RANSOMES
¨
Parts and Maintenance Manual
RANSOMES
GB
Part No. 24194G (rev.2)(RJ 100 092002)
Multimower Reelcutter
Series: LD - Engine type: Kubota GH250
Product codes: LDKA001
WARNING: If incorrectly used this machine can cause se-
vere injury. Those who use and maintain this machine should
be trained in its proper use, warned of its dangers and should
read the entire manual before attempting to set up, operate,
adjust or service the machine.

©2002, Textron Inc. All Rights Reserved

1
RANSOMES MULTIMOWER Series:LD
MAINTENANCE AND PARTS MANUAL
GB
1 CONTENTS
CONTENTS
2 INTRODUCTION
2.1 PRODUCT IDENTIFICATION ................................................................................. 2
2.2 SPARES STOCKING GUIDE .................................................................................. 2
2.3 HOW TO USE THE PARTS MANUAL ....................................................................3
3 SAFETY INSTRUCTIONS
3.1 OPERATING INSTRUCTIONS................................................................................ 4
3.2 SAFETY SIGNS....................................................................................................... 4
3.3 STARTING THE ENGINE........................................................................................4
3.4 DRIVING THE MACHINE ........................................................................................ 4
3.5 TRANSPORTING .................................................................................................... 4
3.6 LEAVING THE DRIVING POSITION.......................................................................5
3.7 SLOPES .................................................................................................................. 5
3.8 BLOCKED CUTTING CYLINDERS ........................................................................5
3.9 ADJUSTMENTS, LUBRICATION AND MAINTENANCE ....................................... 5
4 SPECIFICATIONS
4.1 ENGINE SPECIFICATION....................................................................................... 7
4.2 MACHINE SPECIFICATION .................................................................................... 7
4.3 REELCUTTER SPECIFICATION ............................................................................ 7
4.4 WEIGHT................................................................................................................... 7
4.5 VIBRATION LEVEL ................................................................................................. 7
4.6 SLOPES .................................................................................................................. 7
4.7 RECOMMENDED LUBRICANTS............................................................................ 7
4.8 CUTTING PERFORMANCE.................................................................................... 8
4.9 CUTTING PERFORMANCE (AREA) ...................................................................... 8
5 LUBRICATION AND MAINTENANCE
5.1 ENGINE: FIRST 20 WORKING HOURS AND EVERY 50 WORKING HOURS .... 10
5.2 MACHINE: LUBRICATE THE FOLLOWING POINTS WITH SHELL
DARINA R2 GREASE WEEKLY (EVERY 25 WORKING HOURS): ...................... 10
5.3 ENGINE MAINTENANCE: WEEKLY (EVERY 25 WORKING HOURS) ................ 11
5.4 EVERY 200 WORKING HOURS) ........................................................................... 12
5.5 ANNUALLY (EVERY 500 WORKING HOURS)......................................................13
5.6 ADJUSTING TRANSMISSION CHAIN .................................................................. 14
5.7 BELT TENSIONING ............................................................................................... 14
5.8 REELCUTTER DRIVE BELT ................................................................................. 14
5.9 SETTING THE CUTTING CYLINDER TO THE BOTTOM BLADE...................... 15
5.10 HEIGHT OF CUT ADJUSTMENT .......................................................................... 15
5.11 END OF SEASON SERVICING..............................................................................16
6 TROUBLESHOOTING
6.1 GENERAL............................................................................................................... 17
LIST OF PARTS .....................................................................................................19

2
RANSOMES MULTIMOWER Series: LD
MAINTENANCE AND PARTS MANUAL
GB
2 INTRODUCTION
2.2 Spares Stocking Guide
To keep your equipment fully operational and productive, Ransomes suggests you maintain a stock of the
more commonly used maintenance items. We have included part numbers for the additional support
materials and training aids.
Service Parts
Part No Description Part No. Description
N/A Engine Oil Filter N/A Hydraulic Filter
12454-4316-0 Engine Fuel Filter 033001190 Paint, Green 5 litre
12841-1121-0 Air Cleaner Element MBA6189 Switch Cut Out
12461-6361-0 Switch ON/OFF
Engine
Service Support Material
Part No Description Part No. Description
97898-04610 Engine Parts Manual 24194G Machine Maintenance
and Parts Manual
12609-89113 Engine Operators
Manual 24193G Machine Safety and Operators Manual
97897-00910 Engine Service
Manual N/A Machine Service Manual
2.1 PRODUCT IDENTIFICATION

3
RANSOMES MULTIMOWER Series:LD
MAINTENANCE AND PARTS MANUAL
GB
2 INTRODUCTION
2.3 HOW TO USE THE PARTS MANUAL
ITEM NUMBER
Each part which is identified in the illustrations has an item number. Parts which do not have an item number may not
be readily identified in the illustration but are usually closely associated with the immediately adjacent part.
ASSEMBLIESASSEMBLIES
ASSEMBLIESASSEMBLIES
ASSEMBLIES
A complete assembly, e.g. a wheel motor or hydraulic motor or roll assembly, is listed as a complete item with
subsequent individual components listed separately.
The assembly is listed under it's part number with component parts being listed offset to the right, e.g:-
ITEMTEM
TEMTEM
TEM RANSOMESRANSOMES
RANSOMESRANSOMES
RANSOMES DESCRIPTIONDESCRIPTION
DESCRIPTIONDESCRIPTION
DESCRIPTION QTYQTY
QTYQTY
QTY REMARKSREMARKS
REMARKSREMARKS
REMARKS
PART NO.PART NO.
PART NO.PART NO.
PART NO.
1 LMSD798 Roll Assy. 1 ALL MACHINES
2 MBB4490 • Tube 1
3 LMSD926 • End Cap Assy. 2
4 MBB6851 • • End Cap 1
5 H009116 • • Bearing 1
6 MBB2356 • Seal Housing 1
7 A224016 • Seal 2
* A122192 Screw 2
It may not be possible to illustrate every item. With certain items purchased from outside suppliers some component
parts may not be available from Ransomes and may need to be specially ordered from the supplier e.g. Volvo hydraulic
motor components.
QUANTITIESQUANTITIES
QUANTITIESQUANTITIES
QUANTITIES
Quantities shown are for one assembly or sub-assembly.
USING THE PARTS LISTUSING THE PARTS LIST
USING THE PARTS LISTUSING THE PARTS LIST
USING THE PARTS LIST
Determine the function and application of the part required. Turn to the main index page and select the appropriate
section. Locate the part on the illustration and parts list and read off the quantity from the appropriate MODEL column.
NUMERICAL INDEXNUMERICAL INDEX
NUMERICAL INDEXNUMERICAL INDEX
NUMERICAL INDEX
This is a summary of all part numbers used in the manual arranged in numerical sequence and showing the page and
item number under which the parts appear.
ORDERING OF SPARE PARTSORDERING OF SPARE PARTS
ORDERING OF SPARE PARTSORDERING OF SPARE PARTS
ORDERING OF SPARE PARTS
When ordering replacement parts, it is most important to quote the SERIAL NUMBER of the machine, PART NUMBER,
DESCRIPTION and QUANTITY required.
Any arbitrary modifications carried out on this machine may relieve the manufacturer of liability for any
resulting damage or injury.
ABBREVIATIONS
N/A Not Available
AR As Required

4
RANSOMES MULTIMOWER Series: LD
MAINTENANCE AND PARTS MANUAL
GB
3 SAFETY INSTRUCTIONS
This safety symbol indicates important safety
messages in this manual. When you see this
symbol, be alert to the possibility of injury, carefully
read the message that follows, and inform other
operators.
3.1 OPERATING INSTRUCTIONS
• Ensure that the instructions in this book
are read and fully understood.
• No person should be allowed to operate
this machine unless they are fully
acquainted with all the controls and the
safety procedures.
• Never allow children or people unfamiliar
with these instructions to use this
machine. Local regulations may restrict
the age of the operator.
3.2 SAFETY SIGNS
• It is essential all safety labels are kept
legible, if they are missing or illegible
they must be replaced. If any part of the
machine is replaced and it originally
carried a safety label, a new label must
be affixed to the replacement part. New
safety labels are obtainable from
Ransomes dealers.
3.3 STARTING THE ENGINE
• Before starting the engine check that the
brakes are applied, drives are in neutral,
guards are in position and intact, and
bystanders are clear of the machine.
• Do not run the engine in a building
without adequate ventilation.
3.4 DRIVING THE MACHINE
• Before moving the machine, check to
ensure that all parts are in good working
order, paying particular attention to
brakes, tyres and the security of cutting
blades.
• Replace faulty silencers, mow only in
daylight or good artificial light
• Always observe the Highway Code both
on and off the roads. Keep alert and
aware at all times. Watch out for traffic
when crossing or near roadways.
• Stop the blades rotating before crossing
surfaces other than grass.
• Remember that some people are deaf
or blind and that children and animals
can be unpredictable.
• Keep travelling speeds low enough for
an emergency stop to be effective and
safe at all times, in any conditions.
• Remove or avoid obstructions in the
area to be cut, thus reducing the
possibility of injury to yourself and/or
bystanders.
• When reversing, take special care to
ensure that the area behind is clear of
obstructions and/or bystanders.
• Keep in mind that the operator or user
is responsible for accidents or hazards
occurring to other people or their
property.
• When the machine is to be parked,
stored or left unattended, lower the
cutting means unless the transport
locks are being used.
• While mowing, always wear substantial
footwear and long trousers. Do not
operate the equipment when barefoot
or wearing open sandals.
• Check the grass catcher frequently for
wear or deterioration. After striking a
foreign object. Inspect the lawnmower
for damage and make repairs before
restarting and operating the equipment.
• If the machine starts to vibrate
abnormally, check immediately.
3.5 TRANSPORTING
• Ensure that the cutting units are
securely fastened in the transport
position if applicable. Do not transport
with cutting mechanism rotating.
• Drive the machine with due
consideration of road and surface
conditions, inclines and local
undulations.

5
RANSOMES MULTIMOWER Series:LD
MAINTENANCE AND PARTS MANUAL
GB
3 SAFETY INSTRUCTIONS
3.6 LEAVING THE DRIVING POSITION
• Park the machine on level ground.
• Before leaving the driving position, stop
the engine and make sure all moving
parts are stationary. Apply brakes and
disengage all drives.
3.7 SLOPES
TAKE EXTRA CARE WHEN WORKING ON
SLOPES
• Local undulations and sinkage will
change the general slope. Avoid ground
conditions which can cause the machine
to slide.
• Keep machine speeds low on slopes and
during tight turns.
• Travel on grass slopes requires particular
care.
DO NOT USE ON SLOPES GREATER THAN 15°
3.8 BLOCKED CUTTING CYLINDERS
• Stop the engine and make sure all moving
parts are stationary.
• Apply brakes and disengage all drives.
• Release blockages with care. Keep all parts
of the body away from the cutting edge.
Beware of energy in the drive which can
cause rotation when the blockage is
released.
• Keep other people away from the cutting
units.
3.9 ADJUSTMENTS, LUBRICATION AND
MAINTENANCE
• Stop the engine and make sure all moving
parts are stationary.
• Apply brakes and disengage all drives.
• Read all the appropriate servicing
instructions.
• Use only the replacement parts supplied by
the original manufacturer.
• When adjusting the cutting cylinder take
care not to get hands and feet trapped when
rotating cylinder.
• Make sure that other people are not touching
any cutting unit.
• To reduce the fire hazard, keep the engine,
silencer free of grass, leaves or excessive
grease.
• Replace worn or damaged parts for safety.
• When working underneath lifted parts or
machines, make sure adequate support Is
provided.
• Do not dismantle the machine without
releasing or restraining forces which can
cause parts to move suddenly.
• Do not alter engine speed above maximum
quoted in Engine Specification. Do not
change the engine governor settings or
overspeed the engine. Operating the engine
at excessive speed may increase the hazard
of personal injury.
• When refuelling, STOP THE ENGINE, DO
NOT SMOKE. Add fuel before starting the
engine, never add fuel while the engine is
running.
• Use a funnel when pouring fuel from a can
into the tank.
• Do not fill the fuel tank beyond the bottom of
the filler neck.
• Replace all fuel tank and container caps
securely.
• Store fuel in containers specifically designed
for this purpose.
• Refuel outdoors only and do not smoke
while refuelling.
• If fuel is spilled, do not attempt to start the
engine but move the machine away from the
area of spillage and avoid creating any
source of ignition until fuel vapours have
dissipated.
• Allow the engine to cool before storing in
any enclosure.
• Never store the equipment with fuel in the
tank inside a building where fumes may
reach an open flame or spark.
• If the fuel tank has to be drained, this should
be done outdoors.
• Do not spill fuel onto hot components.
• All waste products should be disposed of in
accordancewiththe Environmental
ProtectionAct1990.

6
RANSOMES MULTIMOWER Series: LD
MAINTENANCE AND PARTS MANUAL
GB
DO NOT USE ON SLOPES GREATER THAN 15°
WARNING
3 SAFETY INSTRUCTIONS
DANGER - Indicates an imminently hazardous
situation which, if not avoided, WILL result
in death or serious injury.
WARNING - Indicates a potentially hazardous
situation which, if not avoided, COULD
result in death or serious injury.
CAUTION - Indicates a potentially hazardous
situation which, if not avoided, MAY result in
minor or moderate injury and property
damage. It may also be used to alert
against unsafe practices.
NEVER START THE ENGINE OR USE THE
MACHINE WITH ANY OF THE SAFETY
GUARDS REMOVED
CAUTION

7
RANSOMES MULTIMOWER Series:LD
MAINTENANCE AND PARTS MANUAL
GB
4 SPECIFICATIONS
4.1 ENGINE SPECIFICATION
TYPE: Kubota 6.0KW (8.0HP) @
3600 RPM, Vertical, single
cylinder , Air cooled,
247cc (15.07 cu.in), four
cycle, recoil starter, Petrol
engine.
Model: GH250
Maximum Speed: 2570rpm
Oil Sump Capacity:0.9 litres (1.6 Imp.pints)
(0.95 US qts)
Fuel: Lead free petrol
Fuel Tank
Capacity: 6 litres (10.5 Imp. pints)
(6.3 US pints)
Spark Plug Gap: 0.95mm (0.037in)
4.2 MACHINE SPECIFICATION
Wheels: 35cm (14in) diameter x 9cm
(3 1/2in) wide pneumatic
Tyre Pressure: 1.75 kg/cm2(25psi)
Gearbox: 2 speed incorporating bevel
gear differential.
Oil Capacity: 0.86litres (1.5 Imp pints)
(0.91 US Quarts)
Gearbox Oil Type: SAE40
4.3 REELCUTTER SPECIFICATION
Chassis: fabricated, pressed steel
construction.
Transmission: Vee belt from engine to
gearbox, Vee belt from
engine to layshaft, final
drive to cutting cylinder by
heavy-duty roller chain.
Clutch: Spring loaded belt clutch.
Cylinder: 196mm (7 3/4in) diameter
x 760mm (30in) wide.
Knives: 4
Rear Roll: Full width
Height of Cut: 13mm (1/2in) to 64mm (2 1/2in)
by sliding roll carriage.
4.4 WEIGHT
Power unit and Reelcutter 171kg (376lbs)
4.5 VIBRATION LEVEL
The machine was tested for whole body and hand/
arm vibration levels. The operator was seated in
the normal operating position with both hands on
the steering mechanism. The engine was running
and the cutting device was rotating with the
machine stationary.
Hand / Arm acceleration level : 3.70 m/s2
4.6 SLOPES
DO NOT USE ON SLOPES GREATER THAN 15°
4.7 RECOMMENDED LUBRICANTS
Engine oil: SAE30 or equivalent
Grease: Shell Darina R2, or equivalent.
TEMPERATURE OIL VISCOSITY
ABOVE 4°C (39°F) SAE30
BELOW 4°C (39°F) SAE5W-30 or 10W-30

8
RANSOMES MULTIMOWER Series: LD
MAINTENANCE AND PARTS MANUAL
GB
4 SPECIFICATIONS
4.8 CUTTING PERFORMANCE
Cutting Ratio:
High Speed: 36 cuts/metre
(33 cuts/yd)
Low Speed: 67 cuts/metre
(62 cuts/yd)
4.9 CUTTING PERFORMANCE (AREA)
High Speed: 2100m2(2500 sq.yd) per hour.
Low Speed: 1500m2(1800 sq.yd) per hour
Performance based on single flat area with
allowance for overlap and turning.

9
RANSOMES MULTIMOWER Series:LD
MAINTENANCE AND PARTS MANUAL
GB
LUBRICATION AND MAINTENANCE CHART
5 LUBRICATION AND MAINTENANCE
Black bullet points are operator checks and white bullet points are workshop maintenance procedures
First
20
hours
Daily Weekly/
Every
50 hours
Every
200
hours
Every
500
Hours
End of
Season
ENGINE
Check oil level l
Change oil l l
Clean air filter element l
Change air filter element l
Clean fuel filters l
Check Spark Plug l
Check Valve Clearance l
MACHINE
Check tyre pressure l
Check Gearbox Oil Level l
Check engine Cooling Fins and Air Intake l
Check nuts & bolts for tightness l
Check belt tension l l
Check parking brake adjustment l
Lubricate the following with Shell Darina R2 grease
Cutting cylinder bearings l l
Roll bearings l l

10
RANSOMES MULTIMOWER Series: LD
MAINTENANCE AND PARTS MANUAL
GB
5.2 MACHINE: Lubricate the following points
with Shell Darina R2 grease Weekly
(Every 50 working hours):
(A) Cutting cylinder bearings
5.1 ENGINE: First 20 working hours and
every 50 working hours
Drain engine oil.
a. Remove the drain plug (5.1.A) and drain
sump.
b. Clean and replace the plug.
c. Clean sump filler cap and surrounding
area (5.1.B).
d. Refill the sump through the filler hole
(5.1.B) until the oil is level with the top of
the filler hole threads.
e. Wipe away excess oil and replace the
filler cap.
NOTE - Ensure machine is on level ground when
checking level of oil.
IMPORTANT: Neglect in changing the engine oil
will cause premature wear.
5 LUBRICATION AND MAINTENANCE

11
RANSOMES MULTIMOWER Series:LD
MAINTENANCE AND PARTS MANUAL
GB
5 LUBRICATION AND MAINTENANCE
5.3 ENGINE Maintenance: Weekly (Every 25
working hours or more frequently under
extreme dusty conditions)
Air cleaner
1. Undo the cover (A) and remove the filter
(B) and element (C) inside.
2. Clean the element in paraffin (kerosene).
Dry completely. Soak in new engine oil.
Squeeze out to remove excess oil.
3. Clean off all dust from cleaner body and
the metal plate behind the foam element.
4. Reassemble the parts in their original
positions.
IMPORTANT: Dirt wears engines. Incorrect
maintenance of the air cleaner will cause
premature wear.
NOTE: Service more frequently if the air cleaner is
very dirty or if operating in dusty conditions.

12
RANSOMES MULTIMOWER Series: LD
MAINTENANCE AND PARTS MANUAL
GB
5 LUBRICATION AND MAINTENANCE
5.4.1 Every 200 working hours)
FUEL FILTER
a. Close fuel tap (handle horizontal).
b. Unscrew the retaining ring and remove
the glass bowl.
c. Clean out the filter bowl thoroughly to
remove all sediment and water.
d. Replace bowl and secure with retaining
ring.
e. Open fuel tap and check for leaks.
5.4.2 SPARK PLUG
Remove the plug and check condition. Good
operating conditions are indicated if the plug has a
light coating of grey or tan deposit. A white
blistered coat could indicate overheating. A black
(carbon) coating may indicate an over rich fuel
mixture caused by a blocked air cleaner or
incorrect carburettor adjustment.
DO NOT sand blast, wire brush or otherwise
service a plug in poor condition.
Best results are obtained with a new plug; set the
gap to 0.95mm (0.037in).

13
RANSOMES MULTIMOWER Series:LD
MAINTENANCE AND PARTS MANUAL
GB
5.5 Annually (Every 500 working hours)
VALVE CLEARANCE
1. Remove tappet cover on side of engine.
2. Set piston at top dead centre on the
compression stroke. This will ensure
valves are seated.
3. Check clearance. Both inlet and exhaust
should be 0.05mm (0.002in) to 0.10mm
(0.0039in). This should be checked by
using a feeler gauge between the tip of
the valvestem and the tappet on both
valves.
4. If the clearance is less than the
recommended gap, remove the valve
and grind the tip of the valve stem with
an oil stone.
5. If the clearance is greater than the
recommended gap then the appropriate
valve or tappet should be replaced.
6. Replace tappet cover securely.
5 LUBRICATION AND MAINTENANCE

14
RANSOMES MULTIMOWER Series: LD
MAINTENANCE AND PARTS MANUAL
GB
5 LUBRICATION AND MAINTENANCE
5.6 ADJUSTING TRANSMISSION CHAIN
This chain is provided with a tensioner sprocket
(5.6.A). To adjust undo the central screw, holding
the chain guard in place and remove the latter.
Slacken the nut holding the tensioner sprocket
spindle in place and slide the sprocket until the
chain is tightened. Do not overtighten. When the
necessary adjustment has been made securely re-
tighten the spindle nut. When adjusted correctly
the chain should be slightly slack in all positions.
5.7 BELT TENSIONING
If slip occurs on the two primary drive belts, these
may be tightened by adjusting the load on the
clutch pulley arms. To make an adjustment turn
the nuts (5.7.B) on the spring hook bolts (5.7.A) in
a clockwise direction. Further adjustment can be
made by moving the engine rearward on its
mounting plates.
The gearbox drive clutch cable has an adjuster
(5.7.C) fitted to the clutch end. This enables
adjustment to be made to ensure that the belt will
slip when the clutch is disengaged. When the
clutch lever is disengaged there should be
approximately 2.4mm (3/32in) free movement
between the outer cable and the tension pulley
arm.
5.8 REELCUTTER DRIVE BELT
This belt can be tensioned by slackening the pivot
bolts (5.8.A) holding the sideplates to the gearbox
and pivoting the unit forward to tighten the belt, or
rearwards, in the case of a new belt, to allow slip
when the clutch is disengaged.

15
RANSOMES MULTIMOWER Series:LD
MAINTENANCE AND PARTS MANUAL
GB
5 LUBRICATION AND MAINTENANCE
5.9 SETTING THE CUTTING CYLINDER TO
THE BOTTOM BLADE
Every Reelcutter Attachment is dispatched with
the cutting cylinder properly adjusted to the
bottom blade, but it is possible that this
adjustment may be upset during transit. If the
mower does not cut perfectly, set the cutting
cylinder carefully to the bottom blade so that the
revolving cutters just touch the bottom blade
throughout the whole width and at the same time
causingnofrictionalpressure.
IMPORTANT: Before making any adjustment
Slacken the chain drive, see section 5.6
To set the cutters, slacken off the clamping bolts
(5.9.A) on either side of the unit and turn the
adjusting screws (5.9.B) in a clockwise direction to
bring the cutting cylinder closer to the bottom
blade. It is advisable to make small and equal
adjustments to each screw alternately.
When correctly set the cutters should revolve
freely and at the same time, be able to cut cleanly
a piece of paper held at the edge of the bottom
blade. This test should be made over the entire
width of the blade. Retighten clamp bolts
IMPORTANT: After setting the cylinder to the
bottom blade readjust the chain drive, see section
5.6
5.10 HEIGHT OF CUT ADJUSTMENT
The height of cut is adjusted by raising or lowering
the rear roll.
1. Slacken the nuts (5.10.A) holding the rear
roll brackets in position on either side of
the unit.
2 Raise or lower the roll as required.
3. Make sure that each bracket has been
adjusted by an equal amount.
4. Tighten the nuts (5.10.A) holding the rear
roll brackets in position on either side of
the unit.

16
RANSOMES MULTIMOWER Series: LD
MAINTENANCE AND PARTS MANUAL
GB
5.12 END OF SEASON SERVICING
STORAGE
The machine should be thoroughly cleaned down
to remove all accumulations of grass clippings and
debris. Turn the cutting cylinder manually a few
times to clean the cutting edge.
Apply a little oil with a brush to all cutters to
prevent rusting.
Empty the fuel tank, turn off the fuel tap.
Run the engine until all fuel in the carburettor has
been used up, clean the filter bowl and tap. Whilst
engine is still warm, drain crankcase and refill with
fresh engine oil.
Remove spark plug and pour in a little anti-
corrosive oil. Turn engine over manually a few
times to spread oil over the cylinder walls and
replace the spark plug. Turn the engine over
slowly until resistance is felt, this will ensure both
valves are fully closed to prevent moisture
entering. Cover the engine. Oil all pivot points,
adjusting screws and the drive chain.
5.11 HAND BRAKE ADJUSTMENT
The hand brake can be adjusted in two ways, either
by the threaded ends of the brake cables or the
screw in the end of the brake lever.
Method 1
(after fitting new cables or brake bands)
a The brake lever should be adjusted to obtain
maximumtravel.
b The locknut (5.11.A) on each brake cable
should be released and each cable adjusted
so that when the brake is released the
machine is free to move and when the brake
is applied the machine remains stationary.
Method 2
Ifthe brakes needadjusting between services the
following procedure can be followed.
a Release brake lever.
b Using a screw driver adjust the screw in the
end of the brake lever (5.11.B) as required,
so that when the brake is released the
machine is free to move and when the brake
is applied the machine remains stationary.
5 LUBRICATION AND MAINTENANCE

17
RANSOMES MULTIMOWER Series:LD
MAINTENANCE AND PARTS MANUAL
GB
6.1 GENERAL
The troubleshooting chart below lists basic problems that may occur during start-up and operation. For more
detailed information contact your local Ransomes Jacobsen Distributor.
6 TROUBLESHOOTING
Symptoms Possible Causes Action Section Ref.
Engine will not start.
1. Fuel tank empty or dirty. 1. Fill with fresh fuel. Change fuel filter. Bleed fuel lines.
2. Operator presence control
lever not being operated. 2. Hold down Operator presence control lever
3. Operator presence control
switch out of adjustment or
defective. 3. Adjust or replace switch.
Engine hard to start
or runs poorly.
1. Fuel level low, fuel or fuel filter
dirty. 1. Fill with fresh fuel. Change fuel filter. Bleed fuel lines.
2. Air cleaner dirty. 2. Inspect and replace air filter.
3. Engine problem. 3. Consult engine manual
Engine stops. 1. Fuel tank empty. 1. Fill with fresh fuel and bleed fuel lines.
Engine overheating 1. Air intake restricted. 1. Clean air intake.
Reel cuts unevenly
1. Cylinder to Bottom Blade not
adjusted correctly. 1. Inspect Cylinder to Bottom Blade adjustment.
2. Engine speed too low. 2. Check engine speed. Run engine at full
throttle.
3. Mow speed not adjusted for
turf conditions. 3. Adjust mow speed for best cut.

18
RANSOMES MULTIMOWER Series: LD
MAINTENANCE AND PARTS MANUAL
GB
NOTES
