SSW-110-22-F-D-VS-K
J3 (bottom side) 5 Pin, dual row, SMT socket (10 posotove) Samtec SSW-105-22-F-D-VS-K
R9 R10 R12 33 Ω, 0805, 5%, .1W Resistor Yageo America 9C08052A33R0JLHFT
R1 R2 R3 R4 R6 0 Ω, 0805, 0.1 W resistor Yageo America 9C08052A0R00JLHFT
TP1 TP2 TP3 TP5 TP7 Red test point loop Keystone 5001
TP4 TP6 Black test point loop Keystone 5000
U1 Varies (see Note)
U2 REF3025 TI REF3025AIDBZT
U3 U5 U6 SN74LVC1G125 TI SN74LVC1G125DBVT
U4 OPA353N TI OPA353NA/250
JMP1 JMP2 JMP5
JMP6 3 Pin , 2 mm header Samtec TMMH-103-C-S-T
JMP3 4 Pin, dual row, TH header (8 positive) Samtec TSW-104-07-L-D
Note: The device installed at location U1 is dependent on the EVM ordered. This device is soldered to the board for best perfor-
mance. U1 may be replaced with any device listed in the EVM compatible device data sheets table found at the beginning
of this document.
Topic Page
6.1 EVM Schematic 6-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 6

EVM Schematic
6-2
6.1 EVM Schematic
The schematic diagram is provided as a reference.
