USER'S INFORMATION MANUAL
APEX™
CONDENSING HIGH EFFICIENCY
GAS-FIRED HOT WATER BOILER
www.thermalsolutions.com

2
The following terms are used throughout this manual to bring attention to the presence of hazards of various risk levels.
Basic Operation and Maintenance
DANGER
There are no user serviceable parts on this boiler. Attempts to service this boiler by someone other than a
qualied gas service technician could void the warranty, cause property damage, personal injury or loss of
life.
CAUTION
Should overheating occur or the gas supply fail to shut off, do not turn off or disconnect the electrical
supply to the pump. Instead, shut off the gas supply at a location external to the appliance.
En cas de surchauffe ou si I'admission de gaz ne peut étre coupée, ne pas couper ni débrancher
l'alimentation électrique de la pompe. Fermer plutôt le robinet d'admission de gaz à l'extérieur de I'appareil.
Do not use this boiler if any part has been under water. Immediately call a qualied service technician to
inspect the boiler and to replace any part of the control system and any gas control which has been under
water.
CAUTION
Like all central heating appliances, this boiler is equipped with safety devices, which could cause it to
shutdown, requiring service to restore normal operation. Where such a shutdown could result in damage
from low temperatures (such as frozen pipes), do not leave the heating system unattended during cold
weather unless alarms or other safeguards are in place to prevent damage.
DANGER
Indicates an imminently hazardous situation
which, if not avoided, will result in death, serious
injury or substantial property damage.
WARNING
Indicates a potentially hazardous situation
which, if not avoided, could result in death,
serious injury or substantial property damage.
CAUTION
Indicates a potentially hazardous situation
which, if not avoided, may result in moderate or
minor injury or property damage.
NOTICE
Indicates special instructions on installation,
operation, or maintenance which are important
but not related to personal injury hazards.

3
B. Maintenance
1. On a continuous basis:
• Keeptheareaaroundtheboilerfreefrom
combustible materials, gasoline, and other
ammablevaporsandliquids.
• Keeptheareaaroundthecombustionairinlet
terminal and the area around the boiler free
from contaminants, including all sources of
hydrocarbons such as bleaches, fabric softeners,
chemicals, sprays, cleaners, paint, paints, paint
A. General
1. This manual covers the proper care and use of
theApex™CondensingHighEfciencyGasFired
Boiler.
2. Instructions to safely operate and shut down
thisboilerareshowninFigure2onpage5,aswell
asonalabelafxedtotheboiler.Controllocations
showninFigure1.
3. Apex™ boilers use an electronic means built into
the ignition system to extinguish the burner in the
eventthatamesexitthecombustionchamber.If
theboilerfailstore,callaqualiedgasservice
technician to diagnose and correct the problem.
4. Apex™ boilers areequippedwithasafetyfeature
which will shut down the burner in the event that
thereisablockageintheventsystem.Intheevent
that the boiler fails to function, and the boiler is
vented through an outside wall accessible from the
ground, inspect the vent terminal on the outside
wall for a blockage such as a bee’s nest or ice.
Ifablockageisfound,theburnershouldignite
approximately 30 seconds after the blockage is
removed.Ifnoblockageisfound,oriftheterminal
is inaccessible from the ground, the problem must
bediagnosedandcorrectedbyaqualiedgas
service technician.
WARNING
Asphyxiation Hazard. In the event that the
ignition system on an Apex boiler does not
permit the boiler to re, there is either a
problem with the ignition system or a problem
with the vent system. Call a qualied gas
service technician to diagnose and correct
the problem.
A shutdown of the burner due to the pressure
switch is an indication that there is a problem
with the vent system, such as a blockage. The
boiler pressure switch should only be reset
after a qualied gas service technician has
diagnosed and corrected the venting problem
that caused the pressure switch to open.
removers, refrigerants, and cat boxes. Traces of
these chemicals can be drawing into the boiler,
causing severe corrosion damage to the boiler
and/or objectionable odors.
• Keeptheboilerroomventilationopeningsopen
and unobstructed.
• Donotexposetheboilertolargeamountsofdust
such as that generated by drywall construction or
woodworking.
2. On a monthly basis:
WARNING
If any of the below listed conditions is found,
follow instructions “TO TURN OFF GAS TO
APPLIANCE” in Figure 2 and contact a qualied
gas service technician to correct the problem
before placing the boiler back in service. Failure
to correct these conditions could result in
property damage, personal injury or loss of life.
• Inspectventandcombustionairintaketerminals
for obstruction or damage due to impact or
excessive temperature.
• Inspectventandcombustionairexteriorwall
penetrations to be sure they are weather tight.
• Inspecttheventandcombustionairintake
system for obstructions, loose joints, condensate
leakage, sags in horizontal runs of pipe,
corrosion, or other deterioration.
• Inspectuetemperaturesensorcapatboilerrear
for leakage and deterioration.
• Inspectwaterandgaslinesforleaks.
• Removeboilerfrontdoorandinspectforcarbon
(soot) in or near the burner compartment,
condensate drain leaks or blockage, or
deterioration of the visible controls, wiring, or
sheet metal components.
• Inspectamefortrueyellowtipping.Adjust
thermostat to highest setting to turn on boiler and
viewamesthroughobservationglasswithfront
doorremoved.Onhighretheameshouldbe
stable and mostly blue. No true yellow tipping
shouldbepresent,howeverintermittentecksof
yellowandorangeintheamecausedbydustin
airarenormal.SeeFigure3.Iftheburnerame
looks satisfactory, adjust thermostat to normal
setting and reinstall boiler front door.
3. On an annual basis:haveaqualiedgasservice
technician perform a more detailed inspection
of the burner, heat exchanger, controls, and vent
systemandprovidemaintenanceasspeciedinthe
Installation,Operating,andServiceInstructions.

4
Figure 1: Control Locations

5
Figure 2: Operating Instructions
Apex™ Series Operating Instructions

6
Figure 3: Burner Flame
NOTICE
The Apex™ has a heat exchanger made from a
special stainless steel alloy which can be severely
damaged by frequent additions of water or by the
addition of boiler water additives which are not
designed for use with stainless steel boilers. If
it is necessary to add water to the boiler, have
a service technician check the system for leaks.
Do not add any chemicals to the boiler not listed
in Section X of the Apex™. Warranty is void if the
service and maintenance procedure shown in
Section XII of the Apex™ instruction manual is
not followed.
WARNING
Carbon (“soot”) in or near the burner
compartment area is an indication of a potential
carbon monoxide hazard. If carbon is found,
immediately follow instructions "TO TURN OFF
GAS TO APPLIANCE" in Figure 2 and contact a
qualied gas service technician to correct the
problem before placing the boiler back in service.

7
All Apex™ repair parts may be obtained through your local Thermal Solutions Wholesale distributor.
Should you require assistance in locating a Thermal Solutions distributor in your area, or have
questions regarding the availability of Thermal Solutions products or repair parts, please contact
Thermal Solutions Customer Service at [phone] or Fax [phone].
Important Product Safety Information
Refractory Ceramic Fiber Product
Warning:
The Repair Parts list designates parts that contain refractory ceramic fibers
(RCF). RCF has been classified as a possible human carcinogen. When
exposed to temperatures above 1805°F, such as during direct flame contact,
RCF changes into crystalline silica, a known carcinogen. When disturbed as a
result of servicing or repair, these substances become airborne and, if inhaled,
may be hazardous to your health.
AVOID Breathing Fiber Particulates and Dust
Precautionary Measures:
Do not remove or replace RCF parts or attempt any service or repair work
involving RCF without wearing the following protective gear:
1. A National Institute for Occupational Safety and Health (NIOSH)
approved respirator
2. Long sleeved, loose fitting clothing
3. Gloves
4. Eye Protection
•Take steps to assure adequate ventilation.
•Wash all exposed body areas gently with soap and water after contact.
•Wash work clothes separately from other laundry and rinse washing
machine after use to avoid contaminating other clothes.
•Discard used RCF components by sealing in an airtight plastic bag. RCF
and crystalline silica are not classified as hazardous wastes in the United
States and Canada.
First Aid Procedures:
•If contact with eyes: Flush with water for at least 15 minutes. Seek
immediate medical attention if irritation persists.
•If contact with skin: Wash affected area gently with soap and water.
Seek immediate medical attention if irritation persists.
•If breathing difficulty develops: Leave the area and move to a location
with clean fresh air. Seek immediate medical attention if breathing
difficulties persist.
•Ingestion: Do not induce vomiting. Drink plenty of water. Seek
immediate medical attention.
