Texecom Premier Elite ComPort+ User manual

Installation Manual
Premier Elite ComPort+
INS664-2

INS664-2 2/6
Content
1.0 Introduction 3 ............................................................................................................................
2.0 PCB Layout and Connections 3 ................................................................................................
3.0 Premier Elite ComPort + Installation 4 ..................................................................................
4.0 Programming the Control Panel 5 ..........................................................................................
5.0 Warranty 6 ..................................................................................................................................

INS664-2 3/6
1.0 Introduction
The Premier Elite ComPort+ plugs into the onboard digi connector on Premier
Elite 12/24/48/64/88 & 168 control panels allowing use of Com Port 3.
N Premier Elite 640 already has Com port 3.
V3 firmware is required to enable the device, which when used allows connection
of any device listed in the Com 3 dropdown menu, or connection to a local PC via a
USBCom for upload/download capability.
2.0 PCB Layout and Connections
The figure below shows the PCB layout of the Premier Elite ComPort +
ComPort 3 Device or USBCom1.
Digi Pins Connection (SELV)2.

INS664-2 4/6
3.0 Premier Elite ComPort + Installation
To install the Premier Elite ComPort+ proceed as follows:
Ensure that all power is removed from the control panel before connecting the
Premier Elite ComPort+.
Plug the Premier Elite ComPort+ onto the 10 way onboard digi pins on the control
panel.
Re-apply power to the system and proceed to the next section.
N Premier Elite 168 shown

INS664-2 5/6
4.0 Programming the Control Panel
The control panel will then need to be programmed correctly in order for the
Premier Elite ComPort+ to function as expected:
Programme Premier Elite ComPort+
Enter the engineer code ????
Press 7 then y/y (UDL/Digi Options).
Press 8 then y/y or (Com Port Setup/Onboard Digicom).
Press n/n then 0 to select Nothing Fitted
Press y/y
USBCom
If the Premier Elite ComPort+ is being used simply for local connection of a laptop
no further programming is required. The device will allow connection to the control
panel from a local PC.
ComPort 3
If the Premier Elite ComPort+ is being used to enable Com 3 for one of the optional
devices listed on Com 3 it should be programmed in the same manner as Com 1 or
2. Please see the Premier Elite Installation Manual INS176 for detailed
instructions.
Supply Voltage: 9 – 16VDC
Current Consumption: <1mA + the connected device
Dimensions: 40mm x 30mm x 10mm
Packed Weight: 25g

INS664-2 6/6
Texecom declares that this product
complies with the requirements of the
following directives:
2004/108/EC EMC Directive
2006/95/EC LVD Directive
2011/65/EU RoHS Directive
The product therefore meets all the
requirements to enable it to be CE
marked.
WEEE Directive: 2012/19/EU (WEEE
directive):
Products marked with this symbol
cannot be disposed of as unsorted
municipal waste in the European Union.
For proper recycling, return this product
to your local supplier upon the purchase
of equivalent new equipment, or
dispose of it at designated collection
points. For more information see:
www.recyclethis.info.
This product is suitable for use in systems designed to comply with EN 50131-1, at
Grade 2 and Environmental Class II.
5.0 Warranty
All Texecom products are designed for reliable, trouble-free operation. Quality is
carefully monitored by extensive computerised testing. As a result the Premier
Elite ComPort+ is covered by a two-year warranty against defects in material or
workmanship.
