Thomson 24fs3246 User manual

THOMSON

SERVICE MANUAL

CHASSIS MT62F

Contents

1ǃProducts Specification----------------------------------------------------------------2

2ǃTest and Alignment---------------------------------------------------------------------3

3ǃBlock Diagram--------------------------------------------------------------------------22

4ǃMB Schematic Diagram--------------------------------------------------------------23

5ǃPSU Schematic Diagram------------------------------------------------------------39

6ǃExplode View----------------------------------------------------------------------------40

This manual is the latest at the time of printing, and does not

include the modification which may be made after the printing, by

the constant improvement of product.

F11 MT62F FDS

24FS3246 26HS3246 32FS3246 37FS3246 40FS3246


Going Price Euro at Intro.

Target Volume (K)

Intro date/month/qtr. Apr. 2010 Apr. 2010 Apr. 2010 Apr. 2010 Apr. 2010

Project Start date

Key Distrubution Channel/s MM, BG, CH, TS MM, BG, CH, TS MM, BG, CH, TS MM, BG, CH, TS MM, BG, CH, TS

Type Classification Small Screen Small Screen Small Screen Large Screen Large Screen

Sizes 24W 26W 32W 37W 40W

Chassis platfrom MT62F MT62F MT62F MT62F MT62F

Styling

F11 F11 F11 F11 F11

Panel Type LCD LCD LCD LCD LCD

BLU CCFL CCFL CCFL CCFL CCFL

Resoulution FHD HD FHD FHD FHD

60Hz/120Hz 60Hz 60Hz 60Hz 60Hz 60Hz

Contrast Ratio Supplier to specify Supplier to specify Supplier to specify Supplier to specify Supplier to specify

Brightness 400nits or Less 400nits or Less 400nits or Less 400nits or Less 400nits or Less

View Angle Supplier to specify Supplier to specify Supplier to specify Supplier to specify Supplier to specify

Anti reflex coated glass Supplier to specify Supplier to specify Supplier to specify Supplier to specify Supplier to specify

Dynamic Contrast Yes Yes Yes Yes Yes

Light sensor Yes Yes Yes Yes Yes

Backlight Control Yes Yes Yes Yes Yes

Anlogue/Digital 2 in 1 2 in 1 2 in 1 2 in 1 2 in 1

MPEG2 Yes Yes Yes Yes Yes

MPEG4 Yes Yes Yes Yes Yes

DVB-T/ T2/ C frontend DVB-T/C DVB-T/C DVB-T/C DVB-T/C DVB-T/C

DVB-S/S2 No No No No No

MHEG 1.06 No No No No No

CI(PCMCIA) Yes Yes Yes Yes Yes

CI+ Yes Yes Yes Yes Yes

OAD Yes Yes Yes Yes Yes

DVBT CVBS output Yes Yes Yes Yes Yes

Comb Filter 3D 3D 3D 3D 3D

De-interlacing 3D 3D 3D 3D 3D

Sound Output 2 X 3W 2 X 3W 2 X 5W 2 X 5W 2 X 5W

No of Speakers 2 2 2 2 2

Mono/Stereo/BBE Stereo Stereo Stereo Stereo Stereo

MEMC No No No No No

Teletext Teletext 1.5 Teletext 1.5 Teletext 1.5 Teletext 1.5 Teletext 1.5

No of pages(Teletext) 1000p 1000p 1000p 1000p 1000p

Close Caption No No No No No

HD Video Playback Yes Yes Yes Yes Yes

MP3 Playback Yes Yes Yes Yes Yes

Photo viewer Yes Yes Yes Yes Yes

OSD Languages

English, Spain, French,

German, Italy, Czech,

Croatian, Danish,

Hungarian, Dutch,

Norwegian, Polish,

Portuguese, Romanian,

Slovak, Slovenian,

Serbian, Finnish, Swedish,

Turkish, Greek, Bulgarian,

Russian,Latvian,Lithuania

n,Estonian,

Ukrainian

English, Spain, French,

German, Italy, Czech,

Croatian, Danish,

Hungarian, Dutch,

Norwegian, Polish,

Portuguese, Romanian,

Slovak, Slovenian,

Serbian, Finnish, Swedish,

Turkish, Greek, Bulgarian,

Russian,Latvian,Lithuania

n,Estonian,

Ukrainian

English, Spain, French,

German, Italy, Czech,

Croatian, Danish,

Hungarian, Dutch,

Norwegian, Polish,

Portuguese, Romanian,

Slovak, Slovenian,

Serbian, Finnish, Swedish,

Turkish, Greek, Bulgarian,

Russian,Latvian,Lithuania

n,Estonian,

Ukrainian

English, Spain, French,

German, Italy, Czech,

Croatian, Danish,

Hungarian, Dutch,

Norwegian, Polish,

Portuguese, Romanian,

Slovak, Slovenian,

Serbian, Finnish, Swedish,

Turkish, Greek, Bulgarian,

Russian,Latvian,Lithuania

n,Estonian,

Ukrainian

English, Spain, French,

German, Italy, Czech,

Croatian, Danish,

Hungarian, Dutch,

Norwegian, Polish,

Portuguese, Romanian,

Slovak, Slovenian,

Serbian, Finnish, Swedish,

Turkish, Greek, Bulgarian,

Russian,Latvian,Lithuania

n,Estonian,

Ukrainian

PIP/PAT/PAP/PIC/PAC PAT/PAP PAT/PAP PAT/PAP PAT/PAP PAT/PAP

Color tone adjustment No No No No No

Switch on Time 8 seconds 8 seconds 8 seconds 8 seconds 8 seconds

PVR Yes Yes Yes Yes Yes

OAD Yes Yes Yes Yes Yes

12V\24V DC input No No No No No

ECO NO NO Yes Yes Yes

Build-in IB NO NO NO NO NO

PC capability (up to maximum format)

WXGA WXGA WXGA WXGA WXGA

Rear CVBS in 1 1 1 1 1

Rear CVBS out No No No No No

Rear YPbPr 1 1 1 1 1

Rear HDMI 2 2 2 2 2

Audio Output No No No No No

SCART 1 Yes Yes Yes Yes Yes

SCART 2 No No No No No

PC Input Yes Yes Yes Yes Yes

SPDIF coaxial coaxial coaxial coaxial coaxial

Headphone jack Yes(PC Input) Yes(PC Input) Yes(PC Input) Yes(PC Input) Yes(PC Input)

Ethernet (RJ-45) No No No No No

Jack audio in 3.5mm Yes Yes Yes Yes Yes

USB connector No No No No No

Side CVBS in No No No No No

Side HDMI 1 1 1 1 1

Side Headphone 1 1 1 1 1

Side USB Yes Yes Yes Yes Yes

No of keys 6 6 6 6 6

Front/Side Side Side Side Side Side

Front Cabinet HG spray paint HG spray paint HG spray paint HG spray paint HG spray paint

Back Cabinet As Moulded As Moulded As Moulded As Moulded As Moulded

DVD slot in No No No No No

Remote control TBD TBD TBD TBD TBD

Table Top Stand Yes Yes Yes Yes Yes

Hard switch

No No No No No

Swivel Stand No No Yes Yes Yes

Voltage Range 230V 230V 230V 230V 230V

Standby Power < 1W < 1W < 0.3W < 0.3W < 0.3W

VESA Mount Yes Yes Yes Yes Yes

Desination Whole Europe Whole Europe Whole Europe Whole Europe Whole Europe

Confirmed

by:

PP-Wu Zhe RBC-Wang Xulin HW-Cai Haoyong SW-Chen Qiang MD-Liu Yadong

Side

Connectivity

Local

Keyboard

Mechanical

Misc

Market

Set Level

Panel Level

Front End +

Digital

requirement


Sound

Feature

Rear

Connectivity

ONLY FOR TCL AOE

MM, BG, CH, TS

Large Screen

40W

MT62F

LCD

CCFL

FHD

60Hz

Supplier to specify

400nits or Less

Supplier to specify

Yes

2 in 1

DVB-T/C

Yes

2 X 3W

2 X 5W

Stereo

Teletext 1.5

Yes

English, Spain, French,

German, Italy, Czech,

Croatian, Danish,

Hungarian, Dutch,

Norwegian, Polish,

Portuguese, Romanian,

Slovak, Slovenian,

Serbian, Finnish, Swedish,

Turkish, Greek, Bulgarian,

Russian,Latvian,Lithuania

n,Estonian,

English, Spain, French,

German, Italy, Czech,

Croatian, Danish,

PIP/PAT/PAP/PIC/PAC

Color tone adjustment

Switch on Time

PC capability (up to maximum format)

Rear CVBS in

Rear CVBS out

ONLY FOR TCL AOE

Yes

DVB-T/C

Yes

2 X 5W

Stereo

Teletext 1.5

1000p

Yes

Norwegian, Polish,

Portuguese, Romanian,

Slovak, Slovenian,

Serbian, Finnish, Swedish,

Turkish, Greek, Bulgarian,

Russian,Latvian,Lithuania

n,Estonian,

Ukrainian

English, Spain, French,

German, Italy, Czech,

Croatian, Danish,

Hungarian, Dutch,

Norwegian, Polish,

Turkish, Greek, Bulgarian,

Russian,Latvian,Lithuania

PAT/PAP

8 seconds

Yes

WXGA

Rear CVBS out

Audio Output

SCART 1

SCART 2

Ethernet (RJ-45)

Jack audio in 3.5mm

USB connector

Side CVBS in

Side HDMI

Side

Connectivity

Local

ONLY FOR TCL AOE

Yes

Serbian, Finnish, Swedish,

Turkish, Greek, Bulgarian,

Russian,Latvian,Lithuania

English, Spain, French,

German, Italy, Czech,

Croatian, Danish,

Hungarian, Dutch,

Norwegian, Polish,

Portuguese, Romanian,

Slovak, Slovenian,

Serbian, Finnish, Swedish,

Turkish, Greek, Bulgarian,

Russian,Latvian,Lithuania

n,Estonian,

English, Spain, French,

German, Italy, Czech,

Croatian, Danish,

Hungarian, Dutch,

Norwegian, Polish,

Portuguese, Romanian,

Slovak, Slovenian,

PAT/PAP

8 seconds

Yes

WXGA

coaxial

Yes(PC Input)

Side Headphone

No of keys

Front/Side

Front Cabinet

Back Cabinet

DVD slot in

Remote control

Table Top Stand

Hard switch

Swivel Stand

Voltage Range

Standby Power

VESA Mount

Confirmed

by:

Mechanical

Misc

ONLY FOR TCL AOE

Zhe

数字签名人Wu Zhe

DN㸸cn=Wu Zhe，c=<

无>，o=TMT，ou=GPC

PP，email=wuzhe@Tcl.

com

日期㸸2009.11.10

15:48:43 +08'00'

王盱林(wangxulin

)

数字签名人王盱林(wangxulin)

DN：cn=王盱林(wangxulin)，ou=Shenzhen，dc=com

日期：2009.11.11

09:44:44 +08'00'

2009.11.1

1 09:56:03

+08'00'

2009.11.1

1 09:58:48

+08'00'

2009.11.1

1 10:11:07

+08'00'

Factory Alignment Specification of normal SIACP

Page 1 of 19

TCL WW R&D

FPD CENTER

Factory Alignment Specification of normal SIACP

For MT5362 serial

Version˖V0.2

For the following Chassis˖

MT62L:A mini edition of MT62B

MT62S: MT62B + MS6M20(MEMC module) for super slim LCD

MT62F:A full function edition of MT62B

PREPARED BY : Wei Lin DATE : 2010-04-16

APPROVED BY : DATE :

Factory Alignment Specification of normal SIACP

Page 2 of 19

Disclosure

The information contained in this document is proprietary to TCL SZ FPD lab and shall not be

disclosed by the recipient to third persons without the written permission of the team leader or

GM of R&D.

Revision History

Status, Ver Date, Drafter Description of changes

V0.10 2010-02-07 This is the first version of normal SIACP

gHDMI as the main absolute input

gThe password of factory menu is 9735

V0.20 2010-04-14 gUpgrade specs for High Pot. and Insulating Resistance Tests

gUpgrade USB upgrade SW method

Factory Alignment Specification of normal SIACP

Page 3 of 19

These chassises are designed for European LCD TV with MPEG4. The main chip is from

Mediatec (MT5362 series) and supports below inputs and outputs:

class item MT62L MT62S MT62F

ATV

( PAL B/G D/K I, SECAM B/G D/K

L/L)

¥¥¥

DTV

(DVB-T,DVB-C,DVB-S)

DVB-T DVB-T

DVB-C

DVB-T

DVB-C

DVB-S

HDMI

(480i/p, 576i/p, 720p up to

1080i/p, compliant v1.2. with

HDCP)

2 5 3

VGA ¥¥

VGA/DVI audio ¥Share with

CMP

(YPrPb can support from 480i up

to 1080p,audio)

¥¥¥

SCART1

(CVBS & RGB,audio)

¥¥¥

SCART2

(CVBS & YC,audio)

Side AV or back AV

(CVBS,audio)

Back

USB player

(picture,video,audio)

Picture Picture,

Video,

audio

Picture,

Video,

audio

SCART1 output

(CVBS,audio)

¥¥¥

SCART2 output

(CVBS,audio)

Headphone output ¥

SPDIF output Coaxial Optical Coaxial

input

output

MEMC ¥

CI+ ¥¥

function

Serial connector P5 P16 P3

Others I2C connector of MEMC module PM3

Serial connector of MT5362 definition:

Pin1:VCC Pin2:RXD Pin3:TXD Pin4:GND

I2C connector of MEMC definition:

Pin1:VCC Pin2:GND Pin3:SCL Pin4:SDA

Factory Alignment Specification of normal SIACP

Page 4 of 19

INFO:

ªAll tests and measurements mentioned hereafter have to be carried out at a normal mains voltage

(220 ~ 240 VAC)

ªAll voltages have to be measured with respect to ground, unless otherwise stated

ªAll final tests have to be done on a complete set including LCD panel in a room with temperature of

25+/-7°C

ªThe White Balance (color temperature) has to be performed into subdued lighted room after at

least 1 hour of warm-up/burn-in. This is applicable for both Alignment and Picture Performance

evaluation at OQA in order to be set free of any temperature drift ( colorimetry vs time)

1. Electrical Assembly Alignment

1.1. Preconditions – DC/DC Check

Before power on, please check the board according to the relevant block diagram and circuit

diagram, and make sure that no serious error should destroy the board. For example,the output

of DC/DC and LDO should not shorted to ground.

Supply a suited voltage and power on , then check the voltage according to the relevant

block diagram , circuit diagram and voltage spec . the error should less than 5% .For example,

the voltage for main chip(DV33, AV33,DV18,DV11,etc.), the voltage for DDR (DDRV) , the

voltage for amplifier(AUDIO_PWR),etc. Only the standby voltage is necessary if there is no

software in the flash .

1.2. SW download

Download the latest release MT62_SW into the flash using MTK SW tool. See Appendixo

“How to download FLASH SW”. Or upgrade the SW from USB port See Appendixp” How to

upgrade FLASH SW from USB”.

Download the latest release MEMC_SW (skip this step if no MEMC module on the chassis).

See Appendixs“How to download FLASH SW for MEMC module”.

1.3. Panel ID check and modify

There is different ID stored in the NVM depended on different Panels. Modify it with Hyper

terminal if the initial ID or a wrong ID make the set can not display clearly. See Appendixr. It can

be checked and modified in Factory menu->Feature->Panel ID if the set can display clearly .

The set should be restart if the panel ID is changed .

1.4. Functional Test

Once the boards (chassis, KB, IR, PSU…) and the panel are well interconnected, connect all

external generator devices to relevant inputs/outputs below according to their respective test

patterns format and check picture content and sound quality accordingly:

Source Test signal (generator) Test pattern (format/image)

Analog /Digital Tuner RF cable Full Band (VHF/UHF) + CATV

DVB-T

Composite(CVBS) Chroma/Fluke PAL Half Color & Gray bars

SCART1 (CVBS)

SCART1 (RGB)

Chroma/Fluke PAL Half Color & Gray bars

Half Color & Gray bars

SCART2 (CVBS)

SCART2 (Y/C)

Chroma/Fluke PAL Half Color & Gray bars

VGA Chroma/QuantumData 1024x768@60Hz

Factory Alignment Specification of normal SIACP

Page 5 of 19

Half Color & Gray bars

CMP (YPrPb) Chroma/QuantumData 1080i@60Hz

Half Color & Gray bars

HDMI DVD with HDMI compliancy Movie 720p@60Hz

Headphone RF cable First channel

Loud Speakers RF cable First channel

SCART1 (CVBS out) RF cable First channel

SCART2 (CVBS out) Chroma/Fluke PAL Half Color & Gray bars

Audio tones can be defined by the factory (ie: 1KHz & 3KHz, sweep, …).

Picture video formats can be changed by the factory according to their own standard.

1.5. ADC Calibration

To ensure the ADC performance, the error of “generator+cable” must be less than 2%. The

following inputs require an ADC calibration for the time being.

VGA(skip this step if no VGA input on the chassis)

Provide a test signal 1024×768@60Hz with WhiteBlack squares.

Select the corresponding FactoryMenu-> ADC Calibration-> Auto Color , then press !OK!

key on RemoteControl to start. Value of status will change to "OK! if succeed.

CMP

Provide a test signal 720p@60Hz with 100% 8 steps ColorBar.

Select the corresponding FactoryMenu-> ADC Calibration-> Auto Color , then press !OK!

key on RemoteControl to start. Value of status will change to "OK! if succeed.

Scart RGB

Provide a test signal PAL 576i with 100% 8 steps ColorBar.

Select the corresponding FactoryMenu-> ADC Calibration-> Auto Color , then press !OK!

key on RemoteControl to start. Value of status will change to "OK! if succeed.

The mean of status value:

"NONE!= no input is successful in ADC calibration.

"OK!= current input is successful in ADC calibration.

"NOK!= current input is fail in ADC calibration.

"ALL!= all inputs required are successful in ADC calibration.

R Gain, G Gain, B Gain, R Offset, G Offset, B Offset in FactoryMenu-> ADC Calibration

page can be fine-tuned if necessary but not required.

1.6. DDC & EDID Test

The E-EDID data structure are according to VESA Enhanced EDID 1.3 (and EIA/CEA-861B for

HDMI).

Both VGA and HDMI have their own separate bin files:

For EDID check, it#s needed to check whether the correct EDID is downloaded by checking

corresponding EDID NVM Checksum or read them out to check bit by bit if it is in line with the

released EDID bin file.

1.7. HDCP Test

For HDCP compliancy, it#s needed to check whether the HDCP key has been well set.

Factory Alignment Specification of normal SIACP

Page 6 of 19

1.8. CI+ Key activation and test(This step is only for the models with CI+ function )

Select factory menu-> Update CI+ Credential-> Update CI+ Credential , then press !OK! key

on RemoteControl to active the CI+ KEY. The Valid(CI+ state) state turn to "Yes! and Cus

Code(Custom Code), Serial Num display if succeed. Download the CI+ Key and try to active it

again if fail.

2. Final Assembly Alignment

2.1. FactoryMenu

Follow the below steps to pop-up the Factory Menu in case of "FactoryKey! is disable:

- press RemoteControl key "MENU! to display main menu

- Select "Picture! and press "OK! key to enter the picture submenu

- Select "Contrast! item

- press the subsequence RemoteControl keys "9!, "7!, "3! and "5!

Press RemoteControl key "Blue! To pop-up the Factory Menu in case of "FactoryKey! is

enable.

The status of "FactoryKey! can be changed in FactoryMenu->System-> FactoryKey

Press RemoteControl "OK! key or "RIGHT! key to enter the submenu.

Press RemoteControl "Menu! key to go back to the root menu.

Press RemoteControl "RIGHT!or "LEFT! key to change the values.

Press RemoteControl "OK! key run the function.

Press RemoteControl "Exit! key exit the factorymenu.

2.2. Entering to “P” Mode

Turned on the factory key to enter into “P” mode.The TV will display “P” in bottom left corner

in “P” mode.

2.3. White Balance Alignment

Make sure that the picture mode is “vivid!, enter to “P” mode(turned on the factory key) and

switch off “Pic. Enhance” in Factory Menu-> WD Alignment before white balance alignment .

VGA,CMP,SCART RGB,DTV,CVBS_PAL Color Coordinates are relative to HDMI.

CVBS_SECAM and CVBS_NTSC Color Coordinates are relative to CVBS_PAL.

Warm and Cool Color Coordinates are relatives to Normal mode.

Only HDMI(YUV 720p@60Hz) input requires color temperature adjustment. All the Relative

Matrix Offsets should be set while doing alignment.

Expected Targets and Tolerances

The measured parameters should be “x, y” coordinates.

The White Balance alignment should be performed using a contact less analyzer (ei: Minolta

CA-210). The analyzer may not touch the screen surface, and measurement must be performed in a

Factory Alignment Specification of normal SIACP

Page 7 of 19

dark environment keeping the probe(s) at 90+/-2° from the panel.

The result should measure up the relevant spec.

The alignment have to fulfill the requirements in Application Form.

Alignment FlowChart

Provide a test signal on the input and align the WB as described inside attached document

ensuring first that the BackLight value is matching below table:

MTK_EuroAlignmentF

lowchart.doc

2.4. High Pot. and Insulating Resistance Tests

At the end of the process, a High Pot. and an Insulating Resistance tests are required for

matching Safety Electrical requirements (ei: xxxx)

High Voltage Withstanding requirements

- “Voltage” Ö3500 VAC

- “Max Leakage Current” Ö10 mA

- “Test Time” Ö5 sec

Insulating Resistance requirements

- “Voltage” ÖDC500V

- “Threshold Max” Ö

- “Threshold Min” Ö4M¡

- •Test Time• Ö3 sec

3. Factory default settings

Do the •Reset shop• before packing.The detail of reset shop follow OOB setting.

Factory Alignment Specification of normal SIACP

Page 8 of 19

“Factory Menu” Definition

1)ˊSystem

Item Sub-item Value Note

Factory Key Off/On OFFġhotkey is invalid

ON ġhotkey(blue key) is availability

Power Mode Boot/Standby/

Last Status

Boot: Enter power on mode

Standby: Enter standby mode

Last Status: power on according to last

status

Burning Mode Off/On Select panel On with left/right key, Press

“EXIT” key to enter the burning mode;

Press “Menu” key on keyboard to exit the

burning mode

Pre-Frequency Poland Run Press “OK” key to run

Pre-Frequency Huizhou Run Press “OK” key to run

Pre-Frequency Thailand Run Press “OK” key to run

Reset User Clear date of NVM in user menu,except

the value of language / related

installation/Factory setting,then set to the

default value.

Reset All clear NVM valuesˈand set to default

valueǄ

System

Reset Shop Clear date of NVM in user menu,include

the value related installation,and Clear

date of factory menu except the item of

Balance and sound ,set to default value

2)ˊFeature

Item Sub-item Value/Sub-item Note

FleshTone Off/On

Adaptive Luma Control Off/On

Light sensor Off/On Some models have have no

this feature.

Auto/Low/Mid/High

(it should be “On/Off

“ in 26 inch and

smaller ones)

Set the backlight mode

Backlight Low Set the backlight value of Low

mode

Backlight Mid Set the backlight value of Mid

mode

Backlight High Set the backlight value of High

(or Off) mode

ADP low control point Set the low point in dynamic

backlight control curve

Feature

Adaptive Backlight

ADP mid control point Set the mid point in dynamic

Factory Alignment Specification of normal SIACP

Page 9 of 19

backlight control curve

ADP high control point Set the high point in dynamic

backlight control curve

White Peak Limitator Off/On

TunerAGC -44~127

Project ID ID Select panel ID with left/right

key, restart the set to take

effect.

In MT62F and MT62S chassises:

There is no “Adaptive Backlight” item, “Auto/Low/Mid/High” “Backlight” “ADP low control

point” “ADP mid control point” “ADP high control point” are in the “feature” page. There is

only “Backlight” item instead of “Backlight Low” “Backlight Mid” “Backlight High”. It set the

backlight value of current backlight mode.

3)ˊADC Calibration

Item Sub-item Value Note

Source HDMI,etc VGA\CMP\scart RGB require Calibration

Auto color Run Press “OK” key to run

Status NONE

/ NOK

/ OK

/ ALL

NONE:No source has been calibrated

NOK:Current source hasn#t been calibrated

OK: Current source has been calibrated

ALL:All sources have been calibrated

R Gain

G Gain

B Gain

R Offset

G Offset

ADC

Calibration

B Offset

For fine tune ADC manually.

4)ˊWD Alignment

Item Sub-item Value Note

Pic. Enhance ON/OFF Press “Right” key to switch off all of the

items in the feature submenu. This should

be done before white balance alignment.

If it#s off, the way to switch it on is to reset

user/shop or set on the features in

Feature sub-item manually.

Source HDMI,etc For balance source˖

HDMI,VGA,DTV,PAL,SECAM,NTSC,Scar

t RGB,CPM, HDMI

Color Temperature Normal

/Warm/Cool 

The value of Warm and cool is the offset

of Normal mode.

R Gain R White balance

Alignment

G Gain G White balance

Factory Alignment Specification of normal SIACP

Page 10 of 19

B Gain B White balance

R Offset R Gray balance

G Offset G Gray balance

B Offset B Gray balance

Scaling Brightness

Scaling Contrast

Scaling Saturation

Auto phase Run Press “OK” key toadjust the signal to

avoid the ripple in CMP source, it is not

necessary.

5)ˊSound

Item Sub-item Value Note

VOL_0 0

VOL_10 5

VOL_50 20

VOL_90 145

Sound

VOL_100 255

6)ˊVersion info

Item Sub-item Value Note

Project: ***

Panel: ***

MT62 Ver: ***

Date: ***

Version

info

MCU Ver: ***

7) ˊFactory Clone& User Clone (MT62S,MT62F have no this function now)

Select “Factory Clone” in the factory menu to ernter the factory clone menu

Item Sub-item Value Note

TV TO USB(Factory) DO Press “Right” key to copy the

data(WB,ADC,picture setting,etc) to USB

Fac Clone

USB TO TV(Factory) DO Press “Right” key to set the

data(WB,ADC,picture setting,etc) from

USB

Enter another password “6” “4” “0” “5” in “menu” -> “picture” -> “contrast” status to ernter the user

clone menu

Value Note

TV TO USB(user) DO Press “Right” key to copy the data(channel map,picture setting,etc)

to USB

USB TO TV(user) DO Press “Right” key to set the data(channel map,picture setting,etc)

from USB

Factory Alignment Specification of normal SIACP

Page 11 of 19

8) ˊUpdate CI+ Credential (only for the chassises with CI+ function)

Item Sub-item Value Note

Update CI+ Credential DO Press “OK” key to active the CI+ KEY

Update from USB DO Press “OK” key to download the CI+ KEY

from USB

Erase CI+ Credential DO Press “OK” key to erase the CI+ KEY

Valid Show the CI+ state

Cus Code Show the CI+ custom code

Update

CI+

Credential

Serial Num Show the CI+ serial number

Factory Alignment Specification of normal SIACP

Page 12 of 19

Appendix n“How to download MCU SW”

Prepare WT_MCU_ISP SW tool for update.

1. Connect the PC to the serial connector on board using a special serial device(USB or

COMx).

2. Provide the a correct voltage to the board.

3. Start “Weltrend MCU ISP.exe” and download the MCU SW. (please see file

Visio-ISPToolGuide_ver090.pdf)

Appendix o“How to download FLASH SW”

Prepare MTK SW tool for update.

1. Connect the PC to the serial connector on board using a special serial device (USB or

COMx).

2. Provide the a correct voltage to the board

3. Start “MTKTOOL.exe” application under MTKxx folder, and set the parameters as below

picture(notice:select MT836X chassiss):

4. Press “Browse” button to select the corresponding SW bin file to upload

5. Press “Upgrade” button to start downloading the SW and wait the gauge displayed “100%”

that means the SW has been successfully downloaded.

In the meanwhile, all operations such erasing flash and so… are parsed into the debug

window script.

6. Once the SW is downloaded, switch-off/on the chassis board and wait few seconds for

eeprom update.

See Appendixp” How to upgrade FLASH SW from USB”

Upgrade with loader:

1. Save the new software file(*.pkg) in the root directory of USB, and modify it’s name as

upgrade.pkg.

2. Plug in the USB when TV set is “power off” or “standby” (TV set should be on “standby” status

if using a touch sensing keyboard).

Factory Alignment Specification of normal SIACP

Page 13 of 19

3. Press down “power” key on keyboard, power on if it is on “power off” status , release the

“power” key 2~5 second later , the LED on IR board will flash after upgrade begin, the TV set

will start up if upgrade succeed.The LED is on but no flash if upgrade fail,check the set and

try again.

Upgrade without loader(The TV set should be able to display normally):

1. Save the new software file(*.pkg) in the root directory of USB, and modify it’s name as

upgrade.pkg.

2. Plug in the USB.

3. Upgrade the SW follow the indication display on the screen

Appendix r“Modify panel ID with Hyper terminal”

ķ. Connect the PC to the board using a special serial device (USB or COMx).

ĸ. Provide a correct voltage to the board

Ĺ. Save the password file “password for hyperTerminal.txt” to your computer.

'?07?䇗䆩䇈ᯢ

ᏆথᏗ?SDVVZRUGI

ĺ. Start HyperTerminal “HyperTrm.exe” in your computer.

Ļ. Fill the name.

ļ. Select the Com Port you are using.

Ľ. Set the items as below picture.

Factory Alignment Specification of normal SIACP

Page 14 of 19

Select “File->Save->” to Save the setting. Then start HyperTerminal “atsc.ht” in your

computer instead of step Ĺto Ľlater

ľ. Send the password.

Ŀ. Select the password file saved in your computer.

Factory Alignment Specification of normal SIACP

Page 15 of 19

ŀ. Under the folder “DTV>” enter “pmx.s.p +ID”,e.g.: pmx.s.p 102

See the panel ID in another document <Panel list for MT62>.

ྣ. Press “Enter”, the panel signal will be printed in the window

Factory Alignment Specification of normal SIACP

Page 16 of 19

Appendix s“How to download FLASH SW for MEMC module”

Prepare MSTAR SW tool for update:

Install the driver:CDM_Setup.exe

Save the MS_TV folder to your PC,

1. Connect the PC to the I2C connector on board using a special I2C device (USB or COMx).

2. Provide a correct voltage to the board.

3. Start “ISP_Tool.exe” application under MS_TV folder:

4. Press “config” button On the Menu to enter the corresponding page, change the ISP slave

address to “0x94” and confirm that if the Port Type is correct, correct it if not.

Factory Alignment Specification of normal SIACP

Page 17 of 19

5. Press “Read” button on the Menu to enter the corresponding page and Press “Read” button

on this page to load the software(*.bin) on your PC

6. Press “Auto” button on the Menu to enter the corresponding page

Factory Alignment Specification of normal SIACP

Page 18 of 19

7. Press “Conect” button on the Menu. A message will popup

to tell you the result. Press “OK” button to close the

message. If fail to connect with “Can’t find the Device

Type!! ” Message ,Check the hardware and parameters

setting of the ISP_Tool , Press “Dis Con” button , then

“Conect” button again, until it identify the flash memory IC.

8. Press “Run” button in the current page to download the software.”Pass” will display on the

right bottom corner if succeed.

This manual suits for next models

Table of contents

Other THOMSON LCD TV manuals

THOMSON

THOMSON LCD TV User manual

THOMSON

THOMSON L4218HD User manual

THOMSON

THOMSON L40M71A2 User manual

THOMSON

THOMSON 20LW052 User manual

THOMSON

THOMSON 32LB115 User manual

THOMSON

THOMSON LCD-IFC228 - annexe 1 User manual

THOMSON

THOMSON 30LB120S4 - annexe 1 User manual

THOMSON

THOMSON IFC228 User manual

THOMSON

THOMSON 42M61NF21 User manual

THOMSON

THOMSON 32FS6646 Installation guide

THOMSON

THOMSON 27LB120S4 - annexe 1 User manual

THOMSON

THOMSON 27LCDB03B User manual

THOMSON

THOMSON LB030 User manual

THOMSON

THOMSON 27LB125 User manual

THOMSON

THOMSON EFC031 User manual

THOMSON

THOMSON AV1 User manual

THOMSON

THOMSON 32LB030B5 User manual

THOMSON

THOMSON INTUITIVA User manual

THOMSON

THOMSON 27LM051B6 User manual

THOMSON

THOMSON 30L03B User manual

THOMSON

THOMSON DVD Player + TV Set + VCR User manual

THOMSON

THOMSON LCD12B User manual

THOMSON

THOMSON 32LB115B5 User manual

THOMSON

THOMSON SCENIUM 42LB330B5 User manual

Popular LCD TV manuals by other brands

Grundig

Grundig 22 VLE 8320 BG user manual

HANNspree

HANNspree ST321MBB user manual

FUNAI

FUNAI F20LCTE-A owner's manual

LG 22LD310 owner's manual

Samsung

Samsung 6 series user manual

Philips

Philips 19PFL3504D - 19" LCD TV user manual

Grunair

Grunair 32 VLE 725 G manual

Insignia

Insignia NS-55E560A11 Quick setup guide

Sharp

Sharp AQUOS LC-60E79U Specifications

Hitachi

Hitachi L19HP03U A Instructions for use

Panasonic

Panasonic SuperFlat CT-27SF26 operating instructions

Sony

Sony Bravia KDL-40W5100 Dimensions

LG 26LU55 specification

Linden Group

Linden Group L24HTV17a instruction manual

Philips

Philips 20PF5320 Specifications

Sharp

Sharp LC-24DFG6001K quick start guide

Sony

Sony BRAVIA KDL-52XBR2 operating instructions

Samsung

Samsung LT28D310EW/UF user manual

THOMSON 24FS3246 User manual

Popular LCD TV manuals by other brands
