THOMSON ICC17 User manual

GB
1
TV
DVD
Contents
Program Info (TV guide) 10
DVD menus 11
DVD remote control 12
Playback 13
Playback modes 14
Display and Sound 15
Preferred languages 16
Locking 17
Info Menus 18
direct access, repeat play
markers, audio, sub-titles, angles 19
rating limits, playback mode,
introscan, audio channel
Remote control unit: other equipment 20
Connections 21
TV menus 22
DVD main menus 23
Precautions 2
Switching on 3
Initial set-up 4
Language - Country - Auto set-up
Programme organisation 4
Command - Name - Delete
Completing set-up 5
Manual or subsequent set-up
Personalised settings and preferences
TV Remote control 6
Everyday use 7
Selecting and scrolling channels
Selecting connected equipment (AV)
Adjusting volume and cutting off the sound
Zoom - Displaying information
Locking the TV/DVD set
Turning theTV/DVD set off - List of channels - Time
Stereo/Nicam/Virtual Dolby sound 8
Teletext 9
The pages of this publication are printed on recycled paper.
This manual applies to several TV/DVD models. Some of the functions or settings may not be available on the model
that you have bought. Refer to the separate table to find out the main functions of the model that you have.
The optional functions are signalled by the following symbol: 
The model number of your TV/DVD is on a label at the back of the set, and on the cover of the user manual.
c17-GB-7L 9/10/00 9:46 Page 1

GB
2
TV
DVD
Precautions
• Safety
Ensure that the mains supply in your house complies with that
indicated on the identification sticker located at the back of your
set.
The TV/DVD’s components are sensitive to heat.The maximum
ambient temperature should not exceed 35° Celsius. Do not
cover the vents at the back or sides of theTV/DVD. Leave sufficient
space around it to allow adequate ventilation.
Moisture in rooms where the set is installed should not exceed
85% humidity. If you have to use the TV/DVD outdoors, do not
expose it to water from rain or splashing.
Moving it from a cold atmosphere into a warm one can cause
condensation on the screen (and on some components inside
the TV/DVD). Leave the condensation to evaporate before turning
the TV/DVD on again.
If you are away for a long period, switch the set off at the on/off
switch. Even when off, some components remain in contact with
the mains electricity supply. To completely isolate it you must
remove the plug from the mains supply socket.
During thunder storms, we recommend that you disconnect the
TV/DVD from the mains and aerial so that it is not affected by
electrical or electromagnetic surges that could damage it. For this
reason, keep the mains socket and aerial socket accessible so
they can be disconnected.
Immediately disconnect the TV/DVD if you notice it giving off a
smell of burning or smoke. You must never under any
circumstances open theTV/DVD yourself.You risk electrocution
if you do so.
The set is provided with adequate shielding to avoid the emission
of X-rays.Work by unqualified persons, modifications to the
high voltage or replacement of the tube by a model not complying
with the manufacturer’s recommendations may cause a sharp
increase in X-ray emissions. A set modified in this way no
longer meets the original specifications and should not be used.
Never open the player or any of its components. It can be
dangerous for you or for certain fragile components.You could
receive an electric shock or touch the laser beam.
Do not place your eyes close to the opening of the disc tray or any
other opening to look inside the player.
THOMSON multimedia is not liable if the TV/DVD is used
other than in accordance with this manual.
• Care
Clean the screen with a glass care cleaner and the rest of the set
with a soft cloth and neutral detergent. Regularly dust the vents at
the back and sides. Using solvents, abrasive or alcohol based
products risks damaging the TV/DVD.
If an object or liquid enters inside the appliance, unplug it
immediately and have it checked by an authorised technician.
• Demagnetization
The appearance of patches of colour on the screen is generally
caused by a disturbance in the earth’s magnetic field.To get rid of
the effect, switch the TV/DVD off at the on/off switch and switch
it on again after a few minutes.
• Discs
Always...
• handle your discs with care. Hold a disc with fingers on the
border or hole,
• place disc with the label facing upward (in case of a single-
sided disc),
•
place the disc properly into the tray using the proper guide
area,
• use a soft cloth to clean discs if necessary, wipe from the
centre to the border,
• always put discs back into their cases after playing and store in
a vertical position.
V
i
d
e
o
D
i
s
c
T
h
o
m
s
o
n
D
i
g
i
t
a
l
If you hear strange noises or vibrations coming out of the unit
once a disc has started to play, rapidly press the STOP key of the
remote control or front of player.
Never...
• never close the tray with two discs on it or with a disc
slipping out of the guide area,
• never play cracked, chipped or deformed discs nor try to
repair them with adhesive tape or glue,
• never write on the disc,
•
never move the player during playback,
• never scratch discs or store them in places of direct
sunlight, high humidity or high temperature,
• never try to play a Photo CD or CD-R in this player,
•
never use record cleaning sprays, benzine, static electricity
liquids or any other solvent, if the disc surface is dirty.Wipe
gently with a soft damp (water only) cloth, never wipe the
disc in a circular motion, since circular scratches are likely to
occur and could cause noise during playback.
c17-GB-7L 9/10/00 9:46 Page 2

GB
3
TV
DVD
More info...
Switching on
Follow the instructions on this page to use your TV/DVD set and the remote control unit before entering the channel set-up
procedure described on the next page.
Mains socket in
continental Europe
220 - 240 V ~ 50 Hz
-
+
SIZE AAA 1,5 V 0%MERCURY
GREENELL
EXTRA HEAVY DUTY
-
+
SIZE AAA 1,5 V 0%MERCURY
GREENELL
EXTRA HEAVY DUTY
Equipment for the UK is supplied with a
mains cable fitted with a moulded plug.
The plug contains safety components
and must not be replaced by a type sold
in shops. It is fitted with a fuse that
protects your TV/DVD. If your set no
longer works, the fuse may have blown.
If it has, replace it with an identical
ASTA certified or BSI (BS 1362) 5 amp
fuse.
5A
MAINS PLUG:
The mains plug carries the power supply to your TV/DVD set. It
should only be connected to an AC supply at 220 - 240 V ~ 50 Hz.
It must not be connected to a DC supply. If the plug is detached
from the cable, do not under any circumstances connect it to a
mains socket as there is a danger of electrocution.
AERIAL SOCKET: (75 Ohms - VHF / UHF / cable)
The aerial socket, located at the back of the TV/DVD set, enables the
connection of an external aerial or one from another item of equipment
fitted with a modulator (video recorder, satellite receiver, etc.).
UK SOCKET
Please respect the environment and prevailing
regulations. Before you dispose of batteries or
accumulators, ask your dealer whether they are subject
to special recycling and if he accepts to take them back.
13 2
+
+
–
–
INSERTING THE BATTERIES:
Put the batteries in the remote control unit.
Connect the TV/DVD to a mains socket.
Connect the outside aerial or cable network to the gsocket at the
back of the TV/DVD set.
We recommend that you do not initially connect other equipment to your TV/DVD
(VCR, decoder, etc.) so as not to complicate the set-up procedure with additional factors.
Connect them up when you have finished setting up the channels by referring to page 21 of
the manual .
NexTView-Link video recorder (see diagram at the end of this user manual)
If you have a NexTView-Link video recorder, you must connect it to the AV1 socket of the
TV/DVD set by means of a SCART cable (21 pins, all wired) before proceeding to the initial
set-up described on page 4.
Turn the TV/DVD on by pressing the on/off button AA.
The first time you turn the TV/DVD on, the language choice menu appears.
Continue on page 4 for a Initial set-up or on page 5 to update
channels if the TV/DVD has already been set up.
Connecting other equipment to the AV (AudioVideo) sockets is detailed on page 21. Before
referring to it, complete the initial set-up (next page) so as to avoid any problems with
selecting the equipment.
2
1
3
4
5
c17-GB-7L 9/10/00 9:46 Page 3

GB
4
TV
DVD
 Languages and countries:the list of languages
and countries depends on the model.
Decoder:If you have connected a decoder to the AV 1
socket, after the initial set-up you should display the Manual
installation menu and confirm the Decoder option. Refer to
page 5.
Missing channels:channels are searched for according to the
country selected, refer to the Manual set-up chapter to set up
channels that have not been found.
For cable networks, if some channels have not been found, select
Other instead of the country and re-start an Auto update.
Subsequent set-ups:display the INSTALLATION SUMMARY (see
page 6) and choose Auto update or Auto installation as
appropriate. Then follow the instructions at the foot of the screen.
• Auto update enables you to set up channels just on-air or add
to your set-up if some channels are missing or wrongly
set up.
•Auto installation is used for setting up after the initial set-
up (e.g. after moving house).
It deletes all channels previously memorised. To set up a new
channel, it is better to use Auto update or Manual
installation.
Programme organisation: at the Initial set-up,
your TV/DVD searched for channels, giving them a number
and name according to the country chosen. The
PROGRAMME ORGANISATION menu enables you to
alter these settings. You are able to name channels whose
name has not been found, change the sequence of channels
and delete channels that are duplicated or of poor quality.
Follow the instructions at the foot of the screen. Identify
channels with the help of a TV programme guide.
• Organising your channels: select the Select program. line.
Look for the channel that you want to assign the number 1 to with
the pr +,pr - or keys,using the channel logos to help you.
The number already assigned appears on the Select program.
line. Select the Swap with PR line, key in 01 and press ok.The
channel goes to first position: the two channels are switched.
Continue for the other channels.
• Deleting a channel: select the Select program. line and
scroll your channels with the pr + and pr - or keys.When
you get to a channel to be deleted, select Delete program., and
press ok.
• Changing the name: select the Change pr. name line and
choose the character to be altered with the keys. Scroll the
alphabet with the 1 and 2 keys.The name will be changed when
you change line or leave the menu.
The TV/DVD you just bought must be configured to receive the channels of your area. The first set-up allows you to adjust the
settings required for the search and storage of all the channels you can receive. The first set-up also enables you to choose the
language which will be used forTV menus, as well as for DVD menus, dialogues and subtitles.Power theTV/DVD set with the On/Off
switch A located at the front and scrupulously follow the steps 1 to 7 of this page.
More info...
Initial set-up
Choose the language from the menus with the or keys.
Confirm with . A list of countries appears.
Choose the country with the or keys.
This is the country you are in, or the country whose channels you want to receive if you live near its
borders.
Confirm with . A welcoming message appears.
Start auto set-up by pressing .
The menu that appears tells you how set-up is progressing. Wait for the end of set-up message
before leaving the menu, otherwise the channels will not all be memorised. Depending on the
number of channels you want to receive, auto set-up can take up to 10 minutes.
According to the country you chose in step 3, the TV/DVD will scan
channels in a pre-set order. If you want to alter this list, to name or re-name
your channels or delete channels memorised twice, press and follow
the instructions in Programme organisation.
If you do not want to reorganise your channels, leave the menu with the
exit key and refer to everyday use on page 6.
ok
ok
ok
ok
When your TV/DVD is first switched on, the language choice menu
appears (1). If it does not appear, put the TV/DVD into stand-by by
pressing the
BB
key on the remote control unit. Press the pr - key for
several seconds until the menu appears.
or
The language chosen during step 1 is automatically selected for the DVD part. Nonetheless, you may
customise the DVD part (menus, dialogues, or subtitles language - on-screen display - rating limit): see
pages 15 to 17.
2
1
3
4
5
6
7
1
COUNTRY SELECTION
Return
BB
United Kingdom
E re
France
Germany
Italy
Spa n
Portugal
Holland
Belg um and Luxembourg
Sw tzerland
Austr a
……
Other
BB
English
França s
Deutsch
Ital ano
Español
Português
Nederlands
Svenska
Dansk
Norsk
……
……
2
5
BB BB
OK
BB
BB
BB BB
OK
BB
BB
SEARCHING
AUTO INSTALLATION
•••••••••••••••••••••
03 STATIONS FOUN
Auto programm ng your TV set.
Please wa t. To cancel press EXIT.
c17-GB-7L 9/10/00 9:46 Page 4

GB
5
TV
Completing set-up More info...
The settings on this page will be useful if you find that some channels have not been memorised on initial set-up or auto update.
This can happen if you set channels up from a cable network. Setting up channels manually requires every setting for every
channel to be entered, one at a time.
Standard: choose the standard for your country.
The choice of standards varies according to the model of TV/DVD: France for France and
Luxembourg, DKK’ for Eastern Europe and the Middle East, UK for the United Kingdom and
Eire, Euro BG for Western Europe.
Reception: choose the channel reception method (terrestrial aerial or cable
network).
Some cable networks use the same frequencies as land based transmissions. If this is the case, select
Aerial instead of Cable.
Autosearch: key in the channel programme number or start a search with the
or keys.
Your TV/DVD will stop at the first channel found. If you want to memorise the
corresponding channel, select the Store on PR number line. Otherwise, continue
the search using the or keys.
Fine tuning: if the picture is not sharp, try to improve it with the or keys.
Store on PR number: to confirm your settings, key in the number that you want
to assign to the channel (e.g. 01 for BBC1). Memorise it with ok.
Name: if the channel is recognised, its name is detected automatically, otherwise
change the name suggested or enter a name. Select the character to be altered with
the or keys.
Scroll the alphabet with the 1 and 2 keys. Change character with the or keys
and start again from stage 5 above.
Decoder: if the channel is encrypted and if you want to connect a decoder to the
AV1 socket (see page 21), tick the box with the or keys and start again at
stage 5 above.
External sound path: turn your decoder on. If the sound is scrambled or if there
is no sound, change the setting (box ticked or not) with the or keys and
start again at stage 5 above.
Leave the menu with exit.
Personal settings: display the INSTALLATION SUMMARY by
holding down the tv menu key on the remote control unit. Select
Personal settings. Confirm with ok. Follow the instructions at the
foot of the screen to choose:
• Menu language: choose your language.
The language chosen in the TV part will automatically be
selected for the DVD part.
• Country: The choice of country is important for the correct
display of Teletext screens in the corresponding language.
• Auto volume level: check the box if you want to keep the
same sound level on all channels.
• AV1 name, AV2 name, AV3 name: give a name to the
socket according to the equipment that you are connecting to
it. Choose the character to be altered with the or . keys.
Using the 1 or 2 keys, display the character you want.
• Programme for reference time: select the Programme for
reference time line and scroll the channels with the or
keys until the time and date are displayed below the channel
number. Setting the time is only possible with channels
broadcasting Teletext.When the time is set you can display it
with the info key.You can also use theWake up timer function.
Leave the menu with exit.
PREFERRED SETTINGS:display the SUMMARY by pressing the
tv menu key on the remote control unit. Select Preferences.
Confirm with ok.
• Show PR. number: tick the box to permanently display the
number of the channel you are watching.
• AV2 video input: configure the socket according to the
equipment connected (Video or S-Video input signal).
• AV3 video input: configure the socket according to the equipment
connected (sockets located at the front or side of the TV set).
• Format control: choose the format for the on-screen picture.
Auto:theTV/DVD (16/9) adapts to the broadcast picture
format if the broadcaster or equipment connected via a
Euro-AV (scart) socket provides a control signal.
16/9 or 4/3: choose the format if the picture is not
automatically adapted.The format returns to auto if you
change channel or switch off the TV/DVD set.
 • Auto zoom: Allows one to activate (box ticked off) or to
deactivate (box not ticked off) the Auto zoom option related
to the picture formats which can be chosen with the Zoom
keys (see page 7).
• Catching priority:Tells the TV/DVD your priorities for data
searching when you change channel. If you select Teletext, the
TV/DVD looks as a priority forTeletext data.This allows a faster
display when you call up Teletext. Likewise for the TV guide.
Leave the menu with exit.
Display the INSTALLATION SUMMARY (see page 6) and select the Manual
installation line. Confirm with ok.Alter each of the settings in turn for the channel that
you want to memorise. Follow the instructions at the foot of the screen.
2
1
3
4
5
6
7
8
MANUAL INSTALLATION
Return
Standard EURO BG
Recept on Aer al
Autosearch <I
> CH--
F ne tun ng
Store on PR number: --
Name ----
Decoder 
External sound path 
c17-GB-7L 9/10/00 9:46 Page 5

TIME
Return
Sleep t mer <I> 00:00
Current t me 11:28
Wake-up t mer 
Wake-up t me 07:07
Programme number 08 EURO
Da ly 
SUMMARY
Ex t
Program Info
Sound
P cture
B Time
Preferences
Installat on
GB
6
TV
Your remote control can control several pieces of equipment. This page shows
you the functions of theTV part. For the DVD part,see page 12.To control other
equipment, see page 20.
The keyboard keys located on theTV/DVD frontside have similar functions to those
of the remote control, except for the OPEN/CLOSE key, which is only available on
the front of the player and enables you to open or close the disc drawer.
TV navigation Display the SUMMARY
by pressing the remote
control unit’s tv menu key
once. From the summary,
you are able to access
other menus (Sound,
Picture,Time, etc.) to set
up or use your TV/DVD.
Choose a menu.
Confirm your choice.
Choose a function.
Increase or decrease a
number or setting bar.
Enable or disable a function
by ticking a box .
Go back to the previous
menu by selecting Return
or leave the menus with
the exit key.
ok
tv
menu
exit
The other keys to control your television
To put your TV/DVD set in stand-by
mode.
Your remote control can control
other equipment, such as VCRs, Hi-Fi
units or satellite receivers.
To control your TV/DVD set, switch
the selector to the tv+dvd position.
To control other equipment, see page
20.
To switch from TV to DVD mode or
from DVD to TV mode.
IMPORTANT
If the batteries of your remote control are
exhausted, you can use the keys on the front of the
unit: they have the same functions as those of the
remote control.
tv dvd
vcr
tv+dvd
sat
hifi
Programmes
To switch from one programme to
another.
Choose a programme by entering its
number. For the 2 figure programme,
first type the 0 key (ex. 12, type 012).
Audio visual programmes
Choose an appliance which is
connected to the SCART socket or the
cinch socket:AV1,AV2,AV3.
23
654
78
9
1
0/--
r
r
av
Sound
Set the volume level.
This function is active in any position of
the function selector except the hifi
position.
Mute and re-establish the sound.
The colour keys
Call the sound and picture preset menu.
Display the list of programmes.
Display the name of the programme, the
time, the type of sound and the zoom.
On the channels which broadcast a
programme guide, information about
current programme.
Display the programme guide.
Display teletext.
The colour keys are also used for teletext operation.
list
info
text
info
text
info
text
TV Remote control
INSTALLATION SUMMARY Menu
Press the tv menu key of the remote
control: the SUMMARY menu appears.
Select the Installation line with the
or keys and confirm with ok.
The INSTALLATION SUMMARY menu
appears.
INSTALLATION SUMMARY
B Exit
Manual Installat on
Auto update
Auto nstallat on
Programme organ sat on
Personal sett ngs
c17-GB-7L 9/10/00 9:46 Page 6

Everyday use More info...
The explanations given on this page will enable you to adjust the image of your TV/DVD set and to program your device to alarm-
clock or self-stopping mode. The channel list will show you , by 10-channel pages, the channels stored in your TV/DVD set, and
will allow you to access them directly.
GB
7
TV
Display SUMMARY with the tv menu key and select the Sound,Picture or
Time menu. Confirm with ok.
SOUND
See page 8.
• Picture preset enables you to optimise the picture depending on the kind of
programme you are viewing (Film,Studio,Sport, Standard or Personal).
• Brightness,Colour,Contrast, and Sharpness adjust the picture to your
liking.These adjustments are enabled every time you choose Personal (see
above).
• Contrast expand adjusts the picture according to the surrounding brightness
(strong or weak).
• Tone adjusts the colour balance (warm, neutral or cold).
TIME
• Sleep timer sets an interval before the TV/DVD is automatically put into stand-by.
Set it to --:-- to cancel.
• Current time enables the time to be adjusted if it is not correct.
• Wake-up timer enables you to set the time at which you want to be woken
up by the TV/DVD.Tick the box to display the menu options. Key in the wake-
up time. Choose the channel that you want to wake you up.Tick the Daily
box for a daily wake-up call. Leave the menu with exit. Put the TV/DVD into
stand-by with the remote control unit’s BBkey.The TV/DVD’s red indicator
flashes.The TV/DVD comes on automatically at the programmed time. If you
do not use the remote control unit it goes off one hour later.
Locking the TV/DVD: It is possible to prevent the TV/DVD from being turned
on using the buttons on the set.The remote control unit is required for it to be
used.You can lock the TV/DVD in 3 ways:
• by pressing the remote control unit’s stand-by key BBfor more than 3 seconds,
• by programming an automatic stop sleep timer (see above),
• by putting it on stand-by after programming a wake-up time.
The flashing red “on” indicator indicates that the TV/DVD is locked. It can only be turned
on by the remote control unit. Press any number key on the remote control unit to unlock it.
Turning theTV/DVD on and off: the TV/DVD is turned on and off
by pressing the
AA
key on its front.A green indicator on the front
indicates that the TV/DVD is on.
Going to and from stand-by: switching the TV/DVD on standby is
performed with the key B on the remote control.This key allows you
to switch off your TV/DVD with the remote control.The status “on
standby” is signalled by the red indicator lamp on the front side
of the TV/DVD set.
To switch on your TV/DVD set again, press any of the remote control
number keys or the ok key.
When you control the TV/DVD with the remote control unit, the
indicator on the front flashes orange.This allows you to check that
the remote control unit is working and the condition of the batteries.
pr + and pr -: to choose a channel with the remote control unit or
with the TV/DVD (Pr 01, Pr 02,… Pr99, AV1,…).
Number keys: to choose a channel with the 1, 2, 3, etc. keys.
Zoom: on 16/9 models you are able to enlarge pictures broadcast
in 4/3 or letterbox format (black strips at the top and bottom of the
screen) so as to get rid of areas with no picture. First press exit if a
menu is on the screen and select the magnification required with
the or keys:
ZOOM 0 4/3 picture (black strips at the sides).
ZOOM 1 for pictures in letterbox centred on the
screen (without sub-titles).
ZOOM 1 (ST) for pictures in letterbox offset to see sub-
titles.
CINERAMA 4/3 picture Filling the screen.
ZOOM AUTO Automatic detection of widescreen
letterbox pictures and smooth adaptation
to fill the screen. (this option is offered if it is
validated in the Preferences menu, see page
5).
Display of information: pressing the info key displays on-screen
the number and name of the channel, the time, the zoom and type
of sound. If the channel you are currently watching broadcasts
Program Info, the name of the programme and its start and end time
will be displayed.
Sound and Picture preference: display the menu with the red
key, select the line wanted and adjust to your liking.
List of channels: press the list key on the remote control unit to
display the LIST. It contains 10 pages at most and gives the name
and number of each channel.An 11th page is dedicated to equipment
connected via the AV sockets.
To watch one of the channels on the page displayed, key into the
remote control unit the last figure of the channel number (e.g. 5 for
25).The list leaves the screen and pictures from the channel appear.
Leave the menu with exit.
Return
P cture preset F lm
Br ghtness
Colour
Contrast
Sharpness
Contrast expand Low
Tone Neutral
TIME
Return
Sleep t mer <I> --:--
Current t me 11:28
Wake-up t mer 
Wake-up t me 07:07
Programme number 08 EURO
Da ly 
c17-GB-7L 9/10/00 9:46 Page 7

GB
8
TV
More info...
Stereo/Nicam/Virtual Dolby sound
The NICAM process consists of sending digital stereo sound comparable to that from an audio CD via a land based transmitter
in addition to its usual mono equivalent. So by means of the NICAM process, you can get digital sound with the quality of a laser
compact disc.
The Virtual Dolby sound enables you to recreate the ambience of the cinema sound (from Dolby encoded sound sources) without
external speakers.
Sound type
Sound mo
Virtual Dolby Surround
Virtual Dolby Surround systems use advanced
”virtualiser” techniques to simulate the soundfield produced by a
Dolby Surround Pro Logic system using only two loudspeakers.
“Dolby” “Pro Logic” and the double D symbol are
registered trademarks of Dolby Laboratories Licensing
Corporation. Made under licence from Dolby Laboratories
Licensing Corporation.
Sound preset
Choose the setting that best suits the programme you are watching:
film, voice (for discussions), music, flat (flat response curve), standard
(factory settings), personal (personal settings).
Display the SUMMARY. Select the Sound line. Confirm with ok.
The SOUND menu appears.
Sound type: the choices you can access depend on the programme. Select
the line then choose the type of sound you want.
Sound mode: the choices you can access depend on the model of TV/DVD and
the type of sound. Select the line then choose the type of sound you want.
The Magic and Virtual Dolby modes are only available if the sound is of a
stereo type.
Surround effect: this line only appears if Dolby Virtual is selected on the
Sound mode line. Select the line and adjust the surround effect.
Balance L/R: select the line, then balance the sound between the Left and
Right speakers.
Sound preset: choose the setting that best suits the sound on the channel
you are watching. Select the line and choose your setting.
Personal represents the graphic equalizer settings.
Graphic equalizer: adjust the tone of the sound using the 5 frequency bars.
Once you have set the equalizer, the Sound Preset option goes automatically
to Personal.
Your settings are memorised as the new personal settings.
Leave the menu with exit.
BROADCAST
Mono
Stereo
Dual
NICAM - 3
AV
CHOICE
Automatic - Mono
Mono - Stereo
Sound 1 - Sound 2
Sound 1 - Sound 2 - Sound 3
Stereo - Sound 1 - Sound 2
Normal
Wide
Magic
Dolby Virtual
original sound (mono or stereo)
stereo effect for mono sound
accentuated stereo effect with stereo
basewidth enlargement for stereo signals
and pseudo stereo for mono signals
Virtual Dolby Surround. Based on Dolby
Surround Pro Logic decoding,Virtual
Dolby Surround plays the Left, Right,
Centre and virtualised Surround
channels on 2 speakers.
SOUN
Return
Sound type <I> Stereo
Sound mode Dolby V rtual
Surround effect
Balance L/R
Sound preset F lm
10 kHz Treble
5kHz
1,5 kHz Med um
500 Hz
100 Hz Bass
c17-GB-7L 9/10/00 9:46 Page 8

GB
9
TV
More info...
Teletext
Used in many countries under various names (TOP Text, Fastext, FLOF text, Videotext), Teletext is a free service offered by
television channels. The service consists of information database (weather, sports results, news, games, etc.) available at all times.
The different headings shown on-screen by blocks of colour are accessed by a single press on the key of the same colour on the
remote control unit.
Sub-page: some channels broadcast Alarm pages that can be
displayed at a chosen time.
E.g. for 3.30 p.m. key in 15.30 as the sub-page number then press
exit. Of course it is necessary to leave the TV/DVD on, on the
channel that broadcasts the Alarm page.
Additional functions: some channels provide teletext subtitles for
some of their programmes and also updated news flashes. The
corresponding page numbers are shown in theTeletext index. Once
the page is found, the subtitle or news flash will be incorporated into
the picture.The navigation strip disappears after a few seconds.To
make it reappear, press the text key.
Page mode:this operating mode enables quick access to the pages
whose numbers are displayed. If the page displayed refers back to
other page numbers, press the text key to go to page mode. Select
the number of the page you want using the or .
Display the page with the ok key. You can display the next or
previous page using the or keys.
Leave page mode with the text key.
Leave Teletext with the exit key.
Press the text key to display the Teletext Index page (page 100).A message will tell you if
there is no Teletext on the channel that you are watching.
Index: to call up the Index page, select 100 with the or keys and confirm with
ok.
Display a page by keying in the three figures of its page number (e.g. 170).After a
moment, the page appears. Refer to the following or previous pages with the .
Scrolling pages: some information takes up several pages.They scroll on-screen as they
are received.To stop them scrolling, select STOP with the or keys and confirm
with ok. Restart scrolling with ok.
Hidden answers: to show or hide an answer (games), select ? ? ? with the or
keys and confirm with ok.
Zoom: select ZOOM with the or keys and press ok once to enlarge the top of
the screen, twice to enlarge the foot of the screen, or three times to return to normal
display.
Display: to superimpose the Teletext on top of the programme picture, select MIX with
the or keys and confirm with ok. One further press on ok returns to normal
display.
Sub-page: to access a sub-page directly, select “----” with the or keys.
Key in the sub-page’s four figure number (e.g. 0003).
According to the channel, displaying the page sub-code may take several
minutes.
Direct access: the yellow and blue keys allow direct access to the pages whose
numbers are displayed in yellow and blue at the foot of the screen.
Fastext: Fastext broadcasts 4 headings in colour that appear at the foot of the screen.
Use the colour keys on the remote control unit to choose the heading.
TOP text:TOP Teletext broadcasts pages grouped into headings containing articles.
Select the first page of a heading by pressing the blue key or select the first page of an
article by pressing the yellow key.
102 EuroNews 16 : 02 : 99 12 : 00 : 40
EUTSCH 101
FRENCH 102
ENGLISH 103
SPANISH 104
Wintersport
c17-GB-7L 9/10/00 9:46 Page 9

GB
10
TV
More info...
Program Info (TV guide)
The programme guide is prepared by yourTV/DVD from Teletext information broadcast on certain channels.You are only able to
access the programme guide with the channels memorised by yourTV/DVD. Depending on the services offered by the channels in
Teletext, it is possible that the programme guide may not be available. The programme guide enables you to find out about
programmes or make a list of programmes that you want to watch or record.You are also able to download timer information to
a NexTView link video recorder to record a programme or automatically start your TV/DVD at the beginning of the chosen
programme.
NexTView Link:When the list of theTV programmes scheduled for
the coming days is displayed on the TV/DVD screen, you may easily
programme your NexTView-Link video recorder on recording the
telecast of your choice. Select it on the screen of yourTV/DVD which
will then download the information to your NexTView Link video
recorder connected via the AV1 socket.
REVIEW:This menu lists programmes chosen for an alarm call or for
a start-of-programme warning.The menu is automatically displayed
once you have confirmed the choice of a programme in the TV
GUIDE menu.You can also display it by selecting Review on the
options line in the TV GUIDE menu and confirming with ok.
The REVIEW menu lets you access the following functions:
Clear allows you to delete one of the programmes from the list.
To do this, select the last line of the menu with the or
keys and display Clear with the or keys. Then use the
or keys to put the cursor on the programme to be
deleted and confirm with ok.
Memo lets you enable (or disable) the display of a message at
the start of a programme on the list.To do this, select the line on
the menu with the or keys and display Memo with
the or keys. Then use the or keys to put the
cursor on the programme that you want to be alerted about and
confirm with ok.A TV is displayed in front of the programme.You
can then watch another channel but you will be alerted by a
message when the selected programme begins. Press the exit
key to clear the message from the screen.
The Return line enables you to go back to TV GUIDE.
The programme guide is not available on all channels: in this case, a message tells you.
Press the blue key to display the programme guide, the first page appears.The first
programme on this page is the one in progress.
To display the previous or next page, use the or keys. Options (Memo,Wake-up,
etc.) are suggested for you on the last line of the
menu. Select them with the or keys.
Memorise: to be alerted while you are watching one programme that another
programme is starting, select the Memo option with the or keys. Choose the
programme to be memorised with the or keys.
Confirm with the ok key.The REVIEW screen appears. Check your settings.
Alarm call: to program the TV/DVD to come on at the start of a chosen programme,
select Wake-up. Choose the programme with the or keys. Confirm with the
ok key.The REVIEW screen appears. Check your programming. Put the TV/DVD into
stand-by with the BBkey on the remote control unit.
The TIMER FULL message means that the programme guide’s 4 timers are full. Refer to the paragraph
opposite to free up memory (More info, Clear).
Recording: to record a programme by letting your TV/DVD set programme a
NexTView-Link video recorder connected via the SCART socket.The time and date
should be set on the TV/DVD and video recorder. Select the Record option. Choose
the programme with the or keys. Confirm with the ok key.
To enable your programming, the NexTView-Link video recorder must be switched on.
You can only cancel recording with the video recorder. Messages tell you the progress of
programming. Follow these instructions. If you press exit while an error message is displayed, the
video recorder will not be programmed.
Set-up:Program Info:When the channel changes its teletext pages, your TV/DVD set is no
longer able to display the Program Guide and the message “No Program Info data found on
this station.” tells you so. Delete the message with the exit key, then call up the teletext and
note down the number of the daily programme page. Leave the teletext with exit, call up the
Program Guide again and immediately the message “No Program Info data found on this
station.” will come up on the screen, press ok to access menu PROGRAM INFO SET-UP.
Select line TV guide page number and with the number keys of your remote control, enter
the number of the programme page which you have previously searched for in the teletext.
Confirm with ok and leave the menu with exit.Your TV/DVD set should now display the
Program Info.
REVIEW
06 : 02
Return Mon15
BBC World News
08 : 00>08 : 15 05 BBCW Mon15
The World Today
09 : 15>10 : 30 02 BBC1 Tue 16
USA irect
10 : 15>10 : 30 01 BBC1 Tue 16
HAR talk
11 : 35>11 : 40 04 BBCWTue 16
Clear
TIMER FULL
TV
TV
20:02
01 BBCW PROGRAM INFO
Mon 15
20:00 The World Today
BB20:55 Correspondent: Bosnia
23:05 The Travel Show
23:30 Europe irect
00:05 Radical Highs
02:25 BBC News and Weather
Memo
PROGRAM INFO SET-UP
01 BBC 1
Return
TV guide page number ➛➛❿❿421
c17-GB-7L 9/10/00 9:46 Page 10

GB
11
More info...
D sc name: Blues Brothers
16/9 DTS 1:00:34 MAIN MENU:
If you have not loaded any disc, the menu appears automatically.
If a disc is being read, press the STOP key.
To select a menu: with keys or , choose a menu, then
press ok. Sub-menus appear.
Press return to come back to the previous menu.
INFO MENU:
To access them, the player must be in play mode.
Press on the remote control info (yellow) key to display all the info.
Press once more on the info key for the menu to disappear.
Press a direct access key of the remote control ( , , )
to access the corresponding information.
PLAYBACK CONTROL (PBC)
Some Video CDs (version 2.0, with “PBC”: Play Back Control,
written on the disc or on the sleeve) offer scenes and information
which may be interactively selected through an on-screen menu. This
menu appears once the disc has been loaded (or after having
pressed the PLAY or disc menu keys).
To select one of the menu elements, enter its number with the digit
keys of the remote control, then press ok to access it.
The symbol appears when a function you request is not
available.
DVD menus
This page shows you the different menus available in DVD mode. If theTV/DVD set is in stand-by mode, switch it on by pressing the PLAY
key of the remote control. If the TV/DVD set is in TV mode, press the tv/dvd key of the remote control or keyboard.
The main menu will enable you:
- to set up the device (menus and disc languages, sound outputs, display
modes)
- to choose the play mode, or lock the device.
The info menu will enable you, during play, to display information about the
disc and to access some special play functions.
The info menu is deactivated when the disc is stopped.
To access it, press the PLAY key to put the disc in playback, then press the
title key.
This menu is available if the disc contains several titles.
Press once more on the title key for the menu to disappear.
INFO menu
Main menu
Disc “summary” menu
Disc “options” menu
To access it, press the PLAY key to put the disc in playback, then press on
the disc menu key.
The “options” menu of the disc is only available if the disc contains a menu.
Press once more on the disc menu key for the menu to disappear.
Appearance and content of the menus vary according to the discs (follow the indications appearing
on the screen).
TV Menu
You may access certain TV menus while remaining in DVD mode.
Press the red key of the remote control to access the sound and image
preferences of the TV part.
By pressing the tv menu key of the remote control, you may access the
zoom function and the image and sound menus of the TV part.
The Zoom line is only available if the disc format is 4/3.
Play
Play mode
Lock
D splay
Sound
Languages
Glossary
Ex t
Zoom ➛➛❿❿ZOOM 1
Sound
P cture
Disc
Summary
(example)
isc Contents
og
breeding
Food
History
Pedigree
dogs
Disc
options
(example)
ISC MENU
D alogue language
1 Engl sh
2 German
3 French
00:11:14 T : 1 C : 05 1 of 1
DVD
c17-GB-7L 9/10/00 9:46 Page 11

GB
12
DVD
DVD remote control
This page shows you the DVD controls available on your remote control.
For theTV part, see page 6.To control other devices, see page 20.
The keyboard keys located on the TV/DVD frontside have the same functions
as those of the remote control, except for the OPEN/CLOSE key, which is only
available on the keyboard and enables you to open or close the disc drawer. To put your TV/DVD set in stand-by.
To control your TV/DVD set, switch
to the tv+dvd position.
To control other devices, see page 20.
Switch from TV to DVD mode or
from DVD to TV mode.
tv dvd
vcr
tv+dvd
sat
hifi
DVD playback
Accesses the audio function of the
INFO menu.
Access the disc “Options” menu (if it
exists).
Accesses the Subtitle function of the
INFO menu: you may then display or
erase the sub-titles (see page 19).
Access the disc “Summary” menu.
Accesses the angle function of the
INFO menu (see page 19).
Accesses the Magnify function
(see page 13).
disc
menu
title
To skip chapters (DVD), tracks
(Audio CD), or indices (Video
CD).
PLAY: to start playback.
REV/ FWD: for a fast forward
or backward move (during
playback).To modify the speed
of a video disc, press this key
several times.
STOP: to stop playing a disc
(to stop it completely and
restart from the beginning,
press twice).
PAUSE: for a pause, a still
frame or an image by image
selection.
PLAY
FWD
STOP
REV
PAUSE
DVD functions
Sound
Adjusts the audio volume.
This function is activated on the
TV/DVD set whatever the position
of the function selector, hi-fi
position excepted.
Mutes or cancels muting.
DVD navigation
If you are in TV mode, press the tv/dvd key.
the other control keys of your DVD
MAIN MENU
These keys enable you:
- to choose a menu.
- to increase or decrease a
value.
- to select a choice.
Use these keys to access a
menu or return to the
previous one.
Confirm your choice.
Call your preferred TV
sound and image settings.
Access to the TV-part menus
(see page 11).
Return to the main menu.
Return to the previous menu.
return
PLAYING A DISC
Access the INFO menus
(see page 18).
Choose an option in an
Info menu.
Choose an Info menu
Confirm your choice.
Call the sound and image
settings you prefer for
your TV set.
Access the menus of the TV
part (Info menus disappear).
Erase Info menus.
Resume reading 10 seconds
backwards.
zoom
zoom
tv
menu
ok
info
text
red key
clear
IMPORTANT
If the batteries of your remote control are
exhausted, you can use the keys on the front of
the TV/DVD: they have the same functions as
those of the remote control.
c17-GB-7L 9/10/00 9:46 Page 12

GB
13
DVD
More info...
Several playback modes are available.
This page shows the simple playback mode. For the other playback modes, see next page.
Playback
Open the drawer using the open/close key next to the drawer.
Place the disc with its printed side upward (if one-sided).
After a few seconds, the disc title (or, by default, the type of disc) appears with the image and audio
format information and its total duration (if this information is available).
Press on the ok or PLAY key to start the playback.
Some discs automatically propose a menu.You can choose an item with the
keys and press ok to confirm your selection.
To stop the playback, press the STOP key.
This disc location is stored by the player: it is the “pickup memory”. If you press once more on the
PLAY key, playback will pick up where you left off.
If you press twice on the STOP key or if you unload the disc, this “pickup memory” will be lost: the
next playback will start at the beginning of the disc.
The DVD player remains in playback when you switch to TV mode
by pressing the tv/dvd key.
For example, this enables you to surf on TV channels without having
to interrupt the playing of the disc.
If the player is locked and the disc has been assigned a rating limit,
you must enter the password to play the disc (see page 17).
The discs capabilities (menus, access functions, dialogue and
sub-title languages, camera angles, interactivity) may vary
from one disc to the next. Please check the instructions given
on the disc. Some discs may have been pre-programmed so
as to render impossible some functions, such as skipping
chapters, still-frame and repeat play.
 The MAGNIFY function
On some DVDs and Video CDs, this function allows you to enlarge
the image during a playback at normal speed or during a pause.The
zoom-in will be 1.5 or 2 or 4 times the normal size for DVDs and
twice the normal size forVideo CDs.
When you press on this remote control key, the image centre is
enlarged.When the image is sufficiently enlarged. you can navigate
from one zone to the next with the keys (on some
discs).
If you call a Info Display while the Magnify function is activated, the
keys will only act for the Info Display.
The Magnify mode will be cancelled if you request one of the
following functions:
- modification of title, or chapter
- disc menu
- stopping (STOP key)
- access to a marker.
Simple playback
Discs you can read
Discs you cannot read
Digital video discs
12 cm and 8 cm, single or double sided, single or dual layer. DVDs are high density optical discs on which high quality picture
and audio are recorded by means of digital signals.
Audio CDs
12 cm and 8 cm.
Video CDs
12 cm and 8 cm (with or without playback control).
NTSC playback
In addition to the PAL DVDs and video CDs, you may enjoy your favourite NTSC movies as well.
+
NTSC
Currently, these are the discs that you cannot play with this unit : CD-I, CD-ROM, DVD-ROM, DVD-RAM, CDV, CD-G. DVD
with regional code other than that of your player.
Do not try to play Photo CD or CD-R.
Regional code number: Your DVD player is designed and manufactured to respond to the region management information
that is recorded on a DVD disc.
If the DVD disc does not carry the region code corresponding to your player, it cannot be played.The region code for your
player is region No. #2. (Europe, the Middle East, Republic of South Africa, Japan).
- types of discs
2
1
3
4
D sc name: Blues Brothers
16/9 DTS 1:00:34
Play
Play mode
Lock
D splay
Sound
Languages
Glossary
c17-GB-7L 9/10/00 9:46 Page 13

GB
14
DVD
More info...
T tle Chapter Program L st


( 5 ) ( 15 )
TC
 
Playback modes
To access playback modes, select the Play Mode menu with the keys, and press ok to confirm.
To validate a mode, select it with keys or , and press ok to confirm.
The Standard Play mode activates a normal playback of the disc.
The Random Play mode activates a random playback.
In the Program Play mode, the sequence sorting is made according to the list
given in the “Edit Program” menu.
If no list has been elaborated, this mode cannot be selected. It is also inhibited if a rating limit
has been set for the film, unless the parental code is entered.
The Edit Program menu enables you to create a list so as to read sequences in
an order chosen by yourself. The displayed list is different according to the type
of disc.
DVDS: to enter a sequence in the program list:
- enter a title and chapter number using the keys or the digit keys of the
remote control
- with the key, select the Add button and press ok.
- use the Delete button to erase a sequence.
- the Play button allows you to start reading the programming.
CDS: the list for Audio CDs is a track list.
Contrary to the DVD, to enter a track number for each line of the programming list is
sufficient. This list displays the chosen track numbers with their respective duration. The
last line indicates the total duration of the chosen tracks.
If Auto Play is validated, the player automatically starts reading as soon as a disc
has been loaded.
The Dub Assist function eases the recording of personal copies of Audio CDs.
According to the duration of your medium (a cassette, for example), Dub Assist
organises the tracks to optimise the recording duration and includes reading
pauses.
Select the Play Order mode:
- Standard: the tracks are sorted in their original order.
- Optimized: the tracks are sorted so as to optimally use the length of the segment (see
the next step) and to leave a minimum length of non-recorded tape on the cassette.
- Program: the tracks are sorted according to the programming list order of the menu
Edit Program.
Choose the length of the segment with keys or .
You can record several segments and switch from one to the other: select the orkey and
press ok.
To start reading the segments, select the on key and press ok to confirm.
The Introscan mode is available for Audio CDs. If validated, the player will read
the first ten seconds of each track.
RANDOM PLAYBACK
For a DVD containing several titles, the titles are played at random.
Each title is completely read (with its random chapters) before the next
title is played.
This mode is inhibited forVideo CDs and films having been assigned a
rating limit (unless the password is entered).
EDIT PROGRAM
The Add key will be modified into Insert if you select a sequence
already recorded in the programming list.
The Editer Prog. menu is not available for Video CDs.
PROGRAM PLAY
If the duration of a track 1 exceeds the segment duration, this
track will be divided into several parts. For example, if the
track lasts 48 min. whereas the segment lasts 45 min., the
track will be divided into two parts: 1A (45 min.) and 1B
(3min.). Parts 1A and 1B will be placed into the segments as
if they were different tracks.
SEGMENTS PLAYING
When you enable the START key, a message appears to start the
reading (you can then press the PLAY key).
This message will be displayed at the end of each segment to
confirm that the following segment is to be played.
Edit Program, DVDs
Playback modes, DVDs
Edit Program, Audio CDs
Dub Assist ,Audio CDs
1All Add
Delete
Play
Done
Track Program L st


Total:
T T me
 
1Add
Delete
Play
Done
Play Order Segment Segment1 
Length (1 of 5)
 Standard 
 Opt m zed 
 Program
Total:
Start
030
Off
Play
Play mode
Lock
D splay
Sound
Languages
Glossary
Standard Play
Random Play
Program Play
Ed t Program
Auto Play
  2
1
3
4
5
6
7
c17-GB-7L 9/10/00 9:46 Page 14

GB
15
DVD
More info...
The DISPLAY menu enables you to choose the image format and the on-screen displays.
The SOUND menu enables you to enable dynamic range compression and choose the type of sound assigned to the digital output.
To reproduce the sound of a movie theatre from the sound recorded on your Dolby Digital DVDs, connect a Dolby Digital (AC-3)
amplifier/decoder to the optical digital audio output jack and select the sound type in the Sound menu.
Display and Sound
Select the Display menu on the main menu using the or
keys, then confirm with ok.
The TV Image menu determines the image format.
Leave the 16x9 format if you want to fill the picture of your TV
(Widescreen).
With the On-Screen Displays menu, choose the information you want to
see on the screen.
Select this sub-menu and press ok to confirm.
With keys or , select an option, then activate or deactivate it with
the ok key.
TV IMAGE
You may select the image format if you use the DVD video output
jacks (see page 21), according to the connected equipment.
Select this sub-menu and validate with ok. Several formats are
offered: 4x3 Letterbox,4x3 Standard,16x9 Wide screen.
Choose the format with keys and press ok to confirm.
ON-SCREEN DISPLAYS
Info Displays: tick the box with the ok key to display time and
transport information during play.
Angle indicator: tick the box to display the angle info when the
disc offers several camera angles to choose from (see page 19).
Scene Again Text: tick the box to enable the action of the return
key during play (resume reading 10 seconds back).
16X9
Play
Play mode
Lock
D splay
Sound
Languages
Glossary
TV Image
On-Screen D splays
 
AUDIO FORMATS
DTS is a digital sound compression technique
developed by DIGITAL THEATER SOUND SYSTEMS for
digital audio multichannel signals.
Dolby Digital (AC-3) is a sound
compression technique elaborated by Dolby
Laboratories for digital audio multichannel signals.The Dolby Digital
system enables any audio channel configuration,from a stereo sound
(2 channels) up to the digital “surround” sound 5.1.
If you have a Dolby Surround Pro
Logic amplifier/decoder, you may fully
enjoy its Pro Logic system,
- either with titles bearing the Dolby Surround label
- or with DVD films whose sound has been recorded
through Dolby Digital 5.1 channels.
In both cases, your Pro Logic decoder must be connected to the 2-
channel analog output of yourTV/DVD set (see page 21 cinch audio
outputs).
PCM
The linear PCM is a signal recording format used for CDs.
CDs are recorded in 44.1kHz /16bits.
DVDs are recorded in 48kHz / 16 bits, or even up to 96kHz / 24 bits.
DIGITAL OUT
On
Dolby D g tal
Play
Play mode
Lock
D splay
Sound
Languages
Glossary
Sound Log c
D g tal Output

Select the Sound menu from the main menu with keys or , then
press ok to confirm.
The Sound Logic function enables you to control the audio levels by
compressing the dynamic range.
When it is activated, it is easier to hear all of the sound track at a low
volume.This function is only available on Dolby Digital (AC3) DVDs.
To activate it, select the Sound Logic line with keys or and display
“On” with the ok key.
Considering the device you connect to the digital audio output jack, choose
the type of sound that will be output by this jack.
Select the Digital Output line with keys or and press ok.
Choose according to the type of disc and the type of sound you want to
output from the digital audio output jack and press ok to confirm.
Digital output according to the chosen options:
Digital output
Disc Format DTS Dolby Digital DTS & Dolby Digital No selection
DTS Encoded No sound Encoded No sound
PCM PCM PCM PCM PCM
Dolby Digital (AC-3) PCM AC-3 / encoded Encoded PCM
CD PCM PCM PCM PCM
c17-GB-7L 9/10/00 9:46 Page 15

GB
16
DVD
Preferred languages More info...
During the initial installation (page 4), the language you choose during the first step has automatically been selected for the DVD
part. Nonetheless, you may change the language for the player menus, and choose the languages you prefer for dialogues, sub-
titles and disc menus.The language selection of the DVD part does not affect the language of the TV part.
For each disc, it will be possible to change the language during playback: see page 19.
Select the Languages menu from the main menu with keys
or , then press ok to confirm.
To change the player menu languages, select Player Menus,then press
ok. Choose the language with keys or and press ok to
confirm.
To change the preferred language for disc menus, select Disc Menus,
then press ok. Choose the language with keys or and press ok
to confirm.
If the chosen language is available for a title, it will automatically be selected.
To change the preferred language for dialogues, select Audio, then
press ok. Choose the language with keys or and press ok to
confirm.
The “Original” option corresponds to a language which has been defined as priority on the
disc.
If the chosen language is available for a title, it will automatically be selected.
If it is not, the priority language of the disc will be selected.
To choose the preferred language for sub-titles, select Subtitles, then
press ok. Choose the language with keys or and press ok to
confirm.
If the chosen language is available, it will automatically be selected when you display the sub-
titles (see page 19). If it is not, the “subtitle” language indicated on the disc will be selected.
If you choose the “automatic” option, the preferred language used for sub-titles will be the
one you chose for the dialogues (see above). Because of that, if the preferred language for
dialogues is not available, while sub-titles are available in this language, these sub-titles will
automatically appear on-screen.
The different languages and sub-titles that are available are
indicated on the DVD sleeve.
You will also find there the audio formats that are available
according to the languages, image format,region and type of disc.
To change the dialogue language during the playback of
a DVD, display the audio info by pressing the key of your
remote control.
Choose the language with keys (see page 19).
To change the sub-title language during the playback of
a DVD, display the sub-title info by pressing the key of your
remote control.
Choose the language with keys (see page 19).
OTHER LANGUAGES :
To select a language other than the displayed ones for the disc
menus, dialogues and sub-titles, select the “Other” line, then enter
the 4 digits of the code corresponding to the chosen language.
You will find the code list at the end of the manual.
Engl sh
Engl sh
Engl sh
Auto
Play
Play mode
Lock
D splay
Sound
Languages
Glossary
Player Menus
D sc Menus
Aud o
Subt tles
 
2
1
3
4
c17-GB-7L 9/10/00 9:46 Page 16

GB
17
DVD
This function enables you to control the access to the player. Select the Lock menu, and press ok to confirm. More info...
Locking
To activate the player lock, you must enter a password:
select the Lock Player line with keys or and press ok to confirm.
A “new password” is required: enter four digits with the digit keys of your
remote control, and press ok to confirm.A confirmation is requested: repeat the
operation.
Choose four digits you will easily remember or note them somewhere.
To deactivate the lock, select the Unlock Player line and press ok to confirm.
To change the password, select the Change Password line and press ok to
confirm.Then enter the four new digits.
Some DVDs contain rating limit information.
The Ratings Limits function enables you to control the type of discs or
programmes that your family may watch: if some discs or passages exceed the
rating limit you have set, they will not be played.
The scene framing by restriction level is determined by the disc publisher.
Select the Ratings Limits line, then press ok to confirm:
- Choose the country whose rating standards comply with your
requirements: select Counrty and press ok to confirm. Select the country
with keys or and press ok to confirm.
- Choose the limit: select Rated Titles and press ok to confirm.
Select the level with keys or and press ok to confirm.
- All the unrated titles may offer a free access or require a password: select
Unrated Titles and press ok to confirm.
Select “Free access” or “Required password” with keys or and
press ok to confirm.
If you forgot your password, you can cancel the lock code; to do this,
when you are asked for your password, press the OPEN/CLOSE key
to open the drawer, then hold simultaneously down both ok and
DISC MENU keys on the TV/DVD unit.
In Europe, only a few discs are assigned a rating limit.
Rating level / indexed titles
Play
Play mode
Lock
D splay
Sound
Languages
Glossary
Lock Player
Unlock Player
Change Password
Rat ngs L m ts
System Test
 
Password requ red
Free Access
8
7
6
5
4
3
2
1
Country
Unrated T tles
Rated T tles 
2
1
3
4
c17-GB-7L 9/10/00 9:46 Page 17

GB
18
DVD
More info...
Info Menus
The Info menus enable you to obtain information and options on the disc while it is being played.
Direct access
A DVD may contain several titles, which may be different films or programmes. These titles may be divided in
numbered chapters.
Audio CDs contain tracks, which you can access directly.
Video CDs may also contain Indices.
To directly access a Title,aChapter,aTrack or an Index, select one of these info
with keys , then choose a number with keys or directly enter a
number with digit keys.
To directly access another part of the disc, select the Time indication info with keys
, then enter a time with digit keys. You must specify the tens and units for
the hour, minutes and seconds: for example, to access the twentieth minute of a
disc, enter 0, 0, 2, 0, 0, 0. Confirm with ok.
This function is not available on some discs, even if the elapsed time appears on the screen.
Repeat play
To repeat the playback of a title, chapter, track,A-B chosen segment (excepted forVideo CDs) or of the whole
disc.
This function is only available with discs for which the elapsed time appears.
Select the Repeat info with keys . Choose an option with keys .
To repeat a sequence between two points A and B, choose the option “repeat A-B”,
then follow the given instructions to enter both points.
To stop repeating the playback:
- select the Repeat info and choose the “stop” option,
- press twice on the STOP key,
- access the disc menu by pressing the disc menu key.
REPEAT PLAY
The repeat principle is a loop reading between a starting and a
finishing point. On some discs, interactive menus may appear
during playback: you must activate some functions within the
menu to proceed with the playback.
A-B REPEAT PLAY for DVDs and Audio CDs.
If during a fast forward or backward reading the B point is reached,
the player will proceed at normal speed from the A point.
If during a fast search the A point is reached, the player will start
reading at normal speed from the A point.
The A-B repeat mode will be cancelled if you press twice on STOP,
if the disc is ejected or if another repeat mode is selected.
Direct access, Repeat play
00:11:14 T : 1 C : 05 1 of 1
DVDs
00:20:22 T : 1
00:03:54 T : 01 I : 1
Audio CDs Video CDs
To display all the information, start reading a disc with the PLAY key, then press the info (yellow) key of the
remote control.
DVDs
00:11:14 T : 1 C : 05
Audio CDs
00:20:22 T : 1
Video CDs
00:03:54 T : 01 I : 1
c17-GB-7L 9/10/00 9:46 Page 18

GB
19
DVD
More info...
Info Menus
Markers (DVD and Audio CD)
The player can memorise up to 6 places on the disc, as long as the disc remains in the player (and if theTV/DVD set has not
been switched off by the On/Off switch). During that time, you can directly access one of these positions.This function is only
possible with discs with which the elapsed time appears in the Info menu.
Select the Marker info with keys , and press ok to confirm the setting of a marker.
Another menu appears and describes the 6 markers.
Audio, Subtitles, Camera angles (DVD)
Some discs have multiple audio tracks, primarily used for the different languages.The default language is the one selected in
the main menu (see page 16).
To define your choice of language during playback, select the Audio info with keys ,
then choose a language with keys .
During reading, you can display or hide the sub-titles and change the subtitle language. The default setting is the one chosen in
the main menu (see page 16).
To display or hide sub-titles, select the Subtitle info with keys , then press ok to confirm.
Choose a language with keys .
Some discs have multiple camera angles for certain scenes.
To change the camera angle, select the Angle info with keys , then choose the angle with
keys .
Playback mode and Introscan (Audio CD)
To change the playback mode, select the Play Mode info with keys , then choose a (Standard,
Random,Program) mode with keys .
The Progr. mode is only available if a list has been drawn in “Edit Program” (“Play Mode ” menu of the main menu, see page 14).
To read the first 10 seconds of each track, select the Introscan info with keys , then
press ok to confirm.
Audio channel (Video CD)
Select the Audio Channel info with keys , then choose an option (stereo sound; left-
hand side channel; right-hand side channel; left & right mono) with keys .
MARKERS
To enter a new marker, select a position indicated as
“unmarked” with keys and press ok.The
indication changes then to indicate the time and number of
chapter or track; the icon also changes, with a play button and
another button indicating a trash can.
To start reading from a marker, select the button and press
ok to confirm.
To suppress a marker, select the button and press ok to
confirm.
DIRECT ACCESS
You can use the remote control keys to directly access the required
info.
To directly access the audio info, press the key of your
remote control.
To directly access the sub-title info, press the key of your
remote control.
To directly access the angle info, press the key of your
remote control.
To automatically display the camera angle info as soon as
several camera angles are available, activate the “Angle indicator”
option in the “On-screen display” of the main menu (see page 15).
Start reading a disc with the PLAY key, then press the info (yellow) key of the remote control.
Markers, Audio, Subtitles, Camera angles,
Playback mode, Introscan, Audio channel
c17-GB-7L 9/10/00 9:46 Page 19

GB
20
TV
DVD
Remote control unit: other equipment
This remote control unit can control other equipment such as video recorders, Hi-fi systems, or satellite receivers.
To control a video recorder
Set the switch to vcr.
Standby / On.
Display the menu.
Vertical scrolling in the menus.
Horizontal scrolling in the menus.
Confirmation of an action.
Leave the menus.
Direct access to the programmes or enter
the numeric values.
To switch from one programme to another.
Select the AV input.
REV Rewind.
PLAY Play.
FWD Fast forward.
REC vcr Record.
STOP Stop.
PAUSE Pause
To control a Satellite Receiver
Set the switch to sat.
Standby / On.
Display the menu.
Vertical scrolling in the menus.
Horizontal scrolling in the menus.
Confirmation of an action.
Exit the menus.
Direct access to the programmes or enter the
numeric values.
To switch from one programme to another.
To control a Hi-fi system
Set the switch to hi-fi
Standby / On.
Mute or re-establish the sound.
Set the volume level.
Choose a radio station by entering the number.
To switch from one programme to another.
vcr
tv+dvd
sat
hifi
vcr
tv+dvd
sat
hifi
tv
menu
ok
exit
23
654
78
9
1
0/--
r
r
vcr
tv+dvd
sat
hifi
tv
menu
ok
exit
23
654
78
9
1
0/--
r
r
23
654
78
9
1
0/--
r
r
av
To program the remote control unit
1. According to the model of remote control unit, press on the vcr key or slide the switch in the position of the equipment to be controlled.
2. Hold the tv menu key down and enter one of the 3 figure codes corresponding to the make of your unit (the code list can be found at the end of this manual).
3. Release the tv menu key.
4. Try to switch off the unit with the key on the remote control unit. If it doesn’t work, try another code.
Depending on the age or type of some products, certain functions may not be available.
Certain codes may cover more functions than others.Test the functions that you can control and maybe try other codes.
Note the code or codes which are best suited here.
When you change the batteries in the remote control unit, remember to reprogram it.
REC vcr
PLAY
FWD
STOP
REV
PAUSE
VCR
SAT
HIFI
c17-GB-7L 9/10/00 9:46 Page 20
