THOMSON THDH001 User manual

DEHUMIDIFIER
THDH001
INSTRUCTION MANUAL
CAREFULLY READ THESE INSTRUCTIONS

SAFETY WARNINGS
Please read these instructions carefully before using the
appliance.
1. Unplug the power supply cord before cleaning or storage.
2. Do not submerge the unit in water, or place the unit close
to water.
3. Do not put the unit close to heat-generating devices or
near flammable and dangerous materials.
4. Never put your fingers or objects into the intake or
discharge ducts.
5. Do not sit or stand on the unit.
6. Discard water that has collected in the tank as required
7. Do not operate the dehumidifier in a closed area such
as inside a closet, as it may cause a fire
8. Install drain piping at a downhill grade to make sure
that condensed water can be drained continuously.
9. This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without
supervision.
10. If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons in
order to avoid a hazard.
11. This product complies with directives 2006/95/EC (LVD) and
2004/108/EC (EMC)

12.This product must be installed according to national fittings
standards
13.Never use the appliance outside and always place it in a dry
environment.
14.Product must be grounded. If the socket outlet or supply
mains don’t have grounded connection, you must not connect
the appliance
15.Maintain the minimum clearance
16.The appliance shall be installed in
accordance with national wiring
regulations
17.For domestic and indoor use only
A thermal magnetic circuit breaker or a standard 16A fuse must be
installed up stream of the main switch of the appliance.
(EC) No 842/2006: R134a is a fluorinated greenhouse gas
covered by the Kyoto Protocol. Its global warming potential
(GWP) 1300
The operational temperature is in the range of 5℃to 35℃.
If the room temperature is outside of this range, the unit will not
operate normally.
220-240V ~ 50Hz
10liter/day*
235W
7.5kg
Refrigerant/charge: R134a (150g)
Design pressure (high/low): 2.18/0.52MPa
Maximum allowable pressure (high pressure side/low pressure side): 4.00/4.00MPa
Water tank capacity 1.9 liters
*The dehumidification capacity is rated at a room temperature of 30℃with a relative humidity of 80%.
Fuse: F1A/250VAC –1 ampere

FEATURES
Powerful Dehumidifying Capability
Taking advantage of refrigeration technology, the dehumidifier powerfully removes
moisture from the air to decrease the humidity level of the room and keep the indoor
air dry and comfortable.
Lightweight Portable Design
The dehumidifier is built to be compact and lightweight. The casters on the bottom of
the unit make it easy to move from room to room.
Low Temperature Operation with Automatic Defrost
When the unit is running in a room temp. between 5℃and 12℃, it will stop to defrost for every 30 minutes
When the unit is running in a room temp. between 12℃and 20℃, it will stop to defrost for every 45 minutes
PRODUCT DIAGRAM
FRONT
Water tank
Wheel
Control panel
Air outlet grill

REAR
OPERATING INSTRUCTIONS
Indication lights
Power Indication Light
The Power indication light will turn on in green when the unit is plugged in, regardless of whether the unit is
operating or not.
tank full indication light
The tank full indication light will turn on in red when the drainage tank is full. If light is on, empty the water
out of the drainage tank and make sure the tank is positioned properly.
Fan speed indication light
The right fan indication light (above the small fan icon) will turns on in green when you program the unit to
run in the low fan speed.
The left fan indication light (above the big fan icon) will turns on in red when you program the unit to run in
the high fan speed.
Air filter
Handle
Continuous drainage port
Supply cord

Push Button Functions
Power Push Button
Press the button once to start operation with the default low fan speed. Press it
again to stop operation.
Fan Speed Push Button
Press to set the desired fan speed. It can be adjusted between high speed and
low speed.
OPERATION
1. Turn the unit On:
When the unit is plugged in, a buzzer will beep and the unit will start to run with a low fan speed.
Press button to start operation.
2. Stop operation
Press the POWER button to stop dehumidification.
Never stop the unit by unplugging the supply cord.
DRAININGTHE COLLECTED WATER
When the drainage tank is full, the tank full indicator light will turn on, the operation will stop automatically
and the buzzer will beep 15 times to alert the user that the water needs to be emptied from the drainage tank.
Emptying the Drainage Tank
1. Hold the top and bottom center of the water tank with both hands and pull it out gently.
2. Discard the collected water
NOTE
1. DO not remove the float from the water tank. The water full sensor will no longer be
able to detect the water level correctly without the float and water may leak from the
water tank.
2. If the drainage tank is dirty, wash it with cold or lukewarm water. Do not use detergent,
scouring pads, chemically treated dust cloths, gasoline, benzene, thinner, or other
solvents, as these can scratch and damage the tank and cause water leakage
3. When replacing the drainage tank, press the tank firmly into place with both hands. If the tank is not
positioned properly, the “TANK FULL” sensor will be activated, and the dehumidifier will not operate.

Continuous Water Drainage
The unit features a continuous drainage port .Using a plastic pipe (with an inner diameter of 10mm), the water
in the drainage tank can be continuously drained out from the continuous port
on the unit.
MAINTENANCE
Cleaning the Dehumidifier
To clean the Body
Wipe it with a soft damp cloth.
To Clean the Air Filter
1. Remove the air filter
2. Clean the air filter
Run a vacuum cleaner lightly over the surface of the air filter to remove dirt. If the air filter is exceptionally
dirty, wash it with warm water and a mild cleanser and dry thoroughly.

3. Attach the air filter
Insert the filter into the unit smoothly.
Storing the Dehumidifier
When the unit is not being used for a long period of time and you want to store it. Note the following steps:
Empty any water left in the drainage tank / Fold up the power supply cord / Clean the air filter /Discard in a
cool and dry place .
TROUBLESHOOTING
If the conditions listed below occur, please check the following items before calling the customer service.
Problem
Possible Cause
Solution
The unit doesn't operate
Has the power cord been
disconnected?
Plug the power cord into the outlet.
Is the tank full indication lamp
blinking? (The tank is full or in a
wrong position.)
Empty the water in the drainage tank and then
reposition the tank.
Is the temperature of the
room above 35℃or below
5℃?
The protection device is activated and the unit
cannot be started.
The dehumidifying
function doesn't work
Is the air filter clogged?
Clean the air filter as instructed under
"Cleaning the dehumidifier".
Is the intake duct or
discharge duct obstructed?
Remove the obstruction from the discharge
duct or intake duct.
No air is discharged
Is the air filter clogged?
Clean the air filter as instructed under
"Cleaning the dehumidifier".
Operation is noisy
Is the unit tilted or unsteady?
Move the unit to a stable, sturdy location.
Is the air filter clogged?
Clean the air filter as instructed under
"Cleaning the dehumidifier".

PROTECTION OFTHE ENVIRONMENT–DIRECTIVE 2012/19/EC
In order to preserve our environment and protect human health, the waste electrical and electronic
equipment should be disposed of in accordance with specific rules with the implication of both suppliers and
users. For this reason, as indicated by the symbol on the rating label or on the packaging, your
appliance should not be disposed of as unsorted municipal waste. The user has the right to bring it to a
municipal collection point performing waste recovery by means of reuse, recycling or use for other
applications in accordance with the directive.
Imported by SOPADIS, 12 Rue Jules Ferry, 93110 Rosny sous Bois, France
THOMSON is a trademark of Technicolor SA used under license by Sopadis.
