TFT SHO-FLOW 1 Programming manual

©Copyright Task Force Tips LLC 2019-2020 LIE-100 August 17, 2020 Rev05
SHO-FLOW ®
Flow Meter Operations
INSTRUCTIONS FOR INSTALLATION, OPERATION,
AND MAINTENANCE
WARNING Understand manual before use. Operation of this device without understanding the manual and
receiving proper training is a misuse of this equipment. Obtain safety information at tft.com/
serialnumber.
This equipment is intended for use by trained and qualied emergency services personnel for
reghting. All personnel using this equipment shall have completed a course of education
approved by the Authority Having Jurisdiction (AHJ).
This instruction manual is intended to familiarize reghters and maintenance personnel with
the operation, servicing, and safety procedures associated with this product. This manual
should be kept available to all operating and maintenance personnel.
TASK FORCE TIPS LLC
MADE IN USA • TFT.com
3701 Innovation Way, Valparaiso, IN 46383-9327 USA
800-348-2686 • 219-462-6161 • Fax [phone]
SHO-FLOW 1
50-300 GPM
SHO-FLOW 2
LOW FLOW
100-500 GPM
SHO-FLOW 2
HIGH FLOW
500-1250 GPM

©Copyright Task Force Tips LLC 2019-2020 LIE-100 August 17, 2020 Rev05
2
DANGER
PERSONAL RESPONSIBILITY CODE
The member companies of FEMSA that provide emergency response
equipment and services want responders to know and understand the
following:
1. Fireghting and Emergency Response are inherently dangerous activities
requiring proper training in their hazards and the use of extreme caution
at all times.
2. It is your responsibility to read and understand any user’s instructions,
including purpose and limitations, provided with any piece of equipment
you may be called upon to use.
3. It is your responsibility to know that you have been properly trained in
Fireghting and /or Emergency Response and in the use, precautions, and
care of any equipment you may be called upon to use.
4. It is your responsibility to be in proper physical condition and to maintain
the personal skill level required to operate any equipment you may be
called upon to use.
5. It is your responsibility to know that your equipment is in operable
condition and has been maintained in accordance with the manufacturer’s
instructions.
6. Failure to follow these guidelines may result in death, burns or other
severe injury.
FEMSA
Fire and Emergency Manufacturers and Service Association
P.O. Box 147, Lynneld, MA 01940 • www.FEMSA.org

©Copyright Task Force Tips LLC 2019-2020 LIE-100 August 17, 2020 Rev05
3
1.0 MEANING OF SAFETY SIGNAL WORDS
A safety related message is identied by a safety alert symbol and a signal word to indicate the level of risk involved with a particular
hazard. Per ANSI Z535.6, the denitions of the four signal words are as follows:
DANGER
DANGER indicates a hazardous situation which, if not avoided, will result in death or serious
injury.
WARNING
WARNING indicates a hazardous situation which, if not avoided, could result in death or serious
injury.
CAUTION CAUTION indicates a potentially hazardous situation which, if not avoided, could result in minor
or moderate injury.
NOTICE NOTICE is used to address practices not related to physical injury.
TABLE OF CONTENTS
1.0 MEANING OF SAFETY SIGNAL WORDS........................................................................................................ 3
2.0 SAFETY............................................................................................................................................................. 4
3.0 GENERAL INFORMATION................................................................................................................................ 4
3.1 VARIOUS MODELS AND TERMS
3.2 SPECIFICATIONS
3.2.1 DEVICE SPECIFICATIONS
3.2.2 APP SPECIFICATIONS
3.3 COUPLINGS
3.4 USE WITH SALT WATER
4.0 INSTALLATION ................................................................................................................................................. 6
5.0 OPERATION...................................................................................................................................................... 7
5.1 FLOW DISPLAY
5.2 DEVICE CONNECTION
5.3 ESTABLISHING A BLUETOOTH CONNECTION
5.4 SETTINGS
5.5 ESTABLISHING A REMOTE VIEWER CONNECTION
6.0 MAINTENANCE .............................................................................................................................................. 10
7.0 TROUBLESHOOTING .................................................................................................................................... 10
8.0 WARRANTY .....................................................................................................................................................11
9.0 OPERATION AND INSPECTION CHECKLIST ............................................................................................... 12

©Copyright Task Force Tips LLC 2019-2020 LIE-100 August 17, 2020 Rev05
4
3.0 GENERAL INFORMATION
The SHO-FLOW is a water-powered re ground ow meter that measures the ow rate in a hose line and transmits ow data using a
Bluetooth wireless connection. Data is received by a paired device and displayed using a smart phone app. The SHO-FLOW does
not have a display. Flow meter power is generated whenever ow causes its turbine to rotate. Data is automatically transmitted
whenever ow is present, and stops when ow stops. An arrow indicates the direction of ow.
The SHO-FLOW is intended for intermittent use with clean re water or solutions of water and foam concentrate. It is not intended for
use with pure foam concentrate, compressed air foam, hydrocarbons, or other types of liquid. Turbine bearings are subject to wear.
The SHO-FLOW is not intended for continuous outdoor storage, use with heated uids, in permanently piped installations, 24/7 wet
conditions, or in extended service conditions (non-re ground).
User Supplied SmartPhone
with SHO-FLOW App
HOSE FROM TRUCK HOSE TO NOZZLE
Figure 3.0
2.0 SAFETY
WARNING
Equipment may be damaged if frozen while containing signicant amounts of water. Such damage
may be di󰀩cult to detect visually. Subsequent pressurization can lead to injury or death. Any time
the equipment is subject to possible damage due to freezing, it must be tested and approved for
use by qualied personnel before being considered safe for use.
WARNING
This equipment is intended for use by trained personnel for reghting. Use of this equipment for
other purposes may involve hazards not addressed by this manual. Seek appropriate guidance
and training to reduce risk of injury.
WARNING This device is not rated as ignition proof, explosion proof, or intrinsically safe. Use only in
locations with adequate ventilation and no hazard of ammable vapor buildup.

©Copyright Task Force Tips LLC 2019-2020 LIE-100 August 17, 2020 Rev05
5
3.2 SPECIFICATIONS
3.2.1 DEVICE SPECIFICATIONS
Model Name SHO-FLOW 1 SHO-FLOW 2 (Low Flow) SHO-FLOW 2 (High Flow)
Operating Flow Range 50-300 GPM
(200-1200 LPM)
100 - 500 GPM
(400 - 2000 LPM)
500 - 1250 GPM
(2000 - 5000 LPM)
Maximum Flow Range 350 GPM (1300 LPM) 600 GPM (2300 LPM) 1350 GPM (5200 LPM)
Minimum Flow Rate Required
to Connect
50 GPM
(200 LPM)
100 GPM
(400 LPM)
500 GPM
(2000 LPM)
Waterway Diameter 1.5” (38mm) 2.5" (65mm) 2.5” (65mm)
Flow Accuracy +/-2.5% Full Scale
Non-recoverable Pressure Loss
@ Maximum Flow 15 PSI @ 300 GPM 10 PSI @ 500 GPM 10 PSI @ 1250 GPM
Maximum Operating Pressure 300 PSI (20 bar)
Hydrostatic Test Pressure 900 PSI (62 bar)
Operating Temperature -
Electronics -20-140°F (-30-60°C)
Length 6.3” (160mm) 7.4" (188 mm)
Width 3.9” (99mm) 4.9" (125 mm)
Weight 2.8 lbs (1.3 kg) 4.2 lbs (1.9 kg)
Materials Aluminum 6000 series hard anodized MIL8625 class 3 type 2, stainless steel 300 series,
POM, nitrile rubber, and CPVC
IP Rating IP65
Power Supply Self-powered, Water Flow Energy Harvesting
Backup Battery CR2032 enabled in app
Table 3.2.1
3.1 PART IDENTIFICATION AND TERMS
QUICKSTART:
tft.com/SHO-FLOW
50 GPM (200 LPM)
Required to Connect
EFF15OL
MAXIMUM
OPERATING PRESSURE
300 PSI (20 BAR)
DEVICE NAME
OPERATING FLOW RANGE
50-300 GPM
(200-1200 LPM)
DO NOT EXCEED
350 GPM (1300 LPM)
MADE IN USA
TFT.COM
PATENT PENDING
PATENT: 9,295,863
50-300 GPM
(200-1200 LPM)
®tft.com/EXXXXXX
INLET THREADS
DIRECTION OF FLOW
UNIQUE DEVICE NAME/SERIAL NUMBER
OUTLET THREADS
Figure 3.1

©Copyright Task Force Tips LLC 2019-2020 LIE-100 August 17, 2020 Rev05
6
4.0 INSTALLATION
SHO-FLOW should be installed with the FLOW arrows on the label pointing in the direction of water ow. Published accuracy is
assured when the ow meter is installed in conditions with minimal turbulence; between two lengths of hose with the same size
couplings as the ow meter. Avoid locations where the ow meter or adjacent hose are used as a step.
HOSE FROM TRUCK
HOSE TO NOZZLE
FLOW DIRECTION
ARROW
NOTICE Turbulence can cause inaccurate readings. Installing the ow meter adjacent to turbulence
causing plumbing like elbows, partially gated valves, eductors, and at adapters is not
recommended. The best accuracy is assured when the ow meter is paired between two sections
of straight hose.
NOTICE Reverse installation will result in incorrect readings and will damage the device over time. Always
ensure the FLOW arrows on the device point in the direction of ow.
3.3 COUPLINGS
The SHO-FLOW 1 is o󰀨ered with standard hose threaded connections: 1.5” NH, 1.5” BSP, or 1.5” NPSH. The SHO-FLOW 2 is
o󰀨ered with standard hose threaded connections: 2.5” NH, 2.5” BSP, or 2.5” NPSH. Inlets are rigid female threaded couplings. Fluid
is sealed using a hose gasket. Do not use thread sealant. Outlets are rigid male threads. Maximum torque 20 ft-lb (27 Nm).
CAUTION Mismatched or damaged waterway connections may cause equipment to leak or uncouple under
pressure. Failure could result in injury. Equipment must be mated to matched connections
CAUTION Dissimilar metals coupled together can cause galvanic corrosion that can result in the inability to
uncouple the connection, or complete loss of engagement over time. Failure could cause injury.
Per NFPA 1962, if dissimilar metals are left coupled together, an anti-corrosive lubricant should
be applied to the connection and the coupling should be disconnected and inspected at least
quarterly.
3.4 USE WITH SALT WATER
Use with salt water is permissible provided the equipment is thoroughly cleaned with fresh water after each use. The service life of
the equipment may be shortened due to the e󰀨ects of corrosion, and is not covered under warranty
3.2.2 APP SPECIFICATIONS
Wireless Communication Bluetooth® Version 4.1
Display SHO-FLOW Smart Phone App
Flow Units GPM, L/min
Pressure Units psi, bar
Force Units lbf, kgf
Table 3.2.2

©Copyright Task Force Tips LLC 2019-2020 LIE-100 August 17, 2020 Rev05
7
5.1 FLOW DISPLAY
The Flow Display (Figure 5.0) screen is used to notify the user of the current
ow rate in the hose line in real time when a SHO-FLOW is connected.
Whenever the app is opened the Home screen (Figure 5.1) will open as
default. Press the Flow Display button to navigate to Flow Display Screen.
Figure 5.1
5.2 DEVICE CONNECTION
The Device Connection screen is used to connect to a SHO-FLOW. The app will remember the device it was connected to and
attempt to connect to that unit. (App will only connect to one SHO-FLOW at a time).
If you wish to connect to a di󰀨erent SHO-FLOW, press the Disconnect button and nd the device you wish to connect to in the device
list. The Bluetooth connection can be released for another user to connect to the SHO-FLOW by one of the following methods:
• Press the Disconnect button on the Device Connection page
• Completely close the app
1. To access this screen press the MENU button.
2. Then press the Device Connection button.
5.0 OPERATION
A smartphone app is required to view the ow rate of the SHO-FLOW. Please
download the app from either the Google Play Store or the Apple App Store
before proceeding. Search SHO-FLOW in either store.
1. Create a ow greater than or equal to the minimum rated ow rate
through the SHO-FLOW to turn on the device and start transmitting the
Bluetooth signal.
2. If the app is not already open, nd and press the SHO-FLOW app icon
from your list of apps, which will launch the app.
3. Allow app to use location if prompted. (This is required for use)
4. If a Bluetooth connection has not already been set up refer to section
5.2.
5. Once a connection is established, the ow rate and SHO-FLOW
pressure loss will be displayed on the Flow Display screen. (Section 5.1)
Figure 5.0

©Copyright Task Force Tips LLC 2019-2020 LIE-100 August 17, 2020 Rev05
8
5.4 SETTINGS
The Settings screen is used to congure the app display using the desired ow units and other conguration values.
1. To return to this screen press the MENU button.
2. Then press the SETTINGS button.
5.3 ESTABLISHING A BLUETOOTH CONNECTION
1. Ensure the SHO-FLOW is owing the minimum rated ow rate to
turn on the device and start transmitting the Bluetooth signal.
2. Press scan button to begin searching for SHO-FLOW.
3. Press button with the matching device name to connect.
4. Press the CONNECT button.
(the name on the SHO-FLOW will match the listed
device on the screen)
DEVICE NAME
tft.com/EXXXXXX
5. Once communication has been checked for proper data transfer:
• Top bar will display the Bluetooth Icon
• The Device Name will update to the connected device
NOTE: The app will remember this device name. When
the app is disconnected, it will automatically search and
connect to that device if it is available. If too much time
has passed a popup will display holding the SHO-FLOW
information until it is dismissed. Begin owing again and hit
continue to resume ow session or cancel to disconnect.
Figure 5.3

©Copyright Task Force Tips LLC 2019-2020 LIE-100 August 17, 2020 Rev05
9
Link Retain Time
Anytime you stop the ow (eg. to talk or adjust the set-up), the power stops and the
Bluetooth link is broken. Typically, it should take less than 5 seconds to reconnect
automatically.
If you plan to start and stop the ow often and do not wish to wait the 5 sec for the
automatic reconnection to occur, it is possible to set a Link Retain Time. Doing this
keeps the SHO-FLOW powered and the Bluetooth connection active when water
is not owing through the device for a short amount of time. If the link retain time is
exceeded, a popup will pause the ow session. To continue the session, raise the
ow higher than the device minimum and click the continue button.
Flow meters come factory equipped with a standard non-rechargable lithium-ion
battery having a 10-year storage lifespan, which can be used to extend Bluetooth
connection times. The default setting for this battery is the disabled condition
(Bluetooth stops immediately after ow stops). This battery can be enabled in app to
allow for the Bluetooth connection to be maintained when water is not owing.
Storage in direct sunlight or hot conditions can shorten battery life. Consult factory
when battery replacement is necessary.
The current setting for Link Retain Time is displayed within the drop down selection.
Figure 5.4
The time can be set by selecting an option from the drop down:
• 0 sec (Default)
• 10 sec
• 30 sec
• 60 sec
5.5 ESTABLISHING A REMOTE VIEWER CONNECTION
NOTE: To use this functionality, you must allow the app to use your device’s location.
A remote viewer is any person that is connected to a SHO-FLOW device through the
Cloud Connection. This person is able to view the ow rate of a broadcasting device
up to 1/4 mile (400M) away.
To start the connection:
1. Press Remote Viewer from menu.
2. Open the Remote Viewer screen. If Internet is available (Wi-Fi or cellular) you
will press the conrm button to update location and see nearby devices populate
the Network Device(s) List with the Remote Discovery Name the Broadcaster
selected. If scanning fails, you may need to press the Refresh button.
3. Press the button of the device you wish to connect to.
4. Once the connection is completed:
• Return to the Flow Display screen to view the same ow rate data as the
broadcasting device.
• The Cloud icon appear.
• The Device Name will update to the connected device.
5. To disconnect, press the DISCONNECT button.
Figure 5.5

©Copyright Task Force Tips LLC 2019-2020 LIE-100 August 17, 2020 Rev05
10
6.0 MAINTENANCE
No maintenance is required. Calibration is not required under normal circumstances. If needed, see section 5.5. If unit becomes
damaged and does not display correct data, send it back to the factory for service.
CAUTION
Any alterations to the product or its markings could diminish safety and constitutes a misuse of
this product.
NOTICE All replacement parts must be obtained from the manufacturer to assure proper operation of the
device.
7.0 TROUBLESHOOTING
Bluetooth Connection
SHO-FLOW:
In a case that the SHO-FLOW device is not discoverable by the App it may be necessary to stop owing for a period of up to one
minute (depending on Link Retain Settings) to allow the SHO-FLOW to power down fully. After one minute has elapsed you can begin
owing water again and connect to the SHO-FLOW. If this does not resolve your issues ensure that you are within operating range
of the SHO-FLOW and the ow is over the minimum required for the SHO-FLOW model.
App:
The SHO-FLOW App requires the user to allow the App to use the device’s location and Bluetooth services. If you deny the usage
of either of these services, the App may not function as it is intended. Depending on operating system, you can verify these services
are enabled.
IOS: Settings > SHO-FLOW Android: Settings > Apps > SHO-FLOW > Permissions
Also, Settings > Locations
Figure 7.0
Cloud Connection
A network connection (Wi-Fi or cellular) is required for this functionality to work. Allow this App to use the network connection if
requested.
Broadcaster
If the Cloud icon is present on the screen and Remote viewers are unable to nd the SHO-FLOW, the Broadcaster’s location may not
have pulled the most current location. To correct this the broadcaster should return to the Device connection screen and press the
Disconnect button. This will disconnect from the SHO-FLOW. Once the SHO-FLOW becomes available again in the device list, you
may select and connect to the device. This will then pull your device location again and reconnect to the Cloud.
Remote Viewer
The Remote Viewer’s location may not have pulled the most current location. To correct this, press the Disconnect Button. Then,
press the Conrm or refresh button if necessary refresh to begin scanning again with the new location.
If you are still encountering any issues it may be necessary to restart the App.
If none of the above work, a restart of your device may be necessary.

©Copyright Task Force Tips LLC 2019-2020 LIE-100 August 17, 2020 Rev05
11
8.0 WARRANTY
Task Force Tips LLC, 3701 Innovation Way, Valparaiso, Indiana 46383-9327 USA (“TFT”) warrants to the original purchaser of
its products (“equipment”), and to anyone to whom it is transferred, that the equipment shall be free from defects in material and
workmanship during the ve (5) year period from the date of purchase. TFT’s obligation under this warranty is specically limited to
replacing or repairing the equipment (or its parts) which are shown by TFT’s examination to be in a defective condition attributable to
TFT. To qualify for this limited warranty, the claimant must return the equipment to TFT, at 3701 Innovation Way, Valparaiso, Indiana
46383-9327 USA, within a reasonable time after discovery of the defect. TFT will examine the equipment. If TFT determines that
there is a defect attributable to it, TFT will correct the problem within a reasonable time. If the equipment is covered by this limited
warranty, TFT will assume the expenses of repair.
If any defect attributable to TFT under this limited warranty cannot be reasonably cured by repair or replacement, TFT may elect to
refund the purchase price of the equipment, less reasonable depreciation, in complete discharge of its obligations under this limited
warranty. If TFT makes this election, claimant shall return the equipment to TFT free and clear of any liens and encumbrances.
This is a limited warranty. The original purchaser of the equipment, any person to whom it is transferred, and any person who is
an intended or unintended beneciary of the equipment, shall not be entitled to recover from TFT any consequential or incidental
damages for injury to person and/or property resulting from any defective equipment manufactured or assembled by TFT.
It is agreed and understood that the price stated for the equipment is in part consideration for limiting TFT’s liability. Some states do
not allow the exclusion or limitation of incidental or consequential damages, so the above may not apply to you.
TFT shall have no obligation under this limited warranty if the equipment is, or has been, misused or neglected (including failure to
provide reasonable maintenance) or if there have been accidents to the equipment or if it has been repaired or altered by someone
else.
THIS IS A LIMITED EXPRESS WARRANTY ONLY. TFT EXPRESSLY DISCLAIMS WITH RESPECT TO THE EQUIPMENT ALL
IMPLIED WARRANTIES OF MERCHANTABILITY AND ALL IMPLIED WARRANTIES OF FITNESS FORA PARTICULAR PURPOSE.
THERE IS NO WARRANTY OF ANY NATURE MADE BY TFT BEYOND THAT STATED IN THIS DOCUMENT.
This limited warranty gives you specic legal rights, and you may also have other rights which vary from state to state

©Copyright Task Force Tips LLC 2019-2020 LIE-100 August 17, 2020 Rev05
TASK FORCE TIPS LLC
MADE IN USA • TFT.com
3701 Innovation Way, Valparaiso, IN 46383-9327 USA
800-348-2686 • 219-462-6161 • Fax [phone]
9.0 OPERATION AND INSPECTION CHECKLIST
BEFORE EACH USE the device must be inspected to this checklist
1. There is no obvious damage such as missing, broken or loose parts, damaged labels, etc.
2. The waterway is clear of obstructions and the turbine is free of debris.
3. Coupling is tight and leak free.
BEFORE BEING PLACED BACK IN SERVICE, device must be inspected to this checklist;
1. There are no broken or missing parts.
2. There is no obvious damage to the device that could impair operation (e.g. dents, cracks, corrosion, or other defects).
3. The thread and gasket are in good condition.
4. The waterway is clear of obstructions and internal turbine is free of debris.
5. Device is clean and markings are legible.
6. Coupling is retightened properly.
WARNING
Equipment failing any part of the checklist is unsafe for use and must have the problem corrected
before use or being placed back into service. Operating equipment that has failed the checklist is
a misuse of this equipment.
