Texim Europe Quanmax QBOX-2061 User manual

I
QBOX-2061 User’s Manual
QBOX-2061
Fanless BOX PC with Dual Core Intel® Atom™
Processor D2550
User’s Guide

II
QBOX-2061 User’s Manual
Contact Info: Quanmax Inc.
4F, No. 415, Ti-Ding Blvd. Sec. 2NeiHu District,
Taipei 114Taiwan
Tel: [phone]
Fax: [phone]
Visit our site at: www.quanmax.com
© 2012 Quanmax Inc. All rights reserved.
The information in this user’s guide is provided for reference only. Quanmax does not assume any
liability arising out of the application or use of the information or products described herein. This user’s
guide may contain or reference information and products protected by copyrights or patents and does
not convey any license under the patent rights of Quanmax, nor the rights of others.
Quanmax is a registered trademark of Quanmax. All trademarks, registered trademarks, and trade
names used in this user’s guide are the property of their respective owners. All rights reserved. This
user’s guide contains information proprietary to Quanmax. Customers may reprint and use this user’s
guide in other publications. Customers may alter this user’s guide and publish it only after they remove
the Quanmax name, cover, and logo.
Quanmax reserves the right to make changes without notice in product or component design as
warranted by evolution in user needs or progress in engineering or manufacturing technology.
Changes which affect the operation of the unit will be documented in the next revision of this user’s
guide.
Revision Date Edited by Changes
1.0
2012/03/23 Betsy
Initial Release

Content
3
QBOX-2061 User’s Manual
Content
Content.......................................................................................................................3
Figures.......................................................................................................................4
Tables.........................................................................................................................5
Safety Instructions......................................................................................................6
Before You Begin.........................................................................................6
When Working Inside a Computer...............................................................7
Preventing Electrostatic Discharge..............................................................8
Instructions for Lithium Battery....................................................................9
Preface.....................................................................................................................10
How to Use This Guide..............................................................................10
Unpacking..................................................................................................10
Regulatory Compliance Statements ..........................................................10
Warranty Policy ......................................................................................... 11
Maintaining Your Computer.......................................................................12
Chapter 1 Introduction...........................................................................................15
Overview ...................................................................................................15
Product Specifications...............................................................................16
System Tour...............................................................................................17
Mechanical Dimensions.............................................................................19
Chapter 2 Getting Started......................................................................................20
Setting up your PC ....................................................................................20
Chapter 3 AMI BIOS Setup....................................................................................25
Overview ...................................................................................................25
Main Menu.................................................................................................26
Advanced Menu.........................................................................................27
Boot Menu.................................................................................................36
Security Menu............................................................................................37
Save & Exit Menu......................................................................................37
Chapter 4 Driver Installation..................................................................................39

Figures
4
QBOX-2061 User’s Manual
Figures
Figure 1 Front Panel..................................................................................17
Figure 2 Rear Panel...................................................................................18
Figure 3 Mechanical Dimensions...............................................................19
Figure 4 DVI-I / HDMI ................................................................................20
Figure 5 Connect USB mouse & keyboard................................................21
Figure 6 RJ45 connector............................................................................21
Figure 7 Com ports....................................................................................22
Figure 8 DIO port.......................................................................................23
Figure 9 Turning on the system..................................................................24

Tables
5
QBOX-2061 User’s Manual
Tables
Table 1 QBOX-2061 Specification..............................................................16
Table 2 BIOS Main Menu...........................................................................26
Table 3Advanced Menu.............................................................................27
Table 4 Advanced Menu – Display Configuration.......................................28
Table 5 Advanced Menu –Power Management Configuration....................29
Table 6 Advanced Menu –CPU Advanced Configuration...........................30
Table 7Advanced Menu –SATA Configuration...........................................31
Table 8 Advanced Menu –USB Configuration............................................31
Table 9Advanced Menu –DIO Configuration.............................................32
Table 10 Advanced Menu – Super IO Configuration..................................33
Table 11 Advanced Menu – Super IO Configuration – Serial Port 1
Configuration...............................................................................33
Table 12 Advanced Menu – Super IO Configuration – Serial Port 2
Configuration...............................................................................34
Table 13 Advanced Menu –H/W Monitor....................................................35
Table 14 Boot Menu...................................................................................36
Table 15 Security Menu .............................................................................37
Table 16 Save & Exit Menu........................................................................37

Safety Instructions
6
QBOX-2061 User’s Manual
Safety Instructions
Before You Begin
Before handling the product, read the instructions and safety guidelines on the
following pages to prevent damage to the product and to ensure your own personal
safety. Refer to the “Advisories” section in the Preface for advisory conventions used
in this user’s guide, including the distinction between Warnings, Cautions, Important
Notes, and Notes.
Always use caution when handling/operating a computer. Only qualified,
experienced, authorized electronics service personnel should access the
interior of a computer. The power supplies produce high voltages and
energy hazards, which can cause bodily harm.
Use extreme caution when installing or removing components. Refer to the
installation instructions in this user’s guide for precautions and procedures.
If you have any questions, please contact Quanmax Post-Sales Technical
Support.
Access can only be gained by service persons or by users who have
been instructed about the reasons for the restrictions applied to the
location and about any precautions that shall be taken; and access is
through the use of a tool or lock and key, or other means of security,
and is controlled by authority responsible for the location.
WARNING
High voltages are present inside the chassis when the unit’s power cord is
plugged into an electrical outlet. Turn off system power, turn off the power
supply, and then disconnect the power cord from its source before
removing the chassis cover. Turning off the system power switch does not
remove power to components.
The product chassis may be hot when the system is working. Please do
not touch the surface before turn off the system power and wait for
about 5 minutes until the system cools down.

Safety Instructions
7
QBOX-2061 User’s Manual
When Working Inside a Computer
Before taking covers off a computer, perform the following steps:
1. Turn off the computer and any peripherals.
2. Disconnect the computer and peripherals from their power sources or
subsystems to prevent electric shock or system board damage. This does not
apply when hot swapping parts.
3. Follow the guidelines provided in “Preventing Electrostatic Discharge” on the
following page.
4. Disconnect any telephone or telecommunications lines from the computer.
In addition, take note of these safety guidelines when appropriate:
To help avoid possible damage to system boards, wait five seconds after
turning off the computer before removing a component, removing a system
board, or disconnecting a peripheral device from the computer.
When you disconnect a cable, pull on its connector or on its strain-relief loop,
not on the cable itself. Some cables have a connector with locking tabs. If you
are disconnecting this type of cable, press in on the locking tabs before
disconnecting the cable.As you pull connectors apart, keep them evenly
aligned to avoid bending any connector pins.Also, before connecting a cable,
make sure both connectors are correctly oriented and aligned.
CAUTION
Do not attempt to service the system yourself except as explained in this
user’s guide. Follow installation and troubleshooting instructions closely.

Safety Instructions
8
QBOX-2061 User’s Manual
Preventing Electrostatic Discharge
Static electricity can harm system boards. Perform service at an ESD workstation
and follow proper ESD procedure to reduce the risk of damage to components.
Quanmax strongly encourages you to follow proper ESD procedure, which can
include wrist straps and smocks, when servicing equipment.
You can also take the following steps to prevent damage from electrostatic
discharge (ESD):
When unpacking a static-sensitive component from its shipping carton, do not
remove the component’s antistatic packing material until you are ready to install
the component in a computer. Just before unwrapping the antistatic packaging,
be sure you are at an ESD workstation or grounded. This will discharge any
static electricity that may have built up in your body.
When transporting a sensitive component, first place it in an antistatic container
or packaging.
Handle all sensitive components at an ESD workstation. If possible, use
antistatic floor pads and workbench pads.
Handle components and boards with care. Don’t touch the components or
contacts on a board. Hold a board by its edges or by its metal mounting bracket.
Do not handle or store system boards near strong electrostatic, electromagnetic,
magnetic, or radioactive fields.

Safety Instructions
9
QBOX-2061 User’s Manual
Instructions for Lithium Battery
WARNING
Danger of explosion when battery is replaced with incorrect type. Only replace
with the same or equivalent type recommended by the manufacturer.
Do not dispose of lithium batteries in domestic waste. Dispose of the battery
according to the local regulations dealing with the disposal of these special
materials (e.g. to the collecting points for disposal of batteries)

Preface
10
QBOX-2061 User’s Manual
Preface
How to Use This Guide
This guide is designed to be used as step-by-step instructions for installation, and as
a reference for operation, troubleshooting, and upgrades.
NOTE
Driver downloads and additional information are available under
Downloads on our web site: www.quanmax.com.
Unpacking
When unpacking, follow these steps:
1. After opening the box, save it and the packing material for possible future
shipment.
2. Remove all items from the box. If any items listed on the purchase order
are missing, notify Quanmax customer service immediately.
3. Inspect the product for damage. If there is damage, notify Quanmax
customer service immediately. Refer to “Warranty Policy” for the return
procedure.
Regulatory Compliance Statements
This section provides the FCC compliance statement for ClassA devices.
FCC Compliance Statement for Class A Devices
The product(s) described in this user’s guide has been tested and found to comply
with the limits for a ClassA digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the user’s guide, may cause harmful
interference to radio communications. Operation of this equipment in a residential

Preface
11
QBOX-2061 User’s Manual
area (domestic environment) is likely to cause harmful interference, in which case
the user will be required to correct the interference (take adequate measures) at
their own expense. The user is encouraged to try to correct the interference by one
or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment to an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by Quanmax could void the user's
authority to operate the equipment.
NOTE
The assembler of a personal computer system may be required to test
the system and/or make necessary modifications if a system is found to
cause harmful interference or to be noncompliant with the appropriate
standards for its intended use.
Warranty Policy
Limited Warranty
Quanmax Inc.’s detailed Limited Warranty policy can be found under Support at
www.quanmax.com. Please consult your distributor for warranty verification.
The limited warranty is void if the product has been subjected to alteration, neglect,
misuse, or abuse; if any repairs have been attempted by anyone other than
Quanmax or its authorized agent; or if the failure is caused by accident, acts of God,
or other causes beyond the control of Quanmax or the manufacturer. Neglect,
misuse, and abuse shall include any installation, operation, or maintenance of the
product other than in accordance with the user’s guide.
No agent, dealer, distributor, service company, or other party is authorized to change,
modify, or extend the terms of this Limited Warranty in any manner whatsoever.
Quanmax reserves the right to make changes or improvements in any product
without incurring any obligation to similarly alter products previously purchased.

Preface
12
QBOX-2061 User’s Manual
Return Procedure
For any Limited Warranty return, please contact Support at www.quanmax.com and
login to obtain a Return MaterialAuthorization (RMA) Number. If you do not have an
account, send an email to [e-mail] to apply for one.
All product(s) returned to Quanmax for service or credit must be accompanied by a
Return MaterialAuthorization (RMA) Number. Freight on all returned items must be
prepaid by the customer who is responsible for any loss or damage caused by
common carrier in transit. Returns for Warranty must include a Failure Report for
each unit, by serial number(s), as well as a copy of the original invoice showing the
date of purchase.
To reduce risk of damage, returns of product must be in a Quanmax shipping
container. If the original container has been lost or damaged, new shipping
containers may be obtained from Quanmax Customer Service at a nominal cost.
Quanmax owns all parts removed from repaired products. Quanmax uses new and
reconditioned parts made by various manufacturers in performing warranty repairs
and building replacement products. If Quanmax repairs or replaces a product, its
warranty term is not extended.
Shipments not in compliance with this Limited Warranty Return Policy will not be
accepted by Quanmax.
Limitation of Liability
In no event shall Quanmax be liable for any defect in hardware, software, loss, or
inadequacy of data of any kind, or for any direct, indirect, incidental, or
consequential damages in connection with or arising out of the performance or use
of any product furnished hereunder. Quanmax’s liability shall in no event exceed the
purchase price of the product purchased hereunder. The foregoing limitation of
liability shall be equally applicable to any service provided by Quanmax or its
authorized agent.
Maintaining Your Computer
Environmental Factors
Temperature
The ambient temperature within an enclosure may be greater than room
ambient temperature. Installation in an enclosure should be such that the
amount of air flow required for safe operation is not compromised.
Consideration should be given to the maximum rated ambient temperature.
Overheating can cause a variety of problems, including premature aging and

Preface
13
QBOX-2061 User’s Manual
failure of chips or mechanical failure of devices.
If the system has been exposed to abnormally cold temperatures, allow a
two-hour warm-up period to bring it up to normal operating temperature before
turning it on. Failure to do so may cause damage to internal components,
particularly the hard disk drive.
Humidity
High-humidity can cause moisture to enter and accumulate in the system. This
moisture can cause corrosion of internal components and degrade such
properties as electrical resistance and thermal conductivity. Extreme moisture
buildup inside the system can result in electrical shorts, which can cause
serious damage to the system.
Buildings in which climate is controlled usually maintain an acceptable level of
humidity for system equipment. However, if a system is located in an unusually
humid location, a dehumidifier can be used to maintain the humidity within an
acceptable range. Refer to the “Specifications” section of this user’s guide for
the operating and storage humidity specifications.
Power Protection
The greatest threats to a system’s supply of power are power loss, power spikes,
and power surges caused by electrical storms, which interrupt system operation
and/or damage system components. To protect your system, always properly
ground power cables and one of the following devices.
Surge Protector
Surge protectors are available in a variety of types and usually provide a level
of protection proportional with the cost of the device. Surge protectors prevent
voltage spikes from entering a system through theAC power cord. Surge
protectors, however, do not offer protection against brownouts, which occur
when the voltage drops more than 20 percent below the normalAC line voltage
level.
Line Conditioner
Line conditioners go beyond the over voltage protection of surge protectors.
Line conditioners keep a system’s AC power source voltage at a fairly constant
level and, therefore, can handle brownouts. Because of this added protection,
line conditioners cost more than surge protectors. However, line conditioners
cannot protect against a complete loss of power.

Preface
14
QBOX-2061 User’s Manual
Uninterruptible Power Supply
Uninterruptible power supply (UPS) systems offer the most complete protection
against variations on power because they use battery power to keep the server
running whenAC power is lost. The battery is charged by theAC power while it
is available, so whenAC power is lost, the battery can provide power to the
system for a limited amount of time, depending on the UPS system.
UPS systems range in price from a few hundred dollars to several thousand
dollars, with the more expensive unit s allowing you to run larger systems for a
longer period of time whenAC power is lost. UPS systems that provide only 5
minutes of battery power let you conduct an orderly shutdown of the system,
but are not intended to provide continued operation. Surge protectors should be
used with all UPS systems, and the UPS system should be Underwriters
Laboratories (UL) safety approved.

Chapter 1
15
QBOX-2061 User’s Manual
Chapter 1
Introduction
Overview
The QBOX-2061 is a fanless BOX PC is ideal for space critical applications. This
embedded hardware platform is designed with Intel®Atom™ D2550 Processor which
provides with excellent performance. The system is supported with Intel®NM10
Express chipset, and DDR3 SO-DIMM up to 4GB. Featured are 1x 2.5” SATA HDD or
SSD, 1x mini-PCIe slot, 2x GbE, 6x USB 2.0, 1x DVI-I, 1x HDMI, 2x COMs, 1x
mSATA slot, 1x DIO.
The QBOX-2061 provides high reliability rugged case not only for great protection
from EMI, cold and heat, but also integrated with passive cooling design for quiet
fan-less operation such as Transportation, Surveillance andAutomation.
Checklist
QBOX-2061
Power Adapter
Power Cord
Driver CD
Quick installation Guide
Optional wireless LAN
Features
Intel®Atom™ Processor D2550
Intel®NM10 Express Chipset
Intel®Graphics Media Accelerator 3650
DDR3 800/1066 MHz SODIMM up to 4GB
1xDVI-I, 1xHDMI, 1xDP, 2xGbE, 2xCOM, 6xUSB and Audio ,1x DIO
1x 2.5” SATA HDD or SSD, 1x Mini-PCIe slot, 1x mSATA slot supported
Fanless design

Chapter 1
16
QBOX-2061 User’s Manual
Product Specifications
CPU Support Intel®Atom™ Processor D2550 (1M Cache, 1.86 GHz)
Chipset
Intel®NM10 Express chipset
Memory
1x Single Channel DDR3 800/1066 MHz SODIMM support (4GB max)
BIOS
AMI Plug & Play SPI BIOS
Graphic
Intel®Graphics Media Accelerator 3650
External
Display
1x HDMI
1x DVI-I
LAN
2x Gigabit Ethernet (Realtek RTL8111E)
PXE/WOL supported
Audio
Realtek ALC662 HD Codec w/ 2W Audio Amplifier
Mic-In, Line-In, Line-Out Supported
Storage
1x 2.5” SATA HDD or SSD
1x mSATA
USB
6x USB 2.0
COM
2x COM [RS-232] ports with power selection
(1x COM port with RS-232/422/485 selection on COM1)
DIO
Digital I/O supported (8bit 4xDI / 4xDO)
Expansion slot
1x Mini-PCIe slot (SIM Card socket supported)
Hardware
Monitor
Operating voltage, CPU temperature
Watchdog
Timer
1-255 step, can be set with software on Super I/O
Power
DC 12V Input
OS Support
Windows 7
Dimensions
210x35x135mm(WxHxD)
Environment
Operation Temp: 0ºC - 50ºC
Storage Temp.: -20ºC - 60ºC
Humidity: 0% - 95%
Certification
CE, FCC Class A
Table 1 QBOX-2061 Specification

Chapter 1
17
QBOX-2061 User’s Manual
System Tour
Refer to the figure below to identify the components of the system.
Front Panel
Figure 1 Front Panel
Power Switch
The power button allows powering ON and OFF the system.
Power LED (Green)
The power LED will light when the PC is power-on.
HDD LED (Red)
The hard disk LED blinks when data is being written into or read from the HDD.
Line Out
The stereo headphone jack is used to connect the system’s audio out signal to
amplified speakers or headphones.
MIC-IN
The microphone jack is designed to connect the microphone used for video
conferencing, voice narrations, or simple audio recordings.
Line-IN
The Line-in jack is designed to take input from a higher-powered sound source.
COM
D-Sub 9 pin connector

Chapter 1
18
QBOX-2061 User’s Manual
Rear Panel
Figure 2 Rear Panel
DC Jack
The supplied power adapter convertsAC power to DC for use with this jack.
Power supplied through this jack supplies power to the PC. To prevent damage
to the PC, always use the supplied power adapter.
DVI-I Port
The DVI-I (Digital Visual Interface-Integrated) connector allows you to connect an
LCD monitor. It provides a high-speed digital interconnection between the
computer and its display device.
Ethernet
The eight-pin RJ-45 LAN port supports a standard Ethernet cable for
connection to a local network.
USB
The USB (Universal Serial Bus) port is compatible with USB devices such as
keyboards, mouse devices, cameras, and hard disk drives. USB allows many
devices to run simultaneously on a single computer, with some peripheral
acting as additional plug-in sites or hubs.
HDMI
HDMI connector for display output
Digital I/O
This interface used to connect digital signals for input and output purposes.
Wireless LAN Antenna (Optional)
The reserved holes for wireless antenna connections.

Chapter 1
19
QBOX-2061 User’s Manual
Mechanical Dimensions
210 x 35 x135 mm (W x H x D)
Figure 3 Mechanical Dimensions

Chapter 2
20
QBOX-2061 User’s Manual
DVI-I
HDMI
Chapter 2
Getting Started
Setting up your PC
Connect the DVI-I / HDMI cable from your display to the DVI-I / HDMI port.
Figure 4 DVI-I /HDMI
NOTE
When the system reboots without connecting the DVI-I /HDMI, there might
be no image on screen when you insert the DVI-I /HDMI cable.
Please pressing <Ctrl>+<Alt>+<F4> simultaneously to show the image on
screen.
