The box PA 18 ECO User manual

PA 18 ECO
High-Performance 700-Watt 18" PA Subwoofer
Users manual
DATA-MANFULL_PA18_ECO_ENG_Rev_A.PMD 20.02.2006, 15:161

2
PA 18 ECO
SAFETY INSTRUCTIONS
1) Read these instructions
2) Keep these instructions
3) Heed all warnings
4) Follow all instructions
5) Do not use this device near water
6) Clean only with a dry cloth
7) Be sure to mount your speakers on a solid, stable and level base or stand Vibrating
floors do not provide reliable support for speaker enclosures or stacks
8) Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat
9) Only use attachments/accessories specified by the manufacturer
10) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or
sold with the device When a cart is used, use caution when moving the cart/device
combination to avoid injury from stumbling over it
11) Refer all servicing to qualified service personnel Servicing is required when the unit
has been damaged in any way, liquid has been spilled or objects have fallen into the device,
the unit has been exposed to rain or moisture, does not operate normally, or has been
dropped
12) Do not block any ventilation openings Install in accordance with the manufacturers
instructions
DATA-MANFULL_PA18_ECO_ENG_Rev_A.PMD 20.02.2006, 15:162

3
PA 18 ECO
1. CONNECTIONS
Connections
Two ¼ loudspeaker inputs are wired in parallel You can alternatively connect one of the
connectors to the output on your power amp and tap into the signal from the amp once
again on the second connector, in order to feed this signal into an additional loudspeaker
¼" TS connector
+ATTENTION: Never connect more than one power amp output to the
loudspeaker system. This may permanently damage your setup.
DATA-MANFULL_PA18_ECO_ENG_Rev_A.PMD 20.02.2006, 15:163

4
PA 18 ECO
2. POWER AMP RATING
The power rating of your amp should be roughly twice the speaker load capacity
ATTENTION!
+When several loudspeakers are wired in parallel the overall impedance
Zges to e handled y the power amp can e calculated, as shown elow,
from the individual impedance values of the connected speakers:
Your amplifier may e damaged if the actual impedance drops elow its
input impedance. Please make sure that the calculated total impedance
Zges is not smaller than the minimum impedance specified for your amplifier.
3. WIRING
Using an external (active) crossover, the main output signal of a mixing console is split into
a stereo signal and a mono signal The mono signal covers the lower frequency range and
the stereo signal covers all other frequency ranges Then, the stereo signal is connected
to a stereo power amplifier A high-to-mid-range box is connected to each of the amp
outputs The mono subwoofer signal is connected to one channel of an additional power
amplifier, which powers one PA 18 ECO subwoofer
Stereo operation with a subwoofer
DATA-MANFULL_PA18_ECO_ENG_Rev_A.PMD 20.02.2006, 15:164

5
PA 18 ECO
4. SPECIFICATIONS
6<67(0'$7$ 3$(&2
Type Subwoofer
Frequency response 45 Hz - 400 Hz
Power rating (Peak program) 700 W
Impedance 4
:
Sound pressure level (1 W @ 1 m) 98 dB (Full Space)
Dispersion -
Crossover frequency 350 Hz (recommended)
Rigging/fittings 2 x ergonomically shaped handles
Pole socket for mounting with spacer rod
&20321(176
HF driver -
Woofer 18" (460 mm)
',0(16,216:(,*+7
(W x H x D) ca. 21.3" x 28.9" x 15.8"
(541 mm x 735 mm x 400 mm)
Weight approx. 68.3 lbs. (31.0 kg)
Shipping weight approx. 72.8 lbs. (33.0 kg)
THOMANN MUSIKHAUS is constantly striving to maintain the highest professional standards. As a
result of these efforts modifications may be made from time to time to existing products without prior
notice. Specifications and appearance may differ from those listed or illustrated.
