thomann Millenium DM-30 User manual

DM-30
e-drum monitor
user manual

Musikhaus Thomann e.K.
Treppendorf 30
96138 Burgebrach
Germany
Telephone: [phone]
E-mail: [email protected]
Internet: www.thomann.de
30.12.2013, ID: 137566

Table of contents
1 General notes............................................................................................................................................... 4
2 Safety instructions..................................................................................................................................... 7
3 Features....................................................................................................................................................... 11
4 Installation and starting up ............................................................................................................... 12
5 Connections and operating elements........................................................................................... 13
6 Technical specifications....................................................................................................................... 18
7 Plug and connection assignment.................................................................................................... 19
8 Protecting the environment.............................................................................................................. 20
Table of contents
DM-30
3

1 General notes
This user manual contains important information on safe operation of the device. Read and
follow all safety notes and all instructions. Save this manual for future reference. Make sure
that it is available to all persons using this device. If you sell the device, include the manual for
the next owner.
Our products are subject to a process of continuous development. We therefore reserve the
right to make changes without notice.
This section provides an overview of the symbols and signal words used in this user manual.Symbols and signal words
General notes
e-drum monitor
4

Signal word Meaning
DANGER! This combination of symbol and signal word
indicates an immediate dangerous situation
that will result in death or serious injury if it is
not avoided.
CAUTION! This combination of symbol and signal word
indicates a possible dangerous situation that
can result in minor injury if it is not avoided.
NOTICE! This combination of symbol and signal word
indicates a possible dangerous situation that
can result in material and environmental
damage if it is not avoided.
Warning signs Type of danger
Warning – high-voltage.
General notes
DM-30
5

Warning signs Type of danger
Warning – danger zone.
General notes
e-drum monitor
6

2 Safety instructions
This device is intended to be used to amplify and play back E-drums signals. Use the device
only as described in this user manual. Any other use or use under other operating conditions is
considered to be improper and may result in personal injury or property damage. No liability
will be assumed for damages resulting from improper use
This device may be used only by persons with sufficient physical, sensorial, and intellectual
abilities and having corresponding knowledge and experience. Other persons may use this
device only if they are supervised or instructed by a person who is responsible for their safety.
DANGER!
Danger for children
Ensure that plastic bags, packaging, etc. are disposed of properly and are not
within reach of babies and young children. Choking hazard!
Ensure that children do not detach any small parts (e.g. knobs or the like) from
the unit. They could swallow the pieces and choke!
Never let children unattended use electrical devices.
Intended use
Safety
Safety instructions
DM-30
7

DANGER!
Electric shock caused by high voltages inside
Within the device there are areas where high voltages may be present. Never
remove any covers.
There are no user-serviceable parts inside.
DANGER!
Electric shock caused by short-circuit
Always use proper ready-made insulated mains cabling (power cord) with a pro‐
tective contact plug. Do not modify the mains cable or the plug. Failure to do so
could result in electric shock/death or fire. If in doubt, seek advice from a regis‐
tered electrician.
Safety instructions
e-drum monitor
8

CAUTION!
Possible hearing damage
The device can produce volume levels that may cause temporary or permanent
hearing impairment. Over an extended period of time, even levels that seem to
be uncritical can cause hearing damage.
Decrease the volume level immediately if you experience ringing in your ears or
hearing impairment. If this is not possible, keep a greater distance or use suffi‐
cient ear protectors.
NOTICE!
Risk of fire
Do not cover the device nor any ventilation slots. Do not place the device near
any direct heat source. Keep the device away from naked flames.
Safety instructions
DM-30
9

NOTICE!
Operating conditions
This device has been designed for indoor use only. To prevent damage, never
expose the device to any liquid or moisture. Avoid direct sunlight, heavy dirt, and
strong vibrations.
NOTICE!
Power supply
Before connecting the device, ensure that the input voltage (AC outlet) matches
the voltage rating of the device and that the AC outlet is protected by a residual
current circuit breaker. Failure to do so could result in damage to the device and
possibly injure the user.
Unplug the device before electrical storms occur and when it is unused for long
periods of time to reduce the risk of electric shock or fire.
Safety instructions
e-drum monitor
10

3 Features
Special features of the device:
nInputs:
– ‘Drum’: for the left and right outputs of an E-drum module
– ‘AUX’: for source devices (e.g. MP3 player) or for the monitor mix of the rest of the
band
n10" two-way coaxial speakers
nSeparate volume controls for ‘Drum’ and ‘AUX’ inputs
nTone controls for bass, mids und treble
nBlack textured coating
nEnergy saving mode: after the amplifier has not received any signal for 20 minutes on one
of its inputs it turns to standby. To switch it on again, press the POWER button.
Features
DM-30
11

4 Installation and starting up
Unpack and carefully check that there is no transportation damage before using the unit. Keep
the equipment packaging. To fully protect the device against vibration, dust and moisture
during transportation or storage use the original packaging or your own packaging material
suitable for transport or storage, respectively.
Establish all connections as long as the unit is switched off. Use the shortest possible high-
quality cables for all connections.
NOTICE!
Possible property damage by magnetic fields
Loudspeakers produce a static magnetic field. Therefore, maintain an appropriate
distance to devices that can be adversely affected or damaged by an external
magnetic field.
Installation and starting up
e-drum monitor
12

5 Connections and operating elements
Top side
Connections and operating elements
DM-30
13

1DRUM IN L, R
1/4" phone sockets to connect the E-drum module (left and right channel).
2AUX IN
1/4" phone socket to connect a mixer or source device.
3DRUM VOLUME
Volume control for the E-drum channels.
4AUX VOLUME
Volume control for the AUX channel.
Connections and operating elements
e-drum monitor
14

5BASS
Low frequency control.
MIDDLE
Mid frequency control.
TREBLE
High frequency control.
6 Power indicator LED
Lights up when the device is switched on and operational.
7POWER
Mains switch to turn the device on, off and from energy saving mode to normal operation.
Connections and operating elements
DM-30
15

Rear panel
Connections and operating elements
e-drum monitor
16

8 IEC chassis connector with fuse holder.
Find technical specifications about replacement fuses and operating supply voltage beneath the fuse holder.
Connections and operating elements
DM-30
17

6 Technical specifications
E-drum inputs 1/4" phone sockets
‘AUX’ input 1/4" phone socket
Output power 30 W (RMS)
Operating supply voltage AC 220 … 240 V , 50/60 Hz
Fuse 1 A / 250 V, slow-blow
Dimensions (W × D × H) 351 mm × 345 mm × 367 mm
Weight 15 kg
Technical specifications
e-drum monitor
18

7 Plug and connection assignment
This chapter will help you select the right cables and plugs to connect your valuable equip‐
ment in such a way that a perfect sound experience is ensured.
Please note these advices, because especially in ‘Sound & Light’ caution is indicated: Even if a
plug fits into the socket, an incorrect connection may result in a destroyed power amp, a short
circuit or ‘just’ in poor transmission quality!
1 Signal
2 Ground, shielding
Introduction
1/4" TS phone plug (mono,
unbalanced)
Plug and connection assignment
DM-30
19

8 Protecting the environment
For the transport and protective packaging, environmentally friendly materials have been
chosen that can be supplied to normal recycling.
Ensure that plastic bags, packaging, etc. are properly disposed of.
Do not just dispose of these materials with your normal household waste, but make sure that
they are collected for recycling. Please follow the notes and markings on the packaging.
This product is subject to the European Waste Electrical and Electronic Equipment Directive
(WEEE). Do not dispose with your normal household waste.
Dispose of this device through an approved waste disposal firm or through your local waste
facility. When discarding the device, comply with the rules and regulations that apply in your
country. If in doubt, consult your local waste disposal facility.
Disposal of the packaging mate‐
rial
Disposal of your old device
Protecting the environment
e-drum monitor
20
