thomann Pyrit 212 Sub A User manual

Pyrit 212 Sub A
active subwoofer
user manual

Musikhaus Thomann e.K.
Treppendorf 30
96138 Burgebrach
Germany
Telephone: [phone]
E-mail: [email protected]
Internet: www.thomann.de
20.11.2014, ID: 299664

Table of contents
1 General notes............................................................................................................................................... 4
2 Safety instructions..................................................................................................................................... 7
3 Features....................................................................................................................................................... 12
4 Installation.................................................................................................................................................. 13
4.1 Tips on handling speakers............................................................................................................ 14
4.2 Pin assignment.................................................................................................................................. 15
5 Connections and operating elements........................................................................................... 17
6 Technical specifications....................................................................................................................... 20
7 Protecting the environment.............................................................................................................. 21
Table of contents
Pyrit 212 Sub A
3

1 General notes
This user manual contains important information on safe operation of the device. Read and
follow all safety notes and all instructions. Save this manual for future reference. Make sure
that it is available to all persons using this device. If you sell the device to other users, be sure
that they also receive this manual.
Our products are subject to a process of continuous development. We therefore reserve the
right to make changes without notice.
General notes
active subwoofer
4

This section provides an overview of the symbols and signal words used in this user manual.
Signal word Meaning
DANGER! This combination of symbol and signal word indicates an
immediate dangerous situation that will result in death or
serious injury if it is not avoided.
CAUTION! This combination of symbol and signal word indicates a pos‐
sible dangerous situation that can result in minor injury if it
is not avoided.
NOTICE! This combination of symbol and signal word indicates a pos‐
sible dangerous situation that can result in material and
environmental damage if it is not avoided.
Warning signs Type of danger
Warning – high-voltage.
Symbols and signal words
General notes
Pyrit 212 Sub A
5

Warning signs Type of danger
Warning – danger zone.
General notes
active subwoofer
6

2 Safety instructions
This device is intended to be used in a sound reinforcement system. Use the device only as
described in this user manual. Any other use or use under other operating conditions is consid‐
ered to be improper and may result in personal injury or property damage. No liability will be
assumed for damages resulting from improper use.
This device may be used only by persons with sufficient physical, sensorial, and intellectual
abilities and having corresponding knowledge and experience. Other persons may use this
device only if they are supervised or instructed by a person who is responsible for their safety.
DANGER!
Danger for children
Ensure that plastic bags, packaging, etc. are disposed of properly and are not
within reach of babies and young children. Choking hazard!
Ensure that children do not detach any small parts (e.g. knobs or the like) from
the unit. They could swallow the pieces and choke!
Never let children unattended use electrical devices.
Intended use
Safety
Safety instructions
Pyrit 212 Sub A
7

DANGER!
Electric shock caused by high voltages inside
Within the device there are areas where high voltages may be present. Never
remove any covers.
There are no user-serviceable parts inside.
DANGER!
Electric shock caused by short-circuit
Always use proper ready-made insulated mains cabling (power cord) with a pro‐
tective contact plug. Do not modify the mains cable or the plug. Failure to do so
could result in electric shock/death or fire. If in doubt, seek advice from a regis‐
tered electrician.
Safety instructions
active subwoofer
8

CAUTION!
Possible hearing damage
The device can produce volume levels that may cause temporary or permanent
hearing impairment. Over an extended period of time, even levels that seem to
be uncritical can cause hearing damage.
Decrease the volume level immediately if you experience ringing in your ears or
hearing impairment. If this is not possible, keep a greater distance or use suffi‐
cient ear protectors.
CAUTION!
Risk of injury due to heavy weight
Due to the heavy weight of the device, at least two persons are required for trans‐
port and installation.
Safety instructions
Pyrit 212 Sub A
9

NOTICE!
Risk of fire
Do not cover the device nor any ventilation slots. Do not place the device near
any direct heat source. Keep the device away from naked flames.
NOTICE!
Operating conditions
This device has been designed for indoor use only. To prevent damage, never
expose the device to any liquid or moisture. Avoid direct sunlight, heavy dirt, and
strong vibrations.
Safety instructions
active subwoofer
10

NOTICE!
Power supply
Before connecting the device, ensure that the input voltage (AC outlet) matches
the voltage rating of the device and that the AC outlet is protected by a residual
current circuit breaker. Failure to do so could result in damage to the device and
possibly injure the user.
Unplug the device before electrical storms occur and when it is unused for long
periods of time to reduce the risk of electric shock or fire.
Safety instructions
Pyrit 212 Sub A
11

3 Features
Special features of the device:
nClass-D amplifier
nIntegrated sound processor (DSP) with 3 modes, designed for use together with matching
tops with midrange speaker and tweeter (T10a, T12a or T15a).
nConnections: XLR / 1/4" combo socket for signal input, XLR chassis plug for signal output
nEach one pole mount flange (36mm) on top and right side of the housing
nTwo carrying handles
nBlack textured coating
nPowder-coated front grille
Features
active subwoofer
12

4 Installation
Unpack and carefully check that there is no transportation damage before using the unit. Keep
the equipment packaging. To fully protect the device against vibration, dust and moisture
during transportation or storage use the original packaging or your own packaging material
suitable for transport or storage, respectively.
Establish all connections as long as the unit is switched off. Use the shortest possible high-
quality cables for all connections.
CAUTION!
Risk of injury due to heavy weight
Due to the heavy weight of the device, at least two persons are required for trans‐
port and installation.
Installation
Pyrit 212 Sub A
13

NOTICE!
Possible property damage by magnetic fields
Loudspeakers produce a static magnetic field. Therefore, maintain an appropriate
distance to devices that can be adversely affected or damaged by an external
magnetic field.
4.1 Tips on handling speakers
We recommend you to set up the speakers in a way, that the sound signals can reach the audi‐
ence unobstructedly. It will often be helpful to mount the speakers on tripods. Thus, the sound
will be evenly spread with maximum range throughout the audience area.
Always use high grade cable to connect your equipment. Otherwise you won't reach max‐
imum sound quality.
If you notice distortion during operation, the active speaker is overloaded. This may perma‐
nently damage the device. Always reduce the volume as soon as you hear distortion.
Installation
active subwoofer
14

4.2 Pin assignment
XLR chassis sockets serve as signal inputs, XLR chassis plugs serve as signal outputs. Drawing
and table indicate the XLR pin assignment.
Balanced wiring:
1 Ground, shielding
2 Positive signal (+)
3 Negative signal (–)
XLR connections for signal in
and outputs
Installation
Pyrit 212 Sub A
15

Balanced wiring (TRS plug):
1 (Tip) Positive signal (+)
2 (Ring) Negative signal (–)
3 (Sleeve) Ground, shielding
1/4" phone sockets for signal
inputs
Installation
active subwoofer
16

5 Connections and operating elements
Connections and operating elements
Pyrit 212 Sub A
17

1MODE
Slide switch for selecting the operating mode of the integrated sound processor: T10a, T12a, T15a. Use this switch
to adjust the sound characteristics according to the used top (midrange and tweeter).
LEDs indicate the selected operating mode.
Switch the device off before changing the operating mode to avoid any damages.
2PWR LED: indicates that the power supply is present.
SIG LED: Indicates that the input signal is present.
CLIP LED: Indicates overload (clipping) due to excessive input signal level.
3VOLUME
Volume control.
4LINE IN A
XLR / 1/4" combo socket as balanced Line signal input.
5LINE OUT A
XLR chassis plug as Line signal output.
Connections and operating elements
active subwoofer
18

6LINE IN B
XLR / 1/4" combo socket as balanced Line signal input.
7LINE OUT B
XLR chassis plug as Line signal output.
8Power supply connection
IEC chassis connector for power supply.
9 Fuse holder
If the fuse blows you have to replace it by a new one with same specifications. Before, you must disconnect the unit
from the mains power.
10 POWER ON/OFF
Use this mains switch to turn the device on or off.
Connections and operating elements
Pyrit 212 Sub A
19

6 Technical specifications
Speakers 2 × 12" woofer (4" voice coil)
Inputs XLR / 1/4" combo sockets (balanced)
Input impedance ≥ 20 kΩ
Outputs XLR chassis plug
Frequency response 31.5 Hz … 120 Hz (–3 dB)
Power handling 1000 W (RMS) / 4000 W (PEAK)
Sound pressure level 132 dB / 1 m (max.)
Sensitivity 96 dB (1 W / 1 m)
Operating supply voltage AC 220 – 240 V , 50/60 Hz
Dimensions (W × H × D) 735 mm × 475 mm × 520 mm
Weight 41.0 kg
