ThingsMatrix TMX08 User manual

TMX08 IoT Wireless Device
User Manual

1 Product Introduction
This product is used to collect all sensor data from Ice Merchandiser. It can automatically provide
the location, temperature, volume and the current draw of the device, and through LTE-M
communication module the device will send data to the ice merchandiser operation platform.
2 Function
➢Location: The Ice Merchandiser operation company can check the location of the ice
merchandiser to avoid equipment missing.
➢Data Reporting: The IoT wireless device will report the collected data such as temperature,
volume and compressor current draw, then report to the backend platform, so that the
customer can monitor overall status of merchandiser.
➢Power supply alarm: If the input power supply is break, the device will automatically start
its own battery, and send alarm to backend platform to inform the situation of the power
supply is gone.
➢Over-Temp. alarm: When the temperature inside the merchandiser is over spec, alarm will
be sent to the backend platform.

3 Device Installation Guidance:
Device Installation Steps:
1) Connection the Main cable to the Device like below

2) Connection the Power Adaptor to the main cable

3) Connection the Current Draw Sensor to the main cable

4) Connection the ultrasonic/temperature sensor to the main cable

The ultrasonic/temperature sensor cable should go through the drilled hole of the
merchandiser and connect to the sensor which need to be fixed on the inner roof of the
merchandiser.

5) Connection the GPS antenna and Cellular antenna to the device.

6) Fix the bracket to the top of the merchandiser, then fasten the device with cables to the
bracket.
7) Plug the power adaptor to the power socket.
5 Function Test
After the product is installed and connected correctly, from platform side, we can read all related
data so that we can judge the overall status of the equipment is good or not.
LED Descriptions:
Green LED light:
Off: the device power off;
Slow Flash: LTE-M network Acquiring;
Fast Flash: LTE-M network Acquired, Server connecting;
Steady On: Server connected.
Blue LED light:
Off: GPS not configured;
Blue Slow Flash: GPS Malfunction;
Blue Fast Flash: GPS Acquiring;
Blue Steady On: GPS Acquired.
6 Performance
Item
Parameter
Size
120mm*75mm*28mm
Working Voltage
6~18VDC
Current (avg. working)
<125mA@12V
Current (Static)
<45mA@12V
Working Temp.
-20 C°~+75C°

7 Federal Communication Commission Interference Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one of the following
measures:
⚫Reorient or relocate the receiving antenna.
⚫Increase the separation between the equipment and receiver.
⚫Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
⚫Consult the dealer or an experienced radio/TV technician for help.
FCC Caution:
➢Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate this equipment.
➢This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.
Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20cm
between the radiator & your body.
