thomann Fun generation User manual

LED Diamond Dome
LED effect
user manual

Musikhaus Thomann
Thomann GmbH
Hans-Thomann-Straße 1
96138 Burgebrach
Germany
Telephone: [phone]
E-mail: [email protected]
Internet: www.thomann.de
17.01.2017, ID: 383676, 383684, 383686

Table of contents
1 General notes............................................................................................................................................... 5
1.1 Further information........................................................................................................................... 6
1.2 Notational conventions.................................................................................................................... 7
1.3 Symbols and signal words............................................................................................................... 8
2 Safety instructions.................................................................................................................................. 11
3 Features....................................................................................................................................................... 16
4 Installation and starting up................................................................................................................ 17
5 Connections and controls................................................................................................................... 23
6 Operating.................................................................................................................................................... 29
6.1 Operating Modes ‘Preprogrammed Automatic Show’ and ‘Manual’............................ 30
6.2 Operating mode ‘Slave’................................................................................................................. 36
6.3 Operating mode ‘Sound’............................................................................................................... 36
6.4 Operating mode ‘DMX’.................................................................................................................. 37
6.4.1 Functions in 4-channel operation, Diamond Dome RGBW 4-in-1.............................. 37
6.4.2 Functions in 4-channel DMX operation, Diamond Dome RGBWA UV 6-in-1......... 40
Table of contents
LED Diamond Dome
3

6.4.3 Functions in 4-channel DMX operation, Diamond Dome UV....................................... 42
7 Technical specifications....................................................................................................................... 44
8 Plug and connection assignments.................................................................................................. 45
9 Troubleshooting...................................................................................................................................... 46
10 Cleaning....................................................................................................................................................... 48
11 Protecting the environment.............................................................................................................. 49
Table of contents
LED effect
4

1 General notes
This manual contains important instructions for the safe operation of the unit. Read and follow
the safety instructions and all other instructions. Keep the manual for future reference. Make
sure that it is available to all those using the device. If you sell the unit please make sure that
the buyer also receives this manual.
Our products are subject to a process of continuous development. Thus, they are subject to
change.
General notes
LED Diamond Dome
5

1.1 Further information
On our website (www.thomann.de) you will find lots of further information and details on the
following points:
Download This manual is also available as PDF file for you to download.
Keyword search Use the search function in the electronic version to find the topics of
interest for you quickly.
Online guides Our online guides provide detailed information on technical basics
and terms.
Personal consultation For personal consultation please contact our technical hotline.
Service If you have any problems with the device the customer service will
gladly assist you.
General notes
LED effect
6

1.2 Notational conventions
This manual uses the following notational conventions:
The letterings for connectors and controls are marked by square brackets and italics.
Examples: [VOLUME] control, [Mono] button.
Texts and values displayed on the device are marked by quotation marks and italics.
Examples: ‘24ch’, ‘OFF’.
Letterings
Displays
General notes
LED Diamond Dome
7

The individual steps of an instruction are numbered consecutively. The result of a step is
indented and highlighted by an arrow.
Example:
1. Switch on the device.
2. Press [Auto].
ðAutomatic operation is started.
3. Switch off the device.
1.3 Symbols and signal words
In this section you will find an overview of the meaning of symbols and signal words that are
used in this manual.
Instructions
General notes
LED effect
8

Signal word Meaning
DANGER! This combination of symbol and signal word indicates an
immediate dangerous situation that will result in death or
serious injury if it is not avoided.
WARNING! This combination of symbol and signal word indicates a pos‐
sible dangerous situation that can result in death or serious
injury if it is not avoided.
NOTICE! This combination of symbol and signal word indicates a pos‐
sible dangerous situation that can result in material and
environmental damage if it is not avoided.
Warning signs Type of danger
Warning – high-voltage.
Warning – suspended load.
General notes
LED Diamond Dome
9

Warning signs Type of danger
Warning – danger zone.
General notes
LED effect
10

2 Safety instructions
This device is intended to be used as an electronic illumination effect using LED technics. The
device is designed for professional use and is not suitable for use in households. Use the
device only as described in this user manual. Any other use or use under other operating con‐
ditions is considered to be improper and may result in personal injury or property damage. No
liability will be assumed for damages resulting from improper use.
This device may be used only by persons with sufficient physical, sensorial, and intellectual
abilities and having corresponding knowledge and experience. Other persons may use this
device only if they are supervised or instructed by a person who is responsible for their safety.
Intended use
Safety instructions
LED Diamond Dome
11

DANGER!
Danger for children
Ensure that plastic bags, packaging, etc. are disposed of properly and are not
within reach of babies and young children. Choking hazard!
Ensure that children do not detach any small parts (e.g. knobs or the like) from
the unit. They could swallow the pieces and choke!
Never let children unattended use electrical devices.
DANGER!
Electric shock caused by high voltages inside
Within the device there are areas where high voltages may be present. Never
remove any covers.
There are no user-serviceable parts inside.
Do not use the device if covers, protectors or optical components are missing or
damaged.
Safety
Safety instructions
LED effect
12

DANGER!
Electric shock caused by short-circuit
Do not modify the mains cable or the plug. Failure to do so could result in electric
shock/death or fire. If in doubt, seek advice from a registered electrician.
WARNING!
Eye damage caused by high light intensity
Never look directly into the light source.
WARNING!
Risk of epileptic shock
Strobe lighting can trigger seizures in photosensitive epilepsy. Sensitive persons
should avoid looking at strobe lights.
Safety instructions
LED Diamond Dome
13

NOTICE!
Risk of fire
Do not cover the device nor any ventilation slots. Do not place the device near
any direct heat source. Keep the device away from naked flames.
NOTICE!
Operating conditions
This device has been designed for indoor use only. To prevent damage, never
expose the device to any liquid or moisture. Avoid direct sunlight, heavy dirt, and
strong vibrations.
Safety instructions
LED effect
14

NOTICE!
Power supply
Before connecting the device, ensure that the input voltage (AC outlet) matches
the voltage rating of the device and that the AC outlet is protected by a residual
current circuit breaker. Failure to do so could result in damage to the device and
possibly injure the user.
Unplug the device before electrical storms occur and when it is unused for long
periods of time to reduce the risk of electric shock or fire.
Safety instructions
LED Diamond Dome
15

3 Features
The LED Diamond Dome is characterized by an extraordinary light output and effects.
nLED configuration
–LED Diamond Dome RGBW 4-in-1 with 1 × 4-in-1 LED, RGBW, 10 W
–LED Diamond Dome RGBWA UV 6-in-1 with 1 × 6-in-1 LED, RGBWA and UV, 12 W
–LED Diamond Dome UV with 3 × UV LED, 3 W
nDispersion characteristics: VNSP (Very Narrow Spot)
ntransparent hemisphere with Narrow-Beam lenses
nDiamond circle effect
nControl via DMX (four channels), buttons and display on the unit or an optional IR remote
control
npreprogrammed automatic shows
nSound control
nStand-alone mode
nMaster / Slave mode
nStrobe effect
nbuilt-in fan
Features
LED effect
16

4 Installation and starting up
Unpack and carefully check that there is no transportation damage before using the unit. Keep
the equipment packaging. To fully protect the device against vibration, dust and moisture
during transportation or storage use the original packaging or your own packaging material
suitable for transport or storage, respectively.
Installation and starting up
LED Diamond Dome
17

The device is designed for ceiling or wall mounting and has for this purpose two mounting
tabs on the bottom.
A Mounting tabs for ceiling or wall mounting of the unit.
Ceiling or wall mounting
Installation and starting up
LED effect
18

WARNING!
Risk of injury caused by falling objects
Make sure that the installation complies with the standards and rules that apply
in your country. Always secure the device with a secondary safety attachment,
such as a safety cable or a safety chain.
NOTICE!
Risk of overheating
Always ensure sufficient ventilation.
The ambient temperature must always be below 40 °C (104 °F).
Installation and starting up
LED Diamond Dome
19

NOTICE!
Possible data transmission errors
For error-free operation make use of dedicated DMX cables and do not use ordi‐
nary microphone cables.
Never connect the DMX input or output to audio devices such as mixers or ampli‐
fiers.
Use appropriate mounting hardware to attach the unit to the ceiling or a wall. The designated
fastening area must be sufficiently stable for the load, level and vibration-free.
Create all connections while the device is off. Use the shortest possible high-quality cables for
all connections. Take care when running the cables to prevent tripping hazards.
Installation and starting up
LED effect
20
