Sinclair R-9112 User manual

R-9112
DEHUMIDIFIER
Thank you for choosing our product.
For proper operation, please read and keep this manual carefully.
Instruction Manual

CONTENTS
SAFETY PRECAUTIONS ……………………………….…....... 2
ABOUT THE CONTROLS ON THE DEHUMIDIFIER .…...... 3-4
USING THE DEHUMIDIFIER..................................................... 5
-6
How the Dehumidifier Operates ……………………...........5
Automatic Defrost………….…………………………........... 5
Choosing a Location…………………………………........... 5
Removing Collected Water …………………….....……...... 6
Water Level…………………………………………….…...... 6
CARE AND CLEANING OF THE DEHUMIDIFIER........................ 7
Grille and Case…………………… …………………........... 7
Water Bucket…… ……………………………………........... 7
Air Filter …… ………………......……………………............ 7
TROUBLESHOOTING ………………………………….............. 8
LONG TERM STORAGE ……………………………….............. 9
IMPORTANT INSTRUCTIONS
Do not install and use your dehumidifier before completely reading these instruction.
This will help you optimize the operation of your dehumidifier.
The following advice and instructions should be followed closely:
1.Your unit must always be used in an upright posit
ion because it
contains cooling agent.
2.After unpacking Your unit, place the unit upright to
Failure to comply with
allow the cooling agent to stabilize, and wait 2 hours
these instructions may
before use.
damage the unit and
3.This product must not be disposed together with the
will invalidate the
domestic waste.This product has to be disposed at
warranty.
an authorized place for recycling of electrical and
electronic appliances.
4.The appliance shall not be installed in the laundry.
5.The appliance shall be installed in accordance with national wiring
regulations and must be positioned so that the plug is accessible.
6.If the power cord is damaged, it must be replaced by the manufacturer,
service agent or qualified person in order not to get any dangers.
7.Please check before the first operation:Check if the floater on bucket is at
right position. If the position is not correct, move it by hand to the right position.
1

IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
WARNING!
For your safety, the information in this manual must be followed to minimize the risk of fire,
electric shock or personal injury.
SAFETY PRECAUTIONS
When using this dehumidifier, always follow basic safety precautions, including the following:
This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision
or instruction concerning use of the appliance in a
safe way and u
nderstand the hazards involved.
Children shall not play with the appliance.
Do not place the power cord under a carpet.
Never install the unit in direct sunshine.
Prevent children from climbing on the unit.
To turn on your unit, always use the switch
on the control panel.
Cleaning and user maintenance shall not be made
by children without supervision.
Never unplug the dehumidifier while it is
working, This could damage the electronic
circuits.
Always operate the product from a power source
of the same volta
ge, frequency and rating as
indicated on the product identification plate.
Never place anything on top of the unit and
do not cover it with any kind of cloth while it
is plugged in or in-use.
Close supervision is necessary when any product
is used by or ne
ar children or invalids. Do not
allow children to use it as a toy.
Do not operate any product with a damaged
cord or plug, or after the product malfunctions,
or is dropped or appears damaged in any way.
Return the complete product to the place of
purchase for inspection, repair or replacement.
Do not place objects on the product or allow
objects to obstruct the inlet or outlet openings,
or operate in close proximity to walls or curtains,
etc.
The use of attachments or accessories not
recommended or sold by
the product distributor
may cause personal or property hazards or injuries.
Never connect the unit to a defective socket.
To avoid tripping the circuit, DO NOT USE
AN EXTENSION CORD FOR THIS UNIT.
Keep the area around the warm air outlet
sufficiently clean
and make sure that it is not
congested.
Make sure that the unit is correctly connected
before turning on the unit's power. Never lay
down the unit while it is working.
This product is intended for normal domestic
/household use only.
Always keep it in an upright position to avoid
any damage to the unit.
Repairs should only be carried out by
competent service department.
Switch off and unplug from outlet when not in
use or before cleaning.
2

ABOUT THE CONTROL ON THE DEHUMIDIFIER
3
4
High and Low fan
indicator lights
Bucket full light indicates
bucket needs to be emptied
or it is not in the proper place
4 hour or 2 hour
delay on/off
Continuous operation on
indicator light
indicator lights
Power On
indicator light
Clean the Filter
indicator light
2
6
5
1
NOTE: When the bucket is full or removed, the
controls cannot be set.
the humidity control to 45% or 50%. Allow
at least 24 hours for the dehumidifier to
achieve the humidity level. If you still have
damper air than desired, set the humidity
level to a lower setting or select Continuous
for maximum dehumidification.
This unit has 3-min lag due to the device
for protecting circuit .In order to prolong
the compressor's working life, the compressor
will not start until the unit has run for 3 minutes.
ON/OFF Pad
Press to turn the dehumidifier on and off.
FILTER Pad
After 250 hours of operation, the Clean the
Filter indicator light will glow to remind you to
clean the filter. Remove the filter and clean it.
Press to turn off the Clean the
Filter light. See
the Care and Cleaning section.
Display
Shows the set % humidity level while
setting, then shows the actual (+/– 5%
accuracy) room % humidity level.
FAN SPEED
Controls the fan speed.
Press to select High or Low fan
speed.
Set the fan control to High for maximum
moisture removal. When the humidity
has been reduced and quiet operation is
preferred, set the fan control to Low.
Humidity Set ControlPads
The humidity level can be set within a range
of 80% RH (Relative Humidity) to 35% RH
(Relativ
e Humidity) in 5% reduce or at
CO for continuous operation.
NOTE: If CO (Continuous) is selected, the
dehumidifier will operate continuously at
its maximum dehumidification settings if
attached to a hose to drain or until the
bucket is full.
For drier air, press the - pad and set to
a lower percent value (%).
For damper air, press the + pad and set
to a higher percent value (%).
TIMER Pad
If unit is turned on and running in timer mode
for 2hr or 4hr,can turn off the unit. When unit
stand by and running in timer mode for 2hr or
4hr can turn on the unit.
When you first use the dehumidifier, set
Other Features
BUCKET FULL Light
the bucket is removed or not replaced in the
proper position.
Auto Defrost
When frost builds up on the evaporator coils,
the compressor
will cycle off and the fan will
continue to run until the frost disappears.
Power Outage
In the case of a power outage or interruption,
the unit will automatically restart, in the settings
last used, after the power is restored.
Glows when the bucket is ready to be emptied,
or when the bucket is removed or not replaced
in the proper position.
Alarm
If the bucket is full or missing for more than three
minutes, an alarm will sound for about 10 seconds
to remind you to empty and replace the bucket.
Auto Shut
Off
The Water Level Control Switch shuts off the
dehumidifier when the bucket is full, or when
3

Other Features
BUCKET FULL
Light Glows when the bucket is ready to be emptied,or when the bucket is removed or not
replaced in the proper position.
Alarm
If the bucket is full or missing for more than three minutes, an alarm will sound for about 10
seconds to remind you to empty and replace the bucket.
Auto Shut Off
The Water Level Control Switch shuts off the dehumidifier when the bucket is full, or when
the bucket is removed or not replaced in the proper position.
Auto Defrost
When frost builds up on the evaporator coils,the compressor will cycle off and the fan will
continue to run until the frost disappears.
Power Outage
In the case of a power outage or interruption,the unit will automatically restart,in the setting
last used, after the power is restored.
4

USING THE DEHUMIDIFIER
When first using the dehumidifier, operate the unit continuously 24 hours.
How the Dehumidifier Operates
Automatic Defrost
Moist, humid air is drawn over a cold refrigerated
dehumidifying coil. Moisture in the air condenses
on this coil and drains into a bucket (or through
a hose and drain).
When frost builds up on the evaporator coils, the
compressor will
cycle off and the fan will continue
to run until the frost disappears.
Dry, clean air is drawn through the condenser
where it is heated and discharged out the top grille
into the room.
In defrosting mode, fan motor normally run,
compressor stop running.
It is normal that the surrounding air to become slightly
warmer as the dehumidifier operates.
Choosing a Location
NO
YES
A dehumidifier operating in a basement will have
little or no effect in drying an adjacent enclosed
storage area, such as a closet, unles
s there is
adequate circulation of air in and out of the area.
Do not use outdoors.
This dehumidifier is intended for indoor residential
applications only. This dehumidifier should not be
used for commercial or industrial applications.
Place the dehumidifier on a smooth, level floor
strong enough to support the unit with a full bucket
of water.
Allow at least 12
–18 inches of air space on all sides
of the unit for good air circulation(The place with a
draught leaves the distance of the wall as 40 inches).
Place the dehumidifier in an area where the
temperature will not below 5°C. Or the coils
can become covered with frost, which may
reduce performance.
NOTE:The dehumidifier has rollers to aid placement,
but it should only be rolled on smooth, flat surfaces.
D
o not attempt to roll the dehumidifier on carpet or
over objects.
Use the dehumidifier to prevent moisture damage
anywhere books or valuables are stored.
Use the dehumidifier in a basement to help prevent
moisture damage.
The dehumidifier must be operated in an enclosed
area to be most effective.
Close all doors, windows and other outside openings
of the room.
5

USING THE DEHUMIDIFIER
Always make sure the water bucket is locked into place on the dehumidifier.
Removing Collected Water
There are 2 ways to remove collected water:
1
Use the bucket. When the bucket is removed,
the unit will shut off. Empty and replace the
bucket.
2) Screw the drain connector to(included in the
package) the spout by turning clockwise.
NOTE: Support bucket with
both hands when emptying.
3) Insert the drainage hose into drain connector.
Important: Do not use the hose if using the
water tank to collect water. When the hose
is connected, water will be drained out through
it onto floor instead of into the tank.
NOTES:
Do not remove the bucket while the unit
is in operation or it has just stopped.
Otherwise it may cause some water to
drip from the draining pan.
ATTENTION: When using continuous drainage option,
place dehumidifier on a level surface and make sure
garden
hose is clear of any obstructions and is directed
downward. Press down drain door so it rests on top of
the hose.
The bucket must be in place and securely
seated for the dehumidifier to operate.
This is just the schematic plan, please refer
to the actual product.
Placing dehumidifier on an uneven surface or improper
hose installation may result in water filling up the bucket
and causing the unit to shut off. Empty water bucket if
shut off occurs, then check dehumidifier location and
hose for proper setup.
Use a hose. Water can be automatically
emptied into a floor drain by attaching
14mm inner diameter hose (not included).
2
1) Remove the continuous drain cap 1by turning
×
×
×
it counter clockwise then remove the rubber
stopper 2 from the spout.
Water Level
The dehumidifier will turn off automatically
when the bucket is full, or when the bucket is
removed or not replaced in the proper position.
The bucket must be replaced in the proper position for
the dehumidifier to work. The light will be on and the
deh
umidifier will not run if the bucket is not in the
proper position.
6

CARE AND CLEANING OF THE DEHUMIDIFIER
Turn the dehumidifier off and remove the plug from the wall outlet before cleaning.
Grille and Case
To clean the case:
To clean the front grille:
Use water and a mild detergent. Do not use
bleach or abrasives.
Use a vacuum attachment or brush.
Water Bucket
To clean:
Every few weeks, clean the bucket to prevent
growth of mold, mildew and bacteria. Partially fill
the bucket
with clean water and add a little mild
detergent. Swish it around in the bucket, empty
and rinse.
NOTE: Do not use a dishwasher to clean the
water bucket.
To remove:
Remove the bucket and pour any water out.
To replace:
Slide the bucket into the dehumidifier.
NOTE: The bucket must be in place and securely seated
for the dehumidifier to operate.
Air Filter
The air filter should be checked and cleaned at
least every 250 hours of operation or more
often if necessary.
Buttons
※After 250 hours of operation, the Clean the Filter
indicator light will glow to remind you to clean the
filter. Remove the filter and clean it. Replace the
filter and press the Filter RESET pad to turn off the
Clean the Filter light.
To remove:
Press the two buttons, then pull out the filter.
To clean:
Clean the filter with warm, soapy water. Rinse and
let the filter dry before replacing it.
To install:
Put the filter back into the dehumidifier.
NOTE: DO NOT rinse or put the filter in an automatic
dishwasher.
NOTE: Avoid using a dishwasher to clean the filter .
Caution: Do not operate the dehumidifier
without a filter because dirt will gather and affect the
unit 's performance.
7

TROUBLESHOOTING
Problem
Possible Causes
What To Do
• Make sure the dehumidifier’s plug is pushed completely
into the outlet.
Dehumidifier
does not start
The dehumidifier
is unplugged.
Dehumidifier has reached its
preset level or bucket is full.
• The dehumidifier automatically turns off when either
condition occurs. Change to a lower setting or empty
the bucket and replace properly.
Bucket is not in the
proper position.
• The bucket must be in place and securely seated for the
dehumidifier to operate.
Power failure.
• There is a protective time delay (up to 3 minutes) to
prevent tripping of the compressor overload. For this
reason, the unit may not start normal dehumidifying
for 3 minutes after it is turned back on.
Did not allow enough time
to remove the moisture.
• When first installed, allow at least 24 hours to maintain
Dehumidifier does
not dry
the air as it
should
the desired dryness.
Airflow is restricted.
• Make sure there are no curtains, blinds or furniture
blocking the front or back of the dehumidifier. See the
Choosing a Location section.
Dirty filter.
• See the Care and Cleaning section
The Humidity Control may
not be set low enough.
• For drier air, press the “-” pad and set to a lower percent
value (%) or at CO (continuous) for maximum
dehumidification.
Doors and windows may not
be closed tightly.
• Check all doors, windows and other openings
are securely closed.
Clothes dryer may be
blowing moisture
-laden
air into the room.
• Install the dehumidifier away from the dryer.
The dryer should be vented to the outside.
Room temperature
is too low.
• Moisture removal is best at higher room temperatures.
Lower room temperatures will reduce the moisture
removal rate. Models are designed to be operated at
temperatures above 5°C.
Dehumidifier runs
too much
Area to be dehumidified
is too large.
• The capacity of your dehumidifier may not be adequate.
Doors and windows are open.
• Close all doors and windows to the outside.
Frost appears on
the coils
Dehumidifier has been recently • This is normal. Frost will usually disappear
within 60 minutes. See the Automatic Defrost section.
turned on, or room temperature
is below 5°C.
Controls cannot be The compressor will turn off
• This is normal. Wait approximately 3 minutes and set the
fan as desired.
and the fan will automatically
set
continue to run for
approximately 3 minutes at a
fixed setting.
Fan noise
There is sound created when
wind passing the unit. That is
the sound of wind.
• This is normal.
Hose connection may be loose. • Check the hose connection.See the Removing Collected
Water section.
Water on floor
Intend to use the bucket to
col
lect water, but a hose
is attached.
• Disconnect the hose if using the bucket to collect water.
See the Removing Collected Water section.
8

LONG TERM STORAGE
when you do not use the unit for a long period, we suggest you to take following steps to store the
unit in good condition;
Make sure there is no water left in the water tank and take off the draining hose.
Take off the power cord and plug and warp them well.
Clean the unit and packed it well to keep it from dust.

IMPORTANT INFORMATION
FOR CORRECT DISPOSAL OF THE PRODUCT IN ACCORDANCE
WITH EC DIRECTIVE 2002/96/EC.
At the end of its working life, the product must not be disposed of as urban waste.
It must be taken to a special local authority differentiated waste collection centre or t
o a dealer
providing this service.
Disposing of a household appliance separately avoids possible negative consequences for the
environment and health, deriving form inappropriate disposal and enables the constituent materials to
be recovered to obtain sign
ificant savings in energy and resources. As a reminder of the need to
dispose of household appliances separately, the product is marked with a crossed
-out wheeled
dustbin.
