Thermadyne Fabricator 252i US User manual

CONTROL PCB REPLACEMENT INSTRUCTIONS
0-5248 Rev AB 1 May 16, 2012
© 2012 by Thermadyne Industries
Kit Componants
The following components are included in this kit.
• ControlPanelPCBAssembly
• AntiStaticStrap
• MountingScrews(4)
• Instructions
Control PCB Replacement
NOTE
This process is the same for the Fabricator and the Transmig units. Transmig is shown in these in-
structions.
1. Disconnect power from the power supply
2. Locate the anti static strap in this kit and follow instructions for proper use and fit it to your body.
3. Removefour(4)ControlPanelscrews(#1).
#1
Art # A-1
Figure1:FrontPanelScrewRemoval(Transmigshown)
ThermadyneHoldingsCorporation
Suite300,16052SwingleyRidgeRoad
St.Louis,MO63017,USA
Telephone:1-800-426-1888•Fax:1-800-535-0557
Email: [email protected]
www.thermalarc.com
Manual 0-5248
Control PCB Replacement and
Part Numbers for
Fabricator 252i US W7005381
Fabricator 252i EU W7005388
Transmig 250i W7005336
Assembly Instructions

CONTROL PCB REPLACEMENT INSTRUCTIONS
4. TiltpaneltowardyouanddisconnecttheRibbonCablebyippingthetwolockingtabsoutwardthenlifting
the harness connector from the board.
Art # A-10???
Figure2:ControlPCBAccess
5. Remove the control panel assembly and replace with the new one by reversing these procedures.
6. LocatethenewControlPanelPCBAssemblyandorientitliketheonejustremovedandattachtheribbon
cable making sure it snaps into place with both locking tabs being activated.
7. Carefullysetthecontrolpanelassemblybackintothefrontpanelandsecurewiththefourscrews.
8. Apply power to the unit and verify the control panel is working.
NOTE
Any information/calibrations previously stored are now gone. All information is now factory default
and any desired calibrations will need to be done again.
