thomann Tri Flood MK II User manual

Tri Flood MK II
15×15 W RGB
LED floodlight
user manual

Musikhaus Thomann e.K.
Treppendorf 30
96138 Burgebrach
Germany
Telephone: [phone]
E-mail: [email protected]
Internet: www.thomann.de
23.01.2013

Table of contents
1 General notes............................................................................................................................................... 5
2 Sicherheitshinweise.................................................................................................................................. 8
3 Features....................................................................................................................................................... 12
4 Installation.................................................................................................................................................. 13
5 Starting up.................................................................................................................................................. 16
6 Connections and operating elements........................................................................................... 19
7 Operation.................................................................................................................................................... 22
7.1 Starting up the device.................................................................................................................... 22
7.2 Main menu.......................................................................................................................................... 22
7.3 Menu overview................................................................................................................................. 32
7.4 Functions in DMX mode 1............................................................................................................. 33
7.5 Functions in DMX mode 2............................................................................................................. 34
7.6 Functions in DMX mode 3............................................................................................................. 35
7.7 Functions in DMX mode 4............................................................................................................. 35
7.8 Functions in DMX mode 5............................................................................................................. 36
Table of contents
Tri Flood MK II 15×15 W RGB
3

7.9 Functions in DMX mode 6............................................................................................................. 38
8 Technical specifications....................................................................................................................... 40
9 Troubleshooting...................................................................................................................................... 41
10 Cleaning....................................................................................................................................................... 43
11 Protecting the environment.............................................................................................................. 44
Table of contents
LED floodlight
4

1 General notes
This user manual contains important information on safe operation of the device. Read and
follow all safety notes and all instructions. Save this manual for future reference. Make sure
that it is available to all persons using this device. If you sell the device, include the manual for
the next owner.
Our products are subject to a process of continuous development. We therefore reserve the
right to make changes without notice.
This section provides an overview of the symbols and signal words used in this user manual.Symbols and signal words
General notes
Tri Flood MK II 15×15 W RGB
5

Signal word Meaning
DANGER! This combination of symbol and signal word
indicates an immediate dangerous situation
that will result in death or serious injury if it is
not avoided.
WARNING! This combination of symbol and signal word
indicates a possible dangerous situation that
can result in death or serious injury if it is not
avoided.
NOTICE! This combination of symbol and signal word
indicates a possible dangerous situation that
can result in material and environmental
damage if it is not avoided.
Warning signs Type of danger
Warning – high-voltage.
General notes
LED floodlight
6

Warning signs Type of danger
Warning – suspended load.
Warning – danger zone.
General notes
Tri Flood MK II 15×15 W RGB
7

2 Sicherheitshinweise
This device is intended to be used as an electronic illumination effect using LED technics. Use
the device only as described in this user manual. Any other use or use under other operating
conditions is considered to be improper and may result in personal injury or property damage.
No liability will be assumed for damages resulting from improper use.
This device may be used only by persons with sufficient physical, sensorial, and intellectual
abilities and having corresponding knowledge and experience. Other persons may use this
device only if they are supervised or instructed by a person who is responsible for their safety.
DANGER!
Danger for children
Ensure that plastic bags, packaging, etc. are disposed of properly and are not
within reach of babies and young children. Choking hazard!
Ensure that children do not detach any small parts (e.g. knobs or the like) from
the unit. They could swallow the pieces and choke!
Never let children unattended use electrical devices.
Intended use
Sicherheit
Sicherheitshinweise
LED floodlight
8

DANGER!
Electric shock caused by high voltages inside
Within the device there are areas where high voltages may be present. Never
remove any covers.
There are no user-serviceable parts inside.
DANGER!
Electric shock caused by short-circuit
Do not modify the mains cable or the plug. Failure to do so could result in electric
shock/death or fire. If in doubt, seek advice from a registered electrician.
WARNING!
Eye damage caused by high light intensity
Never look directly into the light source.
Sicherheitshinweise
Tri Flood MK II 15×15 W RGB
9

WARNING!
Risk of epileptic shock
Strobe lighting can trigger seizures in photosensitive epilepsy. Sensitive persons
should avoid looking at strobe lights.
NOTICE!
Risk of fire
Do not cover the device nor any ventilation slots. Do not place the device near
any direct heat source. Keep the device away from naked flames.
NOTICE!
Operating conditions
This device has been designed for indoor use only. To prevent damage, never
expose the device to any liquid or moisture. Avoid direct sunlight, heavy dirt, and
strong vibrations.
Sicherheitshinweise
LED floodlight
10

NOTICE!
Power supply
Before connecting the device, ensure that the input voltage (AC outlet) matches
the voltage rating of the device and that the AC outlet is protected by a residual
current circuit breaker. Failure to do so could result in damage to the device and
possibly injure the user.
Unplug the device before electrical storms occur and when it is unused for long
periods of time to reduce the risk of electric shock or fire.
Sicherheitshinweise
Tri Flood MK II 15×15 W RGB
11

3 Features
The LED floodlight is specially suited for professional lighting tasks, such as at events, on rock
stages, in theatres and musicals, in discos or for architectural and garden illumination.
Special features of this device:
n15 tricoloured LEDs (15 W each)
nControl via DMX (5 different modes) and via buttons and display on the unit
nPreprogrammed automatic shows
nMaster / slave operation
nRobust black metal housing
nOutdoor usability, IP65
Features
LED floodlight
12

4 Installation
Unpack and check carefully there is no transportation damage before using the unit. Keep the
equipment packaging. To fully protect the device against vibration, dust and moisture during
transportation or storage use the original packaging or your own packaging material suitable
for transport or storage, respectively.
You can install the device on the wall, ceiling or floor. A mounting bracket is included in the
package.
WARNING!
Risk of injury caused by falling objects
Make sure that the installation complies with the standards and rules that apply
in your country. Always secure the device with a secondary safety attachment,
such as a safety cable or a safety chain.
Installation
Tri Flood MK II 15×15 W RGB
13

NOTICE!
Risk of overheating
Always ensure sufficient ventilation.
The ambient temperature must always be below 40 °C (104 °F).
NOTICE!
Use of stands
When mounting the device onto a stand, ensure that the stand is in a safe and
stable position and that the weight of the device does not exceed the maximum
permissible load capacity of the stand.
Installation
LED floodlight
14

NOTICE!
Possible data transmission errors
For error-free operation make use of dedicated DMX cables and do not use ordi‐
nary microphone cables.
Never connect the DMX output to audio devices such as mixers or amplifiers.
The unit offers a 3-pin XLR socket for DMX output and a 3-pin XLR plug for DMX input. Please
refer to the drawing and table below for pin assignment.
1 Ground, shielding
2 DMX data (–)
3 DMX data (+)
DMX connections
Installation
Tri Flood MK II 15×15 W RGB
15

5 Starting up
Establish all connections as long as the unit is switched off. Use the shortest possible high-
quality cables for all connections.
Starting up
LED floodlight
16

Connect the DMX input of the device to the DMX output of a DMX controller or another DMX
device. Connect the output of the first DMX device to the input of the second one, and so on
to form a daisy chain. Always ensure that the output of the last DMX device in the daisy chain
is terminated with a resistor (110 Ω, ¼W).
Connections in DMX mode
Starting up
Tri Flood MK II 15×15 W RGB
17

When you configure a group of devices in master/slave mode, the first unit will control the
other units for an automatic, sound-activated, synchronized show. This function is ideal when
you want to start a show immediately. Connect the DMX output of the master device to the
DMX input of the first slave device. Then connect the DMX output of the first slave device to
the DMX input of the second slave device and so on.
Connections in master/slave
mode
Starting up
LED floodlight
18

6 Connections and operating elements
Rear panel
Connections and operating elements
Tri Flood MK II 15×15 W RGB
19

1 Display.
2[MODE] button
Activates the main menu or a submenu respectively.
3[UP] button
Increases the displayed value by one.
4[DOWN] button
Decreases the displayed value by one.
5POWER IN
Cable with special threaded coupling connector for mains power connection.
6POWER OUT
Cable with special threaded coupling connector to feed further units with mains power.
7 Bracket for setup or hanging.
8 Locking screw for the bracket.
Connections and operating elements
LED floodlight
20
