Thermo King SLXi-100 User manual

SLXi-100, 200, 300, 400, SLXi-300 Whisper Pro,
SLXi Spectrum, and SLXi Spectrum Whisper Pro
TK 61452-ML-2-OP (Rev. 0, 01-17)

2
LANGUAGES
English. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Svenska. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Dansk. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Português . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

SLXi-100, 200, 300, 400, SLXi-300 Whisper Pro, SLXi Spectrum,
and SLXi Spectrum Whisper Pro
TK 61452-2-OP (Rev. 0, 01-17)
En

4
TABLE OF CONTENTS
TABLE OF CONTENTS
Table of Contents............................................... 4
Introduction........................................................ 5
General Information ..................................... 5
General Inquires and Unit Maintenance ...... 5
First Aid and Safety........................................... 7
Refrigerant ................................................... 7
Refrigerant Oil ............................................. 7
Refrigerant Information ............................... 7
Safety Precautions ........................................ 8
Auto Start/Stop Operation ............................ 8
Electrical Hazard .......................................... 8
Unit Description................................................. 9
General Information ..................................... 9
Thermo King Smart REEFER 3 (SR-3)
Controller ..................................................... 10
Telematic’s as Standard ............................... 10
CYCLE-SENTRY Start/Stop Controls ........ 12
Defrost .......................................................... 12
Modulation ................................................... 12
Pharma ......................................................... 13
Care and Maintenance........................................14
Pre-Trip Inspection .......................................14
Loading .........................................................15
Inspection and Service Schedules .................16
Warranty.............................................................18
Specifications......................................................20
Engine TK 486V............................................20
Electrical Control System .............................21
Electric Motor (Model 50)............................. 21
Standby Power Requirements .......................22
TK Bluebox ...................................................22
Safety Decals and Serial Numbers .....................23
Safety Decals ................................................23
Serial Number Decals ...................................24
DECLARATION................................................91

5
INTRODUCTION
INTRODUCTION
GENERAL INFORMATION
This manual is published for informational
purposes only and the information being
furnished herein should not be considered as
all-inclusive or meant to cover all
contingencies. If further information is
required, consult your Thermo King Service
Directory for the location and telephone
number of the local dealer.
All service requirements, major and minor,
should be handled by a Thermo King dealer.
Performing pre-trip checks and enroute
inspections on a regular basis will minimize
on-the-road operating problems. A closely
followed maintenance program will also help
keep your unit in top operating condition (see
the “Maintenance Inspection Schedule” in this
manual).
GENERAL INQUIRES AND UNIT
MAINTENANCE
For general inquiries please contact your local
Thermo King dealer.
Go to www.europe.thermoking.com and select
dealer locator for your local Thermo King
dealer.
Or refer to the Thermo King Service Directory
for contact information.
EMERGENCY ASSISTANCE
Thermo Assistance is a multi-lingual
communication tool designed to put you in
direct contact with an authorized Thermo King
dealer.
Thermo Assistance should only be
contacted for breakdown and repair
assistance.
To use this system, you need the following
information before you call: (phone charges
will apply)
• Contact Phone Number
• Type of TK Unit
• Thermostat Setting
• Present Load Temperature
• Probable Cause of Fault
• Warranty Details of the Unit
• Payment Details for the Repair
Leave your name and contact number and a
Thermo Assistance Operator will call you back.
At this point you can give details of the service
required and the repair will be organized.
Please note that Thermo Assistance cannot
guarantee payments and the service is designed
for the exclusive use of refrigerated
transporters with products manufactured by
Thermo King Corporation.
BEA261

6
INTRODUCTION
DISCLAIMER
The manufacturer, Thermo King Corporation,
assumes no responsibility for any act or action
taken on the part of the owner or operator in
the repair or operation of the products covered
by this manual that are contrary to the
manufacturer’s printed instructions. No
warranties expressed or implied, including
warranties arising from cause of dealing or
usage or trade, are made regarding the
information, recommendations, and
description contained herein. The
manufacturer is not responsible and will not
be held liable in contract or in tort (including
negligence) for any special, indirect or
consequential damages, including injury or
damage caused to vehicles, contents or
persons, by reason of the installation of any
Thermo King product, its mechanical failure
or the failure of owner/operator to heed
caution and safety decals strategically located
on the product.
MACHINE INFORMATION POLICY
Use of this product serves as acceptance of the
Thermo King Machine Information Policy
available at: www.europe.thermoking.com.
This product includes a standard feature that
collects and shares Machine Information with
Thermo King. Separate terms may apply
when a customer has entered into an
agreement with Thermo King. Customers that
would like to opt-out of sharing Machine
Information with Thermo King should
forward such inquiries to the email address
[email protected].
SOFTWARE LICENCE
The product includes software that is licensed
under a non-exclusive, non-sub-licensable,
terminable and limited license to use the
software as installed on the product for its
intended purpose. Any removal,
reproduction, reverse engineering, or other
unauthorized use of the software is strictly
prohibited. Hacking the product or installing
unapproved software may void the warranty.
The owner or operator shall not reverse
engineer, decompile, or disassemble the
software, except and only to the extent that
such activity is expressly permitted by
applicable law notwithstanding this
limitation. The product may include third
party software separately licensed as specified
in any documentation accompanying the
product or in an about screen on a mobile
application or website that interfaces with the
product.

7
FIRST AID AND SAFETY
FIRST AID AND SAFETY
REFRIGERANT
EYES
Immediately flush eyes with large amounts of
water and get prompt medical attention.
SKIN
Take off contaminated clothing. Flush area with
large amounts of warm water. Do not apply
heat. Wrap burns with dry, sterile, bulky
dressing to protect from infection/injury and
get medical attention.
INHALATION
Move victim to a fresh air location and restore
breathing if necessary. Stay with them until the
arrival of emergency medical personnel.
REFRIGERANT OIL
EYES
Immediately flush eyes with large amounts of
water for at least 15 minutes while holding the
eyelids open. Get prompt medical attention.
SKIN
Remove any contaminated clothing. Wash
thoroughly with soap and water. Get medical
attention if irritation persists.
INHALATION
Move victim to a fresh air location and restore
breathing if necessary. Stay with them until
arrival of emergency personnel.
INGESTION
Do not induce vomiting. Contact local poison
control centre or physician immediately.
REFRIGERANT INFORMATION
Always observe caution when working with
refrigerants and in areas where they are being
used.
Fluorocarbon refrigerants evaporate rapidly,
freezing anything that they come in contact
with if accidentally released to the atmosphere
from their liquid state.
Refrigerants may produce toxic gases which, in
the presence of an open flame or electrical
short, can become severe respiratory irritants
which can be fatal.
Refrigerants displace air and can cause oxygen
depletion which could result in death by
suffocation. Observe caution at all times when
working with or around refrigerant, or air
conditioning systems which contain refrigerant,
especially in enclosed or confined areas.
RECOVER REFRIGERANT
At Thermo King we recognize the need to
preserve the environment and limit the
potential harm to the ozone layer that can
result from allowing refrigerant to escape into
the atmosphere. We strictly adhere to a policy
that promotes the recovery and limits the loss
of refrigerant into the atmosphere.

8
FIRST AID AND SAFETY
SAFETY PRECAUTIONS
Thermo King recommends all services be
performed by a Thermo King dealer. However,
there are several general safety practices which
you should be aware of:
1. Always wear safety glasses when working
with or around the refrigeration system or
battery.
Refrigerant or battery acid can cause
permanent damage if it comes in contact
with your eyes.
2. Never operate the unit with the compressor
discharge valve closed.
3. Always keep your hands and loose clothing
clear of fans and belts when unit is running
or when opening or closing compressor
service valves.
4. Always use extreme caution if you ever have
occasion to drill holes in your unit. This
could weaken structural components.
Drilling into electrical wiring or refrigerant
lines could cause a fire.
5. All service work on evaporator or condenser
coils be completed by a certified Thermo
King technician. If you ever do have
occasion to be working around the coils, use
extreme caution as exposed coil fins could
cause painful lacerations.
AUTO START/STOP OPERATION
This unit may start up at any time without prior
warning.
CYCLE-SENTRY
If your unit is equipped for CYCLE-SENTRY
operation, the unit may start automatically at
any time when the unit is turned on and the
CYCLE-SENTRY is selected.
ELECTRIC STANDBY
On Model 50 units, the unit may start
automatically at any time when the unit is
switched on, connected to live electric power
and/or the Electric operation is selected.
Be sure to switch the unit off before opening
the doors or inspecting any part of the unit.
ELECTRICAL HAZARD
Units with electric operation or electric standby
present a potential electrical hazard. Always
disconnect the high voltage power cable before
working on the unit.
WARNING!
A battery can be dangerous. A battery
contains a flammable gas that can ignite or
explode. A battery stores enough electricity
to burn you if it discharges quickly. A
battery contains battery acid that can burn
you. Always wear goggles or safety glasses
and personal protective equipment when
working with a battery. If you get battery
acid on you, immediately flush it with water
and medical attention.
WARNING!
Electric welding generates high amperage
currents which can damage electrical and
electronic components. To minimize
damage, prior to any welding operation on
the vehicle, the microprocessor and unit
battery must be electrically disconnected
from the vehicle. Switch the Microprocessor
On/Off switch to Off. Remove the negative
battery cable. Remove all connectors from
the rear of the microprocessor. Close the
control box. Connect the welder ground
cable as close as possible to the area being
welded. When welding is completed,
remove the welder ground cable. Reconnect
the cables to the rear of the
microprocessor. Reattach the negative
battery cable. Switch the microprocessor
On/Off switch to On. Reset all alarms and
codes to previous settings. Run a full
Pretrip. A detailed procedure may be found
in Thermo King Service Procedure A26A.

9
UNIT DESCRIPTION
UNIT DESCRIPTION
GENERAL INFORMATION
The Thermo King SLXi models are one piece,
self-contained, diesel powered cooling/ heating
units operating under the control of a Smart
Reefer 3(SR-3) programmable microprocessor
controller. The units mount on the front of the
trailer with the evaporator extending through an
opening in the front wall.
There are models:
• SLXi-100, 200, 300, 400, and 300 Whisper
Pro Model 30's: Cooling and heating on
diesel engine operation.
• SLXi-100, 200, 300, 400 and 300 Whisper
Pro Model 50’s: Cooling and heating on
diesel engine or electric motor operation.
• SLXi Spectrum and Spectrum Whisper Pro
Model 30's: Multiple trailer compartment
cooling and heating on diesel engine
operation.
• SLXi Spectrum and Spectrum Whisper Pro
Model 50's: Multiple trailer compartment
cooling and heating on diesel or electric
motor operation.
During diesel engine operation, the unit will
operate in one of the following modes
depending on the air temperature in the trailer,
as sensed by the microprocessor controller:
Continuous Run Operation
• High Speed Cool
• Low Speed Cool
• Low Speed Modulated Cool (if equipped
with Modulation)
• Low Speed Modulated Heat (if equipped
with Modulation)
• Low Speed Heat
• High Speed Heat
•Defrost
CYCLE-SENTRY Operation (Selectable)
• High Speed Cool
• Low Speed Cool
• Null (Engine Off)
• Low Speed Heat
• High Speed Heat
•Defrost
Generally, the unit will operate in low speed,
switching back and forth from cooling to
heating as necessary.
On very hot days, with the setpoint at a low
temperature, the unit may cycle between high
speed cool and low speed cool without
switching into a heating cycle.
Likewise, on very cold days, the unit may cycle
between high speed heat and low speed heat.
The unit may switch into cooling for short
periods of time.
During Standby electric operation, the Model
50 units operate in one of the following modes
to maintain the trailer temperature:
• Cool
• Motor Off
•Heat
•Defrost

10
UNIT DESCRIPTION
THERMO KING SMART REEFER 3
(SR-3) CONTROLLER
Your SLXi unit uses the SR-3 control system to
operate cooling, heating, and defrost functions.
See below some basic information on operating
the unit.
Note: Please contact your Dealer in order to
refer to our appropriate “Drivers Guide to
Simple Operation” for more details on
operating the standard unit.
Note: Please refer to the “HSLO” operator
manual supplied with your unit for operating
the HSLO module on the SLXi-300 Whisper
Pro and Spectrum Whisper Pro Models.
The microprocessor on/off switch must be
placed in the Off position ("0/OFF" Key)
before:
• Any inspection, maintenance or service
operation is performed on the unit.
• The unit is placed in a location where a
start-up would be undesirable (for example a
confined area).
The ON/OFF Master Isolator Switch supplies
or removes electrical power to the
microprocessor. It is located above engine
inside unit. (See following page for more
details)
STANDARD DISPLAY
The Standard Display shows the box
temperature and setpoint. The top of the display
shows the unit is operating in either
CYCLE-SENTRY or CONTINUOUS RUN
mode.
The Standard Display defaults to the
Temperature Watch Display after about 2-1/2
minutes of non-use. The Temperature Watch
Display shows the same box temperature and
setpoint but in larger fonts.
TELEMATIC’S AS STANDARD
TK BlueBox: Every SLXi comes with TK
BlueBoxcommunication device and
Bluetooth® as standard. You can also
download from your App store the appropriate
App to connect, and manage your unit from
your mobile device. Please contact your
Thermo King Representative, or
www.europe.thermoking.com for more
information.
See TK Bluebox on page 22 for
Specifications.
FURTHER COMMUNICATION
CAPABILITIES
Cable connection: when using a laptop with
Wintrac™ software
USB key: via the USB port provided as
standard, eliminating the need for laptops and
cables.
GPRS connection: viaTracKing™tool which
allows online fleet and temperature
management.
Wireless communication: As end customers
demand increasing temperature traceability,
transporters need a simple and effective means
of accessing critical data.
WARNING!
This unit is capable of automatic operation
and could start at any time.

11
UNIT DESCRIPTION
SLXi Single-temperature SR-3 Controller Display SLXi Spectrum SR-3 Controller Display
1. CargoWatch Download Port
2. ServiceWatch Download Port
(early units) or USB Port (later
units
3. HMI Control Panel
3
BEN179
1
2
3
1. CargoWatch Download Port
2. ServiceWatch Download Port
(early units) or USB Port (later
units
3. HMI Control Panel
SmartReefer3
OFF
ON
THERMO KING
3
1
2MENU
2.
1
2
ZONE 2ZONE 1
TEMP F
SET
POINT
-22.
2
-23
CONTINUOUS

12
UNIT DESCRIPTION
CONTROL KEYS
SWITCHING “ON” THE UNIT
1. On/Off Master Isolator Switch must be ON.
2. Press the I/ON Microprocessor key for 1
second.
3. Unit is switched “on”.
ON/OFF MASTER ISOLATOR SWITCH
On/Off Master Isolator Switch is located above
engine inside the unit. The switch is normally
left in On position.
On/Off Master Isolator Switch
See “Drivers Guide to Simple operation” for
more information about SR-3 controller.
Contact your Dealer for access to this
document.
CYCLE-SENTRY START/STOP
CONTROLS
The CYCLE-SENTRY system automatically
starts up the unit when heating or cooling is
required and shuts it off when the cargo box
temperature reaches the controller setpoint.
The CYCLE-SENTRY system also maintains
engine temperature by restarting the unit if the
engine block temperature drops below -1°C. It
runs until the controller demand is satisfied and
the engine block temperature reaches 32°C.
CYCLE-SENTRY is designed for use only
with products which do not require tight
temperature control or continuous airflow, such
as all deep frozen products and non-perishable
non-frozen products.
The start/stop nature of CYCLE-SENTRY does
not satisfy the temperature control or airflow
requirements for perishable or temperature
sensitive products. Thermo King therefore does
NOT recommend the use of CYCLE-SENTRY
control for these products.
DEFROST
As the unit is operated to cool the trailer, frost
will gradually build up on the evaporator coils.
Periodically this frost must be melted to
prevent loss of cooling and airflow.
MODULATION
Systems equipped with modulation can provide
precise temperature control of fresh products.
This can reduce product dehydration, increase
product shelf life and protect fresh products
from freeze damage.
On Key Turns the unit on.
(hold button 1 second)
Off Key Turns the unit off.
Defrost Key Initiates a Manual
Defrost
Mode Key Switches the unit
between the CYCLE-SENTRY
and Continuous Run modes.
Soft Keys The four soft keys are
multi-purpose keys. Their
function changes depending on
the operation being performed. If
a soft key is active, it’s function
will be shown in the display
directly above the key.

13
UNIT DESCRIPTION
PHARMA
Single temperature units qualified for pharmaceutical applications under
Thermo King protocol are configured with specific Optiset profiles
visible on the HMI display as follow:
• PHARMA AMBIENT: for temperature ranges +15°C to 25°C
• PHARMA CHILLED: for temperature ranges +2°C to 8°C
• PHARMA FROZEN: for temperature below -20°C
In case the operator is not using the Optiset profiles, ThermoKing
recommends to run the unit with the recommended Setpoints below:
For multi-temperatures units qualified for pharmaceutical applications
under ThermoKing protocol, ThermoKing recommends to operate the
unit with:
• PTC parameter ACTIVATED (ON) [with SLXi this set to default on]
• Zone 1 DAC Kit switch turned ON
• with the recommended Setpoints below :
Temperature
Range Recommended Setpoint Max Deviation Setpoint Max Deviation Returned Air
Temperature <
-20°C -20°C +1.5°C of setpoint + 1°C of setpoint
Temperature
between2°Cand
8°C
+4°C +/- 2°C of
setpoint +/- 1.5°C of setpoint
Temperature
between 15°C
and 25°C
+20°C +/- 2.5°C of
setpoint +/- 2°C of setpoint
Temperature
Range Recommended Setpoint Max Deviation Setpoint Max Deviation Returned Air
Temperature <
-20°C -25°C +2°C of setpoint + 2°C of setpoint
Temperature
between2°Cand
8°C
+6°C +/- 2°C of
setpoint +/- 2°C of setpoint
Temperature
between 15°C
and 25°C
+20°C +/- 4°C of
setpoint +/- 4°C of setpoint

14
CARE AND MAINTENANCE
CARE AND MAINTENANCE
PRE-TRIP INSPECTION
Pre-trip inspections are essential to minimize
operating problems and breakdowns, and must
be performed before every trip involving
refrigerated cargo.
1. Diesel Fuel
Must be sufficient diesel fuel to guarantee
engine operation to the next check point.
2. Engine Oil
Should be at the FULL mark. Never overfill.
3. Coolant
The indicator should be in the FULL (white)
range. If the coolant level is in the ADD (red)
range, add coolant to the expansion tank.
Coolant should be a 50/50 mixture of ethylene
glycol and water to provide protection to
-34°C.
Note: Please refer “Specifications” Chapter
later in this manual, where it is clearly states
which coolant types are allowed to be used
in this unit.
4. Battery
The terminals must be tight and free of all
corrosion. Electrolyte should be at full mark.
Note: To ensure battery remains in optimum
condition during periods when the unit is not
being used, run unit for at least 10-15
minutes once every 2 weeks.
5. Belts
The belts must be in good condition.
Tensioning is automatic. Do not attempt to
adjust.
6. Electrical
Ensure all electrical connections are securely
fastened. Wires and terminals should be free of
corrosion, cracks or moisture.
7. Structural
Visually inspect the unit for leaks, loose or
broken parts and other damage.
8. Gasket
The unit mounting gasket should be tightly
compressed and in good condition.
9. Coils
Ensure condenser and evaporator coils are
clean and free of debris.
• Washing with clean water should be
sufficient.
• The use of cleaning agents or detergents is
strongly discouraged due to the possibility of
degradation of the construction.
• If using a power washer, the nozzle pressure
should not exceed 600 psi (41 bar). For the
best results, spray the coil perpendicular to
the face of the coil. The spray nozzle should
be kept between 1 inch and 3 inches (25 to
75 millimetres) from the coil surface.
• If necessary to use a chemical cleaner or
detergent use a cleaner that does not contain
any hydrofluoric acids and is between 7 and
8 on the pH scale. Ensure dilution
instructions provided by the detergent
supplier are followed. In case of doubt about
the compatibility of the detergent with the
type of materials listed above, always ask the
supplier a written confirmation of the
compatibility.
• Should a chemical cleaner be required, it is
MANDATORY that all components are
thoroughly rinsed with water even if the
instructions of the cleaner specify that it is a
“no rinse” cleaner.
Warning: Failure to comply with above
mentioned guidelines will lead to a
shortened life of the equipment to an
indeterminable degree and also may void
your warranty.
Note: The repeated transportation of meat
and fish waste can cause extensive
corrosion to the evaporator coils and
evaporator section tubing over time due to
ammonia formation and can reduce the
lifespan of the coils. Appropriate additional
measures should be taken to protect the
CAUTION!
Do not remove the expansion tank cap
while the coolant is hot.

15
CARE AND MAINTENANCE
coils against the aggressive corrosion that
can result from transportation of such
products.
10. Cargo Box
Inspect the interior and exterior of the trailer for
damage. Any damage to the walls or insulation
must be repaired.
Note: On trailers equipped with units
qualified for pharmaceutical applications -
under ThermoKing protocol inspect the
integrity of the air chute.
11. Damper Door
The damper door in the evaporator air outlet
must move freely with no sticking or binding.
12. Defrost Drains
Check the defrost drain hoses and fittings to
ensure they are open.
13. Trailer Doors
Ensure doors and weather seals are in good
condition, doors latch securely and weather
seals fit tightly.
14. Remote Evaporators (SLXi Spectrum
and SLXi Spectrum Whisper Pro)
• Visually inspect Evaporator(s) for damaged,
loose, or broken parts.
• Check also for refrigerant leaks.
• Check Defrost initiation and termination
(including defrost timer) by activating/
initiating a manual defrost.
15. HSLO Module
(SLXi-300 Whisper Pro and SLXi Spectrum
Whisper Pro Units Only)
• Check that the module is turned on and
communicating.
• It’s a good idea to check at some stage
throughout your journey if the SR-3 unit
automatically switches to “High Speed Lock
Out” in an area designated for this - i.e. PIEK
assigned Zone.
LOADING
GENERAL INFORMATION
1. Inspect the trailer for proper insulation.
2. Ensure all door seals are tightly sealed with
no air leakage.
3. Inspect the trailer inside and out for damaged
or loose doors or skin.
4. On the inside, look for damaged walls or
floor, air ducts and clogged defrost drain
tubes.
5. Pre-cool the trailer as to desired setpoint.
6. Ensure loads are at correct carrying
temperature when you pick them up. Note
any variance.
7. Supervise loading of the product to assure
sufficient air space around and through the
load so as not to restrict air flow.
INSPECTING THE LOAD
Always inspect load prior to departure.
1. Ensure unit is off before opening the trailer
doors. Otherwise refrigerated air is expelled
hot air drawn in. The unit may be run with
the doors open if the trailer is properly
backed into a refrigerated warehouse.
2. Perform final external and internal load
temperature checks. Note any irregularities
on the manifest.
3. Ensure cargo is not blocking the evaporator
inlets and outlets and that ample circulation
space has been provided around the load.
4. Ensure trailer doors are securely locked.
5. Ensure controller setpoint is at the desired
temperature.
6. If the unit was stopped, restart using the
starting procedures outlined in this manual.
7. Repeat the After Start Inspection.
8. Defrost the unit one half-hour after loading
by selecting the Manual Defrost. The Defrost
cycle terminates automatically.

16
CARE AND MAINTENANCE
ENROUTE INSPECTIONS
1. Carry out an inspection every four hours of operation.
2. Note controller setpoint to ensure setting is unaltered since picking up
the load.
3. Note the return air temperature, it should be +/- 4°C of the controller
setpoint.
If the temperature reading is not +/- 4°C of the controller setpoint,
keep the unit running for 15 minutes and re-check the temperature.
Wait 15 minutes more and if the temperature is still out of range,
contact a Thermo King dealer for service.
4. We recommend you record the return air temperature reading each
time you check the unit. This is important information if you need
service later on.
5. Notes:
If cargo temperature is too high it could indicate:
• Evaporator is plugged with frost in which case standard defrosting
procedure is needed or there is improper air circulation within the
cargo area.
Inspect the unit to determine if the evaporator fan is working and
circulating the usual amount of air. Poor circulation could be caused
by:
– Fan belt slipping or damaged. (Have the fan belt checked by a
qualified mechanic.)
– Defrost damper Door damaged and stuck in closed position.
– Improper loading of product in trailer or load shifting in transit so
that there are restricted air passages around and through the load.
– Unit may have a low refrigerant charge. If you cannot see a liquid
level in receiver tank sight glass with the unit running in COOL, it is
an indication that the charge may be low.
It is advisable that any of the above mentioned problems found during
your enroute inspection be referred to the nearest authorized Thermo
King dealer as quickly as possible. Check your service directory for
phone number and location.
INSPECTION AND SERVICE SCHEDULES
To ensure that your Thermo King unit operates reliably and economically
over its full life, and to avoid limiting its warranty cover, the appropriate
inspection and service schedule must be followed.
WEEKLY CHECKS
In order to keep your unit in good working order - the following checks
must be carried out by the operator on a weekly basis:
1. Check fuel supply.
2. Coolant/engine oil level - Check and adjust if necessary.
3. Perform automatic Pre-Trip.
4. Listen for unusual noises, vibrations etc.
5. Visually inspect belt
6. Visually inspect unit for fluid leaks (fuel, coolant, oil and refrigerant).
7. Visually inspect unit for damaged, loose or broken parts (includes air
ducts and bulkheads if so equipped).
Note: For further best practices, please go to
www.europe.thermoking.com/best-practices

17
CARE AND MAINTENANCE
INSPECTION AND SERVICE INTERVALS
Inspection and Service intervals are determined by the number of unit
operating hours and by the age of the unit. Examples are shown in the
table below. Your Dealer will prepare a schedule to suit your specific
needs.
SERVICE RECORD
Each inspection and service performed should be recorded on the Service
Record Sheet found at the back of this Manual.
Interim Inspection Complete PM Full Service
A Service B Service C Service
Every 1000 hours or
every 12 months
(whichever comes first)
Every 3000 hours or
every 24 months
(whichever comes first)
Every 6000 hours or
every 48 months
(whichever comes first)

18
WARRANTY
WARRANTY
Your Complete Thermo King SLXi unit is covered by Warranty for 24 months from the Date in Service, to the conditions stated below.
Should you require warranty service during the warranty period, simply present your copy of the Service Record Sheet (found at the back of this
Manual) to any of the dealer locations shown in the Thermo King Service Directory. They will be happy to help you in accordance with the conditions
stated below.
THERMO KING IRELAND LTD. 24 MONTH* LIMITED WARRANTY : SLXi
1. Subject to the conditions hereinafter stated, Thermo King Ireland Limited (“Thermo King”) warrants its complete unit to be free from defects in
material and workmanship for a period of twenty four (24) months from the date in service or thirty (30) months from the date the unit is shipped by
Thermo King, whichever is earlier.
– Clutch and Drive Coupling are covered for a maximum of 24 months or 6000 diesel run hours, whichever is sooner.
– Poly-V drive belts are covered for a maximum of 24 months or 6000 diesel & electric run hours, whichever is sooner.
2. Such warranty extends only to the original owner of the unit and is limited at Thermo King’s discretion to repair or replace with new or
re-manufactured parts at any authorised Thermo King service location of any parts which are found by Thermo King to have been defective under
normal use and service within the specified warranty period. Repair or replacement shall be buyers exclusive remedy, and correction of defects in
the above manner shall constitute complete fulfilment of all obligations and liabilities of Thermo King with respect to the unit sold hereunder,
whether based in contract, in tort (including negligence and/or strict liability), or otherwise.
3. Any part of a unit which is repaired or furnished as a replacement under Thermo King’s Warranty will be installed without charge to buyer for labour
or parts. Any part which is replaced shall become the property of Thermo King. Such warranty services must be performed by an authorised Thermo
King service location and will not include call-out charges, overtime, mileage, telephone calls (or other correspondence), or cost of transportation
and/or relocation of equipment or service personnel.
4. Thermo King’s warranty does not cover any installation, adjustments, loose parts or damage. Thermo King’s warranty also does not include
consumable or maintenance items, such as, but not limited to, engine oil, lubricants, fuses, filters and filter elements, glow plugs, cleaning materials,
light bulbs, refrigerant gases, dryers and non-Thermo King supplied batteries
5. In order for the warranty to apply to the mechanical and electrical portions of a refrigeration system using remote evaporators, the unit
interconnecting pipe work and wiring must be installed by an authorised Thermo King Dealer or Service Provider.
6. Thermo King’s warranty shall not apply to any unit which (i) has been so installed, maintained, repaired or altered as, in Thermo King’s judgement,
to affect any integrity, (ii) has been subject to misuse, negligent handling or accident, or (iii) has been operated contrary to Thermo King’s printed
Instructions. Thermo King or any authorised Thermo Service location shall have the right to require that the buyer provide maintenance records to
show that a unit has been properly maintained.
7. In order for the warranty to apply to the TK Bluebox – DO NOT disconnect TK BlueBox from the TK refrigeration unit.

19
WARRANTY
*THIS WARRANTY IS EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE AND ALL WARRANTIES ARISING FROM THE COURSE OF DEALING OR CUSTOM OR USAGE OF TRADE, EXCEPT OF TITLE AND AGAIINST PATENT
INFRINGEMENT.
LIMITATION OF LIABILITY: THERMO KING SHALL HAVE NO LIABILITY IN CONTRACT OR IN TORT (INCLUDING NEGLIGENCE OR STRICT LIABILITY) OR OTHERWISE, FOR ANY
INJURY OR DAMAGE CAUSED TO VEHICLES, CONTENTS, PRODUCT CARGO OR OTHER PROPERTY OR FOR ANY SPECIAL, INCIDENTAL, INDIRECT OR CONSEQUENTIAL
DAMAGES WHATSOEVER. INCLUDING, BUT NOT LIMITED TO, LOSS OR INTERRUPTION OF BUSINESS, LOST PROFITS AND LOSS OF USE. THE REMEDIES OF THE BUYER
HEREIN ARE EXCLUSIVE AND THE TOTAL CUMULATIVE LIABILITY OF THERMO KING SHALL IN NO EVENT EXCEED THE PURCHASE PRICE OF THE UNIT OR PART ON WHICH
SUCH LIABILITY IS BASED.

20
SPECIFICATIONS
SPECIFICATIONS
ENGINE TK 486V (SLXI-100, SLXI-200, SLXI-300, SLXI-300 WHISPER PRO, SLXI-400, SLXI SPECTRUM, SLXI
SPECTRUM WHISPER PRO)
Model Thermo King TK 486V
Fuel Type Diesel fuel must conform to EN 590
Oil Capacity Crankcase and filter (total): 12.3 litres
Fill to full mark on dipstick
Oil Type1Petroleum Multi-grade Oil: API Type CI-4, ACEA Class E3
Synthetic Multi-grade Oil (after first oil change): API Type CI-4, ACEA Class E3
Oil Viscosity -15 to +50 C: SAE 15W-40
-25 to +40 C: SAE 10W-40
-25 to +30 C: SAE 10W-30
-30 to 0 C: SAE 5W-30
Engine RPM SLXi-100: 1200–1450 RPM
SLXi-200: 1200–1450 RPM
SLXi-300: 1200–1450 RPM
SLXi-300 Whisper Pro : 1250–2000 RPM
SLXi-400: 1200–2000 RPM
SLXi Spectrum, SLXi Spectrum Whisper Pro: 1250–2000 RPM
Engine Oil Pressure 2.1 to 5.5 bar (30 to 80 psi)
Low Oil Pressure Switch Opens 0.55 to 0.83 bar (8 to 12 psi)
Coolant High Temperature Switch 101.7 to 107.2 C or higher (Shutdown)
Engine Coolant Thermostat 82 C
Coolant System Capacity 6.6 litres
Drive Direct to compressor; Belts to fans, 12V alternator and water pump
Drive (Model 50) Clutch and belts from electric motor
Radiator Cap Pressure 0.48 bar (7 psi)
