Thermawave Gobi User manual

Gobi

Owner’s Manual

Introduction

Specifications

Control Panel / Remote

Unit Diagrams

Setting Up the Unit

Maintaining the Unit

Safety info / Warnings

Warranty Information

Introduction

Welcome to a more comfortable, efcient way of heating your living spaces during cold weather!

GreenTech Environmental heaters are the most complete and advanced space heating systems on the market.

They heat using a cutting-edge PTC (Positive Thermal Coefcient) element that heats the air efciently without

drying it out.

Gobi is designed to provide years of trouble-free service when used and maintained according to this

Owner’s Manual. The pages of this manual will guide you through proper operation, and maintenance.

Thank you for purchasing Gobi by GreenTech Environmental.

Records

Purchase Date: __________________________________________________________________________

Model Number:__________________________________________________________________________

Serial Number: __________________________________________________________________________

Distributor Name: ________________________________________________________________________

Distributor Phone:________________________________________________________________________

Features

Lifetime Guaranteed PTC Heating Element

On Unit Control Panel

Simple Full Featured Remote

High/Auto/Quiet Modes

Overheat Safety Shut Off

Tip-Over Safety Shut Off

Benets

Clean, Economical, and Safe Heating

Even Distribution of Heat from Floor to Ceiling

No Burnt and Dry Air Effect

Low Operating & Maintenance Cost

Simple Operation and Maintenance

CAUTION: Attempting to service the unit beyond

cleaning the lter creates danger of electric

shock.

WARNING: Keep the unit away from fabric or

other ammable material. Give the unit 3 ft of

space to the front and at least 1 ft of space to

the sides and rear.

WARNING: Do not cover the Hot Air Outlet

Specications

Voltage: .....................................................................120V ~60Hz

Power: ...................................................................up to 1500 watts

Heat Output: ....................................................................5000BTU

Remote Battery: .................................................................. CR2025

Temperature Control Range: .........................................60 - 85 Degrees Fahrenheit

Heating Element: ............................. Infrared Positive Thermal Coefcient (PTC) Element

Air Filter: ...............................................................Lifetime Washable

Coverage: ...................................................................Up to 1000 ft2

Dimensions: ............................................. 13.00” x 16.00” x 16.75” (W x D x H)

Weight: ...........................................................................22 lbs

Certications: ............................................... ETL Canada & US by Intertek

Warranty: ........................................................... 3 Year Factory Limited

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Lifetime Warranty on PTC Triple Heating Element

Warnings

CAUTION: Disconnect the power cord before

cleaning the lter.

Temperature

Gauge

Remote Control

Control Panel

Unit Front Diagram

Control

Panel

Temperature

Sensor

Power

Toggle

Hot Air

Outlet

Filter

Assembly

Power

Cord

Unit Rear Diagram

Setting Up the Unit

1. Unpack the unit by cutting open taped areas at top of the box. Fold back box aps and gently turn entire box

upside down. Lift box off of styrofoam packed contents. Remove styrofoam, turn upright. We recommend

keeping packing materials for future transport or storage of unit.

2. Find a level and unobstructed location to place heater away from cold walls (outside walls).

3. Plug the POWER CORD into a grounded outlet (120V, 15A or higher).

4. Activate the REMOTE by removing the plastic shipping guard from the battery compartment.

Operating The Unit

Turning the Unit On/Off

• Turn the unit on by pressing the “I” on the POWER TOGGLE (Unit Rear).

• Turn the unit off by pressing the “O” on the POWER TOGGLE (Unit Rear).

• Always unplug the unit when not in use.

Controlling the Heater

Press the POWER CONTROL button to activate the Heater. Set the desired heat level using the

TEMPERATURE CONTROL buttons. The selected heat level is indicated by the lights of the

TEMPERATURE GAUGE.

Selecting a Mode

Select a mode by pressing the MODE CONTROL button until the desired mode is indicated by the MODE

INDICATOR LIGHTS.

• HIGH MODE: To quickly heat an environment, select HIGH MODE using the MODE CONTROL button.

• AUTO MODE: The unit begins in AUTO MODE and heats the room as efciently as possible

with the set temperature.

• QUIET MODE: If you feel the unit is too loud for your environment, such as when you are sleeping, press

the MODE CONTROL button until it cycles to QUIET MODE. The unit continues to heat according to the

selected heat leavel, but the fan runs on the most silent speed.

Maintaining The Unit

Cleaning the Filter

The lter should be cleaned every 30 days or more often if you nd that the lter is collecting visible particulate.

1. Unplug the POWER CORD from the outlet.

2. Remove the FILTER ASSEMBLY SCREW using a screwdriver. Place the screw aside where you will not

misplace it.

3. Allow the FILTER ASSEMBLY to lean away from the rear of the unit until it is free to be removed.

4. Remove the FILTER from the FILTER ASSEMBLY by using a at blade screwdriver to release the four

tabs of the FILTER COVER and then carefully lifting the FILTER from the FILTER ASSEMBLY.

5. Use a vacuum cleaner to remove built up particulate from the FILTER. Optionally, you can also clean

the FILTER using warm soapy water. If you opt to using water, ensure that the FILTER dries completely

before continuing.

6. Carefully replace the FILTER in the FILTER ASSEMBLY. Replace the FILTER COVER onto FILTER

ASSEMBLY and ensure all 4 tabs are in place.

7. Set the tabs of the FILTER ASSEMBLY in their place on the rear of the unit and pivot upwards until it is

properly seated.

8. Replace the FILTER ASSEMBLY SCREW using a screwdriver. Tighten until snug.

9. Plug the POWER CORD back into the outlet..

Cleaning the Unit

1. Unplug the POWER CORD from the outlet.

2. Carefully wipe the exterior of the unit with a soft, damp (not wet) cloth and dry thoroughly with a soft, dry

cloth. Do not use harsh or abrasive cleaners as these may damage the aesthetic nish of the unit.

3. Remove particulate that may have gathered in the HOT AIR OUTLET using a vacuum with a brush

attachment.

Safety Info & Warnings

1. Do not operate the heater if any cord or part of the machine is damaged or has malfunctioned.

Return heater for examination and repair if damage has occured.

2. Do not plug heater into anything other than a 3-prong 110V 15amp or higher grounded circuit receptacle.

3. Do not use an extension cord to power this heater.

4. Do not block the front grill or rear lter of the heater. Be sure that there is adequate space around the heater

for air ow.

5. Keep heater away from areas which may have standing water. The heater is not made for use in bathrooms,

laundry areas or areas with similar attributes.

6. Do not insert any foreign objects into the vent as this may cause an electric shock or damage the heater itself.

7. Do not change the heater’s wiring or design as it will void the warranty and could cause injury.

8. Always unplug heater when not in use.

9. Turn heater off before removing plug from outlet.

10. Do not place cord under any kind of covering such as carpet, rugs or similar articles. Place cord away from

high trafc areas to keep from injuring a person or causing damage to the cord or heater.

11. Heater is intended for indoor use only, do not use outdoors.

12. The lter must be cleaned regularly to avoid clogging and possible malfunction of the heater. If the heater

is used in high-trafc areas the lter must be cleaned more often.

13. Air dry the lter, do not use any other method to expedite the process as it could damage the lter.

Consumer Information

GreenTech Environmental declines responsibility for all damages arising from improper use of the unit or in case of

tampering with the unit.

Warranty Information

LIMITED WARRANTY INFORMATION

Your Gobi (Product) is warranted to be free from all defects in material and workmanship in normal household use for a period of (3) Years from date of purchase. e

warranty is granted only to the original purchaser. e warranty is subject to the following provisions:

Any damages or malfunctions caused by negligence, abuse, or use not in accordance with the Product Owner’s Manual are not covered by this warranty. Likewise, any

defects or damages caused by unauthorized service or the use of other than Genuine GreenTech Environmental Parts are not covered.

GreenTech Environmental, LLC will, at its option, repair or replace a defective Product or part(s) for the Product that is/are covered by this warranty. As a matter of

warranty policy, GreenTech Environmental, LLC will not refund the customer’s purchase price.

LIMITED LIFETIME WARRANTY ON TRIPLE HEATING ELEMENT

e heating element in the Product is warranted for the lifetime of the original purchaser. If the heating element fails aer the standard warranty terms have expired, the

purchaser should return the unit to a GreenTech Environmental Service Center for repair or replacement.

OBTAINING WARRANTY SERVICE

To obtain warranty service you must return the defective product along with proof of purchase to the GreenTech Environmental Authorized Service Center. All shipping

costs submitted under this Warranty shall be borne by purchaser. Unless this Warranty is expressly renewed or extended by GreenTech Environmental, LLC, any repaired

or replaced part of unit shall be warranted to the original purchaser only for the length of the unexpired portion of the original warranty. For the location of the nearest

GreenTech Environmental Authorized Service Center or for other service information, please visit us online at: www.GreenTechEnv.com/service

Before any product is sent for service, the customer should contact the GreenTech Environmental Service Center to obtain a Return Merchandise Authorization (RMA)

Number. is RMA Number should be clearly written on the box before shipping. All components/parts including the remote (if applicable), manuals, and original

packaging should be included in the return if available.

FURTHER LIMITATIONS AND EXCLUSIONS ARE AS FOLLOWS

Any warranty that may be implied in connection with your purchase or use of the Product, including any warranty of merchantability or any warranty for Fitness For A

Particular Purpose is limited to the duration of this warranty. Some states do not allow limitations on how long an implied warranty lasts, so the above limitations may

not apply to you.

Your relief for the breach of this warranty is limited to the relief expressly provided above. In no event shall GreenTech Environmental, LLC be liable for any consequential

or incidental damages you may incur in connection with your purchase or use of the Product. Some states do not allow the exclusion or limitation of incidental or

consequential damages, so the above limitation or exclusion may not apply to you.

is Warranty gives you specic legal rights, and you may also have other rights which vary from state to state.

REGISTRATION

Please register your Product within 10 days of purchase by visiting www.GreenTechEnv.com/warranty or ll out and return the enclosed warranty registration card.
