The Mandir Store MWC-08-108-301-753622 User manual

Not to scale
Assembly Guide #03
Page of1 24
Not to scale
v2.0
!
© 2022. The Mandir Store®. All Rights Reserved.
Scan the QR for the digital
This guide works for the following SKUs
MWC-08-108-301-753622
MWC-14-108-345-754822
MWC-08-108-301-674818

Not to scale
Assembly Guide #03
Page of2 24
Not to scale
v2.0
!
© 2022. The Mandir Store®. All Rights Reserved.
Step 1: Assemble the inner drawer(s)!
!
!
handle screw
minifix
pull handle
philips screw driver
x2
x8
x1
x1 | not included
Gather the required planks K1, L1, M1, N1, O1 and P to assemble the inner drawer => Drawer 1.
Required hardware is shown below!

Not to scale
Assembly Guide #03
Page of3 24
Not to scale
v2.0
!
© 2022. The Mandir Store®. All Rights Reserved.
1.a. screw 8 mini fixes into the pre-drilled holes on planks K, Mand O↓
1.b. attach side panels Kand Magainst rear panel Land tighten CAM(s) to secure ↓

Not to scale
Assembly Guide #03
Page of4 24
Not to scale
v2.0
!
© 2022. The Mandir Store®. All Rights Reserved.
1.c. slide the drawer base panel Nalong the routed lines ↓
1.d. secure one handle Son the drawer plank Ousing the provided screws ↓

Not to scale
Assembly Guide #03
Page of5 24
Not to scale
v2.0
!
© 2022. The Mandir Store®. All Rights Reserved.
1.e. attach the drawer front Oon the drawer structure and tighten the CAMs to secure ↓
1.f. simply rest platform extension plank Pon the drawer box ↓

Not to scale
Assembly Guide #03
Page of6 24
Not to scale
v2.0
!
© 2022. The Mandir Store®. All Rights Reserved.
1.g. repeat steps 1.a through 1.f to assembly two more drawers ↓!
Parts for drawer 2 = K2, L2, M2, N2, O2 = Drawer 2
Parts for drawer 3 = K3, L3, M3, N3, O3 = Drawer 3

Not to scale
Assembly Guide #03
Page of7 24
Not to scale
v2.0
!
© 2022. The Mandir Store®. All Rights Reserved.
Step 2: Prepare cabinet doors!
Gather the required planks X and Y to prepare the cabinet doors
Required hardware is shown below
hinge screw
handle screw
pull handle
philips screw driver
x8
x4
x2
x1 | not included

Not to scale
Assembly Guide #03
Page of8 24
Not to scale
v2.0
!
© 2022. The Mandir Store®. All Rights Reserved.
2.a. secure the door hinges in place on doors Xand Yusing the provided screws ↓
2.b. secure the handles Son the doors Xand Yusing the provided screws ↓

Not to scale
Assembly Guide #03
Page of9 24
Not to scale
v2.0
!
© 2022. The Mandir Store®. All Rights Reserved.
Gather the required planks F, G, H, H1, H2, I, J and AA (x2) to assemble base storage structure
Step 3: Assemble the base structure
Required hardware is shown below!
leg screw
minifix
philips screw driver
x16 | optional
x28
x1 | not included

Not to scale
Assembly Guide #03
Page of10 24
Not to scale
v2.0
!
© 2022. The Mandir Store®. All Rights Reserved.
2.a. (optional) you may choose to replace the rubber legs with SS legs on base plank F↓
2.b. screw 4 mini fixes into the pre-drilled holes on parts G and I↓

Not to scale
Assembly Guide #03
Page of11 24
Not to scale
v2.0
!
© 2022. The Mandir Store®. All Rights Reserved.
2.c. screw 4 mini fixes into the pre-drilled holes on part H↓
2.d. screw 20 mini fixes into the pre-drilled holes on parts Jand F↓

Not to scale
Assembly Guide #03
Page of12 24
Not to scale
v2.0
!
© 2022. The Mandir Store®. All Rights Reserved.
2.d. attach side Gto rear plank H, tighten CAM(s) to secure in place ↓
2.e. attach side plank Ito the above assembled structure, tighten CAM(s) to secure it ↓

Not to scale
Assembly Guide #03
Page of13 24
Not to scale
v2.0
!
© 2022. The Mandir Store®. All Rights Reserved.
2.f. attach side plank H1 to the above assembled structure, tighten CAM(s) to secure it ↓
2.g. attach side plank H2 to the above assembled structure, tighten CAM(s) to secure it ↓

Not to scale
Assembly Guide #03
Page of14 24
Not to scale
v2.0
!
© 2022. The Mandir Store®. All Rights Reserved.
2.h. place base plank Fonto the assembled structure, tighten CAM(s), x5 each side, to
secure it↓
2.i. flip the assembled structure and place plank Jon it, tighten CAM(s), x5 each side, to
secure it ↓

Not to scale
Assembly Guide #03
Page of15 24
Not to scale
v2.0
!
© 2022. The Mandir Store®. All Rights Reserved.
2.j. tilt and slide the two shelves labeled AA onto their respective shelf supports↓
2.k. gently pull the inner slides from the base structure and slide the drawer Drawer 3 on
them ↓

Not to scale
Assembly Guide #03
Page of16 24
Not to scale
v2.0
!
© 2022. The Mandir Store®. All Rights Reserved.
2.l. repeat step 2.k and place Drawer 2 in the center and Drawer 1 on top ↓
2.m. clip on the male door hinges on doors X and Y onto the female hinges on the base ↓

Not to scale
Assembly Guide #03
Page of17 24
Not to scale
v2.0
!
© 2022. The Mandir Store®. All Rights Reserved.
Step 3: Affix the back panel to the base structure
Gather the required hardware, back panel Aand the fully assembled base structure
Required hardware is shown below
hex bolt
hex key / allen key
x5 or 6
x1

Not to scale
Assembly Guide #03
Page of18 24
Not to scale
v2.0
!
© 2022. The Mandir Store®. All Rights Reserved.
3.a. align the holes at the back of the panel Awith the holes at the back of the base structure,
then secure the panel in place using the hex bolts provided using the hex key provided along
with the mandir. !
Note: Be sure to align all the bolts using your fingers before fastening any one of the bolts
completely.

Not to scale
Assembly Guide #03
Page of19 24
Not to scale
v2.0
!
© 2022. The Mandir Store®. All Rights Reserved.
Step 4: Affix the hood and decorate the mandir!
Gather the below shown parts to finish decorating your mandir. The Jharoka hanger design (part C)
may vary based on your mandir design but the same assembly instructions apply"
"
Required hardware is shown below
hex bolt
hex key / allen key
hanger screw
philips screw
driver
S hook
x2
x1
x6+
x1 | not included
x4+

Not to scale
Assembly Guide #03
Page of20 24
Not to scale
v2.0
!
© 2022. The Mandir Store®. All Rights Reserved.
4.a. slide the jharoka hanger onto the placeholder tiles and fasten the screws to secure ↓
4.b. repeat the same for the other jharoka hanger side pieces ↓
