1 Safety
2Operating instructions electronicVED plus 0020288449_01
1 Safety
1.1 Intended use
There is a risk of injury or death
to the user or others, or of dam-
age to the product and other
property in the event of im-
proper use or use for which it
is not intended.
This product
–Must only be used to heat up
potable water.
–Is only suitable for household
use within enclosed, frost-free
rooms.
–Is not suitable for operation in
secondary return pipes.
Intended use includes the fol-
lowing:
–observance of the operating
instructions included for the
product and any other install-
ation components
–compliance with all inspection
and maintenance conditions
listed in the instructions.
This product can be used by
children aged from 3 years
and above and persons with
reduced physical, sensory or
mental capabilities or lack of
experience and knowledge if
they have been given supervi-
sion or instruction concerning
use of the product in a safe way
and understand the hazards in-
volved. Children must not play
with the product. Cleaning and
user maintenance work must
not be carried out by children
unless they are supervised.
Any other use that is not spe-
cified in these instructions, or
use beyond that specified in this
document, shall be considered
improper use. Any direct com-
mercial or industrial use is also
deemed to be improper.
Caution.
Improper use of any kind is
prohibited.
1.2 General safety
information
Live lines and connections may
cause a potentially lethal elec-
tric shock.
▶Never remove the casing.
▶Never attempt to carry out
maintenance or repair work
on the product yourself.
▶Faults and damage should be
immediately eliminated by a
competent person.
▶Adhere to the maintenance
intervals specified.
▶Carefully read the enclosed
instructions and all other ap-
plicable documents, particu-
larly the Safety section and
the warnings.

Safety 1
0020288449_01 electronicVED plus Operating instructions 3
▶Only carry out the activities
for which instructions are
provided in these operating
instructions.
1.3 Risk of scalding caused
by hot water
The outlet temperatures at the
draw-off points can be up to
approx. 55 °C.
▶When using the product, en-
sure that you do not scald
yourself.
▶If you want to be protected
from scalding, ask your com-
petent person to activate the
product's scald protection
function.

2 Notes on the documentation
4Operating instructions electronicVED plus 0020288449_01
2 Notes on the
documentation
▶Always observe all operating instruc-
tions enclosed with the installation com-
ponents.
▶Store these instructions and all other
applicable documents for further use.
These instructions apply only to:
Product article number
Validity: Hungary
OR Hong Kong
OR Hong Kong
VED E 18/8 P INT 0010023770
VED E 21/8 P INT 0010023771
VED E 24/8 P INT 0010023772
VED E 27/8 P INT 0010023773
3 Information on the data
plate
Symbol Meaning
The VDE GS mark
confirms that the unit
complies with stand-
ards and has been
tested for safety.
Symbol confirming
conformity with the
electromagnetic com-
patibility standard
Read all of the in-
structions.
Barcode with serial
number,
The 7th to 16th digits
of the serial number
form the article num-
ber
4 CE marking
The CE marking shows that the products
comply with the basic requirements of the
applicable directives as stated on the de-
claration of conformity.
The declaration of conformity can be
viewed at the manufacturer's site.
5 Start-up and operation
5.1 Starting up the product
▶Only start up the product once the cas-
ing has been completely closed.
5.2 Control elements and display
ecoMEMO+–
°C
max. 42 °C
1
2
3
4
1 Information
/menu item
2 Selected water
temperature,
available menu
items, selection
options
3 Current assign-
ment of the se-
lection buttons
4 Selection but-
tons
5.3 Button functions
Button as-
signment
Function
+and −–Setting the domestic hot
water temperature
–Changing the set value
▲and ▼ – Scrolling in the menu

Start-up and operation 5
0020288449_01 electronicVED plus Operating instructions 5
Button as-
signment
Function
+and −at the
same time for
longer than
three seconds.
–Activating and deactivat-
ing the button lock
+and −briefly
at the same
time
–Temporarily activating the
comfort temperature
MEMO and
eco at the
same time
–Calling up the menu
MEMO –Calling up saved temper-
ature values
eco –Activating/deactivating the
eco function
Reset –Resetting the consump-
tion values
←–Going one selection level
higher
OK –Going one selection level
lower
–Confirming the setting
Saving –Saving desired temperat-
ure
The current function of the buttons is
shown in the display.
You must always confirm a change to a
value. Only then is the new setting saved.
You can use ←to cancel a process at any
time.
The appendix contains an overview of the
end user level menus.
End user level menu overview (→Page 8)
5.4 Operating the product
When you open a domestic hot water
draw-off point, the product automatically
switches on and heats up the potable
water.
In accordance with the applicable stand-
ards, the maximum permissible outlet tem-
perature for electric instantaneous water
heaters is 55 °C. The maximum outlet tem-
perature for the product has been restric-
ted to 55 °C.
The product regulates the temperature but
does not regulate the volume of water that
is drawn.
The domestic hot water temperature de-
pends on:
–Water inlet temperature
–Water outlet volume
–Performance category of the product
ecoMEMO+–
°C
max. 42 °C
During operation, the display shows the
selected water temperature in the middle
line, and the maximum water temperature
in the top line. You can use +and −to set
any desired temperature between 20 °C
and 55 °C.
▶If the product does not reach the set
water temperature at low temperatures
when drawing a large volume of water,
temporarily reduce the water volume at
the draw-off point.
◁The product increases the water
temperature very quickly.
▶You can also call up saved desired tem-
peratures. (→Page 5)
5.5 Calling up and changing saved
temperatures
The MEMO function allows the current
domestic hot water temperature to be
changed quickly. You can select from four
saved desired temperatures.

6 Faults
6Operating instructions electronicVED plus 0020288449_01
M1 M2 M3 M4
°C °C °C °C
▶Press MEMO.
▶Press the desired temperature, e.g. M3.
▶In order to change a saved temperat-
ure, press and hold the desired temper-
ature for three seconds.
▶Use +and –to change the saved tem-
perature, and confirm your changes.
5.6 Activating the comfort
temperature
The comfort temperature allows you to
temporarily draw off hot water without hav-
ing to permanently change the desired
temperature that is set. Once the water
has been drawn off, the product automat-
ically switches the comfort temperature
back.
▶Briefly press +and –at the same time.
▶Draw off water within 30 seconds.
◁The water is heated up to the set
comfort temperature.
To set the comfort temperature, see
the overview of end user levels in the
appendix.
5.7 Activating/deactivating the eco
function
The eco function saves water and energy.
When the eco function is activated, the
water flow rate is limited to eight litres per
minute.
▶Press eco in order to activate and deac-
tivate the eco function.
◁eco appears in the top left of the
display.
6 Faults
There are no faults in the product that you
are able to eliminate yourself.
▶In the event of any product fault, inform
your heating specialist company imme-
diately.
7 Maintenance and care
7.1 Maintenance
An inspection every three years and main-
tenance of the product carried out by a
competent person is a prerequisite for
ensuring that the product is permanently
ready and safe for operation, reliable, and
has a long working life.
7.2 Caring for the product
▶Clean the casing with a damp cloth and
a little solvent-free soap.
▶Do not use sprays, scouring agents,
detergents, solvents or cleaning agents
that contain chlorine.
8 Recycling and disposal
▶The competent person who installed
your product is responsible for the dis-
posal of the packaging.
If the product is labelled with this
mark:
▶In this case, do not dispose of the
product with the household waste.
▶Instead, hand in the product to a collec-
tion centre for waste electrical or elec-
tronic equipment.
If the product contains batteries that
are labelled with this mark, these batteries
may contain substances that are hazard-
ous to human health and the environment.

Recycling and disposal 8
0020288449_01 electronicVED plus Operating instructions 7
▶In this case, dispose of the batteries at
a collection point for batteries.

Appendix
8Operating instructions electronicVED plus 0020288449_01
Appendix
A End user level menu overview
Setting level Values Unit Increment, select Factory
setting
Min. Max.
Set the display →
Lighting Current value On/Off/Auto Auto
Output display Current value kW On, Off Off
Volume flow display Current value l/min On, Off Off
Scald protection →between 30 °C and 55 °C
Max. temperature Current value ℃1− −
Comfort temperature Current value ℃1− −
Consumption →
Consumption →Energy consumption →
The product is not a calibrated gauge. The consumption data that is displayed is not legally suit-
able for creating or comparing energy consumption calculations.
Since reset Current value kWh Reset
The last 30 days Current value kWh Reset
The last 365 days Current value kWh Reset
Consumption →Water consumption →
The product is not a calibrated gauge. The consumption data that is displayed is not legally suit-
able for creating or comparing energy consumption calculations.
Since reset Current value l Reset
The last 30 days Current value l Reset
The last 365 days Current value l Reset
Setting the language Current lan-
guage
Languages available for selection Coun-
try-spe-
cific

Contents
0020288449_01 electronicVED plus Installation instructions 9
Installation instructions
Contents
1 Safety .......................................... 10
1.1 Intended use ................................ 10
1.2 General safety information........... 10
1.3 Regulations (directives, laws,
standards).................................... 12
2 Notes on the documentation .... 13
3 Product description................... 13
3.1 Design.......................................... 13
3.2 Function ....................................... 13
3.3 Information on the data plate ....... 13
3.4 CE marking .................................. 14
4 Set-up.......................................... 14
4.1 Checking the scope of delivery .... 14
4.2 Selecting an installation
location ........................................ 14
4.3 Installation clearances ................. 14
4.4 Installing the product on the
wall............................................... 14
5 Installation.................................. 16
5.1 Setting up the domestic hot and
cold water connection .................. 16
5.2 Connecting the product to the
electricity supply .......................... 17
6 Start-up ....................................... 18
6.1 Removing air pockets from the
product......................................... 18
6.2 Fitting the product casing............. 19
6.3 Attaching the product casing so
that it is rotated by 180° ............... 20
6.4 Checking the function .................. 20
6.5 Calling up the installer level
menu............................................ 20
6.6 Connecting a remote control
(optional)...................................... 20
6.7 Disconnecting the remote
control (optional) .......................... 20
6.8 Activating scald protection –
between 30 °C and 55 °C ............ 21
7 Handing over to the end
user ............................................. 21
8 Recycling and disposal............. 21
9 Troubleshooting ........................ 21
9.1 Procuring spare parts .................. 21
10 Inspection and maintenance .... 21
11 Decommissioning...................... 22
11.1 Temporarily decommissioning
the product................................... 22
11.2 Permanently decommissioning
the product................................... 22
Appendix ............................................... 23
A Installer level menu
overview ..................................... 23
B Troubleshooting ........................ 23
C Technical data............................ 24

1 Safety
10 Installation instructions electronicVED plus 0020288449_01
1 Safety
1.1 Intended use
There is a risk of injury or death
to the user or others, or of dam-
age to the product and other
property in the event of im-
proper use or use for which it
is not intended.
This product
–Must only be used to heat up
potable water.
–Is only suitable for household
use within enclosed, frost-free
rooms.
–Is not suitable for operation in
secondary return pipes.
Intended use includes the fol-
lowing:
–observance of accompanying
operating, installation and
maintenance instructions for
the product and any other
system components
–installing and setting up the
product in accordance with
the product and system ap-
proval
–compliance with all inspection
and maintenance conditions
listed in the instructions.
Intended use also covers in-
stallation in accordance with the
IP code.
Any other use that is not spe-
cified in these instructions, or
use beyond that specified in this
document, shall be considered
improper use. Any direct com-
mercial or industrial use is also
deemed to be improper.
Caution.
Improper use of any kind is
prohibited.
1.2 General safety
information
1.2.1 Risk
caused by inadequate
qualifications
The following work must only
be carried out by competent
persons who are sufficiently
qualified to do so:
–Set-up
–Dismantling
–Installation
–Start-up
–Inspection and maintenance
–Repair
–Decommissioning
▶Proceed in accordance with
current technology.
Validity: Hong Kong
OR Hong Kong
In these instructions, the re-
gistered gas installer is referred
to throughout as "competent
person".
In these instructions, the re-
gistered electrical worker is re-

Safety 1
0020288449_01 electronicVED plus Installation instructions 11
ferred to throughout as "quali-
fied electrician".
1.2.2 Risk of material damage
caused by frost
▶Do not install the product in
rooms prone to frost.
1.2.3 Risk of death from
electric shock
There is a risk of death from
electric shock if you touch live
components.
Before commencing work on
the product:
▶Disconnect the product from
the power supply by switch-
ing off all power supplies
at all poles (electrical parti-
tion with a contact gap of at
least 3 mm, e.g. fuse or circuit
breaker).
▶Secure against being
switched back on again.
▶Check that there is no
voltage.
1.2.4 Risk of death from
electric shock from live
lines and connections
The potable water that is used
must demonstrate a specific
resistance of ≥900 Ωcm at
15 °C. Otherwise, the product
must not be used.
▶Before installing the unit, ask
your water company to inform
you about the water resist-
ance and conductivity.
1.2.5 Risk of death due
to incorrect electrical
installation
▶The product must be con-
nected to the protective con-
ductor.
▶The product must be perman-
ently connected to fixed wir-
ing.
1.2.6 Risk of scalding caused
by hot water
If a solar thermal energy install-
ation is connected upstream,
hot water temperatures of over
42 °C could be generated even
if the scald protection function is
set.
If a solar thermal energy system
is connected upstream of the
product, the inlet temperature
must be limited by including
precautionary features in the
design (e.g. a mixing valve).
Condition: VED 18 - 24/8
▶Install a mixing valve to limit
the inlet temperature to 55 °C.
Condition: VED 27/8
▶Install a mixing valve to limit
the inlet temperature to 25 °C.

1 Safety
12 Installation instructions electronicVED plus 0020288449_01
1.2.7 Risk of being burned
or scalded by hot
components
▶Only carry out work on these
components once they have
cooled down.
1.2.8 Risk of material damage
caused by using an
unsuitable tool
▶Use the correct tool.
1.3 Regulations (directives,
laws, standards)
▶Observe the national regula-
tions, standards, directives,
ordinances and laws.

Notes on the documentation 2
0020288449_01 electronicVED plus Installation instructions 13
2 Notes on the
documentation
▶Always observe all operating instruc-
tions enclosed with the installation com-
ponents.
▶Store these instructions and all other
applicable documents for further use.
These instructions apply only to:
Product article number
Validity: Hungary
OR Hong Kong
OR Hong Kong
VED E 18/8 P INT 0010023770
VED E 21/8 P INT 0010023771
VED E 24/8 P INT 0010023772
VED E 27/8 P INT 0010023773
3 Product description
3.1 Design
9
8
10
11
12
7
6
5
4
3
2
1
1 Power supply
terminal
2 Top grommet
3 Adjustment
spindle
4 Safety switch
5 Electronics
6 Optional space
underneath for
the power supply
terminal
7 Strainer
8 Cold water con-
nection
9 Bottom grommet
10 Domestic hot
water connection
11 Safety cut-out
12 Heating block
3.2 Function
The product heats up potable water via a
bare wire in the heating block using the
flow-through principle.
The electronics measure the temperature
of the water in the cold water supply and
the water volume flow. The electrical per-
formance that is required to heat the water
to the required domestic hot water temper-
ature is calculated using these two values.
The temperature can be set to any tem-
perature between 20 °C and 55 °C in in-
crements of 0.5 °C. The set temperature is
shown in the display.
The domestic hot water temperature de-
pends on:
–Water inlet temperature
–Water outlet volume
–Performance category of the product
If the set domestic hot water temperature
is not reached, reduce the water volume.
3.3 Information on the data plate
Symbol Meaning
The VDE GS mark
confirms that the unit
complies with stand-
ards and has been
tested for safety.
Symbol confirming
conformity with the
electromagnetic com-
patibility standard
Read all of the in-
structions.
Barcode with serial
number,
The 7th to 16th digits
of the serial number
form the article num-
ber

4 Set-up
14 Installation instructions electronicVED plus 0020288449_01
3.4 CE marking
The CE marking shows that the products
comply with the basic requirements of the
applicable directives as stated on the de-
claration of conformity.
The declaration of conformity can be
viewed at the manufacturer's site.
4 Set-up
4.1 Checking the scope of delivery
Quantity Designation
1 Product
1Operating and installation in-
structions
1
Bag containing fixing material
(2 bolts, 2 wall plugs, 3 seals, 1
special fixing screw)
1 G 1/2" cold water connector
with a cold-water isolation valve
1 G 1/2" domestic hot water con-
nector
2 Double nipple
1 Strainer for the cold water inlet
1 Mounting plate
1 Mounting template
4.2 Selecting an installation
location
▶Install the product as close as possible
to the draw-off points that are used
most frequently.
Note
The product may also be in-
stalled above baths or in a
shower area.
4.3 Installation clearances
C
D
E
A
C
BB
A≥50 mm
B≥50 mm
C≥120 mm
D≥130 mm
E≤22 mm
The bottom section of the product (D) must
be level with the product's bearing area on
the wall;.
4.4 Installing the product on the
wall
4.4.1 Dimensions
1
2
3
4
5
6
481
312
240
100
277
50
12
19
16
100
35 35
1 Top grommet
2 Central attach-
ment
3 G 1/2" domestic
hot water con-
nection
4 G 1/2" cold wa-
ter connection
5 Bottom grommet
6 G 1/2" outside
thread

Set-up 4
0020288449_01 electronicVED plus Installation instructions 15
4.4.2 Removing the product casing
A
C
B
E
X7
D
▶Remove the product casing as shown.
4.4.3 Installing the product
390
277
8585 1
34
12
1 Mounting plate
2 Fixing points
3 Cold water con-
nection
4 Domestic hot
water connection
1. Hold the mounting template against the
wall and mark the fixing points (2).
–Product alignment: Vertically on the
wall
2. Use wall plugs and screws to secure
the mounting plate (1) to the fixing
points.
Danger!
Risk of electric shock caused
by penetrating water
The grommet prevents wa-
ter from penetrating along the
power supply cable and into the
product.
▶Never cut off the grommet
completely.
▶Cut the end of the grommet
in such a way that the sleeve
tightly surrounds the power
supply cable.
3. Fold the grommet up or down depend-
ing on the location of the power supply
cable.
4. Feed the cable through the grommet
and into the product's interior.

5 Installation
16 Installation instructions electronicVED plus 0020288449_01
1
2
3
4
5. Fit the product (2) to the retaining
screw (1) on the mounting plate.
6. Use the adjustment spindle (4) to ad-
just the product.
7. Use the fixing screw (3) to secure the
product.
5 Installation
1. If you are using plastic pipes, only use
those that are approved for normal
operating mode at 65 °C.
2. If you are using plastic pipes, only use
those that maintain a maximum tem-
perature of 95 °C and a maximum
pressure of 1 MPa (10 bar) for at least
one hour (check the manufacturer de-
tails).
3. Flush the cold water pipes thoroughly
before installation.
5.1 Setting up the domestic hot and
cold water connection
1. Note the water connections for the
installation:
–An expansion relief valve on the cold
water pipe is not required.
–All hot and cold water pipes can be
made of steel, copper or plastic.
–The product must be permanently
connected to permanently installed
water pipes. It must not be temporar-
ily connected to hose lines.
–You must not connect any water
supply pipes from other water-heat-
ing systems to the product's cold wa-
ter connection.
–You must not directly connect water
taps or similar to the product's do-
mestic hot water connection.
1
2. To simplify installing the water con-
nection, the bottom section of product
frame can be folded up (1).
–Do not remove the folding frame.

Installation 5
0020288449_01 electronicVED plus Installation instructions 17
1
2
3
4
7
6
3
5
Caution.
Risk of damage caused by
leaks.
Mechanical stress on connec-
tion pipes may cause leaks and
damage to the product.
▶Avoid mechanical stress on
connection pipes.
3. Put hemp on the two double nipples
(2) and (6) and use the connections to
screw the double nipples to the wall (1)
and (7).
4. Insert the seals (3) in the union nuts
of the cold water (4) and domestic hot
water connections (5).
5. Screw the cold water connector (4)
to the cold water connection double
nipple (2) in the wall (1).
6. Screw the domestic hot water con-
nector (5) to the domestic hot water
connection double nipple (6) in the
wall (7).
7. Insert a seal into the union nut of the
domestic hot water connection on the
boiler side.
Caution.
Risk of damage due to pipes
being blocked by foreign
bodies in the water.
The product must not be used
without a strainer in the cold
water inlet.
▶When you set up the cold
water connection, install the
supplied filter strainer in the
product's cold water inlet.
8. Screw the unit connections to the do-
mestic hot and cold water connections.
9. Hinge the lower section of the product
frame back until it engages.
5.2 Connecting the product to the
electricity supply
1. Note the specifications on the data
plate when carrying out the electrical
installation.
2. You must comply with the following
requirements:
–The product must be installed using
a permanent connection.
–It must be possible to switch off the
permanent connection at all poles
via an on-site partition (e.g. via a
circuit breaker) that has a contact
gap of at least 3 mm.
–The product must be connected to
the protective conductor.
–When using the lower grommet, the
power supply terminal that was in-
stalled at the top at the factory can
be routed for the electrical connec-
tion in the lower section.

6 Start-up
18 Installation instructions electronicVED plus 0020288449_01
5.2.1 Carrying out the top electrical
connection
L1 L2 L3
2
1
1. Guide the connection cable through the
upper grommet (2).
2. Connect the individual phases to L1,
L2, and L3 on the power supply ter-
minal (1).
3. Connect the PE protective conductor to
.
5.2.2 Carrying out the bottom
electrical connection
L1 L2 L3
3
2
1
1. Guide the connection cable through the
lower grommet (3).
2. Unscrew the power supply terminal (1).
3. Route the power supply terminal, in-
cluding the internal cable, to the lower
position (2) in the product.
4. Screw the power supply terminal tightly
to the lower position.
5. Check whether the cables for the
power supply terminal are routed
correctly.
6. Connect the individual phases to L1,
L2, and L3 on the power supply ter-
minal.
7. Connect the PE protective conductor to
.
5.2.3 Installing an optional load-
shedding relay
If required, a load-shedding relay that con-
forms with current standards can be con-
nected to the product. The role of the re-
lay is to switch off other power consumers
while hot water is being drawn off via the
product so that the house installation is not
overloaded. The load-shedding relay must
fulfil the following criteria:
–Pull-in current < 15 A
–Continuous current > 50 A
▶Install the load-shedding relay in the L2
outer conductor.
▶If the product is a replacement product,
also replace the load-shedding relay.
6 Start-up
6.1 Removing air pockets from the
product
Caution.
Risk of damage from heating
wire dry fire
Air pockets in the pipes may
lead to dry fire on the heating
wires during start-up.
