Achat 404PAM
3

1 General information
This user manual contains important information on the safe operation of the device. Read and
follow all safety notes and all instructions. Save this manual for future reference. Make sure
that it is available to all persons using this device. If you sell the device to another user, be sure
that they also receive this manual.
Our products and user manuals are subject to a process of continuous development. We there‐
fore reserve the right to make changes without notice. Please refer to the latest version of the
user manual which is ready for download under www.thomann.de.
General information
battery-powered speaker
4

1.1 Further information
On our website (www.thomann.de) you will nd lots of further information and details on the
following points:
Download This manual is also available as PDF le for you to download.
Keyword search Use the search function in the electronic version to nd the topics of
interest for you quickly.
Online guides Our online guides provide detailed information on technical basics
and terms.
Personal consultation For personal consultation please contact our technical hotline.
Service If you have any problems with the device the customer service will
gladly assist you.
General information
Achat 404PAM
5

1.2 Notational conventions
This manual uses the following notational conventions:
The letterings for connectors and controls are marked by square brackets and italics.
Examples: [VOLUME] control, [Mono] button.
1.3 Symbols and signal words
In this section you will nd an overview of the meaning of symbols and signal words that are
used in this manual.
Letterings
General information
battery-powered speaker
6

Signal word Meaning
DANGER! This combination of symbol and signal word indicates an
immediate dangerous situation that will result in death or
serious injury if it is not avoided.
WARNING! This combination of symbol and signal word indicates a pos‐
sible dangerous situation that can result in death or serious
injury if it is not avoided.
CAUTION! This combination of symbol and signal word indicates a pos‐
sible dangerous situation that can result in minor injury if it
is not avoided.
NOTICE! This combination of symbol and signal word indicates a pos‐
sible dangerous situation that can result in material and
environmental damage if it is not avoided.
Warning signs Type of danger
Warning – danger zone.
General information
Achat 404PAM
7

2 Safety instructions
This device is designed for sound reinforcement. Use the device only as described in this user
manual. Any other use or use under other operating conditions is considered to be improper
and may result in personal injury or property damage. No liability will be assumed for damages
resulting from improper use.
This device may be used only by persons with sucient physical, sensorial, and intellectual
abilities and having corresponding knowledge and experience. Other persons may use this
device only if they are supervised or instructed by a person who is responsible for their safety.
DANGER!
Danger for children
Ensure that plastic bags, packaging, etc. are disposed of properly and are not
within reach of babies and young children. Choking hazard!
Ensure that children do not detach any small parts (e.g. knobs or the like) from
the unit. They could swallow the pieces and choke!
Never let children unattended use electrical devices.
Intended use
Safety
Safety instructions
battery-powered speaker
8

CAUTION!
Possible hearing damage
The device can produce volume levels that may cause temporary or permanent
hearing impairment. Over an extended period of time, even levels that seem to
be uncritical can cause hearing damage.
Decrease the volume level immediately if you experience ringing in your ears or
hearing impairment. If this is not possible, keep a greater distance or use su‐
cient ear protectors.
WARNING!
Incorrect handling of lithium batteries can result in injury
In the event of a short circuit, overheating or mechanical damage, lithium bat‐
teries can cause severe injuries.
Follow the advice on the correct handling of lithium batteries in the present sec‐
tion.
Safety instructions
Achat 404PAM
9

NOTICE!
External power supply
The device is powered by an external power supply. Before connecting the
external power supply, ensure that the input voltage (AC outlet) matches the
voltage rating of the device and that the AC outlet is protected by a residual cur‐
rent circuit breaker. Failure to do so could result in damage to the device and pos‐
sibly the user.
Unplug the external power supply before electrical storms occur and when the
device is unused for long periods of time to reduce the risk of electric shock or
re.
Safety instructions
battery-powered speaker
10

NOTICE!
Operating conditions
This device has been designed for indoor use only. To prevent damage, never
expose the device to any liquid or moisture. Avoid direct sunlight, heavy dirt, and
strong vibrations.
Only operate the device within the ambient conditions specied in the chapter
‘Technical specications’ of this user manual. Avoid heavy temperature uctua‐
tions and do not switch the device on immediately after it was exposed to tem‐
perature uctuations (for example after transport at low outside temperatures).
Dust and dirt inside can damage the unit. When operated in harmful ambient
conditions (dust, smoke, nicotine, fog, etc.), the unit should be maintained by
qualied service personnel at regular intervals to prevent overheating and other
malfunction.
Safety instructions
Achat 404PAM
11

NOTICE!
Possible damage due to incorrect storage
Deep discharge can cause batteries to become permanently damaged or lose
some of their capacity.
Before prolonged rest periods, charge the batteries to around 50 % of their
capacity and then switch the equipment o. Store the equipment at a tempera‐
ture between 10 °C and 32 °C in as dry an environment as possible. During
extended storage periods, charge the batteries to 50 % approximately every three
months.
Safety instructions
battery-powered speaker
12

3 Features
Special features of the device:
nInputs: XLR/1/4" combi socket, RCA sockets, 1/8" socket
nOutput: 12 V power supply for wireless systems
nDC cable included (item number 323989)
n4 ×4" neodym woofer, 1" compression driver
nBuilt-in rechargeable battery with lithium/manganese technology providing long opera‐
tion time and very low self-discharge
nVolume, treble and bass control
nBuilt-in small mixer with EQ and presets for speech and music
nBlack textured coating
nCabinet is ready to host a 9.5" wireless system
nTripod mounting thread
Features
Achat 404PAM
13

4 Installation and starting up
Unpack and check carefully there is no transportation damage before using the unit. Keep the
equipment packaging. To fully protect the product against vibration, dust and moisture during
transportation or storage use the original packaging or your own packaging material suitable
for transport or storage, respectively.
Create all connections while the device is o. Use the shortest possible high-quality cables for
all connections. Take care when running the cables to prevent tripping hazards.
NOTICE!
Possible property damage by magnetic elds
Loudspeakers produce a static magnetic eld. Therefore, maintain an appropriate
distance to devices that can be adversely aected or damaged by an external
magnetic eld.
Installation and starting up
battery-powered speaker
14

NOTICE!
Use of stands
When mounting the device onto a stand, ensure that the stand is in a safe and
stable position and that the weight of the device does not exceed the maximum
permissible load capacity of the stand.
The device is prepared for connection to a wireless receiver. A 9.5" receiver can be accommo‐
dated in the front part of the housing ap and fastened securely with the Velcro straps pro‐
vided. Connect the 12-V-power supply output (4) of the box with the corresponding input of
the wireless-receiver and the signal input (5) of the box with signal output of the wireless-
receiver (see also Ä Chapter 5 ‘Connections and controls’ on page 18).
The device can either be powered via the supplied external power supply or via the built-in
lithium-manganese battery. If the external power supply is connected, the battery is also
charged during operation.
Connecting a wireless system
Operating supply voltage
Installation and starting up
Achat 404PAM
15

4.1 Dealing with lithium batteries
WARNING!
Incorrect handling of lithium batteries can result in injury
In the event of a short circuit, overheating or mechanical damage, lithium bat‐
teries can cause severe injuries.
Follow the advice on the correct handling of lithium batteries in the present sec‐
tion.
When handled correctly and appropriately lithium batteries pose no risk.
Store lithium batteries in a cool, dry place, ideally in the original packaging.
Store lithium batteries away from heat sources (e.g. radiators or sunlight). Lithium batteries are
hermetically sealed. Never attempt to open a lithium battery.
If the battery housing is damaged small amounts of the electrolyte may leak out. If this should
happen, seal the lithium battery in airtight packaging and wipe up the traces of electrolyte
using absorbent paper towels. You must wear protective rubber gloves when doing so. Clean
your hands and the aected surface thoroughly with cold water.
Installation and starting up
battery-powered speaker
16

Never attempt to recharge non-rechargeable lithium batteries. When charging lithium bat‐
teries you must use a suitable charging device intended for the purpose.
Before disposing of the device remove the lithium batteries. Protect used lithium batteries
against potential short circuits, e.g. by covering the poles with adhesive tape.
Only use powder extinguishers or other suitable extinguishing agents to extinguish a burning
lithium battery.
Installation and starting up
Achat 404PAM
17

5 Connections and controls
Connections and controls
battery-powered speaker
18

1[POWER]
Main switch. Turns the device on and o.
2[DC INPUT]
Connection socket for external 18 V power supply for mains operation or for charging the built-in battery.
3[FULL]
This LED lights up in normal operation as long as the charge capacity of the built-in battery is sucient for proper
operation. Charge the built-in battery as soon as the LED turns o.
4[CHARGING]
This LED lights up while charging and turns o as soon as the built-in battery is fully charged.
5[MIC/LINE IN]
Combo XLR/¼" connector for signal input. The pushbutton (22) is used to change the sensitivity.
6[WL POWER]
Connection socket for power supply (12 V) of a wireless system.
7[WL INPUT]
Signal input from the wireless system, designed as a ¼" phone socket.
Connections and controls
Achat 404PAM
19

8[AUX IN]
Additional signal input, designed as RCA sockets for left and right channels. The signals of both channels are mixed
internally into one mono channel.
9[INPUT]
3.5 mm phone socket to connect, e.g., an MP3 player.
10 [AUX VOL]
Volume control for the AUX input (8) signal.
11 [TREBLE]
Control for attenuating / boosting the high frequencies.
12 [MIC VOL]
Volume control for the MIC/LINE input (5) signal.
13 [LOW]
Control for attenuating / boosting the low frequencies.
14 [MIC WL VOL]
Volume control for the WL input (7) signal.
Connections and controls
battery-powered speaker
20
