Texas Instruments LMK00105 User manual

1
SNLU097A–March 2012–Revised July 2019
Submit Documentation Feedback Copyright © 2012–2019, Texas Instruments Incorporated
LMK00105 User’s Guide
User's Guide
SNLU097A–March 2012–Revised July 2019
LMK00105 User’s Guide
This user guide describes how to set up and operate the LMK00105 evaluation board kit (EVK). The
LMK00105 is a high performance, low noise, low voltage CMOS fanout buffer. The core voltage can be
2.5 or 3.3 volts, while the power supply for the outputs can be selected from: 1.5 V, 1.8 V, 2.5 V, or 3.3 V,
provided that it does not exceed the core supply voltage™
Contents
1 Introduction ................................................................................................................... 2
2 Quick Start Setup............................................................................................................ 2
2.1 Quick Start Description............................................................................................. 3
3 Signal Path and Control Switches......................................................................................... 3
4 Power Supplies .............................................................................................................. 4
5 Clock Inputs .................................................................................................................. 4
5.1 Crystal Oscillator Interface......................................................................................... 4
5.2 Configuring OSCin for a Crystal Mode........................................................................... 4
6 Clock Outputs ................................................................................................................ 4
7 Schematics ................................................................................................................... 5
8 PCB Layout................................................................................................................... 7
9 Bill of Materials............................................................................................................... 9
List of Figures
1 LMK00105 Quick Start Setup.............................................................................................. 2
2 Schematic Sheet 1 .......................................................................................................... 5
3 Schematic Sheet 2 .......................................................................................................... 6
4 PCB Top ...................................................................................................................... 7
5 Bottom Side (Layer Inverted, Not to Scale) .............................................................................. 8
List of Tables
1 Part Description.............................................................................................................. 2
2 Default Clock Output Modes / Interfaces................................................................................. 3
3 Input Selection (0=SW OFF, 1=SW ON) ................................................................................. 3
4 Output Enable Selection (0=OFF, 1=ON) ............................................................................... 3
5 Power Supply Configuration................................................................................................ 4
6 Bill of Materials............................................................................................................... 9

Output
Power Supply
Core
Power Supply
Single Ended
Oscillator Input
CLKin
Differential
Input Select
DIP Switches
CLKout0-
CLKout1
CLKout2-C
CLKout4C
Introduction www.ti.com
2SNLU097A–March 2012–Revised July 2019
Submit Documentation Feedback
Copyright © 2012–2019, Texas Instruments Incorporated
LMK00105 User’s Guide
1 Introduction
This user guide describes how to set up and operate the LMK00105 evaluation board kit (EVK). The
LMK00105 is a high performance, low noise, low voltage CMOS fanout buffer. The core voltage can be
2.5 or 3.3 volts, while the power supply for the outputs can be selected from: 1.5 V, 1.8 V, 2.5 V, or 3.3 V,
provided that it does not exceed the core supply voltage.
Table 1. Part Description
BUFFER IC PACKAGE
U1 LMK00105 LLP-24
2 Quick Start Setup
Figure 1. LMK00105 Quick Start Setup

www.ti.com Quick Start Setup
3
SNLU097A–March 2012–Revised July 2019
Submit Documentation Feedback Copyright © 2012–2019, Texas Instruments Incorporated
LMK00105 User’s Guide
2.1 Quick Start Description
The LMK00105 EVK allows full verification of the device functionality and performance specifications. To
quickly set up and operate the board with basic equipment, refer to the quick start procedure below and
test setup shown in Figure 1.
1. 1. Verify the output mode control switches, S1[1:4], match the states shown in Table 2 to reflect the
default output clock interfaces configured on the EVK.
Table 2. Default Clock Output Modes / Interfaces
SW POSITION/NAME SW STATE
S1[1]/SEL 0 (OFF)
S1[2]/NC Unused
S1[3]/OE 1 (OFF)
S1[4]/NC Unused
2. 2. Connect the Vdd SMA from the board to a 3.3 V source. This powers the core portions of the
LMK00105.
3. 3. Connect the Vddo SMA from the board to a 3.3 V source. This powers the output drivers of the
LMK00105
4. 4. Set the desired clock input using the input selection control switches, S1[1], per Table 3. A
differential clock source can be connected to SMAs CLKin/CLKin*.
Table 3. Input Selection (0=SW OFF, 1=SW ON)
SELECTED INPUT DEFAULT INPUT MODE S1CLKin_Sel State
CLKin/CLKin* Differential clock 0
OSCin Select OSCin 1
Note: CLKin path is configured by default to receive a differential clock as the input. The SMA input is
AC coupled to the device inputs and terminated with 100 Ωdifferential. Refer to the Clock Inputs
section to configure the EVK for a single-ended input.
5. 5. Connect and measure any clock output SMA labeled CLKoutX to an oscilloscope or other test
instrument using SMA cable(s). The output clock will be level-translated/buffered copy of the selected
clock input or crystal oscillator. Note: All output clocks are AC-coupled to the SMA connectors to
ensure safe use with RF instruments.
Note: Switching noise from one or more un-terminated outputs may impair the signal quality of the
measured output(s). To minimize switching noise and EMI, properly terminate any unused output path
using an SMA load or the component options near the SMA outputs, or alternatively, remove the 0 Ω
series resistor nearest the unused output pin.
3 Signal Path and Control Switches
The LMK00105 supports single-ended or differential clocks on CLKin. A second input, OSCin, has an
integrated crystal oscillator interface that supports a fundamental mode, AT-cut crystal or an external
single- 4 LMK00105 Users Guide SNLU097 March 2012 ended clock. The two-input multiplexer is pin-
controlled. To achieve the maximum operating frequency and lowest additive jitter, it is recommended to
use a differential clock with high input slew rate (>1 V/ns) and DC coupling to the CLKin port.
All control pins are configured with the control switch, S3. The output enable logic is shown in Table 4.
Table 4. Output Enable Selection (0=OFF, 1=ON)
CLKout ENABLE MODE S1[3]-OE
Disabled/Hi-Z 0
Enabled 1

Power Supplies www.ti.com
4SNLU097A–March 2012–Revised July 2019
Submit Documentation Feedback
Copyright © 2012–2019, Texas Instruments Incorporated
LMK00105 User’s Guide
4 Power Supplies
By default, Vdd and Vddo are supplied by two external power supplies. To modify the EVK with a different
power supply configuration, populate the resistor options as shown in Table 5. Then, apply the appropriate
voltage(s) to the EVK power input(s).
Decoupling capacitors and 0-ohm resistor footprints, which can accommodate ferrite beads, can be used
to isolate the EVK power input(s) from the device power pins. Do not disconnect or ground any of the
Vddo pins as they are all internally connected inside the device.
Table 5. Power Supply Configuration
DUAL EXTERNAL INPUTS(DEFAULT) SINGLE EXTERNAL INPUT 3.3 V
Vdd input Apply 3.3 V Apply 3.3 V
Vddo input Apply Voltage ≤Vdd Not used
R26 0 ΩDNP
R27 DNP 0 Ω
R28 0 Ω0Ω
5 Clock Inputs
The SMA inputs labeled CLKin &CLKin* are configured to receive a differential clock or single ended
clock. Best performance is achieved with a DC-coupled differential input clock. To configure CLKin for a
single-ended clock remove R8. Then either CLKin or CLKin* may be driven single ended.
5.1 Crystal Oscillator Interface
The LMK00105 has an integrated crystal oscillator interface (OSCin/OSCout) that supports a fundamental
mode, AT-cut crystal. If the crystal input is selected, an optional onboard crystal on either footprint Y1 or
Y2 will start-up and the oscillator clock can be measured on any enabled output.
A crystal with the HC49 footprint can be populated on the bottom side of the PCB. Alternatively, a 3.2 x
2.5 mm crystal can be populated on Y2, located on the top side. Only one crystal footprint should be used
at a time.
The values of C12 and C10 (CEXT) depend on the load capacitance (CL) specified for the crystal. The OSC
input capacitance (CIN) of the device is 1 pF differential, and the trace capacitance (CTRACE) of OSCin and
OSCout is around 1 pF. If the selected crystal is specified for CLof 18 pF, the CEXT is calculated as
follows:
CEXT= (CL–CIN–CTRACE/2) * 2 (1)
CEXT = (18 pF – 1 pF – 1 pF/2) * 2 (2)
CEXT = 33 pF (3)
5.2 Configuring OSCin for a Crystal Mode
To configure the board to use crystal mode remove C15 to disconnect the OSCin Port. Install 0 Ωresistors
on R14 and R9. Install a crystal in either footprint (Y1 or Y2) and install the proper load capacitors in C10
and C12.
6 Clock Outputs
All clock outputs are LVCMOS. In the case that not all outputs are used, any unused outputs should be
left floating.

1 1
2 2
3 3
4 4
5 5
6 6
DD CC
BB AA
1 2
LMK00101 Main Schematic
1/9/2012
LMK0105ENG_Sheet1.SchDoc
Sheet Title: Size: Schematic:
Mod. Date:
File:
Rev: Sheet: of
B
Texas Instruments and/or its licensors do not warrant the accuracy or completeness of this specification or any information contained therein. Texas Instruments and/or its licensors do not warrant that this design will meet the specifications, will besuitable for your application or fit for any particular purpose, or will operate in an implementation. T
exas Instruments and/or its
licensors do not warrant that the design is production worthy.You should completely validate and test your design implementation to confirm the system functionality for your application. http://www.ti.com
Contact: http://www.national.com/support
LMK00105 EVK
Project: Designed for: Public Release
870600754 X1
Assembly Variant: Customer
© Texas Instruments 2012
1
2
3
4
5
CLKin* 142-0701-851
1
2
3
4
5
CLKin 142-0701-851
100 R8
GND
GND
51 R12
DNP 51
R13
DNP
0 R6 0 R10
51 R2
DNP
51
R1
DNP
51 R3
DNP
51 R24
DNP
VDDO
VDDO
GND
VDD
VDDO
5.6pF
C10
DNP
5.6pF C12
DNP
0 R9
DNP
0
R14
DNP
1
2
3
4
5
OSCin 142-0701-851
0.1 F
μ
C15
51 R20
GND GND
40 MHz
Y1
DNP
0 R19
0 R18
GND
0.1 F
μ
C9
0.1 F
μ
C11
Y2
DNP
GND
51 R25
DNP
0.1 F
μ
C3
0.1 F
μ
C1
0.1 F
μ
C2
GND GND
GND
1
2
3
4
5
CLKout3
142-0701-851
GND
1
2
3
4
5
CLKout2
142-0701-851
GND
1
2
3
4
5
CLKout4 142-0701-851
GND
0.1 F
μ
C18
1
2
3
4
5
CLKout0 142-0701-851
GND
GND
0.1 F
μ
C19
GND
1
2
3
4
5
CLKout1 142-0701-851
GND
VDD
10 F
μ
C4
1 F
μ
C5
0.01 F
μ
C6
GND
VDD
SEL
C1_P C1_N
Cin_N
Cin_P
0
R5
GND
VDDO
GND GND
GND
100 R7
DNP
100 R11
DNP
0R17
0R21
6
3 18 27
5
4
S1 A6S-4104-H
0
R4
0 R22
0 R23
0
R16
Note: Parts with Designators greater than or equal to 300 are on the bottom side.
100pF C16
GND
100pF C17
GND
100pF C8
GND
100pF C7
GND
Vddo
2
CLKout0
3
GND
4
CLKout1
5
Vddo
6
GND 7
Vdd 8
GND
1
OSCout 10
GND 11 GND 12 CLKout2 13
Vddo 14
CLKout3 15
GND 16
OSCin 9
Vddo 18
GND
19
CLKin*
20
CLKin
21
SEL
22
Vdd
23
OE
24
CLKout4 17
DAP 25
U1 LMK00105
GND
100pF C14
GND
GND
VDD
OE
www.ti.com Schematics
5
SNLU097A–March 2012–Revised July 2019
Submit Documentation Feedback Copyright © 2012–2019, Texas Instruments Incorporated
LMK00105 User’s Guide
7 Schematics
Figure 2. Schematic Sheet 1

1 1
2 2
3 3
4 4
5 5
6 6
DD CC
BB AA
2 2
LMK00101 Power Supply
1/9/2012
LMK0105ENG_Sheet2.SchDoc
Sheet Title: Size: Schematic:
Mod. Date:
File:
Rev: Sheet: of
B
Texas Instruments and/or its licensors do not warrant the accur
acy or completeness of this
specification or any information contained therein. Texas Instruments and/or its licensors do not warrant that this design will meet the specifications, will besuitable for your application or fit for any particular purpose, or will operate in an implementation. T
exas Instruments and/or its
licensors do not warrant that the design is production worthy.You should completely validate and test your design implementation to confirm the system functionality for your application. http://www.ti.com
Contact: http://www.national.com/support
LMK00105 EVK
Project: Designed for: Public Release
870600754 X1
Assembly Variant: Customer
© Texas Instruments 2012
600754 001
551
PCB Part Number: REV A
-
1
2
3
4
5
Vdd 142-0701-851
11 22
Vdd_TB TERMBLOCK_2
DNP
0
R29
0
R30
DNP
Vdd_In
IN
4
ADJ 6
GND 3
NC
7
SD
8
DAP
9
OUT 5
BYP 1
NC
2
U3 LP3878SD-ADJ/NOPB
DNP
10 F
μ
C23
1 F
μ
C24
0.01 F
μ
C25
GND
VDD
10 F
μ
C304
DNP 10 F
μ
C306
DNP
2200pF C305
DNP
0.01 F
μ
C307
DNP
51k
R310
DNP 2.00k
R312
DNP
866 R311
DNP
GND
GND
GND
GND TP_VDD_LDO
TP_Vdd
TP_Vdd_In
0 R31
DNP
0
R309
DNP
IN
4
ADJ 6
GND 3
NC
7
SD
8
DAP
9
OUT 5
BYP 1
NC
2
U2 LP3878SD-ADJ/NOPB
DNP
10 F
μ
C300
DNP 10 F
μ
C302
DNP
2200pF C301
DNP
0.01 F
μ
C303
DNP
51k
R306
DNP 1.30k
R308
DNP
866 R307
DNP
GND
GND
TP_VDDO_LDO
0 R27
DNP
1 F
μ
C21
VDDO
10 F
μ
C20
0
R28
DNP
1
2
3
4
5
Vddo 142-0701-851
0
R26
GND
TP_Vddo
SO1 0.375" Standoff
SO2 0.375" Standoff
SO3 0.375" Standoff
SO4 0.375" Standoff
0.1 F
μ
C22
GND
GND
Resistor Combinations for Different Output Voltages R116 and R151 = Ra R117 and R152 = Rb Output Voltage Ra Rb 3.3 V 10.7 kOhms 4.7 kOhms 2.5 V 7 kOhms 4.7 kOhms 1.8 V 2.7 kOhms 4.7 kOhms 1.5 V 2.4 kOhms 4.7 kOhms
11 22
Vddo_TB TERMBLOCK_2
DNP
SO5 0.375" Standoff
SO6 0.375" Standoff
LOGO PCB Texas Instruments LOGO PCB ESD Susceptible
Schematics www.ti.com
6SNLU097A–March 2012–Revised July 2019
Submit Documentation Feedback
Copyright © 2012–2019, Texas Instruments Incorporated
LMK00105 User’s Guide
Figure 3. Schematic Sheet 2

www.ti.com PCB Layout
7
SNLU097A–March 2012–Revised July 2019
Submit Documentation Feedback Copyright © 2012–2019, Texas Instruments Incorporated
LMK00105 User’s Guide
8 PCB Layout
Figure 4. PCB Top

PCB Layout www.ti.com
8SNLU097A–March 2012–Revised July 2019
Submit Documentation Feedback
Copyright © 2012–2019, Texas Instruments Incorporated
LMK00105 User’s Guide
Figure 5. Bottom Side (Layer Inverted, Not to Scale)

www.ti.com Bill of Materials
9
SNLU097A–March 2012–Revised July 2019
Submit Documentation Feedback Copyright © 2012–2019, Texas Instruments Incorporated
LMK00105 User’s Guide
9 Bill of Materials
Table 6. Bill of Materials
ITEM DESCRIPTION QTY DESIGNATOR MANUFACTURER
1CAP, CERM, 0.1uF, 16V, +/-10%, X7R,
0603 8 C1, C2, C3, C9, C11, C15, C18, C19 TDK
2CAP, CERM, 10uF, 10V, +/-10%, X5R,
0805 3 C4, C20, C23 MuRata
3 CAP, CERM, 1uF, 16V, +/-10%, X7R, 0603 3 C5, C21, C24 TDK
4CAP, CERM, 0.01uF, 100V, +/-5%, X7R,
0603 2 C6, C25 Kemet
5CAP, CERM, 100pF, 50V, +/-5%,
C0G/NP0, 0603 5 C7, C8, C14, C16, C17 AVX
6CAP, CERM, 0.1uF, 16V, +80/-20%, Y5V,
0603 1 C22 TDK
7 Connector, SMT, End launch SMA 50 ohm 10 CLKin, CLKin*, CLKout0, CLKout1, CLKout2, CLKout3, CLKout4, OSCin,
Vdd, Vddo Emerson Network
Power Connectivity
8 RES, 0 ohm, 5%, 0.1W, 0603 13 R4, R5, R6, R10, R16, R17, R18,
R19, R21, R22, R23, R26, R29 Vishay-Dale
9 RES, 100 ohm, 5%, 0.1W, 0603 1 R8 Vishay-Dale
10 RES, 51 ohm, 5%, 0.1W, 0603 1 R20 Vishay-Dale
11 DIP Switch, 4 position slide actuatoor,
SPST, SMD 1 S1 Omron Electronic Components
12 0.375" Standoff 6 SO1, SO2, SO3, SO4, SO5, SO6
13 Testpoint NA TP_Vdd, TP_Vdd_In, TP_VDD_LDO,
TP_Vddo, TP_VDDO_LDO NA
14 LMK00105 1 U1 Texas Instruments
15 CAP, CERM, 5.6pF, 50V, +/-5%,
C0G/NP0, 0603 0 C10, C12 AVX
16 CAP, CERM, 10uF, 10V, +/-10%, X5R,
0805 0 C300, C302, C304, C306 MuRata
17 CAP, CERM, 2200pF, 100V, +/-5%, X7R,
0603 0 C301, C305 AVX
18 CAP, CERM, 0.01uF, 25V, +/-5%,
C0G/NP0, 0603 0 C303, C307 TDK
19 RES, 51 ohm, 5%, 0.1W, 0603 0 R1, R2, R3, R12, R13, R24, R25 Vishay-Dale
20 RES, 100 ohm, 5%, 0.1W, 0603 0 R7, R11 Vishay-Dale
21 RES, 0 ohm, 5%, 0.1W, 0603 0 R9, R14, R27, R28, R30, R31, R309 Vishay-Dale
22 RES, 51k ohm, 5%, 0.1W, 0603 0 R306, R310 Vishay-Dale
23 RES, 866 ohm, 1%, 0.1W, 0603 0 R307, R311 Vishay-Dale
24 RES, 1.30k ohm, 1%, 0.1W, 0603 0 R308 Vishay-Dale
25 RES, 2.00k ohm, 1%, 0.1W, 0603 0 R312 Vishay-Dale
26 Micropower 800mA Low Noise "Ceramic Stable" Adjustable Voltage Regulator for
1V to 5V Applications, 8-pin LLP, Pb-Free 0 U2, U3 Texas Instruments
27 Crystal, xxxMHz, xxpF 0 Y1
28 Crystal, Citizen CS325, 52 MHz 0 Y2 Citizen

Revision History www.ti.com
10 SNLU097A–March 2012–Revised July 2019
Submit Documentation Feedback
Copyright © 2012–2019, Texas Instruments Incorporated
Revision History
Revision History
NOTE: Page numbers for previous revisions may differ from page numbers in the current version.
Changes from Original (March 2012) to A Revision ....................................................................................................... Page
• Changed document throughout.......................................................................................................... 2

IMPORTANT NOTICE AND DISCLAIMER
TI PROVIDES TECHNICAL AND RELIABILITY DATA (INCLUDING DATASHEETS), DESIGN RESOURCES (INCLUDING REFERENCE
DESIGNS), APPLICATION OR OTHER DESIGN ADVICE, WEB TOOLS, SAFETY INFORMATION, AND OTHER RESOURCES “AS IS”
AND WITH ALL FAULTS, AND DISCLAIMS ALL WARRANTIES, EXPRESS AND IMPLIED, INCLUDING WITHOUT LIMITATION ANY
IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE OR NON-INFRINGEMENT OF THIRD
PARTY INTELLECTUAL PROPERTY RIGHTS.
These resources are intended for skilled developers designing with TI products. You are solely responsible for (1) selecting the appropriate
TI products for your application, (2) designing, validating and testing your application, and (3) ensuring your application meets applicable
standards, and any other safety, security, or other requirements. These resources are subject to change without notice. TI grants you
permission to use these resources only for development of an application that uses the TI products described in the resource. Other
reproduction and display of these resources is prohibited. No license is granted to any other TI intellectual property right or to any third
party intellectual property right. TI disclaims responsibility for, and you will fully indemnify TI and its representatives against, any claims,
damages, costs, losses, and liabilities arising out of your use of these resources.
TI’s products are provided subject to TI’s Terms of Sale (www.ti.com/legal/termsofsale.html) or other applicable terms available either on
ti.com or provided in conjunction with such TI products. TI’s provision of these resources does not expand or otherwise alter TI’s applicable
warranties or warranty disclaimers for TI products.
Mailing Address: Texas Instruments, Post Office Box 655303, Dallas, Texas 75265
Copyright © 2019, Texas Instruments Incorporated
