Thane Fitness ORBITREK MX User manual

NOTE
During Manual Mode, Training Program Mode can be applied anytime by pressing the
FUNCTION button and it will start within 3 sec.
Orbitrek™ MX shuts off automatically after 30minutes per use. The unit will notify with
Beeping noise minute prior to the automatic shut off.
DO NOT try to forcefully stop or slow down the pedals when they are in motion at any
speed level and/or exercise program. By doing so at speed level 3, 4, and 5, the built-in
overload feature will shut down the motor. If the pedals are forcefully resisted at speed
level 1, 2 for a few minutes, the motor can be damaged.
CARE AND MAINTENANCE
• Store the unit in a dry, cool and ventilated area.
• Do not store the unit in direct sun light.
• Do not store in humid areas such as bathrooms.
• Always unplug the unit prior to cleaning.
• Use a soft damp cloth to clean the surface of the unit. Mild detergent may be used to clean.
TROUBLESHOOTING
Please refer to below problems and solutions
SPECIFICATIONS Voltage: 100V-240V Frequency: 50 ~ 60Hz
Rating Power: 50W Automatic Shut Off Time: 30m
MX
Thane Canada Inc.
Mississauga ON L4W 5M6, Canada
www.thane.ca
Thane USA, Inc.
Canton OH 44718, U.S.A.
www.thane.com
Thane Direct UK Limited
Thanet House 231-232 Strand,
London WC2R 1DA
www.thane.tv
Danoz Direct Pty Ltd.
Bondi Junction, NSW, 2022, Australia
www.danoz.com.au
OPERADORA AINOA SAPI DE CV
Av. Magnocentro No. 5 Piso 1 Centro
Urbano Interlomas,
Municipio Huixquilucan de Degollado,
Estado de México. C.P: 52760
www.mejorcompratv.com
TVNS Scandinavia AB
SE-211 74 Malmö, Sweden
www.tvins.com
Orbitrek MX MNL ENG R3 201119
© 2020 Thane IP Limited.
“Thane”, “Orbitrek™ XM” and related logos and variations are trademarks or registered trademarks, in Canada and/or other
countries, of Thane IP Limited and/or its affiliated companies.
MADE IN CHINA
Distributed by:
INSTRUCTION MANUAL
Important Warnings
• Do not stand on the unit, always remain
seated while using the unit.
• This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities
or lack of experience and knowledge,
unless they have been given supervision or
instruction concerning use of the appliance
by a person responsible for their safety.
• This is not a toy. Please keep away from
children at all times. This unit can be used
adults only.
• This unit is intended for household use only.
• Do not use outdoors.
• Please check the unit and its parts thoroughly
for any damages.
• Do not use the unit if any parts are damaged
or if the unit malfunctions. Please do not
try and make any self-repairs, please contact
a qualified service agent for repairs.
• Any servicing should be performed by an
authorized service representative.
• Please use extreme caution when the unit
is being used around children, disabled
or invalids persons. Do not leave the unit
unsupervised.
• Always unplug the unit when not in use.
• Do not submerge the unit into water or
any liquids. Do not reach for the unit if it
has fallen into the water. Unplug immediately.
• Do not insert foreign objects into the vents,
bars or openings of the unit. This may
cause an electric shock, fire or damage the unit.
• Please use this unit as described in the
manual, any misuse or mishandling may
cause malfunctioning.
• Always operate the unit in an upright and
seated position.
• Do not leave the unit unattended when
plugged in.
• Do not use the product in wet or dusty
environment. Do not use in humid
environment, such as bathroom.
• Store the unit in a cool and dry place.
• Do not use foreign attachments on this
unit. Use the attachments provided by the
manufacturer only.
• Keep air openings free of lint, hair and dust.
• Do not use the unit on insensitive skin or
in presence of poor circulation.
• This unit is not intended for medical use.
• Do not cover the unit when it is in
operation/usage to avoid overheating or
malfunction.
• Do not use the unit for more than 30
minutes at a time.
• Extensive use may damage the unit.
• This unit should not be used by an individual
suffering from any physical aliment that
may limit the user’s capacity to operate
controls.
• The unit may turn off after an extended
period of use.
• Keep fingers away from the foot plate
while machine is in use.
• Please allow the unit to be used by person
at a time only.
• Do not jump on the machine.
• Do not operate the unit with wet hands.
• If you feel uncomfortable or experience
any adverse symptoms while using the
unit stop use immediately.
• This unit is not suitable for therapeutic
use. Do not use with other medical
electronic equipment such as pacemakers.
• Use the unit on a levelled surface, keep at
least 3 feet of free space all around it.
• In case of any power surge during use,
stop using the product immediately.
Sudden restoration of power may cause
injuries.
• Do not place the power cord under the
product or any heavy object.
• Do not use the power cord to move the
product.
• The product’s rated voltage fits 110V, rated
power is 50W, rated time is 30 mins.
PLEASE CONSULT YOUR DOCTOR PRIOR TO USAGE IF YOU ARE:
• PREGNANT • HAVE A PACEMAKER • DIABETIC • OR HAVE ANY CONCERNS REGARDING HEALTH
Problem Cause Solution
Unit is not functioning Not powered Please check the power
cord is plugged in correctly.
Press the Power button
and Start/stop button to
function
Suddenly stopped while
operating
Power failure
Time exceeded 30 minutes
Overheated
Check if power is connected
Press power button and
start again
Let the unit cool down and
start again
Do not stand on the unit
Do not remove the Anti-Slip pads underneath the unit.
ONLY USE THE UNIT WHILE SITTING. DO NOT STAND ON THE UNIT
!WARNING

CONTROLS
Power: Turns the unit ON or OFF
Start/Stop: Starts the Machine/Pause
5 Speed Modes: 01, 02, 03, 04, 05. Range from 1-5.7 km/hr
Function: Pre-Installed Training (3 Programs)
Direction: Changes the direction of the cycle
Mode: Change Screen Display readings
HOW TO OPERATE THE UNIT
Plug in the power supply cord into the power socket on the unit.
4 RED bars will appear ---- on LCD Display to Indicate the unit is on stand-by.
To start the unit, Please Press the power button to turn the unit ON/OFF, Then Press
START/STOP button to Activate or Stop the machine anytime.
OPERATING INSTRUCTIONS
TRAINING PROGRAM MODE
Press FUNCTION button once for Program 1, Twice for Program 2 and thrice for Program 3.
Once decided press START/STOP button to start the program.
The pedals will rotate at different speeds and direction depending on the set program.
DURING AUTO EXERCISE, SPEED AND DIRECTIONS CANNOT BE ADJUSTED
MANUAL MODE (HA)
Press the POWER button and when HA is displayed on Screen, press the START/STOP
button to start the unit. Select from 5 speed levels by pressing the up and down ARROW
speed button.
The Direction of the Pedal can be changed anytime during MANUAL mode by pressing
the DIRECTION button.
Press the MODE button to switch between displays for:
• Scan: Automatically Scan through different function reading every 5 seconds
• Time: Time of Training (Minutes, Second) Max Working Time: 30Minutes
• Distance: Measurement of Walking Distance in Meters
• Speed: Display shows the Current Speed
• Counter: Shows accumulated cycles
• Calorie: Current Calories burned
Pedals start the cycle
reverse with the speed
at 01. Gradually the
speed increases and
the directions change.
Pedals start the cycle
with the speed at 01
and gradually increases
the speed and
direction at different
workout points.
The cycle speed
changes at faster pace,
reaching max speed
levels.
PARTS & ACCESSORIES
X2 AAA Batteries
Required
(Not Included)
LCD Display
Anti-Slip
pads
Handle
Remote Holder
Pedals
PROGRAM 1 PROGRAM 2 PROGRAM 3
Power cord socket
(Cord Included)
