Thermador Professional P24WK User manual

For Thermador Professional®Cooktops
INSTALLATION
INSTRUCTIONS
Models
P24WK
PC304
PC36
PC48

IMPORTANT INSTALLATION INFORMATION
Contents
Warnings . .................................................................................. Below
Introduction........................................................................................ 1
Important Installation Information ....................................................... 2
Step 1: Ventilation Requirements ...................................................... 3
Step 2: Cabinet Preparation ......................................................... 4 – 7
Step 3: Unpacking, Moving, Placing and Anchoring the Cooktop ...... 8
Step 4: Gas Requirements and Hookup..................................... 9 – 10
Step 5: Electrical Requirements, Connection and Grounding ......... 11
Step 6: Backguard Installation.......................................................... 12
Step 7: Test Adjustment ................................................................... 13
Installer Checklist ............................................................................. 14
WARNING
Improper installation, adjustment, alteration,
service or maintenance can cause injury or
property damage. Refer to this manual. For
assistance or additional information consult a
qualified installer, service agency, manufac-
turer (dealer) or the gas supplier.
ForMassachusettsInstallations:
1. Installation must be performed by a qualified or licensed contractor, plumber or gas
fitter qualified or licensed by the state, province or region where this appliance is being
installed.
2. Shut-off valve must be a "T" handle gas cock.
3. Flexible gas connector must not be longer than 36 inches.
WARNING:
If the information in this manual is not
followed exactly, a fire or explosion may
result causing property damage, per-
sonal injury or death.
— Do not store or use gasoline or other
flammable vapors and liquids in the vicinity
of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS
QDo not try to light any appliance.
QDo not touch any electrical switch.
QDo not use any phone in your building.
QImmediately call your gas supplier from a
neighbor’s phone. Follow the gas supplier’s
instructions.
QIf you cannot reach your gas supplier, call
the fire department.
— Installation and service must be performed
by a qualified installer, service agency or
the gas suppler.
Note: This Cooktop is NOT designed for instal-
lation in manufactured (mobile) homes or for
installation in Recreational Park Trailers.
DO NOT install this appliance outdoors.
DATA RATING PLATE
Cooktop Models:
The data rating plate showing the model and serial
numbers of your Cooktop or Wok is located on the
underside of the Cooktop or Wok chassis near the
gas inlet connection and electric power cord. This
information is required if customer service is
requested. Before installation, the model and serial
numbers should be entered in the appropriate
spaces on Page 30 of the Care and Use Manual.
After installation, accessing the information is
difficult.

TheThermadorProfessional®Cooktopsare available
inanumberofsizesandconfigurations.ModelP24WK
is a 24"-wide wok unit featuring a power burner rated
at 30,000 BTU/HR. The 30"-wide Model PC304 fea-
tures a gas cooking surface with four sealed burners.
The 36"-wide Models PC364GE, PC364GL, and
PC366 feature four sealed burners and an electric
griddle, four sealed burners and a gas grill, or six
sealed burners, respectively. The 48"-wide Models
PC484GGE, PC486GE, PC486GL and PC484WK
feature four sealed burners, electric griddle and gas
grill, six sealed burners and an electric griddle, six
sealed burners and a gas grill, or four sealed burners
and a 30,000 BTU/HR WOK, respectively. All sealed
Introduction
GAS SUPPLY:
Natural Gas – 6 inch water column.
Propane Gas – 11 inch water column.
PLEASE READ ENTIRE INSTRUCTIONS BEFORE PROCEEDING
IMPORTANT:LOCALCODESVARY.INSTALLATION,ELECTRICALCONNECTIONS,
GASCONNECTIONS,ANDGROUNDINGMUSTCOMPLYWITHALLAPPLICABLECODES.
Model PC364GD
(Shown with Low Back Model GPS36LB)
Model P24WK
(Shown with Low Back Model GP24LB)
1
WARNING
Disconnect power before installing. Before
turning power ON, be sure that all controls are
in the OFF position.
ELECTRICAL POWER SUPPLY:
36" Models:
PC366- 120 VAC, 60 Hz., 1 Ph., 10 Amp circuit.
PC364GL- 120 VAC, 60 Hz., 1 Ph., 10 Amp circuit.
PC364GE (with electric griddle)- 120 VAC, 60 Hz., 1 Ph., 15 Amp circuit.
30'' models:
PC304- 120 VAC, 60 Hz., Ph., 10 Amp circuit
48" Models:
PC486GL- 120 VAC, 60 Hz., 1 Ph., 10 Amp circuit.
PC486GE- 120 VAC, 60 Hz., 1 Ph., 15 Amp circuit.
PC486GGE (with electric griddle) - 120 VAC, 60 Hz., 1 Ph., 15 Amp circuit.
PC484WK- 120 VAC, 60 Hz., 1 Ph., 10 Amp circuit.
24"Model
P24WK- 120 VAC, 60 Hz., 1 Ph., 10 Amp circuit.
IMPORTANT: Save these instructions for the Local Electrical Inspector’s use.
INSTALLER: Please leave these Installation Instructions with this unit for the owner.
OWNER: Please retain these instructions for future reference.
burners are rated at 15,000 BTU/HR, electric griddles at
1,600 watts, and grills at 18,000 BTU/HR.
IMPORTANT
• Abackguardmust be utilized when thereisless than
a 12" horizontal clearance between combustible
materials and the back edge of the cooktop. The
Thermador Low Back backguard must be ordered
separately and installed at the rear of the cooktop.
For island installations and other installations with
more than 12" clearance, an optional stainless steel
Island Trim is available to cover the backguard
mounting flanges.
• Verify that the appliance is correct for the type of gas
being provided. Refer to Step 4 before proceeding
with the installation.

CAUTION
(1) When connecting the unit to
propane gas, make certain
the propane gas tank is
equipped with its own high-
pressure regulator in addi-
tion to the pressure regula-
tor supplied with this unit.
Themaximum gas pressure
to this appliance is not to
exceed 14.0 inches water
column from the propane
gas tank regulator.
(2) This unit is designed as a
cooking appliance. Based
on safety considerations,
never use it for warming or
heating a room.
This appliance has been tested
in accordance with ANSI Z21.1,
Standardfor Household Cooking
Appliances (USA) and in accor-
dancewithCAN1.1-M81Domes-
tic Gas Ranges (Canadian).
It is strongly recommended that
this appliance be installed in con-
junctionwith a suitableoverhead
vent hood. (See Step 1 for Ven-
tilation Requirements.) Due to
the high heat capability of this
unit, particular attention should
ImportantInstallationInformation
be paid to the hood and duct
work installation to assure it
meets local building codes.
Check local building codes for
the proper method of appliance
installation. Local codes vary.
Installation, electrical connec-
tions and grounding must com-
ply with all applicable codes. In
the absense of local codes the
appliance should be installed in
accordancewiththe NationalFuel
Gas Code ANSI Z223.1 current
issue and National Gas Code
ANSI/NFPA70 – current issue. In
Canada, installation must be in
accordance with the CAN 1-
B149.1and.2 –InstallationCodes
for Gas Burning Appliances and/
or local codes.
This appliance is equipped with
an intermittent/interrupted igni-
tion device that cycles the two far
left surface burners on and off
when in the ExtraLow®setting.
CAUTION
To eliminate risk of burns or
fire caused by reaching over
heatedsurfaceunits,cabinet
storagelocatedabovethesur-
faceunitsshouldbe avoided.
2

Step1: Ventilation Requirements
It is strongly recommended that
a suitable exhaust hood be in-
stalled above the appliance.
Downdraft ventilation should not
be used. The table below indi-
cates the Thermador hoods, by
model number, that are recom-
mended for use with the 24" Wok
30", 36" and 48" cooktops.
1.SelectHood andBlowerMod-
els:
• For wall installations, the
hood width must, at a mini-
mum, equal the nominal
width of the appliance cook-
ing surface. Where space
permits,ahoodlargerinwidth
thanthe cooking surface may
be desirable for improved
ventilation performance.
• For island installations, the
hood width should, at a mini-
NOTES: * For wall installations where adequate space is available, the installer or user may elect to use
a hood that is wider than the cooktop cooking surface. This may be particularly beneficial for
those cases, such as a long duct run or heavy usage of the grill, in which improved capturing
of the cooking exhaust is desired.
** Thermador offers a choice of remote (VTR1000Q or VTR1400Q) or in-hood (VTN1000Q)
blowers for use in wall installations.
VTR1000Q
VTR1400Q
or VTN1000Q
VTR1000Q
VTR1400Q
or VTN1000Q
VTR1000Q
VTR1400Q
or VTN1000Q
24" WOK
30" COOKTOP
36" COOKTOP
48" COOKTOP
HTNI42YS
HNI42YS
PHI48ZS
HTNI42YS
HNI42YS
PHI48ZS
HTNI48YS, HNI48YS
HTNI54YS, HNI54YS
PHI60ZS
VTR1000Q
VTR1400Q
VTR1000Q
VTR1400Q
VTR1400Q
PH30ZS, PHE30,36
HNW36YS
PH36ZS, PH42ZS
PHE36, 42
HNW 36,42 YS
PH48ZS, PH54ZS
PHE48, 60
HNW48YS
WALLINSTALLATION ISLAND INSTALLATION
NOMINAL COOKTOP WIDTH HOOD* BLOWER** HOOD* BLOWER**
3
mum,overhangtheappliance
cookingsurfaceby3"oneach
side.
• Hood blower speeds should
be variable to reduce noise
and loss of heated or air con-
ditioned household air when
maximum ventilation is not
required.Normally, themaxi-
mum blower speed is only
required when using the grill.
2. Hood Placement:
• For best smoke elimination,
the lower edge of the hood
should be installed a mini-
mum of 30" to a maximum of
36" above the appliance
cooking surface. (See Fig.
1).
• Ifthe hood contains any com-
bustible materials (i.e., a
wood covering), it must be a
minimum of 36" above the
cooking surface.
3. Consider Make-Up Air:
• Due to the high volume of
ventilation air, a source of
outside replacement air is
recommended. This is par-
ticularly important for tightly
sealed and insulated homes.
• A qualified heating and ven-
tilating contractor should be
consulted.
NOTE: Ventilation hoods and
blowers are designed for use
with single-wall ducting. Some
local building codes may require
double-wallducting. Before start-
ing installation, consult local
building codes and agencies to
insure that the installation will
meet local requirements.
