TPA6043A4 Audio Power Amplifier Evaluation Module
Contents1 Introduction ................................................................................................................... 12 Operation ..................................................................................................................... 33 Schematic and Bill of Materials ............................................................................................ 5
List of Figures
1 TI TPA6043A4 Audio Power Amplifier EVM – Top View ............................................................... 22 TPA6043A4 EVM Schematic ............................................................................................... 53 Top Side Layout.............................................................................................................. 64 Bottom Side Layout .......................................................................................................... 6
List of Tables
1 Gain Settings ................................................................................................................. 4
The TPA6043A4 evaluation module (EVM) consists of a single 2-W stereo speaker amplifier and 85-mWDirectPath™ headphone amplifier complete with a small number of external components mounted on acircuit board that can be used to drive speakers and headphones directly with external analog audiosources as inputs. The TPA6043A4 also contains an LDO capable of outputting 3.3 V with a maximumload of 120 mA.
DirectPath is a trademark of Texas Instruments.
SLOU204 – August 2007 TPA6043A4 Audio Power Amplifier Evaluation Module 1Submit Documentation Feedback

www.ti.com
1.2 TPA6043A4 EVM Specifications
Introduction
Figure 1. TI TPA6043A4 Audio Power Amplifier EVM – Top View
Supply voltage range, VDD 4.5 V to 5.5 VSupply current, IDD 1 A, maximumSpeaker amplifier output power per channel, P
O
: 4 Ω, VDD = 5 V, 2 WTHD+N=10%
Headphone output power per channel, P
O
: 32 Ω, VDD = 5 V, THD+N=10% 85 mW
List of Tables2 SLOU204 – August 2007Submit Documentation Feedback

www.ti.com
2 Operation
2.1 Quick-Start List for Stand-Alone Operation
2.1.1 Speaker Amplifier
2.1.2 Power Supply
2.1.3 Evaluation Module Preparations
Operation
Follow these steps to use the TPA6043A4 EVM stand-alone or when connecting it into existing circuits orequipment. Connections to the EVM can be made by inserting stripped wire or using banana plugs for thepower supply and output connections. The inputs accept standard RCA plugs.
1. Ensure that all external power sources are set to OFF.2. Connect an external regulated power supply adjusted to 5 V to the module VDD (J13) and GND (J14)banana jacks, taking care to observe marked polarity.
Inputs and Outputs1. If connecting to a fully differential input or a grounded input (the shield of the RCA is GND), removejumpers J3 and J4 from the EVM. If connecting to a floating source like a portable CD, install jumpersJ3 and J4. After setting the J3 and J4 jumpers appropriately, connect the input source to either thespeaker inputs (J1 and J2) or the headphone inputs (J11 and J12) or both.2. Connect a speaker across +LOUT (J15) and –LOUT (J16). Connect another speaker across +ROUT(J17) and –ROUT (J18).3. Install both gain jumpers GAIN0 (J5) and GAIN1 (J6). This sets the gain of the amplifier to the lowestlevel, 6 dB.4. Connect a set of headphones to the headphone output jack (J10).
Control Inputs1. Speaker Enable: This terminal is active-low. A LOW on the device terminal (<0.8 V) enables theamplifier; a HIGH (>2 V) on the device terminal places the amplifier in the SHUTDOWN state. Holdingdown switch S1 places the amplifier in the SHUTDOWN state. Releasing S1 returns the amplifier tothe active state.2. Headphone Enable: This terminal is active-high. A LOW on the device terminal (<0.8 V) shuts downthe headphone amplifier; a HIGH (>2 V) on the device terminal places the headphone amplifier in theactive state. Holding down switch S2 places the headphone amplifier in the SHUTDOWN state.Releasing S2 returns the headphone amplifier to the active state.3. GAIN0/GAIN1: Together, these terminals determine the gain of the amplifier. See Table 1 . Installing ajumper in J5 or J6 sets the respective terminal to GND. Removing the jumper sets the respectiveterminals to VDD. Removing jumpers increases the gain whereas installing jumpers decreases thegain. Logic levels are TTL compatible.4. Regulator Enable: Shunt J7 and remove jumper for J19 to enable the regulator output. Removejumper for J7 and shunt J19 to disable the regulator output. Never shunt J19 if J7 is shunt.
SLOU204 – August 2007 List of Tables 3Submit Documentation Feedback

www.ti.com
2.1.4 Power Up
Operation
Table 1. Gain Settings
GAIN0 (J5)
(1)
GAIN1 (J6)
(1)
Amplifier Gain (dB)
ON ON 6ON OFF 10OFF ON 15.6OFF OFF 21.6(1)
OFF = Jumper removed; ON = Jumper installed
1. Verify correct voltage and input polarity, and turn on the external power supplies.The EVM should begin operation.2. Adjust the input signal.3. Adjust the control inputs to the desired settings.4. Adjust the amplifier gain by installing/removing the gain jumpers, J5 and J6.
List of Tables4 SLOU204 – August 2007Submit Documentation Feedback

www.ti.com
3 Schematic and Bill of Materials
3.1 TPA6043A4 EVM Schematic
Schematic and Bill of Materials
Figure 2. TPA6043A4 EVM Schematic
SLOU204 – August 2007 List of Tables 5Submit Documentation Feedback

www.ti.com
3.2 TPA6043A4 EVM PCB Layers
K002
Schematic and Bill of Materials
Figure 3. Top Side Layout
Figure 4. Bottom Side Layout
6List of Tables SLOU204 – August 2007Submit Documentation Feedback

www.ti.com
3.3 TPA6043A4 EVM Bill of Materials
Schematic and Bill of Materials
REF. DESCRIPTION SIZE QTY MFG PART NO. VENDOR NO.
Capacitor, ceramic, 0.47- μF, ±10%,C1–C4 0603 4 TDK C1608X5R1A474K Digi-Key/445-1320-2-NDX5R, 10-V
Capacitor, ceramic, 1- μF, ±10%, X5R,C5–C12 0603 8 TDK C1608X5R1A105KT Digi-Key/445-1321-210-V
Capacitor, ceramic, 0.1- μF, ±10%,C13 0603 1 TDK C1608X7R1H104KT Digi-Key/445-1314-2X7R, 50-V
Capacitor, ceramic, 2.2- μF, 6.3 V,C14 0603 1 TDK C1608X5R0J225M Digi-Key/445-1323-1-NDX5R, 20%
Capacitor, ceramic, 10- μF, 6.3 V,C15–C17 0805 3 TDK C2012X5R0J106 Digi-Key/445-1363-1-NDY5R, 20%
R1–R5 Resistor, chip, 100 k Ω, 1/10W, 5% 0603 5 Panasonic ERJ-3GEYJ104V Digi-Key/P100KG
J1, J2, J11, J12 Phono jack, PC mount, switched 4 Switchcraft PJRAN1X1U03 Newark/16C1860
J3–J7 Header, 2 position, male 2 mm 5 Norcomp 2163-36-01-P2 Digi-Key/2163S-36
J10 Headphone jack 3 Kycon, Inc. STX-3081-5N Mouser/806-STX-3081-5t
Banana jack w/knurled thumbnutJ15–J18 6 Johnson 111-2223-001 Digi-Key/J587(nickel plate)
J19, J20 2 pin 0.1 in. breakaway header 0.1 in. 2 Sullins PBX26SAAN Digi-Key/PBC36SAAN
S1, S2 Switch, momentary, SMD, low profile 2 Panasonic EVQ-PPBA25 Digi-Key/P8086S
TPA6043A4 2-W stereo audio powerU1 RTV (S-PQFP-N32) 1 TI TPA6043A4amplifier
32-pin QFN 5-mm sq. and 0,5-mm spacing and exposed thermal pad
SLOU204 – August 2007 List of Tables 7Submit Documentation Feedback
