Thermaltake ARGENT K6 RGB User manual

Low Profile Mechanical Keyboard User Guide
ARGENT K6 RGB
01

TT Premium | Argent K6 RGB Low Profile Mechanical Keyboard User Guide
PAGE 39
PAGE 19
KEYBOARD FEATURES OVERVIEW
TT iTAKE INSTALLATION
FUNCTIONS AVAILABLE ON THE HOME PAGE
KEY CONFIGURATIONS
Default Functions
Single Key Functions
Macros
Multimedia Functions
Hot Keys
Program Execution
Gaming Profiles
Key Disable Functions
FUNCTIONS AVAILABLE ON THE MACRO PAGE
PAGE 05
--------------------------------------- 22
--------------------------------------- 23
--------------------------------------- 25
--------------------------------------- 27
--------------------------------------- 29
--------------------------------------- 31
--------------------------------------- 36
--------------------------------------- 38
02
PAGE 16
PAGE 21
Table of Contents

TT Premium | Argent K6 RGB Low Profile Mechanical Keyboard User Guide
HOW TO RECORD MACROS
Recording a Macro
Recording a Character Set
FUNCTIONS AVAILABLE ON THE LIGHTING EFFECTS PAGE
LIGHTING EFFECTS OVERVIEW
Static
Pulse
Blink
Wave
Spiral Rainbow
RGB Spectrum
Reactive
Flow
Ripple
Raindrop
Snake
Music Mode
System Temperature
Brick
Pervade
PAGE 41
--------------------------------------- 52
--------------------------------------- 56
--------------------------------------- 60
--------------------------------------- 64
--------------------------------------- 68
--------------------------------------- 72
--------------------------------------- 73
--------------------------------------- 77
--------------------------------------- 81
--------------------------------------- 85
--------------------------------------- 87
--------------------------------------- 89
--------------------------------------- 91
--------------------------------------- 92
--------------------------------------- 94
PAGE 49
PAGE 51
--------------------------------------- 42
--------------------------------------- 47
03
Table of Contents

TT Premium | Argent K6 RGB Low Profile Mechanical Keyboard User Guide
FUNCTIONS AVAILABLE ON THE SETTINGS PAGE
04
Table of Contents
PAGE 98

TT Premium | Argent K6 RGB Low Profile Mechanical Keyboard User Guide
Chapter 1: KEYBOARD FEATURES
OVERVIEW
05

Argent K6 RGB Keyboard User Guide
EMAIL
Open the default email box.
Keyboard Features Features Overview
06
RESTORE FACTORY
SETTINGS Press and hold for five seconds to restore factory settings (including all lighting effects and
macros).
※After the settings are restored, a startup animation will run once to indicate that all settings
have been restored.
WEB BROWSER
Open the default web browser/return to the home page.
+
+
+

Argent K6 RGB Keyboard User Guide
MULTIMEDIA PLAYER
Open the system's built-in multimedia player.
+
CALCULATOR
Open the system's built-in calculator.
+
MY COMPUTER
Open my computer.
Keyboard Features Features Overview
07
+

Argent K6 RGB Keyboard User Guide
SWITCHING LIGHTING
EFFECTS
Static:
(1). Fn + F9 (red), F10 (green), and F11 (blue) to change the color of the lighting effect.
Pulse:
(1). Fn + F7 (slower) and F8 (faster) to adjust the speed of the lighting effect.
(2). Fn + F12 to switch between monochrome and random color modes.
(3). Under monochrome mode, Fn + F9 (red), F10 (green), and F11 (blue) can be used to adjust the color of the lighting effect.
Wave:
(1). Fn + F7 (slower) and F8 (faster) to adjust the speed of the lighting effect.
(2). Fn + ↑, ↓, ←, or → to change the direction of running lights.
(3). Fn + F9 (red), F10 (green), and F11 (blue) to change the color of the lighting effect.
Spiral Rainbow:
(1). Fn + F7 (slower) and F8 (faster) to adjust the speed of the lighting effect.
(2). Fn + ← (counterclockwise) or → (clockwise) to switch the direction of running lights.
(3). Fn + F9 (red), F10 (green), and F11 (blue) to change the color of the lighting effect.
RGB Spectrum:
(1). Fn + F7 (slower) and F8 (faster) to adjust the speed of the lighting effect.
Reactive:
(1). Fn + F7 (slower) and F8 (faster) to adjust the speed of the lighting effect.
(2). Fn + F12 to switch between monochrome and random color modes.
(3). Under monochrome mode, Fn + F9 (red), F10 (green), and F11 (blue) can be used to adjust the color of the lighting effect.
Flow:
(1). Fn + F7 (slower) and F8 (faster) to adjust the speed of the lighting effect.
(2). Fn + F12 to switch between monochrome and random color modes.
(3). Under monochrome mode, Fn + F9 (red), F10 (green), and F11 (blue) can be used to adjust the color of the lighting effect.
Ripple:
(1). Fn + F7 (slower) and F8 (faster) to adjust the speed of the lighting effect.
(2). Fn + F12 to switch between monochrome and random color modes.
(3). Under monochrome mode, Fn + F9 (red), F10 (green), and F11 (blue) can be used to adjust the color of the lighting effect.
Raindrop:
(1). Fn + F7 (slower) and F8 (faster) to adjust the speed of the lighting effect.
(2). Fn + F12 to switch between monochrome and random color modes.
(3). Under monochrome mode, Fn + F9 (red), F10 (green), and F11 (blue) can be used to adjust the color of the lighting effect.
Bricks:
(1). Fn + F7 (slower) and F8 (faster) to adjust the speed of the lighting effect.
(2). Fn + ↑ or ↓ to change the direction of running lights.
(3). Fn + F12 to switch between monochrome and random color modes.
(4). Under monochrome mode, Fn + F9 (red), F10 (green), and F11 (blue) can be used to adjust the color of the lighting effect.
Concentric Circles:
(1). Fn + F7 (slower) and F8 (faster) to adjust the speed of the lighting effect.
(2). Fn + F12 to switch between monochrome and color modes.
(3). Under monochrome mode, Fn + F9 (red), F10 (green), and F11 (blue) can be used to adjust the color of the lighting effect.
Keyboard Features Features Overview
08
+

Argent K6 RGB Keyboard User Guide
DECREASING THE SPEED
OF LIGHTING EFFECTS
Five different lighting effect speeds (the will flash when the speed is set to the
slowest setting).
ADJUST THE BRIGHTNESS
OF THE RED LIGHT Ten brightness level settings for the red light (the will flash when the brightness is
set to the brightest setting).
※Press and hold for three seconds to clear the red value (once cleared, the will flash
at the same time).
INCREASING THE SPEED
OF LIGHTING EFFECTS
Five different lighting effect speeds (the will flash when the speed is set to the
fastest setting).
Keyboard Features Features Overview
09
+
+
+

Argent K6 RGB Keyboard User Guide
SWITCHING COLOR
MODES Can be used to switch between monochrome and random color modes for a specific lighting
effect.
※Under monochrome mode, this key serves as the mixed-color indicator.
+
ADJUST THE BRIGHTNESS
OF THE BLUE LIGHT Ten brightness level settings for the blue light (the will flash when the brightness is
set to the brightest setting).
※Press and hold for three seconds to clear the blue value (once cleared, the will
flash at the same time).
ADJUST THE BRIGHTNESS
OF THE GREEN LIGHT Ten brightness level settings for the green light (the will flash when the brightness
is
set to the brightest setting).
※Press and hold for three seconds to clear the green value (once cleared, the will
flash at the same time).
Keyboard Features Features Overview
10
+
+

Argent K6 RGB Keyboard User Guide
SWITCHING PROFILES Up to six profiles can be saved. The current active profile is shown by the
color displayed on the .
P1: Red, P2:Green, P3:Blue, P4:Yellow, P5:Purple, P6:Aquamarine.
※The color statuses described above are only visible under Game Mode.
Keyboard Features Features Overview
11
CHANGING THE DIRECTION
OF LIGHTING EFFECTS
You can switch the running direction of a specific lighting effect.
+
+

Argent K6 RGB Keyboard User Guide
ON-THE-FLY MACRO
RECORDING Macro Recording (only available under Game Mode):
(1). Press Fn + PrtSc to enter recording mode (the entire keyboard will light up and the Record button will
begin to flash).
(2). Press Fn + Any Key (excluding the recording key)
to specify a key to save the macro under (a red light will
appear after a slight delay; if you press Fn + the same key, a blue light will appear without a delay).
Once the
key selection is completed, all lights on the keyboard will go out, and the recording key will change from
flashing to constantly lit.
(3). Enter the sequence to be recorded (keys recorded will flash in white).
(4). After the sequence is entered, press Fn + PrtSc to exit recording mode (the light for the Recording key
will go off).
Macro Prompt Function:
While in recording mode, if the key's backlight is solid white, that means there is currently no macro
assigned to this key. If the key is solid green, that means a macro has been assigned to this key.
Shown in the following figure: the "A" key has a macro assigned to it.
※Press and hold a key which has been assigned a macro for more than 3 seconds to erase the saved macro.
Keyboard Features Features Overview
12
+

Argent K6 RGB Keyboard User Guide
RECORDING AREA
BACKLIGHT
Recording procedure (recording can only be activated while in area backlight mode):
(1). Press Fn + ScLk to enter area backlight mode.
(2). Press Fn + Pause to enter backlight recording mode (the recording button will flash).
(3). Press Fn + F9 (Red), F10 (Green), and F11 (Blue) to produce a desired color by mixing the
three colors together (F12 will display the blended color).
(4). Press the key in each display area in order.
(5). Once completed, press Fn + Pause to exit recording mode (the recording button will stop
flashing).
※Press and hold for five seconds to restore the area's preset light position and color value
( indicator lights will flash at the same time to indicate that the settings have been
restored).
AREA BACKLIGHT
Supports up to five presets: FPS1、FPS2、MMO、MOBA、RTS。
Keyboard Features Features Overview
13
+
+

Argent K6 RGB Keyboard User Guide
SWITCHING WASD AND
THE DIRECTION KEYS
Switches the functions of WASD keys with the arrow keys.
FULL KEYBOARD LOCK
Lock the entire keyboard ( indicator lights will flash at the same time to indicate the
current status).
Keyboard Features Features Overview
14
GAME MODE When this key is lit up in white, this means it is in non-game mode. Once game mode is
activated, the indicator color will light up in the color specified in the setup profile.
※While not operating under game mode, all keys will function according to their preset values.
+
+

Argent K6 RGB Keyboard User Guide
MULTI-FUNCTION WHEEL Fn + Wheel Side Button (Mute) : Switches multi-function ( indicator lights will flash
at the same time to indicate the current status).
Multi-Function:
Scroll Up / Down : Mouse wheel up / down
Press mute button : Previous page
Press mute button twice : Next page
LOCKING THE WINDOWS
KEY The windows key can be replaced with the function of the ctrl key.
※Before the key is locked, a white-colored light will turn on. After the key is locked, an
aquamarine-colored light will turn on.
Keyboard Features Features Overview
15
FULL BRIGHTNESS
ADJUSTMENT
A total of five brightness levels are available for adjusting the brightness of the keyboard's
lighting effects.
+

TT Premium | Argent K6 RGB Low Profile Mechanical Keyboard User Guide
Chapter 2: TT iTAKE INSTALLATION
16

Argent K6 RGB Keyboard User Guide
17
Software Installation Setup Instructions
Step 2:Step 1:
Click Install to begin the setup process.Launch the setup executable file (.EXE) file and click Next.

Argent K6 RGB Keyboard User Guide
Software Installation Setup Instructions
18
Step 3:
Click Finish to complete the installation.

TT Premium | Argent K6 RGB Low Profile Mechanical Keyboard User Guide
Chapter 3: FUNCTIONS AVAILABLE ON
THE HOME PAGE
19

Argent K6 RGB Keyboard User Guide
Keyboard Page Key Assignment Setting
Assigning Key Functions
Nine different functions can be assigned.
Other Settings / Shrink Window / Close Window
Other Settings: Software version, Amazon Alexa setting and switching the language
used for the user interface.
Shrink Window: Close the display and minimize the program to the taskbar.
Close Window: Close the display and minimize the program to the lower right corner.
Functions for Managing Profiles
Up to 15 profiles can be added for use. The functions of
each button from left to right are:
Add: Create a new profile.
Delete: Delete an existing profile.
Copy: Copy a profile.
Import: Import a profile.
Export: Export a profile.
Profiles
The Argent K6 RGB can support up to 6 profiles, which
can be switched as required.
Restore Keyboard Settings for All Keys / Apply
Restore Keyboard Settings for All Keys: All key functions saved
under the current profile will be restored to factory default values.
Apply: Save and apply all settings to the selected key.
20
Switching Configuration Pages
Switches between the configuration pages customize
key operation, macro recording, lighting effects and
sync setting.
Correcting the Name of a Profile
The name of a new profile can be modified directly.
Home Page
You can switch the keyboard model.
